Beurer MG 260 User manual

MG 260 HD 2in1
Beurer GmbH •Söflinger Str. 218 •89077 Ulm, Germany
Tel.: +49 (0)731 / 39 89-144 •Fax: +49 (0)731 / 39 89-255
www.beurer.de •Mail: [e-mail]
D Shiatsu-Sitzauflage
Gebrauchsanweisung
G Shiatsu seat cover
Instructions for use
F Siège de massage Shiatsu
Mode d’emploi
E Colchoneta de asiento Shiatsu
Manual de instrucciones
I Coprisedile shiatsu
Istruzioni per l’uso
T Koltuk üstü shiatsu
Kullanım kılavuzu
r Массажная накидка шиацу на
сиденье
Инструкция по применению
Q Shiatsu – masażer na siedzenie
Instrukcja obsługi

9
ENGLISH
Items included in the package:
• Shiatsu seat cover
• These operating instructions
Explanation of symbols
The following symbols are used in the operating instructions and on the type plate:
WARNING Warning of risks of injury or health hazards.
CAUTION Safety information about possible damage to appliance/accessories.
Note Important information.
The device has double protective insulation and therefore complies with protection class 2.
Only use indoors.
1. About Shiatsu massage
Shiatsu is a form of body massage which was originally developed in Japan around 100 years ago. It is
based on ideas anchored in traditional Chinese medicine, in particular the meridian system, i.e. the paths in
the human body along which energy is conveyed.
The aim of any Shiatsu massage is to promote the physical, emotional and mental wellbeing of the person
being treated. To do this, energy blocks and bottlenecks in the meridians need to be dissolved and the self-
regulating ability of the body needs to be stimulated.
Shiatsu therapists achieve this by exercising pressure in flowing movements along the meridians. Although
Shiatsu can be literally translated as “finger pressure”, practitioners also use the heels of their hands, their
elbows and knees as well as their fingers. In the process, the therapist will use his or her full body weight in
order to generate the required pressure.
2. Getting to know your appliance
Your Shiatsu massage device has rotating massage heads which imitate the pressure and kneading motions
of a Shiatsu massage.
This product comes complete with rotating massage heads and provides a powerful and intensive deep mas-
sage for the whole back. You have to place the Shiatsu seat cover on a suitable seat pad for this purpose.
The device is only for private use and is not intended for medical or commercial purposes.
3. Proper use
This device is solely intended for massaging the backs of human beings. It cannot replace medical treatment.
Do not use the massage device if any of the following warnings apply to you.
WARNING
Use of the massage device is prohibited in the following cases:
•
Not with changes caused by disease or injury in the back region (e.g. disc problems, open wounds),
• not on children,
• not during pregnancy,
• never while you sleep,
• not in the car,
• not on animals,
• not during activities during which an unexpected reaction may be dangerous,

10
• not while ingesting substances that reduce reaction times (e.g. painkiller medications, alcohol),
• never longer than 15 minutes (risk of overheating) and allow it to cool off for at least 15 minutes
before using it again.
P lease consult your doctor if you are unsure whether or not the massage device is suitable for you.
T his device is not intended for use by persons (including children) with restricted physical, sensory or
mental capabilities and/or by persons lacking the required understanding of the equipment and how
it is used, unless they are supervised by a person who is responsible for their safety or they are given
instructions on how to use the device.
C hildren should be supervised to ensure that they do not use the device as a toy.
T he device has an adjustable heating function in the massage heads. Persons who do not feel heat
must be careful when using this function.
Y ou should consult your doctor before using the massage device if:
• you suffer from a serious illness or are recovering from an operation on the upper body,
• you are fitted with a cardiac pacemaker, implant or other aid,
• Thromboses,
• Diabetes,
• in case of pains of unclarified origin.
The device is only intended for the purpose described in these operating instructions. The manufacturer
cannot be held liable for damage occurring as a result of inappropriate or careless use.
4. Safety information
Please read these operating instructions carefully. Failure to observe the information provided below can
lead to personal injury or material damage. Keep these instructions in a safe place where they can also be
read by other persons using the device. Always pass on these instructions together with the appliance if
you sell it or pass it on.
WARNING
K eep children away from the packaging materials. Risk of suffocation.
WARNING: Electric shock
Just like any other electrical appliance, this massage device must be handled with due care and at-
tention in order to prevent the risk of electric shock.
For this reason, the device must only be operated as follows:
• With the mains voltage specified on the device only,
• Do not use the device if damage to the device itself or any of its accessories is evident.
• Never use the appliance during a thunderstorm.
In the event of a defect or malfunction, switch the device off immediately and disconnect it from the
power supply. Never pull on the power cable or on the appliance in order to disconnect the plug from
the mains outlet. Never hold or carry the device by the power cable. Keep the cables away from hot
s urfaces. Do not pinch, kink or twist the cables. Do not stick in any pins, needles or sharp objects.
M ake sure that the massage device, the switch, the power supply unit and the cable do not come into
contact with water, steam or other fluids.
For this reason, the device must only be operated as follows:
• Only in dry inside rooms (e.g. never in the bathtub or sauna).
• Only with dry hands.
Never try to retrieve the device if it falls into water. Disconnect the plug immediately from the mains
outlet.
Do not use the device if damage to the device itself or any of its accessories is evident.
Do not subject the device to any impact and do not drop it.

