Technical data sheet H6..SP
Globe valve, partial pressure relief,
2-way, Flange, PN 16
• Forclosed(hightemperature)hot
waterandsteamsystemsinthenon-
critical range
• Forwater-sidemodulatingcontrolof
air-handlingandheatingsystems
Type overview
Type DN
[ ]
kvs
[ m³/h]
Stroke
[ mm]
PN
[ ]
Svmin.
[ ]
H640SP 40 25 15 16 100
H650SP 50 40 15 16 100
H664SP 65 58 18 16 100
H679SP 80 90 18 16 100
H6100SP 100 145 30 16 100
H6125SP 125 220 40 16 100
H6150SP 150 320 40 16 100
Technical data
Functional data Media Hot water and steam ( ∆p/P1 <0.4), water with
max. 50% volume of glycol
Medium temperature 5...150°C
Medium temperature note 120°C up to 1600 kPa
150°C up to 1400 kPa
Permissible pressure ps 1600 kPa
Flow characteristic equal percentage (VDI/VDE 2173) n(gl) = 3,
optimised in the opening range
Leakage rate max. 0.05% of the kvs value
Pipe connectors Flange according to ISO 7005-2 (PN 16)
Closing point Bottom (▼)
Installation position Upright to horizontal (in relation to the stem)
Maintenance Maintenance-free
Materials Housing EN-JL1040 (GG25), with protective paint
Closing element Stainless steel
Stem Stainless steel
Stem seal PFTE V-ring
Seat Stainless steel
Safety notes
!
• The valve has been designed for use in stationary heating, ventilation and air-
conditioning systems and is not allowed to be used outside the specified field of
application, especially in aircraft or in any other airborne means of transport.
• Only authorised specialists may carry out installation. All applicable legal or
institutional installation regulations must be complied during installation.
• The valve does not contain any parts that can be replaced or repaired by the user.
• The valve may not be disposed of as household refuse. All locally valid regulations
and requirements must be observed.
• When determining the flow rate characteristic of controlled devices, the recognised
directives must be observed.
www.belimo.eu H6..SP • en-gb • 2014-11-27 • subject to changes 1

Mode of operation The globe valve is adjusted by a globe valve actuator. The actuators are controlled
by a commercially available modulating or 3-point control system and move the valve
cone, which acts as a mixing device, to the opening position dictated by the positioning
signal. High closing pressures are permitted with as a result of both the partial
pressure relieving stem and the overflow channels in the valve.
Flow characteristic An equal percentage flow characteristic is produced by the profile of the valve cone.
Installation notes
Recommendedinstallationpositions The globe valve may be mounted upright to horizontal. It is not permissible to mount
the globe valves with the spindle pointing downwards.
90
°9
0°
Waterqualityrequirements The water quality requirements specified in VDI 2035 must be adhered to.
Belimo valves are regulating devices. For the valves to function correctly in the long
term, they must be kept free from particle debris (e.g. welding beads during installation
work).
The installation of suitable strainer is recommended.
Maintenance Globe valves and globe valve actuators are maintenance-free.
Before any kind of service work is carried out on the actuator, it is essential to isolate
the globe valve actuator from the power supply (by disconnecting the electrical cables
if necessary). Any pumps in the part of the piping system concerned must also be
switched off and the appropriate shut-off valves closed (allow everything to cool down
first if necessary and reduce the system pressure to ambient pressure level).
The system must not be returned to service until the globe valve and the globe valve
actuator have been mounted properly in accordance with the instructions and the
pipes have been refilled in the proper manner.
Flow direction The direction of flow, specified by an arrow on the housing, is to be complied with,
since otherwise the valve could become damaged.
AAB AAB
H6..SP Globe valve, partial pressure relief, 2-way, Flange, PN 16
Product features
www.belimo.eu
H6..SP • en-gb • 2014-11-27 • subject to changes
2

