Beko METPOINT BDL portable User guide

EN-US - english
Instructions for installation and operation
Mobile hand-held measuring device
METPOINT®BDL portable
10-133

2 METPOINT®BDL portable
Dear customer,
Thank you for deciding in favor of the METPOINT®BDL portable. Please read these installation and operat-
ing instructions carefully before mounting and starting up the device and follow our directions. Perfect func-
tioning and safe operation of the METPOINT®BDL portable can only be guaranteed when the provisions
and notes stipulated here are strictly adhered to.

Contents
METPOINT®BDL portable 3
Contents
1Pictograms and symbols........................................................................................................................5
2Signal words in accordance with ISO 3864 and ANSI Z 535.................................................................5
3Safety instructions..................................................................................................................................6
4Field of application .................................................................................................................................7
5Proper use..............................................................................................................................................7
6Type plate/product identification ............................................................................................................8
7Storage and transport ............................................................................................................................9
8Technical data METPOINT®BDL portable ..........................................................................................10
9Input signals ext. sensor METPOINT®BDL portable...........................................................................11
10 Installation............................................................................................................................................12
10.1 Line cross-sections...............................................................................................................................12
11 Connection diagrams of the different sensor types..............................................................................13
11.1 PIN assignment for the sensor connection ..........................................................................................13
11.2 Connection dew point sensors DP series ............................................................................................14
11.3 Connection dew point sensors DP/FS series.......................................................................................14
11.4 Connection dew point sensors SD series ............................................................................................14
11.5 Connection pulse sensors....................................................................................................................15
11.6 Analogue 2-wire, 3-wire, and 4-wire current signal..............................................................................16
11.7 3 and 4-wire voltage supply 0 - 1/10/30 VDC ......................................................................................17
11.8 2, 3, and 4-wire terminal assignment of PT100/PT1000/KTY81..........................................................18
11.9 Assignment with RS485.......................................................................................................................18
12 Operation METPOINT®BDL portable..................................................................................................19
12.1 Membrane keyboard ............................................................................................................................19
12.1.1 On and off key......................................................................................................................................19
12.1.2 Brightness keys....................................................................................................................................19
12.1.3 Screenshot button................................................................................................................................19
12.1.3.1 Storing a screenshot.........................................................................................................19
12.1.3.2 Exporting screenshots......................................................................................................20
12.2 Touch panel..........................................................................................................................................22
12.3 Main menu (home)...............................................................................................................................23
12.3.1 Initialization...........................................................................................................................................23
12.3.2 Main menu............................................................................................................................................24
12.3.2.1 Settings.............................................................................................................................25
12.3.2.1.1 Password setting............................................................................................................25
12.3.2.1.2 Sensor settings ..............................................................................................................26
12.3.2.1.2.1 Selection of the ext. sensor type (example: BEKO digital sensor type)..................27
12.3.2.2 Denoting the measuring data and determining the resolution of the decimal places.......30
12.3.2.2.1.1 Recording measuring data......................................................................................30
12.3.2.2.1.2 Alarm settings (alarm pop-up).................................................................................31
12.3.2.2.1.3 Advanced settings (scaling analogue output) .........................................................32
12.3.2.3 Dew point sensor with the BEKO digital type...................................................................33
12.3.2.3.1.1 Marking and setting text fields.................................................................................34
12.3.2.3.1.2 Configuration of analogue sensors .........................................................................37
12.3.2.3.1.3 Types 0 - 1/10/30 Volt and 0/4 –20 mA.................................................................37
12.3.2.3.1.4 Types PT100x and KTY81......................................................................................39
12.3.2.3.1.5 Type pulse (pulse value).........................................................................................40

