Becker R12/17C User manual

R12/17C...R40/17C
Version: PROF+A2
en Assembly and Operating Instructions
Roller shutter drive with integrated radio receiver
915.3 Mhz
Important information for:
• Fitters / • Electricians / • Users
Please forward accordingly!
These instructions must be kept safe for future reference.
Becker-Antriebe GmbH
Friedrich-Ebert-Straße 2-4
35764 Sinn/Germany
www.becker-antriebe.com

Table of contents
Contents ............................................................................................................................................................................. 3
General .............................................................................................................................................................................. 3
Warranty ............................................................................................................................................................................. 5
Safety instructions ............................................................................................................................................................... 5
Intended use ....................................................................................................................................................................... 7
Assembling and disassembling the plug-in connecting cable .................................................................................................. 7
Assembling the plug-in connecting cable .................................................................................................................... 7
Disassembling the plug-in connecting cable for tubular drives dia. 45 and dia. 58 ........................................................... 8
Installation .......................................................................................................................................................................... 9
Assembling the drive ................................................................................................................................................. 9
Undoing the mounting pin .......................................................................................................................................... 9
Drive adapter for obstacle detection ........................................................................................................................... 9
Assembling the drive adapter with drive adapter safety catch ...................................................................................... 10
Assembling the drive adapter with screw connection .................................................................................................. 10
Securing the drive against axial displacement ............................................................................................................ 10
Fixing the drive adapter to the barrel dia. 45 .............................................................................................................. 10
Mounting the drive in the tube .................................................................................................................................. 11
Confirming the drive ................................................................................................................................................ 11
First operation ................................................................................................................................................................... 12
Programming the master transmitter ........................................................................................................................ 13
Checking that the running direction is correct ............................................................................................................ 13
Intelligent installation management ........................................................................................................................... 13
Setting the limit positions ......................................................................................................................................... 14
Upper stop to lower stop .......................................................................................................................................... 14
Upper point to lower point ........................................................................................................................................ 14
Upper stop to lower point ......................................................................................................................................... 14
Upper point to lower stop ......................................................................................................................................... 15
Changing the set limit positions ................................................................................................................................ 15
Deleting the limit positions ....................................................................................................................................... 15
Intermediate positions I + II ...................................................................................................................................... 16
Programming additional transmitters ........................................................................................................................ 17
Deleting transmitters ............................................................................................................................................... 17
Overwriting the master ............................................................................................................................................. 18
Upper anti-freeze mechanism ............................................................................................................................................ 19
Activating/Deactivating upper anti-freeze mechanism ................................................................................................ 19
Obstacle detection ............................................................................................................................................................ 19
Fly screen protection function ............................................................................................................................................ 20
Programming the run times ................................................................................................................................................ 20
Deleting the run times ........................................................................................................................................................ 21
Disposal ........................................................................................................................................................................... 21
Maintenance ..................................................................................................................................................................... 21
Technical data dia. 45 ........................................................................................................................................................ 21
What to do if...? ................................................................................................................................................................. 22
Sample wiring diagram ...................................................................................................................................................... 23
Declaration of conformity ................................................................................................................................................... 24
2

