Billy Goat PR550 Installation instructions

Part No. 350324 Form No. F031605A
Page 1 of 16
Thank You for SelectingThank You for Selecting
Thank You for SelectingThank You for Selecting
Thank You for Selecting
Operator Owner's Manual
The Powerful PR and OS
POWER RAKES and OVERSEEDERS
Specifications
FLAIL BLADES
P/N 35 186.
A complete replacement set. 52
of our high quality flail lades for
your PR. Includes 8 new lock
clips for replacement installa-
tion.
PR550, PR550H, PR550V,
PR550HV, OS551, OS551H
FLAIL SHAFTS
P/N 35 185.
A full set of four shafts for
replacement. Includes 8 new
lock clips for replacement
installation.
Note: We recommend
replacing the shafts when you
replace flails.
REPLACE ENT PARTS
DRIVE BELT
P/N 35 116.
Original Equipment drive elt for
your PR.
SLICING REEL
P/N 35 113.
A complete verti-slicing reel for
your PR. 20" wide reel for use
in grasses that require vertical
cutting, and for assisting in lawn
overseeding projects.
ACCESSORIES
SLICING BLADES
P/N 35 187.
A full set of twenty lades for
replacement. Includes 40 new
capscrews, and lock nuts for
replacement installation.
21
3
SPACER BU PERS
P/N 35 258.
A complete replacement set.
44 of 1/2" spacer umpers
and 4 of 1/4" spacer umpers
OVERSEEDER KIT
P/N 35 325 / 35 328.
The new light weight Plastic
Overseeding Kit is constructed
of dura le High Density
Polypropolene with two lift
handles on each side to assist
in lifting the entire unit and easily
converts a PR Series Power
Rake into an overseeder with 4
olts and minimal tools.
NOTE: Overseeder Conversion
Kit (350328) includes Slicing
Reel (350113). Part No.
(350325) comes with the
Overseeder Box only.
NEW
PR550 PR550V PR550H PR550HV OS551 OS551H
ENGINE: H.P. 5.5 (4.1 kW) 5.5 (4.1 kW) 5.5 (4.1 kW) 5.5 (4.1 kW) 5.5 (4.1 kW) 5.5 (4.1 kW)
ENGINE: TYPE B&S OHV B&S OHV HONDA OHV HONDA OHV B&S OHV HONDA OHV
ENGINE: FUEL CAP. 3.0 qt. (2.84 L) 3.0 qt. (2.84 L) 3.88 qt. (3.6 L) 3.88 qt. (3.6 L) 3.0 qt. (2.84 L) 3.88 qt. (3.6 L)
ENGINE: OIL CAP. 0.66 qt. (0.62 L) 0.66 qt. (0.62 L) 0.69 qt. (0.65 L) 0.69 qt. (0.65 L) 0.66 qt. (0.62 L) 0.69 qt. (0.65 L)
WEIGHT: UNIT 160# (72.5 kg) 163# (74.1 kg) 158# (71.8 kg) 161# (73.2 kg) 173# (78.5 kg) 171# (77.6 kg)
WEIGHT: SHIPPING 183# (83.0 kg) 183# (83.0 kg) 178# (80.9 kg) 178# (80.9 kg) 208# (94.3 kg) 209# (94.8 kg)
ENGINEWEIGHT: 36# (16.3 kg) 36# (16.3 kg) 34# (15.4 kg) 34# (15.4 kg) 36# (16.3 kg) 34# (15.4 kg)
MAX. ENGINEOPERATINGSLOPE 15° 15° 20° 20° 15° 20°

Part No. 350324 Form No. F031605APage 2 of 16
IN THE INTEREST OF SAFETY
THIS SY BOL EANS WARNING OR CAUTION. DEATH, PERSONAL INJURY AND/OR PROPERTY
DA AGE AY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY.
BEFORE STARTING ENGINE, READ AND UNDERSTAND THE “ENTIRE OPERATOR'S ANUAL & EN-
GINE ANUAL.”
WARNING: DO NOT
1. DO NOT run engine in an enclosed area.
Exhaust gases contain car on monoxide, an
odorless and deadly poison.
2. DO NOT place hands or feet near moving
or rotating parts.
3. DO NOT store, spill or use gasoline near
an open flame, or devices such as a stove,
furnace, or water heater which use a pilot
light or devices which can create a spark.
4. DO NOT refuel indoors where area is not
well ventilated. Outdoor refueling is recom-
mended.
5. DO NOT fill fuel tank while engine is
running. Allow engine to cool for 2 minutes
efore refueling. Store fuel in approved
safety containers.
6. DO NOT remove fuel tank cap while
engine is running.
7. DO NOT operate engine when smell of
gasoline is present or other explosive
conditions exist.
8. DO NOT operate engine if gasoline is
spilled. Move machine away from the spill
and avoid creating any ignition until the
gasoline has evaporated.
9. DO NOT transport unit with fuel in tank.
10. DO NOT smoke when filling fuel tank.
11. DO NOT choke car uretor to stop
engine. Whenever possi le, gradually
reduce engine speed efore stopping.
12. DO NOT run engine at excessive
speeds. This may result in injury & /or
damage to unit.
13. DO NOT tamper with governor springs,
governor links or other parts which may
change the governed engine speed.
14. DO NOT tamper with the engine speed
selected y the engine manufacturer.
15. DO NOT check for spark with spark plug
or spark plug wire removed. Use an
approved tester.
16. DO NOT crank engine with spark plug
removed. If engine is flooded, place throttle
in “FAST” position and crank until engine
starts.
17. DO NOT strike flywheel with a hard
o ject or metal tool as this may cause
flywheel to shatter in operation. Use proper
tools to service engine.
18. DO NOT operate engine without a
muffler. Inspect periodically and replace, if
necessary. If engine is equipped with
muffler deflector, inspect periodically and
replace, if necessary, with correct deflector.
19. DO NOT operate engine with an
accumulation of grass, leaves, dirt or other
com usti le material in the muffler area.
20. DO NOT use this engine on any forest
covered, rush covered, or grass covered
unimproved land unless a spark arrester is
installed on the muffler. The arrester must
e maintained in effective working order y
the operator. In the State of California the
a ove is required y law (Section 4442 of
the California Pu lic Resources Code).
Other states may have similar laws. Federal
laws apply on federal lands.
21. DO NOT touch hot muffler, cylinder, or
fins ecause contact may cause urns.
22. DO NOT run engine without air cleaner
or air cleaner cover.
23. DO NOT operate during excessive
vi ration!
24. DO NOT leave machine unattended
while in operation.
25. DO NOT park machine on a steep grade
or slope.
WARNING: DO
1. ALWAYS DO remove the wire from the
spark plug when servicing the engine or
equipment TO PREVENT ACCIDENTAL
STARTING.
2. DO keep cylinder fins and governor
parts free of grass and other de ris
which can affect engine speed.
3. DO pull starter cord slowly until resis-
tance is felt. Then pull cord rapidly to avoid
kick ack and prevent hand or arm injury.
4. DO examine muffler periodically to e
sure it is functioning effectively. A worn or
leaking muffler should e repaired or
replaced as necessary.
5. DO use fresh gasoline. Stale fuel can
gum car uretor and cause leakage.
6. DO check fuel lines and fittings frequently
for cracks or leaks. Replace if necessary
7. Follow engine manufacturer operating
and maintenance instructions.
8. Inspect machine and work area efore
starting unit.
VIBRATION
VIBRATION LEVELS 3.2 g max.
Vi ration levels at the operators handles were
measured in the vertical, lateral, and longitudinal
directions using cali rated vi ration test equipment.
Tests were performed on 09/08/97 under the
conditions listed:
SOUND
5
6
8
7
○○○○○○
SAFETY INSTRUCTIONS
GENERAL SAFETY
ASSEMBLY
CONTROLS
LABELS
OPERATION
MAINTENANCE
PARTS DRAWING & LIST...
TROUBLESHOOTING
WARRANTY PROCEDURE
○○○
○○○○○○○
○○○ ○○○○○
○○○○○○○○
○○○○○
○○
10
16
16
6 - 9
4 - 5
4
3
3
2
TABLE OF CONTENTS
14 - 15
WARNING: The Engine Exhaust from this product contains chemicals known
to the State of California to cause cancer, irth defects or other reproductive harm.
○○○○○○○○
Sound tests conducted were in accordance with 2000/14/EEC
and were performed on 2/13/2002 under the conditions listed:
NOTE: Sound power level listed is the highest value for any model in this manual. Please
refer to serial plate on the unit for the sound power level for your model.
101 dB WIND DIRECTION:
HUMIDITY:
TEMPERATURE:
BAROMETRIC PRESSURE:
GENERAL CONDITION:
29.91" Hg (760mm Hg)
31 %
East
10 MPH (16.1 kmh)
85° F (29.4° C)
Sunny
WIND SPEED:
WIND DIRECTION:
HUMIDITY:
TEMPERATURE:
BAROMETRIC PRESSURE: 30.34" Hg (770mm Hg)
29 %
South East
2 MPH (3.2 kmh)
48° F (8.9° C)
Sunny
WIND SPEED:
GENERAL CONDITION:
(PR550 MODEL)
Sound level of 82 dBA at operator position

