APPLICATIONS
The lightweight, closed DT 297 headset has been developed for
professional broadcasting use.
The headphone features an efficient neodymium magnet system,
giving very precise reproduction and excellent intelligibility.
Another special feature is the wide frequency response of
10 - 30,000 Hz. The headsets are available with 80 Ωor 250 Ω
systems.
This headset is equipped with a condenser capsule with an extended
bass response. The microphone can be optimally positioned with
the flexible gooseneck. The optimum distance to the mouth is around
5 to 10 cm. The frequency response for this distance corresponds
to recommendations of the IRT (Institute for Radiotechnology in
Munich). The microphone holder is rotatable so that the micro-
phone can be worn on the left or right side. The soft circumaural ear
pads and the fully adjustable padded headband offer a outstanding
comfort.
The cardioid polar pattern ensures high-gain-before feedback and
noise cancellation. The wide frequency response ensures clear and
precise speech reproduction and intelligibility.
All parts such as earpads, headband and gooseneck microphone
are easy to replace.
FEATURES
• Closed headphone
• Good ambient noise attenuation
• Neodymium magnet system for very high
reproduction precision
• Soft, circumaural ear pads
• Cardioid condenser microphone
• Single-sided connecting cable, plug-in type
(delivery does not include the connecting cable)
• Limiter (optional)
• Flexible, pivotable gooseneck for optimal positioning with
elasticated microphone suspension
• Improvement of immunity against RFI (Radio Frequency
Interference) caused by GSM, DECT, UMTS, Tetra etc.
• DT 287 single-sided version
SPARE PARTS
EDT 250 V Ear pads, velours,
circumaural . . . . . . . . . . . . . . . . . Order # 942.704
EDT 250 S Ear pads, soft PVC,
circumaural . . . . . . . . . . . . . . . . . Order # 943.549
WS 97 AZ Wind / pop shield,
charcoal-grey . . . . . . . . . . . . . . . . Order # 465.313
TECHNICAL SPECIFICATIONS
Headphone
Transducer principle. . . . . . . . . . . . . . . . Dynamic
Operating principle . . . . . . . . . . . . . . . . Closed
Transmission range . . . . . . . . . . . . . . . . 10 - 30,000 Hz
Nominal impedance. . . . . . . . . . . . . . . . 80 Ωor 250 Ω
Nominal sound pressure level at 1 kHz. . 100 dB
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . < 0.2%
Ambient noise insulation . . . . . . . . . . . . approx. 16 dBA
Average pressure on ears. . . . . . . . . . . . 4.5 N
Weight without cable . . . . . . . . . . . . . . 240 g
Microphone. . . . . . . . . . . . . . . . . . . . . DT 297 PV
Transducer principle. . . . . . . . . . . . . . . . Condenser
(back electret)
Transmission range . . . . . . . . . . . . . . . . 40 - 20,000 Hz
Polar pattern . . . . . . . . . . . . . . . . . . . . . Cardioid
Output voltage at a distance of 5 cm. . . . . 5.5 mV
Nominal impedance. . . . . . . . . . . . . . . . approx. 300 Ω
Nominal output impedance . . . . . . . . . . > 1000 Ω
Open circuit voltage . . . . . . . . . . . . . . . 5 mV/Pa at f = 1 kHz
Max. SPL . . . . . . . . . . . . . . . . . . . . . . . . 132 dB
S/N ratio . . . . . . . . . . . . . . . . . . . . . . . . 62 dB
Current consumption . . . . . . . . . . . . . . approx. 3.5 mA
Phantom supply. . . . . . . . . . . . . . . . . . . 12 - 48 V
Microphone. . . . . . . . . . . . . . . . . . . . . DT 297 V.11
Transducer principle. . . . . . . . . . . . . . . . Condenser
(back electret)
Transmission range . . . . . . . . . . . . . . . . 20 - 20,000 Hz
Polar pattern . . . . . . . . . . . . . . . . . . . . . Cardioid
Output voltage at a distance of 5 cm. . . . . 52 mV - 1.3 V, adjustable
