BDI Sweep User manual

1
B1 - Hex Driver x 1
B2 - Hex Wrench x 1
Sweep is engineered for easy assembly. Carefully
follow this procedure to prevent any damage.
Placement and Maintenance
Sweep is designed for indoor use on level floors.
Clean wood veneer with a moist cloth. Clean
glass with glass cleaner.
Step 1
Unpack and Identify
Unpack and identify the components at left. Note that some
components are shipped inside the cabinet. The assembly
workspace should be a non-marring surface such as clean carpet.
For missing hardware pieces, please contact BDI Customer Service
at [email protected]. For all other concerns, please
contact your BDI Retailer.
Component List
Designed by Louis A. Lara.
These distinctive product congurations are protected by US and
international patents, trade dress, and/or copyright laws.
BDI are trademarks of Becker Designed, Inc.
All Rights reserved. ©2015, BDI
Made in China. 8438REV083115v1
sweep
8438
cabinet
assembly instructions
bdiusa.com [email protected]
C - 1/4-20 x 70 mm
Screw x 2
D - 1/4-20 x 15 mm
Screw x 16
E - Cabinet x 1
F - Metal Leg x 2
G - Wood Leg x 1
HL - Adjustable Shelf x 1
HR - Adjustable Shelf x 1
IR - Adjustable Shelf x 1
IL - Adjustable Shelf x 1
J - Back Panel x 2
J
E
HL
HR
IR
C
D
F
G
F
D
IL

2assembly instructions
bdi
usa.com [email protected]
sweep
8438 cabinet
Step 2
Build Base Assembly
With the help of another person, position the cabinet on its back. Attach Metal Legs (F)
to Cabinet (E) using Screws (D) and tighten with Hex Driver (B1). Attach Wood Leg (G)
to Cabinet (E) using Screws (C) and tighten with Hex Driver (B1).
Step 3
Turn Cabinet Over and Install Back Panels
With the help of another person, position the cabinet right side up. Install Back Panels
(J) to the backside of the cabinet by inserting top edge in upper channel then tipping
bottom edge forward and into lower channel.
NOTE: Velcro straps are included for your convenience to facilitate wire management.
TWO PERSON ASSEMBLY
TWO PERSON ASSEMBLY
C x 2
D x 16
G
E
F
F
D
D
D
D
C
C
B1
J
1
1
2
2

3assembly instructions
bdi
usa.com [email protected]
sweep
8438 cabinet
Step 4
Adjust Shelf Height
If desired, lift Adjustable Shelf (H, I) away, loosen & remove related Shelf
Support Pins, reinstall the Shelf Support Pins at desired height, then reinstall
Adjustable Shelf.
I H

4assembly instructions
bdi
usa.com [email protected]
sweep
8438 cabinet
Fine tuning your new BDI Sweep Home Theater Furniture
These steps are to be followed after you have unpacked and completed the simple assembly instructions for
your Sweep AV cabinet. Due to jostling in freight or perhaps an uneven floor, the doors on your Sweep cabinet
may not appear to be in perfect alignment. Making a few minor adjustments can rectify this situation. Be aware
that depending on your situation, patience and a bit of trial and error are required. The high-quality European
hinge hardware is infinitely adjustable, but changing one element can cause the need for further adjustments.
Through a little adjustment, you can modify the orientation of the cabinet doors to make sure that they are
sitting perfectly on your Sweep unit.
STEP 1 - Level your Sweep unit
Levelers are integrated into each leg assembly and are accessed at the bottom of each cabinet leg using Hex
Wrench (B2). If your floor is uneven, you may extend one or more levelers to attain a level, stable cabinet
placement. Turning the leveler clockwise will extend the leveler; turning it counter-clockwise will retract it.
CORRECT! Door is
sitting squarely and
evenly spaced on tops
and sides.
INCORRECT! Door is
out of alignment with
the rest of the unit.
STEP 2 - Adjust Door Hinges (if needed)
The doors on your cabinet should be evenly spaced and the doors should open and close freely without rubbing
against the door frame.
If the cabinet’s doors appear out of alignment, this condition can be corrected with minor adjustment to the
European hinges on each door.
Because these hinges are infinitely adjustable, adjusting one hinge element can sometimes cause the need for
adjustments to other elements. But with a few adjustments, you can modify the orientation of the cabinet doors
to make sure that they hang perfectly within your cabinet.
Use the Phillips Screwdriver (A) supplied to adjust Sweep's
door hinges:
• By adjusting Screw 1, the door will move LEFT or
RIGHT within the frame. Make minor adjustments
at both top and bottom hinges for best results.
• By adjusting Screw 2 the entire door will move IN or
OUT, opening or closing the gap between the door
frame and cabinet. (This screw rarely needs adjustment.)
1.
2.
2.
1.