Part No. 350324 Form No. F031605A
Page 3 of 16
PUT OIL IN ENGINE BEFORE STARTING
Read all safety and operating instructions
before assembling or starting this unit.
Engine
Manual Per
Model
These items should be included in your carton. If
any of these parts are missing, contact your dealer.
ASSEMBLY
PACKING CHECKLIST
GENERAL SAFETY
For your safety and the safety of others, these directions should be followed:
Use of Ear Protection is recommended while
operating this machine.
Use of Eye and Breathing protection is recommended
when using this machine, especially in dry and dusty
conditions.
·DO NOT place hands or feet underneath unit, near de ris
outlet or near any moving parts.
·DO NOT start engine without height adjust lever in up
position and clutch ail disengaged.
·DO NOT start or operate machine with guards removed.
·DO NOT perform any service on the unit without removing
the spark plug wire.
·DO NOT operate a machine that exhi its excessive vi ration.
·DO NOT operate this machine on slopes greater than19°.
·DO NOT use this unit on any surface other than grass lawns.
·DO NOT allow children to operate this equipment.
-DO read all maintenance and operating instructions efore egining
work.
-DO read all engine manufacturers operating and maintenance
instructions.
-DO inspect lawn efore egining work. Remove all rocks, wire,
string, or other o jects that can present a hazard during work prior to
starting.
-DO identify and mark all fixed o jects to e avoided during work,
such as sprinkler heads, water valves, uried ca les, or clothes line
anchors, etc.
9
1
11
Do not operate this machine without first reading
owner's manual and engine manufacturer's manual.
Check
Check
Briggs & Stratton
5.5 Intek OHV
Per Model
Honda 5.5 OHV
Your Billy Goat Power Rake is shipped from the factory in one
carton, completely assem led.
1. UNFOLD the upper handle (item 26) and slide handle lock
loops(item 28) into place to secure the upper handle to the lower.
2. CHECK engine oil level and fill to proper level with engine manufac-
turers recommended grade of oil. Move height adjust lever to down
position, to level engine during checking. See engine manufacturers
instruction manual.
3. CONNECT spark plug wire.
Literature
Assembly
35 11
Wearing gloves is recommended while
operating this machine.
Check Owner's
Manual
35 324
Literature PR
Accessories
35 14
Check
Check EU Declaration
of Conformity &
EU Distributor
List 35 139
Check
Warranty
Card 4 972
28
28
26
28
OS551 & OS551H
PR55 , PR55 H,
PR55 V, & PR55 HV

Part No. 350324 Form No. F031605APage 4 of 16
15 ENGINE LABELS
13 CONTROLS
Set lever to choke position when
starting a cold engine
Set lever to desired engine speed.
Move lever completely to the left to stop
engine
Briggs & Stratton
'
'
'
..
Honda
OIL ALERT
ENGINE STOPS IMMEDIATELY.
WHEN OIL LEVEL LOW,
RUN CHOKE
STOP
B & S ENGINE THROTTLE CONTROLHONDA ENGINE THROTTLE CONTROL
THROTTLE LEVER
FUEL VALVE CHOKE LEVER
RUN CHOKE
ON
OFF
Read and follow Operating
Instructions before running engine.
Gasoline is flammable. Allow engine
to cool at least 2 minutes before fueling.
Engines emit carbon monoxide,
DO NOT run in enclosed area.

