Bernina Foldable Sit Down Table User manual

Foldable Sit Down Table
Assembly instructions

Table of Contents
3
Table of Contents
IMPORTANT SAFETY INSTRUCTIONS ................. 4
1 WARNING ............................................................. 4
Important information ........................................ 5
2 My BERNINA ........................................................ 6
2.1 Introduction ........................................................... 6
2.2 Overview of foldable sit down table ....................... 6
3 Unpacking and setting up the sit down table .. 7
4 Adjusting the table height ................................. 8
5 Mounting the Q 16 .............................................. 9
5.1 Mounting the insert ............................................... 9
5.2 Placing the machine ............................................... 9
5.3 Lifting the table tops .............................................. 10
6 Mounting the Q 20 .............................................. 12
6.1 Placing the machine ............................................... 12
6.2 Lifting the table tops .............................................. 12
6.3 Mounting the insert ............................................... 12

Important safety instructions
4
IMPORTANT SAFETY INSTRUCTIONS
Note the following basic safety instructions when assembling the sit down table,
and carefully read through the operating instructions for the BERNINA Q Series
machine before using the sit down table.
WARNING
To protect persons from injuries:
• The packaging of the sit down table is large and heavy. The packaging
should, therefore, always be carried by at least two adults together.
• Position the packaging such that it cannot fall over.
• Setting up the sit down table requires at least two adults.
• During assembly of the individual and small parts, ensure that the parts are
kept out of the reach of small children (risk of suffocation).
• During assembly, ensure that your fingers do not get trapped or caught.
• Only use the sit down table for the purpose described in these assembly
instructions.
• Do not use the sit down table as a toy.
• The sit down table can be assembled by children over the age of eight, as
well as by persons with reduced physical, sensory or mental capacities or
with a lack of experience and knowledge, as long as they are supervised or
have been made aware of the potential hazards.
• Do not move, tip or fold the sit down table as long as the machine is
mounted on it. Remove the machine before moving, tipping or folding the
sit down table.
• Position the folded sit down table such that it cannot fall over.
• Do not sit or lean on table tops.

Important information
5
Important information
Availability of the instruction manual
The manual forms part of the product.
• Store the manual in a suitable location near the product and keep it available to consult.
• If the product is passed on to third parties, always include the manual with the product.
Proper use
The foldable sit down table serves as a workstation for machines of the Q Series, which are suited for use as
sit down models. Any other use is not considered proper. BERNINA assumes no liability concerning
consequences resulting from an improper use.
Environmental Protection
BERNINA International AG is committed to environmental protection. We make every effort to increase the
environmental friendliness of our products by continually improving their design and production technology.
If the product is no longer required, disassemble all components and dispose of them in an environmentally
friendly way in accordance with the national guidelines. Do not dispose of it in household waste.
Explanation of symbols
DANGER Designates a high-risk hazard which can lead to serious injuries or potentially even death if not avoided.
WARNING Designates a medium-risk hazard which can lead to serious injuries if not avoided.
CAUTION Designates a low-risk hazard which can lead to minor or moderate injuries if not avoided.
NOTICE Designates a hazard which can lead to material damage if not avoided.

My BERNINA
6
2 My BERNINA
2.1 Introduction
The foldable sit down table allows you to quilt comfortably while sitting, using the machines of the BERNINA
Q Series, which are suited for use as table models. If the machine has already been disassembled, the sit
down table can be folded and stored in a way that saves space.
2.2 Overview of foldable sit down table
1
2
3
4
5
6
7
8
9
11
10
12
1 Leg, left 7 Table top, right
2 Support bracket, left 8 Support bracket, right
3 Table top, left 9 Leg, right
4 Latch 10 Height adjustment
5 Locking bracket, left 11 Securing pin, table legs
6 Locking bracket, right 12 Opening for machine

Unpacking and setting up the sit
down table
7
3 Unpacking and setting up the sit down table
WARNING Heavy sit down table
Lifting the sit down table can cause back injury.
Accidentally dropping the sit down table can cause injuries and damage to property.
> Always set up the sit down table with the help of a second person.
Unpack the table carefully.
Soft surface
1 2 Set up the table with the help of another person.
3
2x
Remove the 2 securing pins. 4Unfold the legs 5Replace the 2 securing pins.

Adjusting the table height
8
4 Adjusting the table height
Prerequisite
• The machine is not placed into the table.
1With the help of another person, tip the table so that the screws are easily accessible.
Tip the table on its side,
or tip the table forward,
or place table on the table top.
4 x 2
4 x 2
2x
2 3 4
Remove 2 screws from
each of the 4 legs.
Adjust both legs to the
same length.
Tighten 2 screws on each of
the 4 legs.
73 cm
(28 in)
78 cm
(30 in)
83 cm
(32 in)
Table heigth Screws

Mounting the Q 16
9
5 Mounting the Q 16
5.1 Mounting the insert
Push the insert as far back as it will go.
2
Mount the insert with rounded corners to
the rear.
1
5.2 Placing the machine
1 2
Place the machine with the help of another
person.
Push the machine as far back as it will go.

Mounting the Q 16
10
5.3 Lifting the table tops
1Align the two locking brackets as shown in
the picture.
!
2First, slowly lift the right table top.
2x
3Raise the support bracket and snap it in audibly.
!

Mounting the Q 16
11
4 5
6
Lift the left table top. Raise the support bracket and snap it in audibly.
Close the locking brackets.
2x

Mounting the Q 20
12
6 Mounting the Q 20
6.1 Placing the machine
(see page9)
6.2 Lifting the table tops
(see page10)
6.3 Mounting the insert
1Remove the centerpiece. 2Mount the insert with rounded corners to the
front.

in partnership with
BERNINA International AG | CH-8266 Steckborn Switzerland | www.bernina.com | © Copyright by BERNINA International AG
1050655.00A.04
2020-02 EN
