Berker Radio Push button 1gang quicklink User manual

Page 1/12
Radio Push button
6W-5821 08-2012
Radio Push button 1gang quicklink
Order number 8514 51 ..
Radio Push button 2gang quicklink
Order number 8514 61 ..
Radio Push button 4gang quicklink
Order number 8564 81 ..
Operating instructions
1. Safety instructions
Electrical equipment may only be installed and assembled by a qualied electrician in
accordance with the relevant installation standards, regulations, directives and safety
and accident prevention directives of the country.
Failure to comply with these instructions may result in damage to the device, re or other
hazards.
The radio transmission is not suitable for safety or alarm applications.
These instructions are an integral component of the product and must be retained by the
end user.
2. Design and layout of the device
(1)
(2)
(3)
(4)
(5)
(6)
(7)
Figure 1: Design and layout of the device
(1) Insert (see "Accessories", not in scope of delivery)
(2) Frame (not within scope of delivery)
(3) Application module 1, 2 or 4gang
(4) Screw for dismantling protection (not for design lines R.1/R.3)
(5) Button design cover
(6) 2gang button or 4gang button design cover
(7) Interface between insert/application module

Page 2/12
Radio Push button
6W-5821 08-2012
3. Function
System information
This device is a product of the quicklink system, in which installation devices communicate via
radio signals.
Quicklink stands for a conguration mode in which the function-related connection between
transmitters and receivers is set on the device through buttons and displays without further
tools.
All devices congurable by quicklink can be operated together in one system.
Correct use
–For operation and remote control on a switch insert, on a ush-mounted dimmer or on a
power
supply for RF application modules
–The device has been laid out for smaller applications in which a maximum of 20 devices
are allocated
–Only suitable for use in indoor areas with no drip and no spray water

The quicklink conguration of the devices must only be carried out by qualied electricians.
Product characteristics
–Functions for remote control, scenes, control switches via radio signals
–LED display of insert/application module compatibility
–Saving of switch-on brightness-level if operated on a ush-mounted dimmer
4. Operation
Operating concept
The operation of the top or bottom push-button operation area is validated differently for each
button. Simultaneous pressing of top and bottom push-button operation areas triggers special
functions.
Operation on a switch insert
Load status Operation button, factory setting Switch insert
OFF Press top or bottom Switch ON load.
ON Press top or bottom Switch OFF load.
Table 1
Operation on a ush-mounted dimmer
Dimming status Operation button, factory setting Flush-mounted dimmer
OFF Short press on top or bottom Switch ON to saved switch-on brightness-level.
ON Short press on top or bottom Switching OFF.
ON Press top and bottom simultaneously
> 5 s
Save brightness as switch-on brightness-level.
As conrmation, the light switches OFF briey and
ON again.

In delivery condition, the maximum brightness is
saved as switch-on brightness.
ON/OFF long press on top Dimming to maximum brightness-level
ON long press on bottom Dimming to minimum brightness-level
OFF long press on bottom Switching on with minimum brightness-level
Table 2

Page 3/12
Radio Push button
6W-5821 08-2012
Operation on a power supply for RF application modules
The push-buttons are freely congurable; operation is dependent on the conguration (Table 7).
Setting the load
If the dimming and switching performance of loads is unsatisfactory after start-up, especially
when circuited to energy-saving lamps and 230 V LED lamps, a load setting must be carried out
for universal switch inserts or universal touch dimmers.
Switch off load.
Press button top and bottom area simultaneously for more than 10 seconds.
The connected load blinks once. The device is in selection mode.