4 METPOINT®BDL portable
12.3.2.3.1.6 Type no sensor....................................................................................................... 42
12.3.2.3.1.7 Type Modbus.......................................................................................................... 43
12.3.2.3.2 Selection and activation of the sensor type .................................................................. 43
12.3.2.3.2.1.1 General Modbus settings................................................................................. 43
12.3.2.3.3 Modbus settings for the METPOINT®SD23 ................................................................. 47
12.3.2.3.4 Data logger settings ...................................................................................................... 49
12.3.2.3.5 Device settings.............................................................................................................. 53
12.3.2.3.5.1 Language................................................................................................................ 53
12.3.2.3.5.2 Date & time............................................................................................................. 54
12.3.2.3.5.3 SD card................................................................................................................... 55
12.3.2.3.5.4 System update........................................................................................................ 56
12.3.2.3.5.4.1 Securing the device settings............................................................................ 56
12.3.2.3.5.4.2 Check for available updates (USB).................................................................. 57
12.3.2.3.5.4.3 Loading device settings ................................................................................... 58
12.3.2.3.5.5 Reset factory defaults............................................................................................. 59
12.3.2.4 Calibrating the touch screen............................................................................................ 60
12.3.2.4.1 Brightness ..................................................................................................................... 60
12.3.2.4.2 Cleaning........................................................................................................................ 61
12.3.2.4.3 System overview........................................................................................................... 61
12.3.2.4.4 About METPOINT®BDL portable ................................................................................. 61
12.3.2.5 Graphics........................................................................................................................... 62
12.4 Graphics/current values........................................................................................................................66
12.4.1.1 Channels.......................................................................................................................... 68
12.4.1.1.1 Min./max. function......................................................................................................... 68
12.4.1.2 Current values.................................................................................................................. 70
12.4.1.3 Alarm overview ................................................................................................................ 71
12.4.1.4 Export data....................................................................................................................... 72
13 Virtual channels (optional)....................................................................................................................74
13.1 Activate the option "virtual channels" ...................................................................................................74
13.2 Virtual channels setting ........................................................................................................................75
13.2.1 Selection of the sensor type.................................................................................................................75
13.2.2 Configuration of the individual virtual values........................................................................................76
13.2.3 Activation of the individual virtual values..............................................................................................76
13.2.4 Definition of the operands ....................................................................................................................76
13.2.5 Definitions of the operations.................................................................................................................78
13.2.6 Definition of the unit..............................................................................................................................78
13.2.7 Resolution of the decimal places –designating and recording data values ........................................80
14 Analogue total (optional).......................................................................................................................81
14.1 Activating the "analogue total" option...................................................................................................81
14.2 Selection of the sensor type.................................................................................................................82
15 Cleaning/decontamination....................................................................................................................83
16 Dismantling and disposal .....................................................................................................................83
17 SD card and battery..............................................................................................................................84
18 Declaration of conformity......................................................................................................................85
19 Index.....................................................................................................................................................86

Pictograms and symbols
METPOINT®BDL portable 5
1 Pictograms and symbols
General danger symbol (danger, warning, caution)
General note
Observe the installation and operating instructions (on the type plate)
Observe the installation and operating instructions
2 Signal words in accordance with ISO 3864 and ANSI Z 535
Danger!
Imminent hazard
Consequences of non-observance: serious injury or death
Warning!
Potential hazard
Consequences of non-observance: possible serious injury or death
Caution!
Imminent hazard
Consequences of non-observance: possible injury or property damage
Notice!
Potential hazard
Consequences of non-observance: possible injury or property damage
Important!
Additional advice, info, hints
Consequences of non-observance: disadvantages during operation and maintenance, no dan-
ger

Safety instructions
6 METPOINT®BDL portable
3 Safety instructions
Please check whether or not these instructions correspond to the device type.
Please adhere to all advice given in these operating instructions. They include basic infor-
mation which needs to be observed during installation, operation and maintenance. Therefore,
it is vital for the technician and the responsible operator/qualified personnel to read these oper-
ating instructions prior to installation, start-up and maintenance.
The operating instructions must be accessible at all times at the place of application of the
METPOINT®BDL portable. In addition to these operating instructions, local and national regu-
lations need to be observed, where required.
If you have any queries regarding these instructions or the device, please contact the
manufacturer.
Danger!
Supply voltage!
The contact with non-insulated parts carrying supply voltage involves the risk of an electric
shock resulting in severe injuries and death.
Measures:
•Observe all regulations in effect during the electrical installation (e.g. VDE 0100)!
•Maintenance works must only be carried out when the system is de-energized!
•Any electrical works must only be carried out by authorised and skilled personnel.
Danger!
Inadmissible operating parameters!
Under-running or exceeding the limit values involves risks for persons and the material, and
malfunction and service failures may occur.
Measures:
•Make sure that the METPOINT®BDL portable is operated only within the permissible limit values
that are indicated on the type plate.
•Exact compliance with the performance data of the METPOINT®BDL portable in connection with the
case of application.
•Do not exceed the permissible storage and transport temperature.
Further safety advice:
•During installation and operation, the national regulations and safety instructions in force also need to
be observed.
•The METPOINT®BDL portable must not be employed in hazardous areas.
Additional instructions:
•Do not overheat the device!
•The METPOINT®BDL portable must not be disassembled!
Caution!
Malfunctions of the METPOINT®BDL portable
Through incorrect installation and insufficient maintenance, malfunctions of the METPOINT®
BDL portable may occur. These can affect the indications and lead to misinterpretations.