Contents
General
These tubular drives are high-quality products with the following features:
▪Optimised for roller shutter operation
▪Individual, group and central radio control
▪No need to run wires to a switch or relay control device
▪Any combination of drive and transmitter possible
▪Simple to set the limit positions with the transmitter
▪Installation without stops possible (from upper point to lower point)
▪Two freely selectable intermediate positions can be set
▪Flexible radio grouping; can be altered at any time with no need to install/uninstall
▪Integrated memo function facilitates easy programming of one or two switching times on daily repeat.
▪Automatic detection of the lower limit position when using springs in conjunction with the "drive adapter for obstacle detection"
▪Automatic detection of limit positions thanks to intelligent electronic system with stop systems
▪Obstacle detection, even when using anti-lifting devices (axle shaft devices)
▪Secure anti-lifting device
▪Slight pressure applied to the roller shutter curtain makes it difficult to raise or reach under it
▪Suitable for rigid aluminium, steel and wooden profiles
▪The final positions do not have to be reset: Changes in the shading solution are accommodated automatically when using stop
systems.
▪Torque control in the up direction prevents damage to the roller shutter in the event of a frozen or blocked shutter
▪Anti-freeze mechanism in the upper limit position can be enabled
▪Considerably lower stop load, and thus considerably lower shading solution load.
▪Smooth operation of the system and the drive increases the service life
▪For plug-in connecting cable
▪Fly screen protection function
Please observe these Assembly and Operating Instructions when installing and setting the equipment.
Note
In order to identify the type of drive, compare the type plate of the tubular drive with the cover of these in‐
structions.
3

Explanation of nomenclature
Tubular drives:
Example: R12/17C PROF+
R12 / 17 C PROF+
Type Nm min-1 C-Plug =
plug-in connecting cable
Limit switch version
Types:
P= pico tube dia. 35 mm
R= regular tube dia. 45 mm
L= large tube dia. 58 mm
Limit switching versions:
M= mechanical limit switch
HK = mechanical limit switch with crank
G= DC drives with mechanical limit switch
GHK = DC drives with mechanical limit switch and crank
Electronic limit switching:
R= roller shutters
S= sun protection
F= with integrated radio receiver
P= with point-to-point switching
E= reversing in the limit position
O= with sensitive obstacle detection
SMI = Standard Motor Interface
+ (with R) = with automatic detection of anti-lifting devices
+ (with S) = higher closing force for cassette awnings
Software versions
A0…z9
The date of manufacture comes from the first four digits of the serial number.
The numbers 1 and 2 indicate the year and the numbers 3 and 4 indicate the calendar week.
Example: 24th calendar week in 2012
Ser. No.: 1224XXXXX
Explanation of pictograms
Caution
Denotes a potentially hazardous situation. If this is not avoided, injuries may result.
Attention
Denotes a potentially hazardous situation. If this is not avoided, the product or some‐
thing in its vicinity may be damaged.
Note
Denotes user tips and other useful information.
4

Warranty
Structural modifications and incorrect installation which are not in accordance with these and our other instructions can result in
serious injuries, e.g., crushing of limbs. Therefore, structural modifications may only be carried out with our prior approval and
strictly in accordance with our instructions, particularly the information contained in these Assembly and Operating Instructions.
Any further processing of the products which does not comply with their intended use is not permitted.
The end product manufacturer and fitter have to ensure that all the relevant current statutory, official and, in particular, EMC regu‐
lations are adhered to during utilisation of our products, especially with regard to end product manufacture, installation and cus‐
tomer advice.
Safety instructions
The following safety instructions and warnings are intended to avert hazards and to prevent property damage and personal injury.
Please keep these instructions in a safe place.
Caution
Important safety instructions for the user.
Failure to observe these instructions can lead to serious injuries.
▪All work, including maintenance and cleaning, on electrical installations as well as other system parts must
always be performed by authorised specialists, in particular qualified electricians.
▪Do not allow children to play with control units.
▪Systems have to be checked regularly by authorised specialists for wear and damage.
▪Always put damaged systems out of operation immediately until they are repaired by an authorised special‐
ist.
▪Do not operate equipment if people or objects are within the danger zone.
▪Observe the danger zone of the equipment during operation.
▪Stop and disconnect the equipment from the mains power supply when maintenance and cleaning is being
performed either on the system itself or in the immediate vicinity of it.
▪Ensure that there is adequate clearance (at least 40 cm) between moving parts and adjacent objects.
▪Crushing or shearing points must be avoided or protected.
5