Part No. 350324 Form No. F031605A
These labels should be included on your Power Rake. If any of these labels are damaged, replace them before putting this
equipment into operation. Item and part numbers are given to help in ordering replacement labels.
Label Danger Keep Hands
and eet Away
Item 51 Part No.400424
Label Do Not ill While
Engine Is Hot
Item 50 Part No.400268
EXPLOSIVE FUEL
STOP ENGINE AND ALLOWTO
COOL BEFORE REFUELING.
400268
WARNING
14 INSTRUCTION LABELS
DANGER
810736
Label Danger lying Material
Item 48 Part No.810736
CAUTION
READ OWNERS MANUAL
BEFORE OPERATING
BEFORE STARTING, MAKE SURE:
USE PERSONAL
PROTECTION EQUIPMENT
HEIGHT ADJUST LEVER IS IN UP POSITION.
ALL GUARDS ARE ATTACHED.
USE ONLYA QUALIFIED MECHANICTO SERVICETHIS MACHINE.
INSPECT MACHINE BEFORE EACH USE AND REPLACE ANY
WORN AND DAMAGED PARTS.
CHECK ENGINE OIL DAILY .
PROPERLY SECURE EQUIPMENT BEFORE TRANSPORTING.
DISCONNECT SPARK PLUGWIRE BEFORE SERVICING UNIT.
1
2
3
4
5
BLADE DEPTH
FOR PREVENTATIVE MAINTENANCE
INSPECT AND CLEAN ENGINE AIR FILTER
DAILY. REPLACE AS NEEDED.
GREASE REEL BEARINGS AND LUBRICATE DEPTH
CONTROL LEVER EVERY ENGINE OIL CHANGE.
ALWAYS:
6
ROTATE KNOB TO ADJUST BLADE DEPTH-
BLADES UP
TRANSPORT POSITION BLADES DOWN
OPERATING POSITION
PROTECT BYSTANDERS
FLYING DEBRIS
BLADES UP
BLADES DOWN
350176
WARNING
900327
Label Danger Guard
Item 52 Part No.900327
PULLTO ENGAGE CLUTCH
RELEASETO DISENGAGE CLUTCH
830503
Label Clutch Item 49
Part No.830503
LAWN PREPARATION:
- MOW LAWN TO LOWEST SETTING ON YOUR MOWER.
- DO NOT WATER PRIOR TO SEEDING.
- POWER RAKE TO DETHATCH LAWN AND REMOVE THATCH.
- FERTILIZE LAWN WITH BROADCAST SPREADER.
SEED APPLICATION CHART:
THESE SETTINGS ARE APPROXIMATE GUIDELINES. SEEDING RATES ARE SPEED DEPENDENT.
FASTER TRAVEL DELIVERS LESS SEED.
SEEDING RECOMMENDATIONS:
- FOR BEST RESULTS OVERSEED IN TWO PASSES OF ONE-HALF
APPLICATION RATE AT RIGHT ANGLES OR IN A CRISS-CROSS PATTERN.
- WATER HEAVILY IMMEDIATELY THEN LIGHTLY FOR 10 - 14 DAYS
KEEPING SOIL MOIST.
- AFTER GERMINATION WATER LESS OFTEN TO PROMOTE GROWTH.
SEED
TYPE
RYEGRASS
BLUEGRASS
FESCUE
RATE
LBS
1 000 FT
1/2
3/4
1 1/2
2 1/3
3/4
1
1 1/2
2 1/2
3/4
1 1/4
2
3 1/2
STOP
SETTING
1
2
3
4
3
4
5
6
5
6
7
8
SEED
TYPE
BENTGRASS
BERMUDAGRASS
(HULLED & ZOYSIA)
CENTIPEDEGRASS
(COATED)
ST. AUGUSTINE
GRASS
RATE
LBS
1 000 FT
2/3
1 1/3
3/4
1 2/3
2/3
1 1/4
2 1/2
3/4
1
1 1/3
1 1/2
STOP
SETTING
1
2
1
2
1
2
3
3
4
5
6
BILLY
GOAT
SEEDER
SETTING
5
6
7
8
9
SCOTTS
SEEDER
SETTING
6 1/3
8
10
15 1/2
17
3
1
026
57
4
- PULL BACK ON THE KNOB THEN
SLIDE THE BRACKET TO DESIRED
STOP SETTING.
EXAMPLE: STOP SETTING IS ON 4
- IF SLICING WITHOUT DROPPING
SEEDS FOR LONG PERIOD OF TIME
THEN SET THE STOP SETTING TO
ZERO.
KNOB
BRACKET
STOP
SETTING
2 2
REFERENCE
CHART
(ALL DROP
SEEDER
MODELS)
Label Instructions Seeder Box
Item 45 Part No. 350288
Label Instructions Height Adjust
Item 35 Part No. 350176
Page 5 of 16

Part No. 350324 Form No. F031605A
This unit is equipped with a folding upper handle for easier storage
and transportation. The handle can e folded y sliding the handle
lock loops(item 28) up. This releases the upper handle, allowing it to
e folded over the unit.
FOLDING HANDLE
This unit requires two people to lift it. With the handle in
the folded position, lift holding the lower handle and elt/
shaft guard one on each side of the machine. Secure
the machine in place during transport.
HANDLING & TRANSPORTING
Page 6 of 16
ENGINE: See engine manufacturer’s instructions
for type and amount of oil and gasoline used.
Engine must e level when checking and filling oil and
gasoline.
ENGINE SPEED: Controlled y throttle lever on the engine.
Under normal conditions, operate at full throttle to accom-
plish your task.
FUEL VALVE: Move fuel valve to "ON" position (Honda
only).
CHOKE: Operated with lever on the engine.
THROTTLE: Move throttle control on engine to fast position.
Pull starting rope to start engine.
IF YOUR UNIT FAILS TO START:
See Trou leshooting on page 12.
INTENDED USE: This machine is designed for removing
thatch from your lawn, renovation of existing lawns, and to
assist in overseeding operations. The machine should not
e used for any other purpose than that stated a ove.
Inspect machine work area and machine before operat-
ing. Make sure that all operators of this equipment are
trained in general machine use and safety.
Do not operate if excessive vi ration occurs. If excessive
vi ration occurs, shut engine off immediately and check for
damaged or worn reel, loose pulley olts or set screws, loose
engine or lodged foreign o jects. (See trou le shooting
section on page 12).
16 Operation
STARTING ENGINE
Like all mechanical tools, reasona le care must
e used when operating machine.
The lades can e raised or lowered into the ground y
height adjusment lever on the engine ase. The height
adjuster lock lever must e pushed ack against the
adjustment lever in order to lower the lades into the
ground. The resulting lade depth can e adjusted higher
or lower.
See ADJUSTING BLADE DEPTH.
BLADE POSITION & DEPTH CONTROL LEVER
Clockwise:
To lower
lades
Counter Clockwise:
To raise lades
ADJUSTING BLADE DEPTH
The depth of the lades can e raised or lowered y
rotating the kno on the top of the adjustment lever. The
lades are lowered y rotating the kno clockwise, and
raised y rotating the kno counter-clockwise. The
relative depth of the lades can e gauged y using the
depth scale located on the right front corner of the engine
ase. With new lades installed the depth can e
estimated as follows: 2.5 on the scale is even with the
ground, 3 is equal to 0.25" deep, and 3.5 is equal to 0.5"
deep
BLADES UP
TRANSPORT
BLADES DOWN
RUNNING
BLADES UP
TRANSPORT

