Avanti®J-20 XP
Instruction Manual
Expanded-Performance Centrifuge
TM
TM
TM
MADEINU.S.A.

SAFETY NOTICE
This safety notice summarizes information basic to the safe operation of the equipment
described in this manual. The international symbol displayed above is a reminder that all
safety instructions should be read and understood before installation, operation, mainte-
nance, or repair of this instrument. When you see the symbol on other pages, pay special
attention to the safety information presented. Observance of safety precautions will also
help to avoid actions that could damage or adversely affect the performance of the
centrifuge.
Safety During Installation and/or Maintenance
This centrifuge is designed to be installed by a Beckman Coulter field service representa-
tive. Installation by anyone other than authorized Beckman Coulter personnel invalidates
any warranty covering the instrument.
Any servicing of this equipment that requires removal of any covers can expose parts that
involve the risk of electric shock or personal injury. Make sure that the power switch is
turned off and the instrument is disconnected from the main power source, and refer such
servicing to qualified personnel.
Be sure to use the anchoring system to secure the centrifuge in place. The anchoring
system is designed to reduce the possibility of injury or damage that could result from
instrument movement in the event of a major rotor mishap.
Do not replace any centrifuge components with parts not specified for use on this
instrument.
Electrical Safety
To reduce the risk of electrical shock, this equipment uses a three or five-wire electrical
cord and plug to connect this equipment to earth-ground. To preserve this safety feature:
• Make sure that the matching wall outlet receptacle is properly wired and earth-
grounded. Check that the line voltage agrees with the voltage listed on the name-rating
plate affixed to the centrifuge.
•Never use a three-to-two wire plug adapter.
•Never use a two-wire extension cord or a two-wire non-grounding type of multiple-
outlet receptacle strip.
Do not place containers holding liquid on or near the chamber door. If they spill, liquid
may get into the centrifuge and damage electrical or mechanical components.
!

Safety Against Risk of Fire
This centrifuge is not designed for use with materials capable of developing flammable
or explosive vapors. Do not centrifuge such materials (for example, chloroform or ethyl
alcohol) in this instrument nor handle or store them near the centrifuge.
Mechanical Safety
For safe operation of the equipment, observe the following:
• Use only the Beckman Coulter rotors and accessories designed for use in this
centrifuge.
• Do not exceed the maximum rated speed of the rotor in use.
• NEVER attempt to slow or stop a rotor by hand.
• Do not lift or move the centrifuge while a rotor is spinning.
• NEVER attempt to override the door interlock system while the rotor is spinning.
• Do not lean on the centrifuge or place items on it while it is operating.
Chemical and Biological Safety
Normal operation may involve the use of solutions and test samples that are pathogenic,
toxic, or radioactive. Such materials should not be used in this centrifuge, however, unless
all necessary safety precautions are taken .
• Observe all cautionary information printed on the original solution containers prior to
their use.
• Handle body fluids with care because they can transmit disease. No known test offers
complete assurance that they are free of micro-organisms. Some of the most virulent—
Hepatitis (B and C) and HIV (I–V) viruses, atypical mycobacteria, and certain
systemic fungi—further emphasize the need for aerosol protection. Handle other infec-
tious samples according to good laboratory procedures and methods to prevent spread
of disease. Because spills may generate aerosols, observe proper safety precautions for
aerosol containment. Do not run toxic, pathogenic, or radioactive materials in this
centrifuge without taking appropriate safety precautions. Biosafe containment should
be used when Risk Group II materials (as identified in the World Health Organization
Laboratory Biosafety Manual ) are handled; materials of a higher group require more
than one level of protection.
•Dispose of all waste solutions according to appropriate environmental health and safety
guidelines.
It is your responsibility to decontaminate the instrument and accessories before
requesting service by Beckman Coulter.

J320XP-IM-5
May 2005
TM
TM
MADEINU.S.A.
Avanti®J-20 XP
Instruction Manual
Expanded-Performance Centrifuge
© 2005 Beckman Coulter, Inc.
Printed in the U.S.A.