Caution
Important safety instructions for installation and commissioning
Failure to observe these instructions can lead to serious injuries.
▪Observe the safety instructions in EN 60335-2-97. Please note that this list of safety instructions is not ex‐
haustive, since it would be impossible for the standard to include all sources of danger. For example, the
design of the operated product, the way the drive works in the situation it is installed in or even the way the
end product is mounted in the end user’s place of use cannot be taken into consideration by the drive man‐
ufacturer.
If any questions or uncertainties regarding the safety instructions contained in the standard arise, please
contact the manufacturer of the part or end product in question.
▪All work, including maintenance and cleaning, on electrical installations as well as other system parts must
always be performed by authorised specialists, in particular qualified electricians.
▪When electrical or electronic equipment and units are operated, certain components, e.g., the power sup‐
ply unit, are live. Physical injuries or damage to property can result in the event of unauthorised interven‐
tions or failure to heed warnings.
▪Be careful when touching the tubular drive, as it heats up during operation for technological reasons.
▪All applicable standards and regulations for electrical installation must be complied with.
▪Only use spare parts, tools and accessory devices which have been approved by the drive manufacturer.
▪Unapproved third-party products or modifications to the system and its accessories represent a risk to your
safety and the safety of others. This means that the use of unapproved third-party products, or modifica‐
tions which have not been agreed with or approved by us, are prohibited. We do not accept liability for dam‐
ages or injury arising from such actions.
▪Before installation, shut down all lines and control devices that are not essential for operation.
▪Position control devices within sight of the driven product, but away from moving parts, at a height of over
1.5 m.
▪Permanently mounted control devices must be positioned where they can be seen.
▪Ensure that there is adequate clearance between moving parts and adjacent objects.
▪Rated torque and duty cycle must be suitable for the requirements of the driven product.
▪Technical data – rated torque and service life can be found on the type plate of the tubular drive.
▪Moving parts of drives must be installed at a height of over 2.5 m above floor level or any other surface from
which access to the drive is gained.
▪Crushing or shearing points must be avoided or protected.
▪When installing the drive, all-pole disconnection from the mains with a contact gap of at least 3 mm per pole
must be provided (EN 60335).
▪To ensure safe operation of the system after commissioning, the limit positions must be correctly set/
programmed in.
▪If the drive mains connecting cable is damaged, it must be replaced with the same type of mains connecting
cable, which is available from the drive manufacturer.
▪The drive must not be carried by the mains connecting cable.
▪Drives with a H05VV-F connecting cable may only be used indoors.
▪To connect the drive to the driven part, solely mechanical accessory components made by the drive manu‐
facturer from the current product catalogue may be used. The components must be installed in accordance
with the manufacturer's instructions.
▪All latching connections and fastening screws on the brackets must be checked to ensure that they are se‐
cure.
▪If the drive is used for curtains in a specially marked area (e.g. escape routes, hazard zones, safety areas),
compliance with all applicable regulations and standards must be ensured.
6

Intended use
The type of tubular drive described in these instructions is intended solely for the operation of roller shutters.
This type of tubular drive supports not only curtain attachment by means of springs but also mechanical anti-lifting devices (e.g.,
Zurfluh-Feller, Simu, GAH Alberts and Deprat). These are detected automatically.
If the springs or the top lath are not screwed or rivetted to the barrel, a point must be set in the lower limit position.
This type of tubular drive is designed for use in single systems (one roller shutter curtain per barrel and drive).
For sunblinds, please use only the types of tubular drive designed for this purpose.
The tubular drive must not be used in potentially explosive areas.
The mains connecting cable is not suitable for transporting the drive. Always carry the drive by the housing tube.
Other applications, uses and modifications are not permitted in order to protect the safety of the users and others, since these
actions can impair the system’s safety and carry the risk of personal injury and property damage. The drive manufacturer does not
accept liability for damages or injury arising from such actions.
Always observe the information in these instructions when operating or repairing the system. The drive manufacturer does not ac‐
cept liability for damages or injury resulting from improper usage.
Attention
Only use anti-lifting devices if the roller shutter laths are sufficiently strong. The closed curtain must not
project beyond the guide tracks or else there is a risk of the joint between the top two laths being subjected to
excessive strain and getting damaged.
Assembling and disassembling the plug-in connecting cable
Assembling the plug-in connecting cable
Insert the dead connecting cable into the drive head until the locating lug clicks into place in the drive. If necessary, use a suitable
flathead screwdriver to assist with insertion. Set the screwdriver into one of the two plug grooves provided for this purpose.
Check that the cable is properly engaged.
1 = locating lug
7