Part No. 350324 Form No. F031605A
RAKING/SLICING TIPS
Before egining, it is est to evaluate the condition of
the lawn y cutting one or more core samples from
area to e treated. A core can e cut using a piece of
pvc, or metal pipe. Hammer the pipe into the ground,
remove it, push the core out of the pipe and inspect it
to determine the depth of thatch in your yard.
THATCH: Thatch is a dense layer of dead grass,
clippings, and roots that uilds up over time at the
ase of of the lawn preventing air, water, and fertilizer
from reaching the soil. This can cause shallow root
development and make a lawn more suscepti le to
drought and disease. Thatch also provides an ideal
environment for insects to hide and multiply. Periodic
removal of thatch will keep your lawn in good health.
HEAVY THATCH: Lawns with an excessive amount of
thatch will require multiple treatments for effective
removal. Trying to remove excessive thatch (greater
than 3/4"[19 mm] deep) in one treatment will damage
or destroy the living part of the lawn. It is est to
remove heavy thatch in seasonal treatments (i.e.
spring, and fall).
SLOPES: Rake slopes across not up and down. This
is much easier and safer for the operator and is etter
for the lawn. Raking across will help to reduce runoff
during watering and allow the sloped ground to hold
more seed, fertilizer, and water. The units maximum
operating slope is 35% or 19°.
DEPTH: The wide range of depth adjusment on your
unit is provided to allow for lade wear. Setting the
reel deeper will not produce etter, or quicker results.
The flail reel is intended to e set so it just touches the
surface on flat ground. The slicing reel should e set
even with the ground for verti-slicing work, and set to a
maximum 1/2" depth for overseeding jo s. Setting the
reel deeper than this will only result in premature wear
on the unit (i.e. failed elt). If you desire to work the
ground deeper than the a ove guidlines allow, it
should e done gradually in multiple passes..
SLICING / OVERSEEDING: Mow the lawn to shorter
than the normal cut height efore starting (i.e. approxi-
mately 2" tall for fescue grass). For the est result,
Slice/Overseed in criss cross pattern (See Fig. 1 and
See Fig 2).
Hints!
RAKING OPERATION
MOW: Mow the lawn to it's normal cut height.
DRY: Be sure grass is dry. Wet conditions can cause
increased damage to healthy grass.
SET DEPTH: With engine off, set the raking depth so that
the lades just touch on a flat surface (i.e. driveway, or
sidewalk).
START ENGINE: See page 5 for further instruction.
ENGAGE BLADES: Pull ack on the ail on the opera-
tors handle. NOTE: When engaging the blades in heavy
load conditions (i.e. heavy thatch, or very uneven turf),
push down on the operators handle lifting the front
wheels slightly. Engage the blades. Slowly lower the unit
into the turf.
RAKE: Rake a small test area and examine the results.
Thatch should e removed and deposited on top of the
healthy grass. If excessive damage occurs to healty
grass, adjust the lade depth to decrease damage.
Continue raking the yard, working in one direction (i.e.
north-south, or east-west). NOTE: If a large drop in
engine RPM occurs, or the unit pulls you forward and
bounces during operation the blade depth is set too low.
REMOVE THATCH: After raking, a layer of thatch will e
deposited over the top of the lawn. This thatch must e
removed prior to any fertilizing, seeding, or watering of
the lawn. We suggest the use of a lawn vacuum or
wheeled lower for collection and removal of the thatch.
DO NOT- Use this machine on any surface other than a
lawn.
DO NOT- Use this machine on slopes in excess of19°.
DO NOT- Allow persons unfamiliar with this equipment to
operate it.
DO NOT- Allow children to operate this equipment.
Fig. 1
Page 7 of 16
Fig. 2
NOTE: Must have the flail reel assembly (35 112) for
this operation.
OPERATION continued
16

Part No. 350324 Form No. F031605A
OPERATION continued
16
MOW: Mow the lawn to shorter than the normal cut height
(approximately 2" tall)
DRY: Be sure grass is dry. Wet conditions can cause in-
creased damage to healty grass.
SET DEPTH: With engine off, set the raking depth so that the
lades just touch on a flat surface (i.e. driveway, or sidewalk).
START ENGINE: See Page 5.
ENGAGE BLADES: Pull ack on the ail on the operators
handle. NOTE: When engaging the blades in heavy load
conditions (i.e. heavy thatch, or very uneven turf), push down
on the operators handle lifting the front wheels slightly.
Engage the blades. Slowly lower the unit into the turf.
SLICE: Verti-cut a small test area and examine the results.
Some thatch and cut stems should e removed and deposited
on top of the healthy grass. Grass runners should e cut and
ready for removal. If excessive damage occurs to healthy
grass, adjust the lade depth to decrease damage. Continue
raking the yard, working in one direction (i.e. north-south, or
east-west). NOTE: If a large drop in engine RPM occurs, or
the unit pulls you forward and bounces during operation the
blade depth is set too low.
REMOVE THATCH/STEMS: After verti-cutting, a layer of
thatch and cut stems will e deposited over the top of the lawn.
We suggest the use of a lawn vacuum or wheeled lower for
collection and removal of the thatch/stems.
DO NOT- Use this machine on any surface other than a
lawn.
DO NOT- Use this machine on slopes in excess of 19°.
DO NOT- Allow persons unfamiliar with this equipment to
operate it.
DO NOT- Allow children to operate this equipment.
OVERSEEDING OPERATION
MOW: Mow the lawn to shorter than the normal cut
height (approximately 2" tall)
DRY: Be sure grass is dry. Wet conditions can cause
increased damage to healthy grass.
SEED: Spread grass seed according to the seed
suppliers directions (e.g. 10 l s. per 1000 ft2 [4.5 kg. per
93 m2 ])
SET DEPTH: With engine off, set the raking depth so
that the lades reach 1/4"-1/2"(6-12 mm) elow a flat
surface (i.e. driveway, or sidewalk).
START ENGINE: See Page 5.
ENGAGE CLUTCH: Pull ack on the ail on the
operators handle. NOTE: When engaging the clutch in
heavy load conditions (i.e. heavy thatch, or very
uneven turf), push down on the operators handle lifting
the front wheels slightly. Engage the clutch. Slowly
lower the unit into the turf.
DO NOT- Use this machine on any surface other than a
lawn.
DO NOT- Use this machine on slopes in excess of 19°.
DO NOT- Allow persons unfamiliar with this equipment to
operate it.
DO NOT- Allow children to operate this equipment.
SLICE: Run machine over the area that has een
seeded to incorporate the seed into the soil. If exces-
sive damage occurs to healthy grass, adjust the lade
depth to decrease damage. Continue raking the yard,
working in one direction (i.e. north-south, or east-west).
NOTE: If a large drop in engine RPM occurs, or the unit
pulls you forward and bounces during operation the
blade depth is set too low.
WATER/FERTILIZE: After the seed has een worked
into the soil, water and fertilize according to the seed
suppliers directions.
VERTI-CUTTING OPERATION
NOTE: Must have the slicing reel assembly (35 113) for
this operation.
NOTE: Must have the slicing reel assembly (35 113) for
this operation.
Page 8 of 16