Nominal impedance. . . . . . . . . . . . . . . . approx. 300 Ω
Current consumption . . . . . . . . . . . . . . 6 - 56 mA
Dimensions
Gooseneck length: . . . . . . . . . . . . . . . . 120 mm
Capsule diameter: . . . . . . . . . . . . . . . . . 19 mm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . 30 g
DT 287 / DT 297
Headsets with Condenser Microphone
beyerdynamic GmbH & Co. KG
Theresienstr. 8 | 74072 Heilbronn – Germany
Tel. [phone] / 617 - 0 | Fax [phone] / 617 - 204
[email protected] | www.beyerdynamic.com
For further distributors worldwide, please go to www.beyerdynamic.com
Non-contractual illustrations. Contents subject to change without notice. E6/DT 287/297 (07.10)
1 of 3
DT 297
DT 287

VERSIONS
DT 287 PV MK II Single-sided version, 80 Ω,
cardioid condenser
microphone . . . . . . . . . . . . . Order # 701.432
DT 287 V.11 MK II Single-sided version, 80 Ω,
cardioid condenser microphone,
with integrated microphone
pre-amp . . . . . . . . . . . . . . . . Order # 700.517
DT 297 PV MK II Headset, 80 Ω,
cardioid condenser microphone,
with integrated power supply
for phantom powering . . . . . Order # 701.467
DT 297 PV MK II same as above, but 250 Ω. . Order # 721.042
DT 297 V.11 MK II Headset, 80 Ω, cardioid
condenser microphone,
with integrated microphone
pre-amp . . . . . . . . . . . . . . . . Order # 700.533
DT 287 PV MK II LTD Single-ear headset, 80 Ω, condenser
microphone (cardioid), with limiter,
without cable . . . . . . . . . . . . Order # 498.076
DT 287 PV MK II LTD Single-ear headset, 250 Ω, condenser
microphone (cardioid), with limiter,
without cable . . . . . . . . . . . . Order # 498.025
DT 297 PV MK II LTD Headset, 80 Ω, condenser
microphone (cardioid), with limiter,
without cable . . . . . . . . . . . . Order # 490.881
DT 297 PV MK II LTD same as above, but 250 Ω. . Order # 498.114
OPTIONAL ACCESSORIES
K 190.00 Bare-ended straight cable,
1.5 m long . . . . . . . . . . . . . . . . . . Order # 431.575
K 190.00 Bare-ended straight cable,
3 m long . . . . . . . . . . . . . . . . . . . Order # 441.937
K 190.28 Straight cable with
4-pin XLR-socket, 1.5 m long . . . . Order # 445.304
K 190.39 Straight cable for V.11 version
of the DT 290 series, with 5-pin
XLR-plug to connect to professional
cameras (Sony, Philips, Ikegami),
1.5 m long . . . . . . . . . . . . . . . . . . Order # 475.181
K 190.40 Straight cable with
3-pin XLR-plug and 1/4" jack
(6.35 mm), 1.5 m long . . . . . . . . . Order # 445.894
K 190.40 same as above, but 3 m long . . . . Order # 446.750
K 190.41 Straight cable with
5-pin XLR-plug, 1.5 m long. . . . . . Order # 445.312
WK 190.00 Bare-ended coiled cable . . . . . . . . Order # 448.176
DT 287 / DT 297
beyerdynamic GmbH & Co. KG
Theresienstr. 8 | 74072 Heilbronn – Germany
Tel. [phone] / 617 - 0 | Fax [phone] / 617 - 204
[email protected] | www.beyerdynamic.com
For further distributors worldwide, please go to www.beyerdynamic.com
Non-contractual illustrations. Contents subject to change without notice. E6/DT 287/297 (07.10)
2 of 3
WIRING DIAGRAMS

DT 287 / DT 297
beyerdynamic GmbH & Co. KG
Theresienstr. 8 | 74072 Heilbronn – Germany
Tel. [phone] / 617 - 0 | Fax [phone] / 617 - 204
[email protected] | www.beyerdynamic.com
For further distributors worldwide, please go to www.beyerdynamic.com
Non-contractual illustrations. Contents subject to change without notice. E6/DT 287/297 (07.10)
3 of 3
FREQUENCY RESPONSE & POLAR PATTERN
This polar pattern and frequency response curve (measuring tolerance ± 2.5 dB) correspond to a typical production sample for this microphone.
Frequency response curve ±2.5 dB 0 dB = 5 mV/Pa DT 297 PV