Disassembling the plug-in connecting cable for tubular drives dia. 45 and dia. 58
Caution
Prior to disassembly, the power supply to the connecting cable must be disconnected.
On drives with a diameter Ø45 or Ø58, insert a suitable flathead screwdriver right into the recess of the locating latch, so that the
latch releases the locating lug from the plug.
Now you can pull out the connecting cable along with the flathead screwdriver.
dia. 45 and dia. 58
2.
1.
A
A = locating latch
8

Installation
Assembling the drive
Attention
To connect the drive to the driven part, solely mechanical accessory components made by the drive manufac‐
turer from the current product catalogue may be used.
Prior to mounting, the fitter must ensure that the masonry and the system being motorised are sufficiently robust (drive torque plus
weight of the shading solution).
Caution
Electrical connections may only be carried out by a qualified electrician. Prior to assembly, the power supply
must be disconnected and secured. Please give the enclosed connection information to the responsible elec‐
trical contractor.
These drives cannot be operated with conventional switching elements (switches, timers and the like).
If you want the roller shutter curtain to open to the upper stop, proceed as follows: The roller shutter curtain
must be prevented from being drawn into the shutter box with a mechanical stop or an angled end strip. With
face-fixed elements, we recommend concealed stops in the guide tracks.
Calculate the space required at the side (M) by measuring the drive head and wall
bracket. The clear dimension of the box (X) minus the space required at the side (M)
and idler (G) gives the length (L) of the barrel: L=X-M-G.
The space required at the side (M) varies depending on the combination of drive and
wall bracket.
Then mount the wall bracket and idler. Ensure that the barrel is aligned at right angles to the wall and that sufficient axial play is
allowed for the mounted system.
Attention
When using anti-lifting devices, closed brackets must be fitted. The tubular drive presses the closed curtain
down to make it difficult for people to reach under it or raise it. Only use curtains made of sufficiently strong
material, such as aluminium, steel or wood. To prevent damage to the curtain it must run in guide tracks from
top to bottom.
Undoing the mounting pin
When pushed in, the mounting pin (2) locks automatically. To undo the mounting pin
(2), push the tab washer (1) upwards and pull out the mounting pin (2).
Drive adapter for obstacle detection
Note
If you wish to use the "obstacle detection" function, you must use the "drive adapter for obstacle detection".
9

Assembling the drive adapter with drive adapter safety catch
Put the drive adapter (1) onto the drive shaft of the tubular drive. You can see which
way to insert the safety catch (2) from its shape. When inserting the drive adapter
safety catch (2) into the hole (4), make sure that the locking lug (3) engages. You will
hear a click. Check that the safety catch is securely in position by pulling on the drive
adapter (1).
Assembling the drive adapter with screw connection
Put the drive adapter (1) onto the drive shaft of the tubular drive. For the assembly,
use an M6 x 12 screw (3) with appropriate washer (2) and suitable screw retainer.
Threaded hole (4)
Securing the drive against axial displacement
-10 mm
In order to secure the drive against axial displacement, we recommend screwing the
drive adapter to the tube.
Attention
When drilling into the barrel, never drill near the tubular drive!
Fixing the drive adapter to the barrel dia. 45
Size of drive
[mm]
Diameter of barrel
[mm]
Torque
max. [Nm]
Fastening screws
for drive adapter (4 pc.)
dia. 45 60 - 70 mm
plastic or
diecast drive adapter
40 Self-tapping screw
dia. 4.8 x 9.5 mm
We also recommend screwing the opposite end bracket to the barrel.
Attention
Do not hammer or drop the tubular drive into the barrel! The curtain can only be secured using springs or anti-
lifting devices.
10