Part No. 350324 Form No. F031605A
Page 9 of 16
ADJUSTING SEED RATE
LAWN PREPARATION
LAWN PREPARATION
1
1
STOP
SETTING
1
THESE SETTINGS ARE APPROXIMATE GUIDELINES. SEEDING RATES ARE SPEED DEPENDENT.
FESCUE
3 1/2
3/4
1 1/4
261 1/2
33/4
1
1 1/3 4
5
8
GRASS
5
6
7
ST. AUGUSTINE
FASTER TRAVEL DELIVERS LESS SEED.
1,000 FT
BLUEGRASS
RYEGRASS
SEED
TYPE
3/4
1 1/2
2 1/2
1
3/4
2 1/3
1 1/2
1/2
RATE
LBS
2
1 1/3
21 1/4
2 1/2 3
2
1 2/3
2/3
3/4
2
1,000 FT
2/3
LBS
RATE
2
5
6
4
3
4
3
SEED
TYPE
STOP
SETTING
2
1
BERMUDAGRASS
(HULLED & ZOYSIA)
CENTIPEDEGRASS
(COATED)
BENTGRASS
15 1/2
17
8
9
6 1/3
10
8
(ALL DROP
SEEDER
MODELS)
BILLY
5
7
6
GOAT
SEEDER
SETTING
REFERENCE
CHART
SETTING
SEEDER
SCOTTS
SEED APPLICATION CHART:
OPERATION continued
16
- MOW LAWN TO LOWEST SETTING ON YOUR MOWER.
-DO NOTWATERPRIOR TOSEEDING.
- POWER RAKE TO DETHATCH LAWN AND REMOVE
THATCH.
- FERTILIZE LAWN WITH BROADCAST SPREADER.
-FOR BEST RESULTS OVERSEED INTWO PASSES OF
ONE-HALF
APPLICATION RATE AT RIGHT ANGLES OR IN A CRISS-
CROSSPATTERN.
- WATER HEAVILY IMMEDIATELY THEN LIGHTLY FOR 10 -
14 DAYS
KEEPING SOIL MOIST.
- AFTER GERMINATION, WATER LESS OFTEN TO
PROMOTEGROWTH.
- PULL BACK ON THE KNOB THEN
SLIDE THE BRACKET TO DESIRED
STOPSETTING.
EXAMPLE: STOP SETTING IS ON 4
- IF SLICING WITHOUT DROPPING
SEEDS FOR LONG PERIOD THEN SET
THE STOP SETTING TO ZERO . OF
TIME.
STOP
SETTING BRACKET KNOB
DROPPING SEEDS
- AFTER ADJUSTING THE STOP SETTING, LIFT UP ON THE BAR TO OPEN
THEDROP SEEDER DOOR.
- TO STOP DROPPING SEEDS, PUSH FORWARD ON THE HANDLE TO
CLOSE THE DROP SEEDER DOOR.
NOTE: IF SLICING WITHOUT DROPPING SEEDS FOR LONG PERIOD OF
TIME THEN SET THE STOP SETTING TO ZERO .

Part No. 350324 Form No. F031605A
Page 10 of 16
MAINTENANCE
BLADE WEAR AND ROTATING REEL END TO END
1. Wait for engine to cool and disconnect spark plug.
2. Close fuel valve on engine (if availa le).
3. Lean unit ack onto lower handles and secure in place.
4. Inspect lades for wear, and immediately replace any ent or
cracked lades. Measure the overall length of the lade. (See fig. 1)
5. If lades measure less than 3.25"(83 mm) in overall length they
must e replaced. NOTE: We recommend replacing all the flails at
once.
FLAIL BLADE WEAR
Use only a qualified mechanic for
any adjustments, disassembly or
any kind of repair .
DISCONNECT SPARK PLUG WIRE
BEFORE SERVICING UNIT.
WARNING: TO AVOID PERSONAL INJURY, ALWAYS
TURN MACHINE OFF, MAKE SURE ALL MOVING
PARTS COME TO A COMPLETE STOP.
RECONNECT SPARK PLUG WIRE,
AND ALL GUARDS, BEFORE
STARTING ENGINE.
ENGINE: See engine manufacturer
operator's instructions.
17
Engine (See Engine Manual)
Check engine oil
Inspect and clean engine air filter
Grease reel earings
Inspect elt
aintenance Operation
Follow these hourly
maintenance intervals.
aintenance Schedule
Every
25 hrs
Every Use
(Daily)
ROTATING FLAIL REEL END TO END
USE ONLY BILLY GOAT ORIGINAL
EQUIPMENT PARTS FOR
REPLACEMENT AND REPAIR
NOTE: Takes approx. 10 min. and requires 1/2" socket wrench with
extension.
1. Wait for engine to cool and disconnect spark plug.
2 . Remove (3) lock nuts(item 62) holding the elt guard(item 21) in
place. It is necessary to lower the height adjust lever to reach the
locknuts on the guard. Remove the guard.
3. Remove the elt(item 9) y rotating the reel pulley(item 2) and
walking it out of the groove. Discard old elt
4. Install new elt using same procedure to walk the elt into the
groove.
5. With new elt installed pull ail rod ack to engaged position and
measure extension of idler spring. Spring should stretch 3/4" - 1" (19
25 mm) with ail engaged. Adjust clutch ca le as necessary to achieve
this extension.
6. Re-install the elt guard.
DRIVE BELT REPLACEMENT
Inspect for loose, worn,
or damaged parts
Oil height adjustment linkage
To maximize flail lade life and performance the reel can e rotated
end to end periodically to provide a fresh lead cutting edge. Takes
approx. 20 min. and requires 1/2" and 9/16" socket wrenches with
extension ar.
1. Wait for engine to cool and disconnect spark plug.
2. Close fuel valve on engine (if availa le).
3. Lean unit ack onto lower handles and secure in place.
4. Remove (6) lock nuts(item 62) holding the elt and shaft guards(item
21 &22) in place. It is necessary to lower the height adjust lever to reach
the locknuts on the guards. Remove the guards.
5. Remove the drive elt(item 9) y "walking" it out of the groove on the
reel pulley(item 2).
6. Remove the (4) lock nuts(item 60) and washers(item 68) holding the
earings(item 23) to the frame of the unit.
7. The reel is now free from the machine. Slide the reel down and out of
the machine.
8. Remove the capscrew(item 71), lockwasher(item 57), reel pulley(item
2), key(item 42), and reel spacer(item 10) from the end of the reel.
9. Rotate the reel end to end, and re-install these items on the opposite
end of the reel.
1 . Re-install the reel in reverse order of removal. Re-install the guards
in reverse order of removal.
Fig. 1
1. Wait for engine to cool and disconnect spark plug.
2. Close fuel valve on engine (if availa le).
3. Lean unit ack onto lower handles and secure in place.
4. Inspect lades for wear, and immediately replace any ent or
cracked lades. Measure the overall length of the lade from the center
of the attachment olt to the tip of the worn lade.
5. If lades measure less than 3"(76 mm) in length they must e
replaced. NOTE: We recommend replacing all the lades at once.
SLICING BLADE WEAR