11
Repairs
WARNING
• Repairs to electrical appliances must only be carried out by qualified persons. Incorrect repairs
can lead to considerable danger for the user. In the event of repairs, please contact our customer
service or an authorized dealer.
• The zip fastener on the Shiatsu massage device must not be opened. It is only fitted for reasons
relating to the manufacturing of the device.
• If the power cord is damaged it must be replaced by an authorised dealer.
WARNING: Fire hazard
T here is a risk of fire if the device is used incorrectly or if it is not used according to these operating
instructions.
F or this reason, the massage device must only be operated as follows:
• Never use the device under covers, such as blankets or pillows.
• Never use the device in the vicinity of petrol or other easily flammable materials.
Handling
CAUTION
S witch the device off and disconnect the power supply after every use and before every cleaning.
• Never insert any objects into openings on the device, and never insert anything into the
rotating parts. Make sure that all moving parts can move freely at all times.
• Operate the device in an upright position only, never place it flat on the floor.
• Never sit or stand on the moving parts of the device with all your weight and do not place
objects on the device.
• Keep the device away from high temperatures.
Disposal
CAUTION
F ollow local regulations regarding the disposal of materials. The appliance should be disposed
of according to Regulation 2002/96/EC-WEEE (Waste Electrical and Electronic Equipment).
In case of queries, contact the municipal authorities responsible for waste disposal in your
area.

12
5. Appliance description
Shiatsu massage pillow (front)
1 2 neck massage fingers
2 Turning handle for height adjustment
3 4 massage heads
4 Fastening straps
5 Mains cable
6 Storage bag
7 Hand switch
8 Removable and washable covers
9 Removable seat cushion
10 Coat hanger loops (rear)
Hand switch
1. Button
2. timer button (5–10–15 minutes)
3. demo button
4. neck button
5. neck button (anti-clockwise rotation)
6. neck button (clockwise rotation)
7. shiatsu button (shiatsu massage)
8. rolling button (rolling massage)
9. spot buttons (localised massage)
10. Height adjustment button (localised massage)
11. full back button (entire back massage)
12. upper back button (upper back massage)
13. lower back button (lower back massage)
14. speed button (massage intensity)
15. heat button (heating)
6. Start-up
CAUTION
• IMPORTANT: Before using the device for the first time, ensure you have released all transport
locks on the massage mechanism. To do this, remove the screws using the tool provided on
the rear of the seat cover. If the transport lock screws are not removed first and the Shiatsu
seat cover is used immediately, the device will become irreparably damaged and unusable.
The warranty will not apply in this instance.
1
4
4
2
4
4
8
8
5
6
7
9
10
3
3
4
6
8
9
12
15
1
14
11
7
5
2
10
13