Contents
iii
Page
INTRODUCTION
Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Scope of this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Notes, Cautions, and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Typographic Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Radio Interference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Canadian Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
SECTION 1: SPECIFICATIONS AND PREINSTALLATION REQUIREMENTS
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Control Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Operational Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Available Rotors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Preinstallation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Electrical Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
Single and Three-Phase Power Connections . . . . . . . . . . . . . . . . 1-9
Additional Requirements for Three-Phase Power
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Space and Location Requirements. . . . . . . . . . . . . . . . . . . . . . . 1-12
Securing the Centrifuge to the Floor . . . . . . . . . . . . . . . . . . . . . 1-12
Using J2 Series Rotors in the Avanti J. . . . . . . . . . . . . . . . . . . . . . . 1-14
Checking for Rotor Drive Pins . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
Using the JA-18 Rotor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
Using the JCF-Z Continuous Flow/Zonal Rotor . . . . . . . . . . . . 1-15

iv
Contents
Page
SECTION 2: DESCRIPTION
Centrifuge Function and Safety Features . . . . . . . . . . . . . . . . . . . . . . 2-1
Centrifuge Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Safety Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Housing and Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Rotor Chamber. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Friction Reduction System (FRS) . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Temperature Sensing and Control . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Overtemp System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Name Rating Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Controls and Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Power Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
SECTION 3: OPERATION
Summary of Avanti J-20XP Run Steps . . . . . . . . . . . . . . . . . . . . . . . 3-2
Preparation and Loading. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Entering Run Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Selecting a Rotor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Setting Run Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Setting Run Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Setting Run Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Setting Acceleration and Deceleration Rates. . . . . . . . . . . . . . . . 3-8
Setting Up an Elutriation Run . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Starting a Run . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Changing Parameters During a Run . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Changing Time Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Stopping a Run . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Unloading the Centrifuge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15

v
Contents
Page
SECTION 4: TROUBLESHOOTING
Diagnostic Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Accessing the Rotor in Case of Power Failure. . . . . . . . . . . . . . . . . . 4-5
JCF-Z Rotor Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
SECTION 5: CARE AND MAINTENANCE
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Decontamination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Sterilization and Disinfection . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Replacing the Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Circuit Breaker and Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Storage and Transport. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Returning a Centrifuge. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Supply List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Replacement Parts and Supplies . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
APPENDIX: TEMPERATURE CALIBRATION PROCEDURE
Warranty

Illustrations
vi
Tables
Page
Figure 1-1. Single-Phase Electrical Requirements . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Figure 1-2. Three-Phase “Y” Electrical Requirements . . . . . . . . . . . . . . . . . . . . . 1-10
Figure 1-3. Correct and Incorrect Three-Phase Power Configurations . . . . . . . . . 1-11
Figure 1-4. Rear View and Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Figure 1-5. Checking the Rotor for Drive Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15
Figure 2-1. The Power Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Figure 2-2. The Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Figure 3-1. Acceleration and Deceleration Settings Graph . . . . . . . . . . . . . . . . . . . 3-9
Figure 3-2. Elutriation Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Figure 4-1. Emergency Door Release Latch Access . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Figure 4-2. Manual Door Release . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Figure 4-3. Venting the Chamber Vacuum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Figure 4-4. Front Panel Retaining Strip. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
Page
Table 1-1. Nominal Instrument Voltage Ratings for the Avanti J-20XP. . . . . . . . 1-9
Table 1-2. Required Wire Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Table 3-1. Acceleration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Table 3-2. Deceleration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Table 4-1. Diagnostic Message Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Introduction
vii
CERTIFICATION
To ensure full system quality, Beckman Coulter Avanti
®
J-20XP
centrifuges are manufactured in a registered ISO 9001 facility. They
have been designed and tested to be compliant (when used with
Beckman Coulter rotors) with the laboratory equipment reqirements
of applicable regulatory agencies. Declarations of conformity and
certificates of compliance are available at www.beckmancoulter.com.
SCOPE OF THIS MANUAL
This manual is designed to familiarize centrifuge users and site
engineers with the Avanti
®
J-20XP centrifuge, its functions, specifi-
cations, operation, and routine care and maintenance. We recommend
that you read this entire manual, especially the
SAFETY NOTICE
and
all safety-related information, before operating the instrument or
performing instrument maintenance.
• Section 1 contains system specifications and instructions for
preparing your site for centrifuge installation.
• Section 2 contains an overall description of the centrifuge,
including a description of system controls and indicators.
• Section 3 summarizes procedures for operating the centrifuge.
•Section 4 lists system diagnostic messages, together with probable
causes and user-performed corrective actions.
• Section 5 contains procedures for routine maintenance, as well as
a brief list of supplies and replacement parts.
• The appendix contains a procedure to use when temperature
control within ±1°C is required.

viii
Introduction
➠NOTE
If the centrifuge is used in a manner other than
specified in this manual, the safety and perfor-
mance of this equipment could be impaired.
Further, the use of any equipment other than
that recommended by Beckman Coulter has not
been evaluated for safety. Use of any equipment
not specifically recommended in this manual is
the sole responsibility of the user.
CONVENTIONS
Certain symbols are used in this manual to call out safety related and
other important information. These international symbols may also be
displayed on the centrifuge and are reproduced and described on the
inside cover and/or below.
NOTES, CAUTIONS, AND WARNINGS
➠NOTE
Used to call attention to information that should
be followed during installation, use, and/or
servicing of the equipment.
!CAUTION
Used to indicate a potentially hazardous situa-
tion which, if not avoided, may result in minor
or moderate injury and/or mechanical damage.
It is also used to alert against unsafe practices.