Part No. 350324 Form No. F031605A
Page 11 of 16
PARTS DRAWING
POWER RAKE SEEDER BOX KIT P/N 350325
PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY
1 350321 BOXPLASTIC DROP SEEDER MAIN BODY 1
2 350306 BRACKET ADJ DROP SEEDER ASSY 1
3 350276 BAR DOOR LINKGAGE 1
4 350320 SHAFT PLASTIC DROOP SEEDER 1
5 350271 PLATE DOOR DROP SEEDER 1
6 350272 PLATE DOOR DROP SEEDER END 1
7 350273 PLATE DOOR DROP SEEDER ARM 1
8 350322 BOXPLASTIC DROP SEEDER LID ASSEMBLY 1
9 350319 SPROCKET 16T #43 0.625 BORE 1
10 8171003 WASHER 5/16 FLAT CUT 1
11 900321 BEARING CLIP 1.375 OD 4
12 350335 GUARD SPROCKET 1
13 400217 SPRING TENSION 2
14 8024040 BOLT CARRAIGE 5/16 - 18 X 1 1
15 8024021 BOLT CARRIAGE 1/4-20 X 3/4" 1
16 350286 SCREW SHEET METAL 4
17 8160001 NUT LOCK 1/4 1
18 350332 BRACKET SLOT PLASTIC SEEDER BOX 1
19 8160002 NUT LOCK 5/16 1
21 350318 SPROCKET WHEEL 16T 1
22 350280 WASHER 0.906 OD X0.656 ID 4
24 350329 CHAIN 35 PITCH 1
25 8197031 PIN COTTER 1/8" X 1" 1
26 350331 ROLL PIN 1/8 - 1 3/4 1
28 8172007 WASHER 1/4 SAE 1
29 8154007 NUT HEX 10-24 2
30 8059136 SCREWCAP #10-24 X 3/4 2
PARTS BAG SEEDER BOX KIT
15 8024021 BOLT CARRIAGE 1/4-20 X 3/4" 2
17 8160001 NUT LOCK 1/4 2
19 8160002 NUT LOCK 5/16 (REQUIRE ON THE OLD MODELS ONLY) 4
20 8177011 WASHER LOCK 5/16 4
23 8041026 SCREWCAP 5/16-18 x 3/4 4
27 8172020 WASHER 5/16 FENDER 4
28 8172007 WASHER 1/4 SAE 2
31 8171006 WASHER 1/2 FC 3
32 8161044 NUT LOCK 1/2" THIN HGT 1
- 350327 LIT SEEDER BOX (INCLUDES TEMPLATE) 1

Part No. 350324 Form No. F031605A
Page 12 of 16
FLAIL REEL ASSY 35 112
FLAIL SHAFT KIT 35 185 FLAIL BLADE KIT 35 186
item PARTS PR500 QTY
no. LIST Part No.
73 SHAFT FLAIL BLADE 350141 4
74 BLADEFLAIL 350100 52
75 SPACER BUMPER 5/8" x 1/4" 350143 4
76 SPACER BUMPER 5/8" x 1/2" 350144 44
77 SHAFT WA FLAIL REEL 350145 1
78 CLIPLOCK 1/2" 350146 8
79 WASHER1/2 SAE 8172011 8
item PARTS Part No. QTY
no. LIST
73 SHAFT FLAIL BLADE 350141 4
78 CLIPLOCK 1/2" 350146 8
item PARTS Part No. QTY
no. LIST
74 BLADE FLAIL 350100 52
78 CLIP LOCK 1/2" 350146 8

Part No. 350324 Form No. F031605A
Page 13 of 16
SLICING REEL ASSY 35 113
SLICING BLADE KIT 35 187
item PARTS PR500 QTY
no. LIST Part No.
81 BLADESLICING REEL 350147 20
85 SCREWCAP1/4-20 x 3/4, GR. 5 350151 40
86 NUT LOCK 1/4-20 8142004 40
SPACER BUMPER KIT 35 258
item PARTS PR500 QTY
no. LIST Part No.
75 SPACERBUMPER5/8" x 1/4" 350143 4
76 SPACERBUMPER5/8" x 1/2" 350144 44
item PARTS PR500 QTY
no. LIST Part No.
57 LOCK WASHER5/16 TWISTEDTOOTH 800177 1
71 SCREWCAP5/16 - 24 x 1" HCS GR. 5 400164 1
80 SHAFT SLICING WA 350142 1
81 BLADESLICING REEL 350147 20
82 PLATEBLADEMTG. 350148 20
83 SPACER BLADEMTG. 350149 10
84 SPACER BLADEASSY 350150 9
85 SCREWCAP1/4-20 x 3/4, GR. 5 350151 40
86 NUT LOCK 1/4-20 8142004 40
87 COLLARSPACER 350152 1
88 WASHER0.937 x 1.750 x 0.119 350153 1
89 WASHER LOCK 7/8 INT. TOOTH 350154 1
90 NUT JAM7/8-14 350155 1

Part No. 350324 Form No. F031605A
PR550, PR550V, PR550H PR550HV, OS551, OS551H
Page 14 of 16
18 PARTS DRAWING

