BDI LINQ 9117 User manual

LINQ™9117, 9119, 9127, 9129
BED
DESIGNED BY MATTHEW WEATHERLY
LET’S GET STARTED.
INSTRUCTION MANUAL

NEED ASSISTANCE? customerservic[email protected]om | 3
Congratulations on the purchase of your LINQ Bed from BDI. Your bed has been
designed to provide a lifetime of enjoyment. This manual will provide assembly
instructions and other helpful information to ensure you get the most out of your
product. Please save it for future reference.
Your LINQ Bed has been engineered for simple assembly. Please follow these directions
carefully to prevent any damage.
Should you need further assistance, contact BDI at [e-mail].
ENJOY!
Scan to watch the LINQ assembly video.
bdiusa.com/linq-assembly

4 | BDIUSA.COM LINQ BEDS
HARDWARE AND COMPONENTSHARDWARE AND COMPONENTS
Left Side Rail (C1) QTY: 1
Footboard Rail (C3) QTY: 1
Right Side Rail (C2) QTY: 1
Headboard Rail (C4) QTY: 1
Cam Lock (H1) QTY: 4
M6 x 16 Screw (H4) QTY: 37
Cam Stud (H2) QTY: 4
M8 x 70 Screw (H5) QTY: 5
Dowel (H3) QTY: 8
Floor Leveler (H6) QTY: 3
6mm Hex Wrench (T2) QTY: 1
Unpack and identify the parts listed below. The assembly workspace should be a non-marring
surface, such as carpet. For missing hardware pieces, please contact BDI Customer Service at
cust[email protected]om. For all other concerns, please contact your BDI retailer.
Do not use power tools for the assembly of this product.
4mm Hex Wrench (T1) QTY: 1

NEED ASSISTANCE? customerservic[email protected]om | 5
Headboard Corner Bracket (C5) QTY: 2
Footboard Corner Bracket (C6) QTY: 2
Side Support Bracket (C7) QTY: 2
Center Support (C12) QTY: 1
Leg / Rail Connector (C8) QTY: 2
Long Leg (C9) QTY: 3 Short Leg (C10) QTY: 4 Headboard Cleat (C11) QTY: 1
HARDWARE AND COMPONENTS HARDWARE AND COMPONENTS

6 | BDIUSA.COM LINQ BEDS
HARDWARE AND COMPONENTSHARDWARE AND COMPONENTS
Headboard (C13) QTY: 1
Headboard (C13) QTY: 1
Bed Slats (C14) QTY: 2
9127 Cross-LINQ shown
9119 Up-LINQ shown

NEED ASSISTANCE? customerservic[email protected]om | 7
LINQ’s adjustable platform and frame allow the bed to accommodate a variety of mattresses,
positioning the top of the mattress at the user’s preferred height. The bed can accommodate
mattresses from 8"-16", with the recommended height for the top of the mattress being around
24" from the floor.
To determine your ideal bed setup, measure the height of your mattress and subtract that number
from 24". Take the result, and refer to the chart below to find the height that best matches.
LINQ BED SET-UP CONFIGURATIONS
14"
11"
Platform Position High
Frame Position High
Platform Height 14" | 36 cm
Mattress Size 8–10"
Platform Position Low
Frame Position High
Platform Height 11" | 28 cm
Mattress Size 12"
Platform Position High
Frame Position Low
Platform Height 11" | 28 cm
Mattress Size 12"
Platform Position Low
Frame Position Low
Platform Height 8" | 21 cm
Mattress Size 14–16" Mattress
11"
8"
PLATFORM: The inner bed support system,
which includes the side and center supports and
slat system, can be positioned at two heights.
FRAME: The outer wood frame that surrounds
the platform and attaches to the headboard,
can be positioned at two heights.
A
B
A
B

8 | BDIUSA.COM LINQ BEDS
STEP 1. INSTALL CAM LOCKS, CAM STUDS, AND DOWELSASSEMBLY
Lay the Side Rails (C1 & C2) and the Footboard
and Headboard Rails (C3 & C4) on a soft, non-
marring surface, like carpet. Insert 8 Dowels (H3)
and 4 Cam Studs (H2) into the holes on the
ends of the Rails, as shown. Place 4 Cam Locks
(H1) into the large holes at the ends of the Rails,
ensuring that the hole in the Cam Lock (H1)
lines up with the hole on the end of the Rails.
CAM LOCK – H1 QTY
4
CAM STUD – H2 QTY
4
DOWEL – H3 QTY
8
C2
C1
C3
C4
H1
H1
H1
H1
H2
H2
H2
H2
H3
H3
H3
Scan to watch the LINQ assembly video.
bdiusa.com/linq-assembly

NEED ASSISTANCE? customerservic[email protected]om | 9
HEX WRENCH – T2 QTY
1
Connect the Side Rails (C1 and C2) to the
Headboard Rail (C4). Tighten each Cam Lock
(H1) with a 6mm Hex Wrench (T2). Connect the
Footboard Rail (C3) to the ends of the Side
Rails. Tighten each Cam Lock (H1) with a 6mm
Hex Wrench (T2).
ASSEMBLY
STEP 2. CONNECT RAILS
2
3
C1
C2
C4
C3
H1
Turn Cam Lock (H1) Clockwise
1

10 | BDIUSA.COM LINQ BEDS
STEP 3. ATTACH CORNER BRACKETSASSEMBLY
Attach the Headboard Corner Brackets (C5) to
the corners near the Headboard Rail (C4) using
8 Screws (H4). Tighten with Hex Wrench (T1).
Attach the Footboard Corner Brackets (C6) to
the corners near the Footboard Rail (C3) using
8 Screws (H4). Tighten with Hex Wrench (T1).
HEX WRENCH – T1 QTY
1
SCREW– H4 QTY
16
C5
H4
H4
H4
C5
C6
C6
H4
H4
H4
C5