Field of application
METPOINT®BDL portable 7
4 Field of application
The new METPOINT®BDL portable is a universally employable hand-held measuring device for many ap-
plications in the industry like, for example:
►Consumption/flow measurement
►Pressure/vacuum measurement
►Temperature measurement
►Residual moisture/dew point measurement
With the 3.5" graphics display with a touch screen, operation is very easy.
The graphical presentation of the colored measuring curve is unique.
Up to 100 million measured values can be stored with a date and measuring point.
The measured values can be transmitted to the PC via USB stick.
At the freely configurable sensor input, the following sensors can optionally be connected:
Pressure transducers (overpressure and negative pressure)
Consumption sensors, FS 109/211
Temperature sensors PT 100, 4 ... 20 mA
Dew point sensors DP 109/110 and SD 21/23
Electr. power meters
Any external sensors with the following signals: 0 …1/10/30V,
0/4 …20mA,
Pt100, PT1000,
5 Proper use
The METPOINT®BDL portable hand-held measuring device serves for the mobile measured data acquisi-
tion and storage of analogue and digital input signals in non-hazardous areas.
The METPOINT®BDL portable hand-held measuring device is exclusively designed and constructed for the
proper application purpose that is described herein and must only be used correspondingly.
A check in order to ascertain whether or not the device is suitable for the chosen employment must be car-
ried out by the user. It must be ensured that the medium is compatible with the components which come into
contact with it. The technical data listed in the data sheet are binding.
Improper handling or operation outside the technical specifications is impermissible. Claims of any kind on
the basis of improper use are excluded.

Type plate/product identification
8 METPOINT®BDL portable
6 Type plate/product identification
The type plate is on the housing. It includes all the important data regarding the METPOINT®BDL portable
hand-held measuring device which must be communicated to the manufacturer or supplier upon request.
METPOINT® BDL portable
Produktbezeichnung
Supply Voltage:
Versorgungsspannung
Frequency Range:
Frequenzbereich
Degree of Protection:
IP-Schutzart
Ambient Temperature:
Umgebungstemperatur
Weight:
Gewicht
Type:
Interne Artikelnummer (Beispiel)
S/N:
Seriennummer (Beispiel)
Note:
Never remove, damage, or obliterate the type plate!

Storage and transport
METPOINT®BDL portable 9
7 Storage and transport
Despite all due care and attention, transport damage cannot be excluded. Therefore, check the
METPOINT® BDL portable for possible transport damage subsequent to transport and removal of the pack-
aging material. The forwarding agent and BEKO TECHNOLOGIES or the BEKO TECHNOLOGIES agency
shall be informed immediately about any kind of damage.
Warning!
Overheating!
Overheating will destroy the evaluation unit. Observe the permissible storage and transport
temperature, as well as the permissible operating temperature (e.g. protect the measuring
device against direct sunlight).
Warning!
Damage possible!
Damage may occur to the METPOINT®BDL portable through improper transport or storage.
Measures
•The METPOINT® BDL portable must only be transported or stored by authorised and trained skilled
personnel.
•In addition, observe the respectively valid regional provisions and directives.
Caution!
Danger through damaged components!
Do not start-up a damaged METPOINT®BDL portable. Defective components can impair the
operational reliability, falsify the measuring results, and cause further damage.
Store the METPOINT®BDL portable in its original packaging
in a closed, dry, and frost-protected room. The ambient tem-
peratures must not exceed/underrun the values indicated on
the type plate.
Protect the device against atmospheric influences even when
packaged.