ix
Introduction
!
WARNING
Used whenever an action or condition may
potentially cause personal injury or loss of
life. Mechanical damage may also result.
WARNING
Indicates high voltage or risk of electric
shock. Refer servicing of all areas displaying
either symbol to qualified service personnel.
TYPOGRAPHIC CONVENTIONS
Certain typographic conventions are used throughout this manual to
distinguish names of user interface components, such as keys and
displays.
•Control knob names (for example, ROTOR and SPEED) appear in
all capital letters.
•Key names (for example,

_78%68a
and

_7834a
) appear in boxes.
•Display field names (for example, TEMP°C or SPEED ) appear in
bold type.
RADIO INTERFERENCE
This instrument has been tested and found to comply with the limits
for a Class A digital device, pursuant to Part 15 of FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
this instruction manual, may cause interference to radio communica-
tions. Operation of this equipment in a residential area may cause
interference, in which case the user will be required to correct the
interference at his own expense.

x
Introduction
CANADIAN REGULATIONS
This digital apparatus does not exceed the Class A limits for radio
noise emissions from digital apparatus as set out in the radio interfer-
ence regulations of the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques
dépassant les limites applicables aux appareils numériques de Classe
A prescrites dans le reglement sur le brouillage radioelectrique édicté
par le Ministère des Communications du Canada.

1
Specifications and
Preinstallation Requirements
1-1
SPECIFICATIONS
Only values with tolerances or limits are guaranteed data. Values
without tolerances are informative data, without guarantee.
CONTROL FEATURES
Speed
Setting range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 to 26 000 rpm
(in 100-rpm increments below 10 000 rpm,
500-rpm increments above 10 000 rpm),
or equivalent RCF (in 100 × g increments)
Elutriation speed setting range. . . . . . . . . . . . . . . . . . . . 0 to 5 000 rpm
(in 10-rpm or 10 × g increments)
Speed display . . . . . . . . . . . . . from 0 to 10 000 rpm, display indicates
actual rotor speed ±10 rpm
from 10 000 to 26 000 rpm, indicates actual
rotor speed ± 0.1%, or equivalent RCF
Time
Setting range . . . . . . . . . . . . . . . . . . . to 180 min or continuous (hold)
Time display. . . . . . . . . . . . . indicates run time remaining (timed run)
or elapsed time (hold run)
Temperature
Setting range . . . . . . . . . . . . . . . . . –10 to +40°C (in 1°C increments)
Accuracy . . . . . . . . . . . . rotor temperature controlled to within ±2°C
of set temperature (after equilibration)*
Ambient temperature range . . . . . . . . . . . . . 16 to 38°C (60 to 100°F)
†
Cooling fluid . . . . . . . . . . . . . . . . . . . . . . . . . Refrigerant 404A (HFC)
Acceleration maximum or slow
Deceleration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . maximum, slow, or off
______________
*During transient conditions, such as acceleration and deceleration, rotor temperature may be outside this range. Refer to applicable rotor manuals
for specific rotor operating range information.
†
To reach temperatures above ambient, the centrifuge is dependent on the frictional heat generated inside the chamber during operation. At low
run speeds or low ambient temperatures, the centrifuge may not be able to achieve some higher temperatures.
CFC

