CORNER DESK
15049
COMPONENT
ASSEMBLY
INSTRUCTIONS
NO POWER TOOLS

3
2
2:
While the second person holds the desk
frame on its side position, attach Corner
Leg (CD) to the underside of the Desk
Frame Assembly (CB) using Screws (E).
1:
Position the Template (CC) in the desire
location where the corner desk will be
positioned.
CC
CD
CD
CB
E
CB
E
G
E x 4
G x 1

3
2
4:
While the second person holds a panel
up to the edge of the Template, lower the
Desk Frame Assembly into position fitting
the bodies of the the screws into the slots
of the Desk Frame.
3:
Partially install Screws (E) on the second
hole from the top of the panel.
PANEL E
E
E
E
E
E

5
4
E
E
5:
While the second person holds the Desk
Frame, bring the second panel up to the
edge of the Template and align the slots of
the Desk Frame with the Screw (E) bodies.
6:
Tighten the Screws (E) underneath that
fit into the slots of the Desk Frame. At
this time, the cardboard template may be
removed.
E
G
E

5
4
O
G
7:
With the help of another person, carefully
lower the Glass Top (CA) onto the frame.
Register the steel discs on underside of
glass into the holes on the frame; then
attach the glass using Machine Screws (O)
and Hex Drive (G).
NOTE: Do not over-tighten screws!
8: Magnets
Located inside the Corner Leg (CD) are
4 Magnets (CF) that may be peeled and
adhered to the rear side of a power strip
(not included).
CF

7
6
I
9:
Magnetically attach the Corner Leg Cover
(CE) to the Corner Leg (CD).
Leveler
If needed, adjust leveler on Corner Leg
using Allen Wrench (I).
Level each Panel as it is being assembled. Use Leveler Wrench (F) to adjust the
height of the Panel, if necessary.