Technical data METPOINT® BDL portable
10 METPOINT®BDL portable
8 Technical data METPOINT®BDL portable
Color display
3.5" touch panel, TFT transmissive, graphics, curves, statistics
Interfaces
USB interface
Power supply for sensors
Output voltage: 24 VDC ± 10%
Output current: 120 mA in continuous operation
Current supply
Internally chargeable Li-ion batteries, charging time approximately 4 h
METPOINT®BDL portable continuous operation > 4 h
depending on the power consumption for ext. sensor
Power supply unit
100 –240 VAC/50 –60 Hz, 12VDC –1A
Safety class 2 only for the application in dry rooms
Dimensions
82 x 96 x 245 mm
Housing material
PC/ABS
Weight
450 g
Employment temperature
-20 ... +70 °C measuring-gas temperature
0 ... +50 °C ambient temperature
Storage temperature
-20 … +70°C
Optional
Data logger, memory capacity 2 GB memory card standard, optional
up to 4 GB
EMC
DIN EN 61326

Input signals ext. sensor METPOINT® BDL portable
METPOINT®BDL portable 11
9 Input signals ext. sensor METPOINT®BDL portable
Input signals
Signal current
(0 –20 mA/4 –20 mA)
internal or external
power supply
Measuring range
0 –20 mA/4 –20 mA
Resolution
0.0001 mA
Accuracy
0.003 mA 0.05%
Input resistance
50 
Signal voltage
(0 –1 V)
Measuring range
0 –1 V
Resolution
0.05 mV
Accuracy
0.2 mV 0.05%
Input resistance
100 k
Signal voltage
(0 –10 V/30 V)
Measuring range
0 –10 V/30 V
Resolution
0.5 mV
Accuracy
2 mV 0.05%
Input resistance
1 M
RTD
Pt100
Measuring range
-200 –850°C
Resolution
0.1 °C
Accuracy
0.2°C at -100 … 400 °C
0.3°C (remaining range)
RTD
Pt1000
Measuring range
-200 –850°C
Resolution
0.1°C
Accuracy
0.2 °C at -100 –400°C
0.3 °C (remaining range)
Pulse
Measuring range
Min. pulse duration 100 µS
Frequency 0 –1 kHz
Max. 30 VDC

Installation
12 METPOINT®BDL portable
10 Installation
NOTE!
The plug of the power supply unit (charger) is used as a separator.
This separator must be clearly recognizable and easily accessible by the user. A plug connector
with a CEE7/7 system is necessary.
NOTE!
Only use the included type GE12I12-P1J power supply unit.
10.1 Line cross-sections
For the sensor connections/output signals, the following line cross-section needs to be used:
AWG16 –AWG28, line cross-sections 0.14 –1.5 mm2

Connection diagrams of the different sensor types
METPOINT®BDL portable 13
11 Connection diagrams of the different sensor types
11.1 PIN assignment for the sensor connection
An ODU Medi Snap 8 pin is used as a sensor interface connector –reference: K11M07-P08LFD0-6550
.
These are the available connecting leads from BEKO TECHNOLOGIES GMBH:
ODU connector with open ends: order no. 4028338, cable length 5 m.
ODU connector with an SDI connecting plug: order no. 4028337, cable length 5 m.
Plug and cable configuration:
Connector housing
Plug insert
Collet
Clamping nut
View on welding pins of Medi Snap Connector
Leitungslänge5/10m
1weiss white
2braunbrown
3grün green
4gelb yellow
5grau grey
6rosa pink
7blau blue
8rot red
+ RS485
- RS485
SDI (BEKO-internal data transmission for all the dew point/consumption sen-
sors)
ANALOGUE IN + (current signal and voltage signal)
ANALOGUE IN –(current signal and voltage signal)
POWER SUPPLY 500 µA
+Uv, 24V DC power supply for sensors
-Uv, GND sensor
White
Brown
Green
Yellow
Grey
Pink
Blue
Red