Mounting the drive in the tube
For profile tubes:
In the case of some drive adapters, tolerances of the groove widths in different bar‐
rels can be offset by rotating the drive adapter into a different groove recess. These
groove recesses have different sizes and allow the drive to fit exactly.
For round tubes:
First notch the tube on the motor side, so the lug of the thrust ring can also be pushed
into the tube. There must be no play between the lug of the thrust ring and the tube.
For rings without drive lugs, which are used to assist fitting on the thrust ring, the bar‐
rel must be connected to the thrust ring by a 4.8 x 9.5 mm self-tapping screw.
Assemble the tubular drive with the relevant thrust ring (1) and drive adapter (2). In‐
sert the tubular drive with the pre-assembled thrust ring and drive adapter into the
tube to achieve a form fit. Ensure that the thrust ring and drive adapter are secure in
the tube.
Mount the assembled unit comprising barrel, tubular drive and idler on the box and secure the drive according to the type of wall
bracket fixing with a split or spring pin.
After programming the transmitter, position the barrel so that the roller shutter curtain can be mounted with springs or fit the anti-
lifting device in accordance with the manufacturer's instructions.
Note
When using springs/anti-lifting devices, we recommend you use at least three; for longer tubes, use three
springs/anti-lifting devices per meter of barrel.
Lay the connecting cable
Lay the connecting cable up to the tubular drive, and fix The connecting cable and
any antennae must not project into the winding chamber. Cover any sharp edges.
Confirming the drive
The drive audibly confirms each programming and deletion action. The tubular drive makes a barely perceptible movement, which
you hear as a “click" or "click click" sound.
11

First operation
Explanation of symbols
UP button
STOP button
DOWN button
Programming button
The tubular drive clicks once to confirm
The tubular drive clicks twice to confirm
The tubular drive clicks three times to confirm
1 = direction switch
2 = radio switch
N1
2
1
2
4
3
4
230V AC / 50 Hz
L1
PE
Connecting the tubular drive
Connect the tubular drive to the power supply.
1 = blue 3 = black
2 = brown 4 = green-yellow
Readying the tubular drive for programming
Readying the tubular drive for programming by switching on the power
[Switch on the power.
ÆThe tubular drive is ready to programme for 3 minutes
Note
If several tubular drives are to be connected in parallel, you can deactivate the programming mode on one tub‐
ular drive by switching the radio switch to the outside position after turning the power on.
Readying the tubular drive for programming with the radio switch
Switch the radio switch to the inside position. If the radio switch is already in this posi‐
tion, switch it to the outside and back to the inside position.
ÆThe tubular drive is ready to programme for 3 minutes
12

Programming the master transmitter
Press the programming button for 3 seconds when it is ready to programme.
[The tubular drive makes a clicking sound to confirm.
ÆThe programming process is now complete.
Note
If a transmitter is already programmed on the receiver, press the programming button for 10 seconds.
Checking that the running direction is correct
Note
It is only possible to change the direction of rotation if no limit position has been set.
Press the UP or DOWN button
[The shading solution runs in the desired direction.
ÆDirection switch is OK.
If the shading solution runs in the wrong direction, the running direction must be switched. Proceed as follows:
Switch the direction switch (1) to the opposite position.
ÆThe shutter direction is now changed.
Check the shutter direction again.
Intelligent installation management
Limit position status indicator
A brief stopping and restarting indicates that no limit position has been set in that direction of movement.
Completion of installation following automatic setting of limit positions
The drive saves the limit position permanently once the upper limit position is reached 3 times in succession. Installation is then
complete. If the limit position is set above a point, this is stored permanently.
13