Part No. 350324 Form No. F031605A
Page 15 of 16
item PARTS PR550 QTY PR550H QTY OS551
PR550V QTY OS551H PR550HV QTY
no. LIST Part No. Part No. Part No. Part No.
1 Pulley3" OD 350101-01 1 350101 1 350101-01 1 350101 1
1A Spacer Crank PR Honda - - 350339 1 - - 350339 1
2 Pulley6.5" OD X ¾" 350102 1 350102 1 350102 1 350102 1
3 Wheel 8" Front PR 350103 2 350103 2 350103 2 350103 2
4 Wheel 10" Front PR 350104 2 350104 2 350104 2 350104 2
5 Height Adjust Assy 350107 1 350107 1 350107 1 350107 1
6 Reel Flail / Slicing Assy 350112 1 350112 1 350113 1 350113 1
7 PulleyIdler 2.75" 350114 1 350114 1 350114 1 350114 1
8 Arm Idler WA 350115 1 350115 1 350115 1 350115 1
9 Belt 5L X 36 350116 1 350116 1 350116 1 350116 1
10 Spacer Reel Pulley 350118 1 350118 1 350118 1 350118 1
11 Bracket Mount Clutch Cable 350119 1 350119 1 350119 1 350119 1
12 Chassis WA W/ Label 350194 1 350194 1 350194 1 350194 1
13 Frame Front WA 350121 1 350121 1 350121 1 350121 1
14 Bushing 0.375 OD X 0.256 ID X 0.88 350309 1 350309 1 350309 1 350309 1
15 Spring Height Adjust PR500 350125 1 350125 1 350125 1 350125 1
16 Link Height Adjust PR500 350126 1 350126 1 350126 1 350126 1
17 Yoke ½ - 20 350127 1 350127 1 350127 1 350127 1
18 Pin Yoke ½" 350128 1 350128 1 350128 1 350128 1
19 Bracket Mount Hgt. Adj. WA 350182 1 350182 1 350182 1 350182 1
20 Spacer Spanner Wheel PR500 350130 4 350130 4 350130 4 350130 4
21 Guard Belt WA W/ Label 350195 1 350195 1 350195 1 350195 1
22 Guard Shaft WA W/ Label 350196 1 350196 1 350196 1 350196 1
23 Bearing ¾" Cast Pillow Block 350133 2 350133 2 350133 2 350133 2
24 Handle Lower LH WA 350134 1 350134 1 350134 1 350134 1
25 Handle Lower RH WA 350135 1 350135 1 350135 1 350135 1
26 Handle Upper PR500 350136 1 350136 1 350136 1 350136 1
27 Bail Clutch WA 350137 1 350137 1 350137 1 350137 1
28 Loop Folding Handle 350138 2 350138 2 350138 2 350138 2
29 Deflector Rubber 350167 1 350167 1 350167 1 350167 1
30 Shield Bearing 350168 2 350168 2 350168 2 350168 2
31 Bar Clamp Deflector 350171 1 350171 1 350171 1 350171 1
32 Bracket Height Adjust Lock WA 350173 1 350173 1 350173 1 350173 1
33 Guard Pulley Back 350184 1 350174 1 350184 1 350174 1
34 Lever Height Control 350175 1 350175 1 350175 1 350175 1
35 Label Instr. Hgt. Adj. 350176 1 350176 1 350176 1 350176 1
36 Bolt Shoulder ¼" x 1 ¾" 350178 1 350178 1 350178 1 350178 1
37 Bolt Shoulder 5/16" x 1 ¾" 350179 1 350179 1 350179 1 350179 1
38 Cable Clutch Reel PR500 350181 1 350181 1 350181 1 350181 1
39 Spring Extension 400217 1 400217 1 400217 1 400217 1
40 Bolt Shoulder 1/2" X 1" 500114 3 500114 3 500114 3 500114 3
41 ENGINE HONDA 5.5 H.P. GX160 - - 600115 1 - - 600115 1
ENGINE INTEK 5.5HP OHV B&S 350197 1 - - 350197 1 - -
42 KEY 3/16" X 1" 9201078 1 9201078 2 9201078 1 9201078 2
42A KEY 1/4" x 1" 9201113 1 - - 9201113 1 - -
43 GRIP 1" x 13" 400570 2 400570 2 400570 2 400570 2
44 GRIP LEVER 1/8 x 1 x 5" 500181 1 500181 1 500181 1 500181 1
45 LABEL INSTRUCTION SEEDER BOX - - - - 350288 1 350288 1
46 WASHER 5/16 FC (BELT GUARD) 8171003 2 - - 8171003 2 - -
47 LABEL GOAT HEAD 850209 1 850209 1 850209 1 850209 1
48 LABEL DANGER THROWN OBJECT 810736 1 810736 1 810736 1 810736 1
49 LABEL CLUTCH VQ 830503 1 830503 1 830503 1 830503 1
50 LABEL HOT ENGINE 400268 1 400268 1 400268 1 400268 1
51 LABEL WARNING 400424 2 400424 2 400424 2 400424 2
52 LABEL DANGER GUARD 900327 1 900327 1 900327 1 900327 1
53 PLUG CAP 1" RD 890132 2 890132 2 890132 2 890132 2
54 BOLT CARRAIGE 3/8-16 x 1 3/4 8024061 4 8024061 4 8024061 4 8024061 4
55 BOLT CARRAIGE 5/16-18 x 1 3/4 8024043 2 8024043 2 8024043 2 8024043 2
56 BOLT CARRIAGE 5/16 -18 x 3/4 8024039 4 8024039 4 8024039 5 8024039 5
57 LOCK WASHER TW. TOOTH 400502 1 400502 1 800177 1 800177 1
58 NUT LOCK #10-24 8164005 1 8164005 1 8164005 1 8164005 1
59 NUT LOCK 1/4-20 8160001 2 8160001 2 8160001 5 8160001 5
60 NUT LOCK 3/8-16 8160003 9 8160003 9 8160003 9 8160003 9
item PARTS PR550 QTY PR550H QTY
OS
55
1
PR550V QTY
OS
55
1H
PR550HV QTY
no. LIST Part No. Part No. Part No. Part No.
61 NUT LOCK 3/8-16 THIN 8161042 3 8161042 3 8161042 3 8161042 3
62 NUT LOCK 5/16-18 8160002 18 8160002 18 8160002 19 8160002 19
63 SCREWCAP 1/4-20 x 1 1/2 8041008 1 8041008 1 8041008 1 8041008 1
64 SCREWCAP 3/8 - 16 x 1 1/4 8041051 1 8041051 1 8041051 1 8041051 1
65 SCREWCAP 5/16-24 x 3/4" GR.5 8042026 3 8042026 4 8042026 3 8042026 4
65A Washer 3/4 SAE - - 8172015 1 - - 8172015 1
65B Washer 5/16 Twist Tooth - - 430298 1 - - 430298 1
66 SCREWCAP 5/16 - 18 x 1 1/2 8041030 4 8041030 4 8041030 4 8041030 4
67 WASHER 5/16 FLAT CUT 8171003 4 8171003 4 8171003 8 8171003 8
68 WASHER 3/8 FLAT CUT 8171004 8 8171004 8 8171004 8 8171004 8
69 WASHER 1/2 FC 8171006 2 8171006 2 8171006 5 8171006 5
70 NUT LOCK 1/2" - 13 THIN HGT 8161044 4 8161044 4 8161044 4 8161044 4
71 SCREWCAP REEL PULLEY 8041050 1 8041050 1 400164 1 400164 1
72 BUTTON SOCKET 5/16-18X5/8” 350266 4 350266 4 - - - -
FLAIL REEL ASSEMBLY (FOR PR550 AND PR550H MODELS ONLY)
73 SHAFT FLAIL BLADE 350141 4 350141 4 - - - -
74 BLADE FLAIL 350100 52 350100 52 - - - -
75 SPACER BUMPER 5/8" x 1/4" 350143 4 350143 4 - - - -
76 SPACER BUMPER 5/8" x 1/2" 350144 44 350144 44 - - - -
77 SHAFT WA FLAIL REEL 350145 1 350145 1 - - - -
78 CLIP LOCK 1/2" 350146 8 350146 8 - - - -
79 WASHER 1/2 SAE 8172011 8 8172011 8 - - - -
SLICING REEL ASSEMBLY (FOR PR550V, PR550HV, OS551, AND OS551H MODELS ONLY)
80 SHAFT SLICING WA 350142 1 350142 1 350142 1 350142 1
81 BLADE SLICING REEL 350147 20 350147 20 350147 20 350147 20
82 PLATE BLADE MTG. 350148 20 350148 20 350148 20 350148 20
83 SPACER BLADE MTG. 350149 10 350149 10 350149 10 350149 10
84 SPACER BLADE ASSY 350150 9 350150 9 350150 9 350150 9
85 SCREWCAP 1/4-20 x 3/4, GR. 5 350151 40 350151 40 350151 40 350151 40
86 NUT LOCK 1/4-20 8142004 40 8142004 40 8142004 40 8142004 40
87 COLLAR SPACER 350152 1 350152 1 350152 1 350152 1
88 WASHER 0.937 x 1.750 x 0.119 350153 1 350153 1 350153 1 350153 1
89 WASHER LOCK 7/8 INT. TOOTH 350154 1 350154 1 350154 1 350154 1
90 NUT JAM 7/8-14 350155 1 350155 1 350155 1 350155 1
SEEDER BOX ASSEMBLY (FOR OS551, AND OS551H MODELS ONLY)
91 BOX SEEDER MAIN BODY ----350321 1 350321 1
92 BRACKET ADJ DROP SEEDER ----350306 1 350306 1
93BARDOORLINKGAGE ----350276 1 350276 1
94 SHAFT PLASTIC DROOP SEEDER ----350320 1 350320 1
95PLATEDOORDROPSEEDER ----350271 1 350271 1
96PLATEDOORDROPSEEDEREND----350272 1 350272 1
97PLATEDOORDROPSEEDERARM----350273 1 350273 1
98 BOX SEEDER LID ASSEMBLY ----350322 1 350322 1
99 SPROCKET 16T #43 0.625 BORE ----350319 1 350319 1
101 BEARING CLIP 1.375 OD ----900321 4 900321 4
102GUARDSPROCKET ----350335 1 350335 1
103SPRINGTENSION ----400217 2 400217 2
104BOLTCARRAIGE5/16-18X1 ----8024040 1 8024040 1
105BOLTCARRIAGE1/4-20X3/4" ----8024021 3 8024021 3
106SCREWSHEETMETAL ----350286 4 350286 4
108BRACKETSLOTSEEDER ----350332 1 350332 1
109SPROCKETWHEEL16T ----350318 1 350318 1
110 WASHER 0.906 OD X 0.656 ID ----350280 4 350280 4
111CHAIN35PITCH ----350329 1 350329 1
112COTTERPIN1/8-1" ----8197031 1 8197031 1
113ROLLPIN1/8-13/4 ----350331 1 350331 1
114WASHER5/16FENDER ----8172020 4 8172020 4
115WASHERLOCK5/16 ----8177011 4 8177011 4
116SCREWCAP5/16-18x3/4 ----8041026 4 8041026 4
117WASHER1/4"SAE ----8172007 3 8172007 3
118NUTHEX10-24 ----8154007 2 8154007 2
119SCREW10-24X3/4 ----8041026 2 8041026 2