Connection diagrams of the different sensor types
14 METPOINT®BDL portable
DP series: dew point sensors
FS series: consumption sensors
SD series: pressure dew point transmitters
11.2 Connection dew point sensors DP series
METPOINT®BDL portable
DP109
The digital data transmission between the METPOINT®BDL portable
and the DP 109 dew point sensor is implemented via the SDI bus
line.
11.3 Connection dew point sensors DP/FS series
METPOINT®BDL portable
DP 110
FS 109
FS 211
The digital data transmission between the METPOINT®BDL port-
able and the DP110 and FS109/211 sensors is implemented via
the SDI bus line.
11.4 Connection dew point sensors SD series
METPOINT®BDL portable
SD23
The digital data transmission between the METPOINT®
BDL portable and the SD23 sensor is implemented via the RS485
interface
Grün
Blau
Rot
Blau
Rot
Grün

Connection diagrams of the different sensor types
METPOINT®BDL portable 15
11.5 Connection pulse sensors
Signal level 0:
low = 0 –0.7 VDC
Signal level 1:
high = 2.5 –30 VDC
t = 400 µs
max. frequency
(pulse duty factor 1:1) = 1000
Hz
Input resistance:
min. 100 kOhm
Externally required
R = 4K7
Caution:
Counts one unit of consump-
tion when switching on the
DP510
Externally required
R = 4K7
This is impossible!
Gelb
Grau
Grau
Gelb
Blau
Rot
Grau
Gelb
Blau
Rot
Gelb
Grau

Connection diagrams of the different sensor types
16 METPOINT®BDL portable
11.6 Analogue 2-wire, 3-wire, and 4-wire current signal
Sensors with 4 - 20 mA output in 2-wire technology
METPOINT®BDL portable
Sensors with a 0/4 –20 mA output in 3-wire technology
.
METPOINT®BDL portable
Sensors with a 0/4 –20 mA output in 4-wire technology
METPOINT®BDL portable
Gelb
Gelb
Gelb
Grau
Blau
Blau
Blau
Rot
Rot

Connection diagrams of the different sensor types
METPOINT®BDL portable 17
11.7 3 and 4-wire voltage supply 0 - 1/10/30 VDC
Sensors with a voltage output in 3-wire technology
Sensors with a voltage output in 4-wire technology
Gelb
Gelb
Grau
Blau
Blau
Rot
Rot

Connection diagrams of the different sensor types
18 METPOINT®BDL portable
11.8 2, 3, and 4-wire terminal assignment of PT100/PT1000/KTY81
2-wire PT100/PT1000/KTY81
3-wire PT100/PT1000/KTY81
4-wire PT100/ 1000/KTY81
11.9 Assignment with RS485
Sensor with an RS485 interface
Gelb
Gelb
Grau
Grau
Pink
Pink
Rot
Rot
Blau
Weiss
Braun
Rot
Gelb
Pink
Rot

Operation METPOINT® BDL portable
METPOINT®BDL portable 19
12 Operation METPOINT®BDL portable
The operation of the METPOINT®BDL portable is implemented by means of a membrane keyboard and
touch panel.
12.1 Membrane keyboard
12.1.1 On and off key
Switching on or off by pressing the button and holding it.
12.1.2 Brightness keys
With the and buttons, the brightness of the display can be modified.
12.1.3 Screenshot button
By pressing the screenshot button, the current screen display is stored.
An SD card or USB stick serve as a storage medium.
12.1.3.1 Storing a screenshot
Here, the storage location USB stick or SD card can
be selected.
The pictures are stored in a directory per day and
are consecutively numbered.
Directory designation; DJJMMTT
D=fix(for the date)
JJ = Year
MM= Month
TT= Day
Path: DEV0003/PI500/Bitmap
Example: first picture 10 September 2013
\\DEV0003/BDL/Bitmap/D130910/B00000.bmp

Operation METPOINT® BDL portable
20 METPOINT®BDL portable
12.1.3.2 Exporting screenshots
The screenshots that are stored on the SD card can be exported to a USB stick.
Main menu Export data
Main menu Export data Export screenshots
Ausgewählte Dateien: 5
Tot. Size(Kbyte): 83
Main menu Export data Export screenshots Selection
With Export screenshots, the stored screen-
shots can be transmitted to a USB stick.
By means of the Selection buttons, a period of
time between start and end can be set. The
stored bitmaps, which are within this period,
are exported.
The selected date is always highlighted in
green, and the date figures of the Sundays
are red, as is the case in a calendar.
On days on which bitmaps were recorded, the
date figures are optically raised.