Setting the limit positions
Note
The limit positions can only be set with the master transmitter. The shutter direction must be correct. When
setting the limit positions, the tubular drive runs in dead-man mode and limit position status indicator. The up‐
per limit position must always be set first. When setting the upper limit position, ensure that the roller shutter
curtain is not pulled out of the guide tracks.
When first installing, using springs and adjusting the limit position ‘...to lower stop’, the barrel in the lower lim‐
it position turns approx. 1/4 of a turn further than usual. In doing so, the tubular drive is able to automatically
detect the use of anti-lifting devices or springs. The tubular drive switches off automatically.
Attention
When operating the tubular drive without the drive adapter for obstacle detection, if using springs a point must
be set in the lower limit position.
There are 4 ways to set the limit positions:
▪Upper stop to lower stop
▪Upper point to lower point
▪Upper stop to lower point
▪Upper point to lower stop
The limit position becomes fixed after the tubular drive has turned off automatically in the desired position three times.
Upper stop to lower stop
Open to the permanent upper stop.
[The tubular drive switches off automatically.
Then close to the permanent lower stop.
[The tubular drive switches off automatically.
ÆThe limit positions are now set.
Upper point to lower point
Note
There is no shading solution length adjustment with this limit position setting.
Open to the desired upper limit position.
Press the programming button and, within 3 seconds, also press the UP button and
hold the two buttons down.
[The tubular drive makes a “click” sound to confirm.
Then close to the desired lower limit position.
Press the programming button and, within 3 seconds, also press the DOWN button
and hold the two buttons down.
[The tubular drive makes a “click” sound to confirm.
ÆThe limit positions are now set.
Upper stop to lower point
Open to the permanent upper stop.
[The tubular drive switches off automatically.
Then close to the desired lower limit position.
Press the programming button and, within 3 seconds, also press the DOWN button
and hold the two buttons down.
[The tubular drive makes a “click” sound to confirm.
ÆThe limit positions are now set.
14

Upper point to lower stop
Open to the desired upper limit position.
Press the programming button and, within 3 seconds, also press the UP button and
hold the two buttons down.
[The tubular drive makes a “click” sound to confirm.
Then close to the permanent lower stop.
[The tubular drive switches off automatically.
ÆThe limit positions are now set.
Changing the set limit positions
Note
Once set, the limit positions can only be changed with the master transmitter.
1) Shortening the range of travel (the desired limit position is located inside the current range of travel)
Open/close to the desired new limit position.
Press the programming button and, within 3 seconds, also press the DOWN button
for the lower limit position or the UP button for the upper limit position and hold the
two buttons down.
[The tubular drive makes a “click” sound to confirm.
ÆThe new limit position is now saved.
2) Extending the range of travel (the desired limit position is located outside the current range of travel)
Attention
When both or individual limit positions are deleted, all the other set functions (intermediate position I, inter‐
mediate position II, upper anti-freeze mechanism, obstacle detection, run times, fly screen protection func‐
tion) are deleted as well.
Open/close to the limit position in the direction in which you wish to extend the range
of travel.
Press the programming button and, within 3 seconds, also press the STOP button
and hold the two buttons down for 10 seconds.
[The tubular drive makes a clicking sound to confirm.
ÆThe limit position is now deleted.
Open/close to the desired new limit position.
Press the programming button and, within 3 seconds, also press the DOWN button
for the lower limit position or the UP button for the upper limit position and hold the
two buttons down.
[The tubular drive makes a “click” sound to confirm.
ÆThe new limit position is now saved.
Deleting the limit positions
Attention
When both or individual limit positions are deleted, all the other set functions (intermediate position I, inter‐
mediate position II, upper anti-freeze mechanism, obstacle detection, run times, fly screen protection func‐
tion) are deleted as well.
15