If there is no further operation within the next 10 seconds, the insert swiches to switching/
dimming operation.
Briey press the button repeatedly to activate the desired setting mode (Table 3).
The load setting is executed.
Briey
press the
button
Setting mode Conrmation of the
load setting Notes
1 x Load ne-setting Load blinks 1 x after
approx. 30 s and changes
to switching/dimming ope-
ration
Not suitable for ohmic loads (e.g. incandescent,
HV halogen lamps); use factory load setting.
If the load ne-setting does not bring any
improvement for energy-saving lamps or 230 V
LED lamps, select the energy-saving lamp ne-
setting or 230 V LED lamp universal setting.
The load ne-setting is not available on 2gang
universal inserts.
2 x Factory load setting Load blinks 2 x after
approx. 6 s and changes
to switching/dimming ope-
ration
3 x Energy-saving lamp
ne-setting in phase
cut-on
Load blinks 3 x after
approx. 30 s and changes
to switching/dimming ope-
ration
Energy-saving lamps are switched ON at bright-
ness level of at least 50 % brightness in order to
ensure an ignition process.
4 x 230 V LED lamp
universal setting in
phase cut-off
Load blinks 4 x after
approx. 5 s and changes
to switching/dimming ope-
ration
The universal setting contains standard values
which enable the operation of typical dimmable
230 V LED lamps.
For all setting modes Load blinks 5 x The selected setting mode is not supported by
the insert.
Table 3: Load setting mode
Operation via extension unit, push-button, NO contact
Dimming status Operation push-
button
Switch insert Flush-mounted dimmer
OFF Press < 0.4 s Switch ON Switch ON with saved switch-on brightness-level.
ON Press < 0.4 s Switch OFF Switch off
ON Press > 0.4 s Switch OFF Dimming to minimum/maximum brightness-level
with alternating direction
OFF Press > 0.4 s Switch ON Dimming from minimum to maximum brightness-level
Table 4

The switch-on brightness-level cannot be saved on an extension unit push-button.

Page 4/12
Radio Push button
6W-5821 08-2012
5. Information for electricians
Overview of the operating elements beneath the design cover
(9)
(8)
(10)
Figure 2a: Operating elements of the 1gang radio button
(10)
(11)
(9)
(8)
Figure 2b: Operating elements of the 2 and 4gang radio button
(8) Press-activation point of the push-button operation area
(9) fct button with fct LED
(10) cfg button with cfg LED
(11) fct2 button with fct2 LED
5.1 Installation
Selecting installation location
A minimum distance between the transmitter and corresponding receiver of about 1 m must be
maintained.
A minimum distance to electronic devices which emit high frequency signals such as computers,
electronic transformers or microwave devices of approx. 0.5 m must be maintained.
Mounting on or close to metal surfaces may cause impairment of the function.
Take material penetration into account. The range of the system can be optimised by selecting
the best possible installation site:
Material Degree of material penetration
Wood, plaster, plasterboard, uncoated glass approx. 90 %
Brick, press boards approx. 70 %
Reinforced concrete, underoor heating approx. 30 %
Metal, metal grids, aluminium laminates, coated glass approx. 10 %
Rain, snow approx. 1 ... 40 %
Table 5: Material penetration

Page 5/12
Radio Push button
6W-5821 08-2012
Assembly of the device (Figure 1)
The insert is installed (see operating instructions for the insert).
Attach application module (3) together with frame (2) to a suitable insert (1) and establish
a connection between the insert and the application and power module (7) via the interface
between application and power module.
As soon as voltage is supplied to the button, the cfg LED (Figure 2, 10) indicates whether
the button and the insert are compatible with each other:
cfg LED display Meaning
LED blinks in green colour
for 5 s Compatible
LED blinks red for 5 s Not compatible
LED blinks orange for 5 s Compatible, but not con gured to each other. For a new con guration, the
application module must be reset to factory settings.
If available,  x dismantling protection with screw (4).
Click design cover (5 or 6) into place on application module (3).

