Belair W-01L User manual

W-01L
1
DISCLAIMER
• Two people are recommended for the assembly of this product.
• Use hardware provided and tools recommended to avoid any product faults.
• Always assemble product on a clean soft surface to avoid scratching.
PARTS INCLUDED
HARDWARE INCLUDED
TOOLS REQUIRED
33X 33X 27X 4X 12X 3X2X 1X
#2 Phillips Screwdriver #2 Robertson screwdriver
ASSEMBLY INSTRUCTIONS
A B C D E
F G H IJ

W-01L
2
STEP 1
Ensure all pins and cams are inserted
in parts before assembling. Start with
desk assembly. Attach desk top A and
left gable C as shown. Fasten pins and
cams.
STEP 2
Lay desk back B flat and lower top and
gable onto back as shown. Fasten pins
and cams. Flip desk right side up and
proceed to return assembly.
STEP 3
Attach return top G and right gable E as
shown. Fasten pins and cams.
A
C
B
G
E

W-01L
3
STEP 4
Connect small support gable H to
return top. Fasten pins and cams.
STEP 5
Lay return back D flat and lower top
and gables onto back. Fasten pins and
cams and flip unit right side up.
STEP 6
To connect the desk and return insert
green lockdowels into the edge of the
desk top. Line lockdowels with the slots
in the return back. Slide the return back
into the desk back. Fasten pins and
cams.
H
D

W-01L
4
STEP 7
Attach transaction top F to desk back.
Fasten pins and cams.
STEP 8
Connect waterfall top I and back J as
shown. Fasten pins and cams.
STEP 9
Place waterfall on center of transaction
top and secure with screws through
large back.
F
J
I

W-01L
5
STEP 10
Secure desk return top to desk top with
connecting flat brackets as shown.
STEP 11
Use cover caps to cover any visible
cams and screws.

W-01L
1
DISCLAIMER
• Two people are recommended for the assembly of this product.
• Use hardware provided and tools recommended to avoid any product faults.
• Always assemble product on a clean soft surface to avoid scratching.
PARTS INCLUDED
HARDWARE INCLUDED
TOOLS REQUIRED
33X 33X 27X 4X 12X 3X2X 1X
#2 Phillips Screwdriver #2 Robertson screwdriver
ASSEMBLY INSTRUCTIONS
A B C D E
F G H IJ

W-01L
2
STEP 1
Ensure all pins and cams are inserted
in parts before assembling. Start with
desk assembly. Attach desk top A and
right gable C as shown. Fasten pins
and cams.
STEP 2
Lay desk back B flat and lower top and
gable onto back as shown. Fasten pins
and cams. Flip desk right side up and
proceed to return assembly.
STEP 3
Attach return top G and left gable E as
shown. Fasten pins and cams.
A
C
B
G
E

W-01L
3
STEP 4
Connect small support gable H to
return top. Fasten pins and cams.
STEP 5
Lay return back D flat and lower top
and gables onto back. Fasten pins and
cams and flip unit right side up.
STEP 6
To connect the desk and return insert
green lockdowels into the edge of the
desk top. Line lockdowels with the slots
in the return back. Slide the return back
into the desk back. Fasten pins and
cams.
H
D

W-01L
4
STEP 7
Attach transaction top F to desk back.
Fasten pins and cams.
STEP 8
Connect waterfall top I and back J as
shown. Fasten pins and cams.
STEP 9
Place waterfall on center of transaction
top and secure with screws through
large back.
F
J
I

W-01L
5
STEP 10
Secure return top to desk top with
connecting flat brackets as shown.
STEP 11
Use cover caps to cover any visible
cams and screws.
