Sauder Edge Water 414856 User manual

PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
Made in the USA
Archbold, OH
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Lot #: 375077 07 / 14 / 15
Date Purchased: ____________________
English.................... Page 1-19
Français...............Pages 20-22
Espanol.............Páginas 23-25
414856
Lift-Top Coffee Table
Edge Water Collection

ASSEMBLY TOOLS REQUIRED
Hammer
No. 2 Phillips Screwdriver
Tip Shown Actual Size
ADULT ASSEMBLY REQUIRED
TABLE OF CONTENTS
Part Identification.......................3
Hardware Identification .............4
Assembly Steps....................5-19
Français..............................20-22
Espanol...............................23-25
Safety .......................................26
Warranty...................................27
Page 2 www.sauder.com/services 414856
Adjustable Wrench

PART IDENTIFICATION: While not all parts are labeled, some of the parts will have a label or an inked
letter on the edge to help distinguish similar parts from each other. Use this PART IDENTIFICATION to help
identify similar parts.
A RIGHT END 1
B LEFT END 1
C UPRIGHT 2
D TOP 1
E BOTTOM 1
F SHELF 1
G PANEL 2
H2 RIGHT FRONT/LEFT REAR LEG 2
I2 LEFT FRONT/RIGHT REAR LEG 2
J STRETCHER 1
K FOOT SPACER 2
L SKIRT 2
M FOOT 4
Page 3
www.sauder.com/services414856
A
B
C
D
E
F
G
H2
I2
J
K
L
H2
I2
L
G
C
M
M
M
M

HARDWARE IDENTIFICATION
Screws are shown actual size. You may receive extra hardware with your unit.
Page 4 www.sauder.com/services 414856
PLASTIC FOOT - 2
23E
23M LIFT TABLE
MECHANISM SET - 1
SUPPORT BRACKET - 2
37G
HIDDEN CAM - 36
1F CAM DOWEL - 14 2F
BUMPER - 6
2M
BLACK 1-7/8" FLAT HEAD SCREW - 4
2S
BLACK 1-9/16" FLAT HEAD SCREW - 4
30S
BLACK 9/16" LARGE HEAD SCREW - 18
1S
CAM COVER - 18
12P
BROWN 1" FLAT HEAD SCREW - 4
12S
BLACK 3/4” MACHINE SCREW - 4
92S BLACK 1-1/4" MACHINE SCREW - 4 93S
NUT - 8
24M
WASHER - 8
13M
CAM SCREW - 22
20F
METAL PIN - 4
1R

Look for this icon. It means a video
assembly tip is available at:
www.sauder.com/services/tips
1
1
S
t
e
p
Page 5
www.sauder.com/services414856
E
F
Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
Push thirty-six HIDDEN CAMS (1F) into the ENDS (A and B), BOTTOM (E), SHELF (F), PANELS (G), and SKIRTS (L). Then,
insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM in the short edges of the BOTTOM (E) and SHELF (F).
Do not tighten the HIDDEN CAMS in this step.
Do not insert CAM DOWELS into these edges.
Arrow
(14 used)
(36 used) 1F
2F
Arrow
1F
A
B
G
L
L
G
Arrow
1F
Arrow
1F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow

Page 6 www.sauder.com/services 414856
2
2
S
t
e
p
Turn twenty-two CAM SCREWS (20F) into the LEGS (H2 and I2) and SKIRTS (L).
20F
20F
L
L
(22 used)
H2
I2
H2
I2

Page 7
www.sauder.com/services414856
3
3
S
t
e
p
A
B
Fasten the LEGS (H2 and I2) to the ENDS (A and B). Tighten eight HIDDEN CAMS.
Fasten four FEET (M) to the LEGS (H2 and I2). Use four BLACK 1-9/16" FLAT HEAD SCREWS (30S).
M
M
M
MBLACK 1-9/16" FLAT HEAD SCREW
(4 used in this step)
Surface with
HIDDEN CAMS Surface with
HIDDEN CAMS
These edges
should be even.
These edges
should be even.
Smaller
hole
Smaller
hole
Smaller
hole
Smaller
hole
I2
I2
H2
H2
30S

Page 8 www.sauder.com/services 414856
4
4
S
t
e
p
F
G
G
Caution
Risk of damage or
injury. Hidden Cams
must be completely
tightened. Hidden
Cams that are not
completely tightened
may loosen, and parts
may separate.
To completely tighten:
Start Tighten
Arrow
Arrow
Maximum
210 degrees
Minimum
190 degrees
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Fasten the SHELF (F) to the PANELS (G). Tighten six HIDDEN CAMS.

Page 9
www.sauder.com/services414856
5
5
S
t
e
p
E
L
L
Surface with
HIDDEN CAMS
Surface with CAM SCREWS
Surface without CAM SCREWS
Bottom edges
should be even.
Fasten the SKIRTS (L) to the BOTTOM (E). Tighten six HIDDEN CAMS.
Flat edge
Flat edge

Page 10 www.sauder.com/services 414856
6
6
S
t
e
p
F
G
G
B
Fasten the LEFT END (B) to the SHELF (F) and PANELS (G). Tighten four HIDDEN CAMS.
Maximum
210 degrees
Minimum
190 degrees
Arrow
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
These holes
must be here.