If a con guration needs to be made or settings need to be changed, only attach the design
cover afterwards.
Insert/application module combinations and operation in factory setting
Depending on the insert used, the radio button in factory setting has the following function for
local operation.
Radio button
1gang
Radio button
2gang
Radio button
4gang
Switch insert 1gang -- --
Switch insert 2gang --
Flush-mounted
dimmer 1gang
-- --
Flush-mounted
dimmer 2gang
--
Power supply
Switching (see operation on a switch insert)
Dimming (see operation on a  ush-mounted dimmer)
-- Not to be combined
Transmitter command freely con gurable
(see con guration of radio button as transmitter)
Table 6: Button operation in factory setting

Page 6/12
Radio Push button
6W-5821 08-2012
5.2 Radio con guration quicklink
The radio con guration sets the functional connection between commanding (transmitters)
and function-executing (receivers) radio components. In so far wireless e.g. central unit, group,
extension unit and time controls can be realised.
The following can be con gured:
–The local operation of the load connected to the insert
–Radio commands to control other receivers
–Functions which are executed when the radio commands are received

The top and bottom push-button operation area can be con gured differently.

For con guration by means of Hager connection device TX100 or ETS, additional functions
are available (see operating instructions for TX100 or application description for ETS).
Con guration of radio button as a receiver
Con guration to control the load connected to the insert:
–via reception of a radio command
–via the local operation
fct LED
display
Con gurable
functions
Function resulting from transmitter operation,
Notes
On switch insert On  ush-mounted dimmer
ON/OFF ON/OFF,
dimming UP/DOWN
Short press on push-button: Switching ON/OFF
Long press on push-button: Dimming, reverse dimming
direction per actuation
ON ON,
dimming UP
Short press on push-button: Switching ON
Push and hold button: Dimming UP to maximum
brightness-level
OFF OFF,
dimming DOWN
Short press on push-button: Switching OFF
Short press on push-button: Dimming DOWN to
minimum brightness-level
1Scene 1 Receiver is allocated to a scene due to the con guration
of the function.eceivers are allocated to a scene due to
the con guration of the function.
Short press on button: calling up the saved state of the
connected load for the scene
2Scene 2
Timer Switching ON for the set switch-on time
NO contact
(contact duration)
Switching ON when the switching contact is closed
Switching OFF when the switching contact is opened
Delete No function
Assignment to transmitter is deleted
Table 7: Con gurable functions

Local operation is a function that is pre-con gured at the factory and can be changed.
As an example, the con guration of a wall-transmitter and the radio button as receiver is
described down below.
The button design cover is not attached.

Page 7/12
Radio Push button
6W-5821 08-2012
Handling step Result
Start conguration
Short press on cfg button on the wall transmitter.

If there is no further activation, the conguration is
automatically ended after 10 minutes.
The cfg LEDs on the wall-transmitter and the radio
button light up in red colour.
All receivers within radio range also indicate the
conguration mode.
Select transmitter button
Short press on press-activation point on the wall-
transmitter which should activate the function.
The cfg LED on the wall transmitter blinks for 1
second.
If congured already, the fct LED of the radio button
indicates the currently congured function.
Select function at receiver
Repeated short press on fct button on the radio button
until the desired function is displayed (Table 7).
After each activation, the fct LED indicates the
function.

If the transmitter button has already been
congured with a function in a different receiver
and/or the congured function is part of a group
control, only this function can be congured. To
change a function, the existing conguration needs
to be deleted and the new one congured.
Conrming function on receiver
To conrm, keep the fct button pressed for more than
than 2 seconds.
The cfg LED blinks during the saving process (approx.
5 s). The fct LED conrms the function selection by
displaying the corresponding colour.