Dimensionaldrawings
L
H
min. X
C
min. Y
D
K
d
X/Y: Minimum distance with respect to the valve centre.
The actuator dimensions can be found on the respective actuator data sheet.
Type DN
[ ]
L
[ mm]
H
[ mm]
C
[ mm]
D
[ mm]
d
[ mm]
K
[ mm]
X
[ mm]
Y
[ mm]
Weight approx.
[ kg]
H640SP 40 200 136 18 150 4 x 18 110 390 100 9.6
H650SP 50 230 142 20 165 4 x 18 125 390 100 12.3
H664SP 65 290 155 20 185 4 x 18 145 400 100 17.1
H679SP 80 310 173 22 200 8 x 18 160 420 150 23
H6100SP 100 350 193 24 220 8 x 18 180 540 150 36
H6125SP 125 400 245 26 250 8 x 18 210 600 150 47
H6150SP 150 480 306 26 285 8 x 22 240 660 150 65
Furtherdocumentation
• Overview Valve-actuator combinations
• Data sheets for globe valve actuators
• Installation instructions for valves and/or globe valve actuators
• Notes for project planning 2-way and 3-way globe valves
H6..SP Globe valve, partial pressure relief, 2-way, Flange, PN 16
Dimensions/Weight
www.belimo.eu H6..SP • en-gb • 2014-11-27 • subject to changes 3

71557-00001.A
90
°9
0°
AAB
AAB
H6..S(P)

ps <1600 kPa (PN16)
t= +5... +120°C
ps <1400 kPa (PN16)
t= +121... +150°C
H6..S H6..SP LV..A..
500N
NV..A..
1000N
SV..A..
1500N
AV..A..
2000N
EV..A
2500N
RV..A
4500N
DN Hub / Stroke
[mm]
AAB AAB
∆ps
[kPa]
∆pmax
[kPa]
∆ps
[kPa]
∆pmax
[kPa]
∆ps
[kPa]
∆pmax
[kPa]
∆ps
[kPa]
∆pmax
[kPa]
∆ps
[kPa]
∆pmax
[kPa]
∆ps
[kPa]
∆pmax
[kPa]
L
[mm]
H
[mm]
D
[mm]
K
[mm]
d
[mm]
C
[mm]
15 15 H610S ... 11S 1600 1000 1600 1000 1600 1000 130 118 95 65 4 x 14 14
15 15 H612S ... 15S 800 800 1600 1000 1600 1000 130 118 95 65 4 x 14 14
20 15 H619S ... 20S 800 800 1600 1000 1600 1600 150 118 105 75 4 x 14 16
25 15 H624S ... 25S 450 450 1300 1000 1600 1000 160 126 115 85 4 x 14 16
32 15 H632S 300 300 950 950 1550 1000 180 126 140 100 4 x 18 18
40 15 H640S 140 140 500 500 850 850 200 133 150 110 4 x 18 18
40 15 H640SP 1600 1000 1600 1000 200 136 150 110 4 x 18 18
50 15 H650S 60 60 300 300 500 500 230 139 165 125 4 x 18 20
50 15 H650SP 1600 1000 1600 1000 230 142 165 125 4 x 18 20
65 18 H664S 130 130 250 250 290 152 185 145 4 x 18 20
65 18 H664SP 1600 1000 1600 1000 290 155 185 145 4 x 18 20
65 30 H665S 400 400 550 550 1100 1000 290 155 185 145 4 x 18 20
80 18 H679SP 1600 1000 1600 1000 310 173 200 160 8 x 18 22
80 30 H680S 250 250 350 350 700 700 310 170 200 160 8 x 18 22
100 30 H6100S 150 150 200 200 450 450 350 190 220 180 8 x 18 24
100 30 H6100SP 600 600 600 600 600 600 350 193 220 180 8 x 18 24
125 40 H6125S 110 110 250 250 400 228 250 210 8 x 18 26
125 40 H6125SP 600 600 600 600 400 245 250 210 8 x 18 26
150 40 H6150S 70 70 180 180 480 288 285 240 8 x 22 26
150 40 H6150SP 600 600 600 600 480 306 285 240 8 x 22 26
H6..S(P) L
H
min. X
C
min. Y
D
K
d