1-2
Specifications and Preinstallation Requirements
OPERATIONAL FEATURES
Door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.1-cm (2.4-in.) thick structural
foam with steel plate
Rotor chamber diameter . . . . . . . . . . . . . . . . . . . . . . . . . . 51.3 cm (20 in.)
Friction Reduction System (FRS) . . . . . . . . . . . . . . . . 190 mm (7.5 in.) Hg
PHYSICAL DATA
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 cm (28 in.)
Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86 cm (34 in.)
Depth (including air diverter extending
from back panel) . . . . . . . . . . . . . . . . . . . . . . . . . . 102 cm (40.25 in.)
Height, door closed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86 cm (34 in.)
Height to top of control head. . . . . . . . . . . . . . . . . . . . . . 116 cm (45.5 in.)
Height to top of open door . . . . . . . . . . . . . . . . . . . . . . . 149 cm (58.7 in.)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290 kg (640 lb)
Clearances (for adequate ventilation)
Sides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7.6 cm (3 in.)
Back (place air diverter against the wall). . . . . . . . . . 16 cm (6.25 in.)
Surface finish. . . . . . . . . . . . . . . polyester control panel with polycarbonate
coating overlay; polyurethane enamel on
door and covers; acrylic baking enamel on other surfaces
Electrical requirements
200/208/240-V, single-phase instrument . . . . . . . . . . . . .180–264 VAC,
30 A, 50/60 Hz
230-V, single-phase instrument . . . . . . . . . 180–264 VAC, 30 A, 50 Hz
220/380-V plus neutral, three-phase
‡
instrument. . . . . . . 313–457 VAC
plus neutral, 16 A, 50 Hz
Electrical supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Class I
Maximum heat dissipation into room
under steady-state conditions . . . . . . . . . . . . . . . 2.0 kW (6900 Btu/h)
Humidity restrictions. . . . . . . . . . . . . . . . . . . . . . . . <95% (noncondensing)
Noise level 0.91 m (3 ft) in front of instrument
at 26 000 rpm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 dBa
Installation (overvoltage) category . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . II
Pollution degree. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
**
______________
‡ Unbalanced three-phase. Split for single-phase operation internally.
**
Normally, only nonconductive pollution occurs; occasionally, however, a temporary conductivity caused by condensation must be expected.

1-3
Specifications and Preinstallation Requirements
AVAILABLE ROTORS
Refer to the applicable rotor manual for complete rotor descriptions.
a
Maximum speeds are based on a solution density of 1.2 g/mL with the following exceptions: the JA-18.1 rotor is rated for a density of 1.4 g/mL;
the JCF-Z rotor is rated for a density of 1.45 g/mL; and the JE-5.0 rotor is rated for a density of 3 g/mL.
b
Maximum speed for the JA-30.50 Ti rotor is 26 000 rpm in the Avanti J-20XP centrifuge, and 30 000 rpm in the Avanti J-30I centrifuge.
c
Maximum speed for the JS-24.38 and JS-24.15 rotors is 10 000 rpm in the Avanti J-20XP centrifuge,
and 24 000 rpm in the Avanti J-30I centrifuge.
d
In the Avanti J-20XP, the JCF-Z Continuous Flow/Zonal Rotor can be used in the continuous flow and reorienting gradient zonal
configurations only.
Rotor Profile and Description
Max
RPM
a
Max RCF
( × g )
Max
Capacity
Rotor
Manual
Number
JA-30.50 Ti Fixed Angle, 34° (8 place)
r
max
= 108 mm 26 000
b
81 800 8 × 50 mL J-TB-070
JA-25.50 Fixed Angle, 34° (8 place)
r
max
= 108 mm 25 000 75 600 8 × 50 mL J-TB-056
JA-25.15 Fixed Angle, 25° (24 place)
r
max
= 106 mm
(outer row)
r
max
= 86 mm
(inner row)
25 000 74 200
60 200
24 × 15 mL J-TB-057
JA-21 Fixed Angle, 40° (18 place)
r
max
= 102 mm 20 000 45 700 18 × 10 mL J-TB-002
JA-20.1 Fixed Angle, 23° (32 place)
r
max
= 115 mm
(outer row)
r
max
= 98 mm
(inner row)
20 000 51 500
43 900
32 × 15 mL J-TB-022
Continued —

1-4
Specifications and Preinstallation Requirements
a
Maximum speeds are based on a solution density of 1.2 g/mL with the following exceptions: the JA-18.1 rotor is rated for a density of 1.4 g/mL;
the JCF-Z rotor is rated for a density of 1.45 g/mL; and the JE-5.0 rotor is rated for a density of 3 g/mL.
b
Maximum speed for the JA-30.50 Ti rotor is 26 000 rpm in the Avanti J-20XP centrifuge, and 30 000 rpm in the Avanti J-30I centrifuge.
c
Maximum speed for the JS-24.38 and JS-24.15 rotors is 10 000 rpm in the Avanti J-20XP centrifuge,
and 24 000 rpm in the Avanti J-30I centrifuge.
d
In the Avanti J-20XP, the JCF-Z Continuous Flow/Zonal Rotor can be used in the continuous flow and reorienting gradient zonal
configurations only.
Rotor Profile and Description
Max
RPM
a
Max RCF
( × g )
Max
Capacity
Rotor
Manual
Number
JA-20 Fixed Angle, 34° (8 place)
r
max
= 108 mm 20 000 48 400 8 × 50 mL J-TB-003
JA-18.1 Fixed Angle (24 place)
45° adapter
r
max
= 116 mm
25° adapter
r
max
= 112 mm
18 000
17 000
42 100
36 300
24 × 1.8 mL
24 × 1.8 mL
J-TB-037
JA-18 Fixed Angle, 23° (10 place)
r
max
= 132 mm 18 000 47 900 10
× 100 mL J-TB-035
JA-17 Fixed Angle, 25° (6 place)
r
max
= 132 mm 17 000 39 800 14 × 50 mL J-TB-017
JLA-16.250 Fixed Angle, 25° (6 place)
r
max
= 134 mm 16 000 38 400 6 × 250 mL J-TB-072
JA-14 Fixed Angle, 25° (6 place)
r
max
= 137 mm 14 000 30 100 6 × 250 mL J-TB-004
Continued —