A quick blinking of the cfg LED indicates a
combination that is not possible or an error.
Finish conguration
Short press on cfg button on the wall transmitter again.
> 2 s
The cfg LEDs on the wall-transmitter, the radio button
and all receivers within radio range go out. The
function is congured.
Table 8: Conguration of the function for the radio button

Page 8/12
Radio Push button
6W-5821 08-2012
Con guration of radio button as a transmitter
If the radio button is operated as a transmitter, it can support the following functions for the
receivers. The details of the function can vary depending on the receiver being used:
- ON/OFF, single-surface operation
- ON
- OFF
- ON/OFF, dimming UP/DOWN, single-surface operation
- ON/OFF dimming UP
- ON/OFF dimming DOWN
1 - Scene 1
2 - Scene 2
- Timer
- NO contact (contact duration)
- Move UP, stop
- Move DOWN, stop
Down below there is an illustration of the con guration of the radio push-button with receivers
for which the supported displays occur via the cfg LED and fct LED. Differing con guration
displays, such as for receivers with display, are to be taken from the receiver operating
instructions.
Handling step Result
Start con guration
Short press on cfg button on the radio button.

If there is no further operation, the con guration is
automatically ended after 10 minutes.
The cfg LEDs on the radio button and the receivers
within radio range light up red colour.
5 7 8321 4 6
L N S1
fct
cfg
cfg fct
on
off
cfg fct
L N N
LED
LED
Select transmitter button
Press the button of the push-button operation area for
which a command should be con gured.
The cfg LED on the radio button blinks for 1 second.
Afterwards the radio button (transmitter) and receiver
are in con guration mode and the cfg LEDs light up.
If already con gured, the fct LED of the receiver
indicates the current function con gured with the
button.
Select function at receiver
Press the fct input on the receiver again brie y to
select the desired function (see the receiver operating
instructions).
cfg fct
on
off
5 7 8321 4 6
L N S1
fct
cfg
After each actuation, the fct LED indicates a function.

If the channel button has already been con gured
with a function in a different receiver and/or the
con gured function is part of a group control,
only this function can be con gured. To change
a function, the existing con guration needs to be
deleted and the new one con gured.
Con rming function on receiver
To save the allocation of command and function, hold the
fct input on the receiver pressed longer than 2 seconds.
The cfg LED blinks. After a successful saving, the fct
LED signals the saved function.

A quick blinking of the cfg LED indicates a
combination that is not possible or an error.

Page 9/12
Radio Push button
6W-5821 08-2012
Finish conguration
Short press on cfg button on the radio button.
The cfg LEDs on the radio button and all receivers
within radio range go out. The radio command for the
radio button has been congured.
Table 9: Conguration of radio button as a transmitter
Deleting a conguration
To delete a congured receiver or the local operation, execute the conguration again.
Start conguration (see conguration of radio button as a receiver).
Select transmitter button.
Select function on receiver: Select the function Delete on the receiver and conrm function
on the receiver.
Finish conguration: Short press on cfg button on the transmitter.
Conguration of group functions
By means of a group function, one transmitter controls several receivers. To do so, the same
function must be congured on all receivers.
Start conguration (see conguration of radio button as a receiver).
Select transmitter button.
Select function on receiver: Select the group function as described above on each receiver
to be integrated and conrm function on the receiver.
Finish conguration: Short press on cfg button on the transmitter.
Conguration of scenes
Individual settings for lighting and the position of blinds can be combined into scenes. Two
different scenes can be created via quicklink and called up by pressing a button on the
transmitter. A scene is created by conguring a push-button operation area of a transmitter
(radio command) in the corresponding receivers with the scene function (Table 7).
Start conguration.
Select transmitter button: Select the button for the scene command.
Select function on receiver:Select the scene function as described above on each receiver
to be integrated and conrm function on the receiver.
Finish conguration: Short press on cfg button on the transmitter.
Changing/saving scenes
Switching, dimming and blind statuses of the receivers in a scene can be changed and saved.
The load status can be congured locally or by remote control on the receivers integrated
into the scene, e.g. light 1 = 60 % brightness level, light 2 = 40 % brightness level, blind
down.
Keep transmitter button belonging to the congured scene command pressed for more than
5 seconds.
A brief status changeover of the receiver signals the successful saving of the scene.
Locking/unlocking scene changes
To prevent unwanted changes to a scene, the changing of the scene can be locked.
Start conguration.
Select transmitter button: Select the button for the scene command.