Part No. 350324 Form No. F031605A
Page 16 of 16
TROUBLESHOOTING Before Requesting Service Review These Suggestions
Engine stalls or la ors when raking. Raise lades so that they just touch the ground on a
level surface.
Solution
Possible Cause
Problem
Blades set too deep into ground
2
A normal vi ration.
Engine will not start.
Engine is locked, will not
pull over.
De ris locked against reel, or drive pulleys. Engine
pro lem.
Check stop switches, throttle, choke position and
gasoline. Connect spark plug wire. Clean or replace
air cleaner. Contact a qualified service person.
Stop work immediately. Replace any damaged or
missing lades. Tighten all loose olts and nuts.
Damaged or missing lades. Loose handle olts.
Loose engine olts
Stop switch off (Honda only). Throttle in off position.
Engine not in full choke position. Out of gasoline. Bad
or old gasoline. Spark Plug wire disconnected. Dirty air
cleaner. Engine oil level too low (Honda only).
Pull spark plug wire and remove de ris. Contact an
engine servicing dealer for engine pro lems.
MODEL NO.
GENERAL ENGINE SPECIFICATIONS
HORSEPOWER
ENGINE
BRIGGS &
STRATTON
HONDA 5.5
5.5 11 4 2 191E1
GX16 K1QX
GOVERNED RPM
37
36
ENGINE
When servicing engine refer to specific manufacturers engine
owner's manual. All engine warranty is covered y the specific
engine manufacturer. If your engine requires warranty or other
repair work contact your local servicing engine dealer. When
contacting a dealer for service it is a good idea to have your engine
model num er availa le for reference(See ta le page a ove). If
you can not locate a servicing dealer in your area you can contact
the manufacturers national service organization.
To reach:
Briggs & Stratton: 800-233-3723
American Honda: 800-426-7701
Never store engine indoors or in enclosed poorly ventilated
areas with fuel in tank, where fuel fumes may reach an open flame,
spark or pilot light, as on a furnace, water heater, clothes dryer or
other gas appliance.
If engine is to be unused for 3 days or more, prepare as follows:
Remove all gasoline from car uretor and fuel tank to prevent
gum deposits from forming on these parts and causing possi le
malfunction of engine. Drain fuel outdoors, into an approved
container, away from open flame. Be sure engine is cool. Do not
smoke. Run engine until fuel tank is empty and engine runs out of
gasoline.
NOTE: Fuel sta ilizer (such as Sta-Bil) is an accepta le alternative in minimizing
the formation of fuel gum deposits during storage. Add sta ilizer to gasoline in
fuel tank or storage container. Always follow mix ratio found on sta ilizer
container. Run engine at least 10 min. after adding sta ilizer to allow it to reach
the car uretor.
UNIT STORAGE
Engine Service and Warranty
Contact your nearest engine manufacturer's
authorized servicing dealer. (See page 7)
22.1 22
BILLY GOAT INDUSTRIES INC.
1803 S.W. JEFFERSON / LEE'S SUMMIT, MO 64082-2312 / USA
PHONE: [phone] FAX: [phone] www. illygoat.com
WARRANTY PROCEDURE
Purchased
from
Purchase
Date
21 Serial Plate Record your machine model, serial number
and date-of-purchase and where purchased
R
min-1
1803 S. Jefferson
Lee's Summit,
MO 64062 / USA
Tel [phone]
Fax [phone]
Model SerialNo.
Unit(Weight) EnginePower
lbs. kg kW rpm
R
101 dB
Should a Billy Goat Machine fail due to a defect in material and/or
workmanship, the owner should make a warranty claim as follows:
-The Machine must be taken to the dealer from whom it was purchased
or to an authorized Servicing Billy Goat Dealer.
-The owner must present the remaining half of the Warranty
Registration Card, or, if this is not available, the invoice or receipt.
-The Warranty Claim will be completed by the authorized Billy Goat
Dealer and submitted to their respective Billy Goat Distributor for their
territory. Attention: Service Manager. Any parts replaced under
warranty must be tagged and retained for 90 days.
-The distributor service manager will sign off on the claim and submit
it to Billy Goat for consideration.
-The Technical Service Department at Billy Goat will study the claim
and may request parts to be returned for examination. Billy Goat will
notify their conclusions to the distributor service manager from whom
the claim was received.
-The decision by the Quality / Service department at Billy Goat to
approve or reject a Warranty claim is final and binding.
Note: To process a Warranty Claim, it is necessary to quote the Model & Serial
Number which are printed on the Billy Goat Serial Plate (See owner’s manual).