Note
Once set, the limit positions can only be deleted with the master transmitter. Deleted limit positions are dis‐
played on the limit position status indicator.
Deleting individual limit positions
Open/close to the limit position to be deleted.
Press the programming button and, within 3 seconds, also press the STOP button
and hold the two buttons down for 10 seconds.
[The tubular drive makes a clicking sound to confirm.
ÆThe limit position is now deleted.
Deleting both limit positions
Open/close the shading solution to a point between the limit positions.
Press the programming button and, within 3 seconds, also press the STOP button
and hold the two buttons down for 10 seconds.
[The tubular drive makes a clicking sound to confirm.
ÆThe limit positions are now deleted.
Intermediate positions I + II
Note
The intermediate positions I + II are freely selectable positions for the shading solution between the two limit
positions. Each travel button can be assigned one intermediate position. Both limit positions must be set be‐
fore the intermediate position is set.
When both or individual limit positions are deleted, both intermediate positions are deleted as well.
Setting the desired intermediate position
Open/close the shading solution to the desired intermediate position.
Press the STOP button and, within 3 seconds, also press the desired travel button
and hold the two buttons down.
[The tubular drive makes a “click” sound to confirm.
ÆThe intermediate position is now saved.
Setting the desired intermediate position
Press the travel button for the desired intermediate position twice within one second.
ÆThe shading solution runs to the intermediate position assigned to the travel but‐
ton.
Deleting the desired intermediate position
Open/close the shading solution to the desired intermediate position.
Press the STOP button and, within 3 seconds, also press the travel button assigned
to the intermediate position and hold the two buttons down.
[The tubular drive makes a clicking sound to confirm.
ÆThe intermediate position is now deleted.
16

Programming additional transmitters
Note
In addition to the master transmitter, up to 15 further transmitters can be programmed in the tubular drive.
Press the programming button of the master transmitter for 3 seconds.
[The tubular drive makes a “click” sound to confirm.
Now press the programming button of a new transmitter which has not yet been pro‐
grammed in the tubular drive for 3 seconds. Doing so activates the programming
mode of the tubular drive for a new transmitter for 3 minutes.
[The tubular drive makes a “click” sound to confirm.
Now re-press the programming button of the new transmitter you wish to programme
for 3 seconds.
[The tubular drive makes a clicking sound to confirm.
ÆThe new transmitter is now programmed in.
Deleting transmitters
Deleting individual transmitters
Note
The programmed master transmitter cannot be deleted. It can only be overwritten (see Programming the master
transmitter [➙ 13]).
Press the programming button on the master transmitter for 3 seconds.
[The tubular drive makes a “click” sound to confirm.
Now press the programming button of the transmitter to be deleted for 3 seconds.
[The tubular drive makes a “click” sound to confirm.
Then re-press the programming button of the transmitter to be deleted for 10 sec‐
onds.
[The tubular drive makes a clicking sound to confirm.
ÆThe transmitter is now deleted from the tubular drive.
Deleting all transmitters (except the master transmitter)
Press the programming button on the master transmitter for 3 seconds.
[The tubular drive makes a “click” sound to confirm.
Re-press the programming button on the master transmitter for 3 seconds.
[The tubular drive makes a “click” sound to confirm.
Re-press the programming button on the master transmitter for 10 seconds.
[The tubular drive makes a clicking sound to confirm.
ÆAll transmitters (except the master transmitter) are now deleted from the receiver.
17

Overwriting the master
There are two ways to overwrite the master:
▪Readying the tubular drive for programming by switching on the power
▪Readying the tubular drive for programming with the radio switch
Readying the tubular drive for programming by switching on the power
Note
To ensure that the new master transmitter is programmed in the desired tubular drive only, all other tubular
drives which are connected to the same power supply must be deactivated from the programming mode. To do
so, after switching back on the power, execute a drive or stop command using the transmitter for the given
tubular drives or switch the radio switch from inside to outside. If the radio switch is already in this position,
switch it to the inside and back to the outside position.
N1
2
1
2
4
3
4
230V AC / 50 Hz
L1
PE
Switch off the tubular drive power for 5 seconds, then switch it back on.
[The tubular drive is ready to programme for 3 minutes.
1 = blue 3 = black
2 = brown 4 = green-yellow
Now press the programming button of the new master transmitter for 10 seconds.
[The tubular drive makes a clicking sound to confirm.
ÆThe new master transmitter is now programmed and the old master transmitter
overwritten.
Readying the tubular drive for programming with the radio switch
Switch the radio switch to the inside position. If the radio switch is already in this posi‐
tion, switch it to the outside and back to the inside position.
[The tubular drive is ready to programme for 3 minutes.
Now press the programming button of the new master transmitter for 10 seconds.
[The tubular drive makes a clicking sound to confirm.
ÆThe new master transmitter is now programmed and the old master transmitter
overwritten.
18