1-5
Specifications and Preinstallation Requirements
a
Maximum speeds are based on a solution density of 1.2 g/mL with the following exceptions: the JA-18.1 rotor is rated for a density of 1.4 g/mL;
the JCF-Z rotor is rated for a density of 1.45 g/mL; and the JE-5.0 rotor is rated for a density of 3 g/mL.
b
Maximum speed for the JA-30.50 Ti rotor is 26 000 rpm in the Avanti J-20XP centrifuge, and 30 000 rpm in the Avanti J-30I centrifuge.
c
Maximum speed for the JS-24.38 and JS-24.15 rotors is 10 000 rpm in the Avanti J-20XP centrifuge,
and 24 000 rpm in the Avanti J-30I centrifuge.
d
In the Avanti J-20XP, the JCF-Z Continuous Flow/Zonal Rotor can be used in the continuous flow and reorienting gradient zonal
configurations only.
Rotor Profile and Description
Max
RPM
a
Max
RCF
( × g )
Max
Capacity
Rotor
Manual
Number
JA-12 Fixed Angle, 35° (12 place)
r
max
= 144 mm 12 000 23 200 12 × 50 mL J-TB-051
JA-10 Fixed Angle, 25° (6 place)
r
max
= 158 mm 10 000 17 700 6 × 500 mL J-TB-006
JLA-10.500 Fixed Angle, 20° (6 place)
r
max
= 166 mm 10 000 18 600 6
× 500 mL J-TB-048
F10BCI-6x500y Fixed Angle, 23° (6 place)
r
max
= 158 mm 10 000 17 696 6
× 500 mL —
JLA-9.1000 Fixed Angle, 20° (4 place)
r
max
= 185 mm 9 000 16 800 4
× 1000
mL
J-TB-073
JLA-8.1000 Fixed Angle, 20° (6 place)
r
max
= 222.8 mm 8 000 15 970 6
× 1000
mL
J-TB-073
Continued —

1-6
Specifications and Preinstallation Requirements
a
Maximum speeds are based on a solution density of 1.2 g/mL with the following exceptions: the JA-18.1 rotor is rated for a density of 1.4 g/mL;
the JCF-Z rotor is rated for a density of 1.45 g/mL; and the JE-5.0 rotor is rated for a density of 3 g/mL.
b
Maximum speed for the JA-30.50 Ti rotor is 26 000 rpm in the Avanti J-20XP centrifuge, and 30 000 rpm in the Avanti J-30I centrifuge.
c
Maximum speed for the JS-24.38 and JS-24.15 rotor is 10 000 rpm in the Avanti J-20XP centrifuge,
and 24 000 rpm in the Avanti J-30I centrifuge.
d
In the Avanti J-20XP, the JCF-Z Continuous Flow/Zonal Rotor can be used in the continuous flow and reorienting gradient zonal
configurations only.
Rotor Profile and Description
Max
RPM
a
Max
RCF
( × g )
Max
Capacity
Rotor
Manual
Number
JS-24.38 Swinging Bucket (6 place)
r
max
= 161 mm 10 000
c
18 000 6 × 38.5 mL J-TB-058
JS-24.15 Swinging Bucket (6 place)
r
max
= 171.3 mm 10 000
c
19 200 6 × 15 mL J-TB-058
JS-13.1 Swinging Bucket (6 place)
r
max
= 140 mm 13 000 26 500 6
× 50 mL J-TB-036
JS-7.5 Swinging Bucket (4 place)
r
max
= 165 mm 7 500 10 400 4 × 50 mL J-TB-007
JS-5.3 Swinging Bucket (2 place)
r
max
= 194.8 mm 5 300 6 130 24 microplates
8 deep-well plates
4 square-well plates
J-TB-089
JS-4.3 Swinging Bucket (4 place)
r
max
= 204 mm 4 300 4 220 4 × 750 mL J-TB-050
Continued —