13
• Reuse the transport lock screws when transporting the device in the future. Transporting the device
without using the transport locks could cause irreparable damage to the device.
• Position the seat cover upright on a suitable seat with a sitting area and backrest (chair, sofa or
similar). Make sure that the seat has a sufficiently high backrest.
• Use the flexible fastening straps and Velcro strips to secure the Shiatsu seat cover.
• Connect the device to the mains by plugging the plug into the socket.
7. Operation
Gently press your back against the massage device to start with. Then make sure that you are in a comfort-
able position before gradually shifting your weight onto the massage device.The massage must be pleasant
and relaxing at all times. Stop the massage or change your position or the contact pressure if you find it is
painful or unpleasant.
• Do not force or jam any part of your body, in particular your fingers, between the rotating massage elements
or their holders in the unit.
• Sit comfortably and upright on the seat cover. Ensure you sit centered and such that the massage heads
can move to the left and right of your spinal column.
• Switch on the massager with the button.
The LEDs signal the massage functions which are currently selected.
• The automatic switch-off function is activated with selection of the massage region and is preset to 15
minutes. You can set the automatic switch-off function to 5, 10 or 15 minutes by pressing the timer but-
ton. Please note that changing the timer setting makes the timer start to count again from the beginning.
To avoid overheating the device, select the maximum massage duration at the beginning of the massage
and do not change it again during the massage.
You can specify the settings as follows:
1. Neck massage
Press the neck button to start the neck massage. Press neck (anti-clockwise rotation) or neck
(clockwise rotation) to change the direction of the massage.
2. Shiatsu back massage
Press the shiatsu button. Select the desired massage region with full back, upper back, lower back.
You can choose a spot massage i.e. a Shiatsu massage without vertical movement by pressing the spot
button. You can change the position of the spot massage by holding down one of the arrows next to the
spot button until the desired position is reached.
Massage intensity
When using the Shiatsu Massage, two different massage speeds are available, which can be selected
using the speed button. If you have the rolling massage activated, first press the shiatsu button in order
to change to Shiatsu Massage and then set the desired massage speed.
3. Rolling massage
Press the rolling button. Select the desired massage region with full back, upper back, lower back.
When the massage type (Shiatsu or rolling massage) is changed, the preselected region (full, upper, lower
back) is retained. Note that the massage region must be selected again when switching from localised
Shiatsu massage to rolling massage.
Heating function
Press the heat button to switch on the heating function of the massage heads. The blue lights in the mas-
sage heads change colour to red.
• Do not use the massage device for longer than 15 minutes and then allow it to cool. Using the device
for longer can over-stimulate the muscles and cause tension instead of relaxation. The massage can be
finished at any time by pressing the button. Please note that on switching off, the massage heads first
return to the starting position at the lumbar region. This is indicated by the LED flashing. Once this position
is reached, the device switches off.
• If the device is stopped be pressing a massage area button twice, it also returns to the starting position
after 15 minutes and then switches off.

14
• Do not disconnect the device from the mains supply during operation. Always switch it off first and wait
until it has returned to the initial position.
Note
• The device has an automatic shut-off mechanism set to a maximum operating period of 15 minutes.
8. Care and storage
Cleaning
WARNING
• Disconnect the device before cleaning it.
• Only clean the appliance in the manner specified. Fluid must never be allowed to enter into the
device or accessories.
• Smaller stains can be removed using a cloth or moist sponge together with a little liquid detergent
for delicate fabrics if necessary. Do not use any cleaning agents containing solvents.
• The removable covers are machine-washable at 40°C. Please note the symbols for care and
cleaning on the label sewn into the cover.
The velour cover to the rear is secured with a Velcro fastening under the material bearing the beurer
logo and can be removed from there.
The cover for the neck area can be removed using the zip at the side of the control knob for the
height-adjustable neck massage.
• Do not use the device again until it is completely dry.
Storage
If you do not use the device for longer periods, we recommend storing it in the original packaging in a dry
place without weighting it down.
Alternatively, you can hang the device in a wardrobe with a coat hanger. To do so, the coat hanger must be
threaded through the hanging loops on the rear side of the device.
CAUTION
• If you use the transport lock screws, take care to remove these before starting the device when you
next use it.
9. In the event of problems
Problem Cause Remedy
Massage heads
rotating at
reduced speed.
The load on the massage
heads is too great. Reduce the contact pressure on the head.
Massage heads
only rotate in the
upper or lower
region.
The massage has been
activated for the limited
region.
Press the full back, upper back, lower back but-
tons to change the massage region.
Press the neck button to activate the neck mas-
sage.
Massage heads
not moving. Appliance not connected to the power supply. Connect the plug to the mains supply and switch on the appliance.
Device not switched on. Switch the device on with .
Select the massage region.
Transport locks were not re-
moved. Massage mechanism
is damaged.
Contact your authorized dealer or the service ad-
dress.
Overheating protection
tripped, device is damaged. Contact your authorized dealer or the service ad- dress.