Upper anti-freeze mechanism
The upper anti-freeze mechanism helps to prevent the roller shutter from freezing in the upper limit position, as the roller shutter
stops just before the upper stop. The distance from the upper stop is automatically cyclically checked and, if necessary, correc‐
ted.
The upper anti-freeze mechanism is deactivated on delivery.
Both limit positions must be set before the anti-freeze mechanism can be activated.
Note
The anti-freeze mechanism only works if a permanent stop is set at the upper limit position of the roller shut‐
ter. The anti-freeze mechanism is not visible until the shading solution has reached the upper stop from the
lower limit position 3 times in succession.
When both or individual limit positions are deleted, this set function is deleted as well.
Activating/Deactivating upper anti-freeze mechanism
Open the shading solution to the upper limit position.
Press the programming button on the master transmitter for approx. 3 seconds.
[The tubular drive makes a “click” sound to confirm.
Then re-press the programming button and also the STOP and UP buttons for approx. 3
seconds.
ÆThe tubular drive clicks 3 times to confirm.
Obstacle detection
Caution
Obstacle detection is only active in conjunction with the “drive adapter for obstacle detection”.
In addition, please note that the drive must be pushed in to the shaft as far as the band of the thrust ring.
If the drive is correctly installed, it switches off when it detects obstructions or shutter faults.
The following are detected:
In the DOWN direction
▪A curtain jam when closing due to objects on the window sill or sticking of the lateral guide tracks.
In the UP direction
▪Extremely large increase in the load (e.g., ice on the end strip)
To ensure that the roller shutter curtain safely enters the guide tracks, obstacle detection is inactive for approx. 1.5 revolutions of
the barrel from the upper limit position.
19

Fly screen protection function
If the fly screen protection function is activated, obstacle detection is activated after a revolution of the barrel of approx. 140° from
the upper limit position. If the roller shutter curtain meets an opened fly screen door, the drive stops and returns to the upper limit
position.
The fly screen protection function is deactivated on delivery.
Both limit positions must be set before the fly screen protection function can be activated.
Note
When both or individual limit positions are deleted, this set function is deleted as well.
Activating/Deactivating the fly screen protection function
Open the shading solution to the upper limit position.
Press the programming button on the master transmitter for approx. 3 seconds.
[The tubular drive makes a “click” sound to confirm.
Then re-press the programming button and also the STOP and UP buttons for ap‐
prox. 3 seconds.
ÆThe tubular drive clicks 3 times to confirm.
Programming the run times
Note
This function is only available with MemoControl transmitters from the Becker Centronic range of control
units.
When both or individual limit positions are deleted, this set function is deleted as well.
Each tubular drive can each save one switching time for one UP and one DOWN cycle.
In the “Timer” slide switch position, this roller shutter action is repeated every 24 hours.
It does not matter what position the manual/auto slide switch is in when programming the switching time. Any stored switching
times are overwritten.
1. If necessary, run the roller shutter to the opposite limit position.
2. Wait for the time you wish the automatic drive command to be executed.
3. At the desired time, press and hold the relevant direction button until the roller shutter drive briefly stops after approx. 6 sec‐
onds and then continues to the limit position.
4. Release the direction button.
The tubular drive has saved the current time for this direction of travel.
20