Page 10/12
Radio Push button
6W-5821 08-2012
Select function on receiver: When the function Scene 1 or Scene 2 is indicated by the fct
LED blinking in green colour, keep the fct button on the receiver pressed for more than 5
seconds until the cfg LED blinks briey.
Then the fct LED indicates the currently congured status by blinking:
1 x blinking: Possible to change and save scene
2 x blinking: Changing the scene is locked.
Press fct button and select the desired setting.
The setting changes each time the button is pressed.
To accept the selected setting time, keep the fct button pressed for more than 2 seconds.
Finish conguration: Short press on cfg button on the transmitter.
Setting of switch-on time for function "timer"
In order to realise the function Timer, the switch-on time can be set on the receiver in stages.
The factory setting is 3 min.
Start conguration.
Select transmitter button: Select button with timer.
Select function on receiver:If the function Timer is indicated by the fct LED blinking red
(Table 7), keep pressed the fct button on the receiver for more than 5 seconds until the cfg
LED blinks briey.
The blinking fct LED indicates the currently set switch-on time - 5 x for factory setting
(Table 10).
Press fct button.
Each short press on fct button increases the switch-on time by one step.

During the setting, the fct LED indicates the switch-on time (Table 10)
for orientation.
To accept the selected switch-on time, keep pressed the fct button for longer than 2 se-
conds.
Finish conguration: Short press on cfg button on the transmitter.
x-times ashing
of the fct LED
Switch-on time
1 1 s
2 30 s
3 1 min
4 2 min
5 3 min
6 5 min
7 15 min
8 30 min
9 1 h
10 3 h
Table 10: Congurable switch-on times
Resetting the radio button to factory settings
The device is not in conguration mode.
Keep the cfg button pressed for more than 10 seconds until the cfg LED changes from a
red lighting to blinking.
Release the cfg button.
The cfg LED blinks red rapidly. The device re-initialises itself. Meanwhile the cfg LED lights
up red. After that the LED goes out and blinks 5 x to indicate the compatibility. The reset is
made. The process lasts about 20 s.

Page 11/12
Radio Push button
6W-5821 08-2012

This process deletes the complete conguration of the radio button. Settings of the insert
(switch-on brightness-level, load setting) are not reset.
6. Appendix
6.1 Technical data
Radio frequency 868 MHz
Radio protocol KNX radio
Power supply via insert, see accessories
Quicklink logic functions max. 20 transmitters/receivers
Receiver category 2
Transmitter duty cycle < 1 %
Degree of protection IP 20
Relative humidity 0 ... 65 % (no condensation)
Ambient temperature -5 … +45 °C
Storage/transport temperature -20 … +60 °C
Mounting orientation interface between application and power module on top
The Declaration of Conformity can be taken from our Internet site.
6.2 Accessories
For Radio push button 1gang quicklink
Relay insert 8512 12 0x
Universal switch insert 1gang 8512 11 0x
Touch dimmer (R, L) 8542 11 0x
Universal touch dimmer 1gang 8542 12 0x
Power supply for radio application module 8502 01 0x
For Radio push button 2gang quicklink
Universal switch insert 2gang 8512 22 0x
Universal touch dimmer 2gang 8542 21 0x
Power supply for radio application module 8502 01 0x
For Radio push button 4gang quicklink
Relay insert 8512 12 0x
Universal switch insert 1gang 8512 11 0x
Touch dimmer (R, L) 8542 11 0x
Universal touch dimmer 1gang 8542 12 0x
Universal switch insert 2gang 8512 22 0x
Universal touch dimmer 2gang 8542 21 0x
Power supply for radio application module 8502 01 0x

Page 12/12
Radio Push button
6W-5821 08-2012
6.3 Warranty
We reserve the right to make technical and formal changes to the product in the interest of
technical progress.
Our products are under guarantee within the scope of the statutory provisions.
If you have a warranty claim, please contact the point of sale or ship the device postage free
with a description of the fault to the appropriate regional representative.
