BIOS Diagnostics 240DI User manual

1 SECOND
EAR THERMOMETER
with
Instruction Manual
Model: 240DI
01.02.2023

240DI
1 Second Ear Thermometer
with Bluetooth®
Instruction Manual
Table of Contents
1 Features
2 Important Safety Instructions
3 Product Diagram
4 How this Thermometer Measures Temperature
5 Setting Date and Time
6 Directions for Use
7 Setting the Beeper
8 Fever Alarm
9 Changing Between Celsius and Fahrenheit
10 Memory Storage
11 Measuring Surface Temperatures
12 Bluetooth®& MediLink App
13 Care and Cleaning
14 Battery Replacement
15 Error Messages
16 Technical Specifications
17 5 Year Warranty

1 Second Ear Thermometer with Bluetooth
Thank you for purchasing the BIOS Diagnostics 1 Second Ear Thermometer with
Bluetooth. This is a high quality product incorporating the latest technology and
tested in accordance with international standards. With its unique technology,
this thermometer can provide safe, accurate and reliable readings with each
measurement on people over 2 years of age.
Indications for Use:
This digital ear thermometer (240DI) is intended to measure the human body’s
temperature in regular mode, within the ear canal from energy radiated from the
eardrum and the surrounding tissue. This device was designed to be reusable for
clinical or home use, on people over 2 years of age.
1. Features
Multiple Uses (Wide Range Measurement)
This thermometer offers a wide measurement range feature from 0°C to 100.0°C
(32.0°F to 212.0°F), meaning the unit can be used as an ear thermometer to
measure body temperature or it can be used to measure surface temperature of
the following:
• Milk surface temperature in a baby’s bottle
• Surface temperature of a baby’s bath
• Ambient temperature
Measurement in 1 Second
The innovative infrared technology allows measurement of ear temperature in
only 1 second.
Multiple Reading Recall
Users will be able to recall the last 30 readings when entering the recall mode,
enabling efficient tracking of temperature variations.
Fever Alarm
10 short beeps and a red LCD backlight alerts the patient that they may have a
temperature above 37.5°C / 99.5°F.
Illuminated Probe
This thermometer includes a probe LED light which enables the user to find the
correct ear position in the dark. The probe will illuminate for approximately 10
seconds when the thermometer is turned ON.
“Clean Me” Technology
After each temperature measurement “clean me” will flash on the LCD to remind
users to clean the probe. See Care and Cleaning section.

Accurate and Reliable
The unique probe assembly construction incorporates an advanced infrared
sensor, ensuring that each measurement is accurate and reliable.
Free MediLink App
This thermometer accurately tracks each family member’s temperature and
connects via Bluetooth®to the FREE MediLink App. The App provides health
insights on fevers, and when to contact a healthcare professional.
Includes normal temperature ranges, measurement techniques and symptoms
parents should watch for.
Please read these instructions carefully before using this thermometer
and keep both in a safe place.
2. Important Safety Instructions
This thermometer may only be used for the purposes described in this booklet.
The manufacturer cannot be held liable for damage caused by incorrect
application.
Never immerse this instrument in water or other liquids. For cleaning
please follow the instructions in the «Care and Cleaning» section.
• Do not use the thermometer if there are any signs of damage. Do not
attempt to repair the thermometer.
• Earwax in the ear canal may cause a lower temperature reading, therefore it
is important to ensure the patient’s ear canal is clean.
• If the measurement result is not consistent with the patient’s finding or
suspiciously low, repeat the measurement every 15 minutes or double check
the result by another core body temperature measurement.
• This thermometer consists of high quality precision parts. Do not drop this
instrument. Protect it from severe impact and shock.
• Keep the thermometer away from direct exposure to the sun and keep it in a
dust-free dry area.
• If the thermometer is not going to be used for a prolonged period the battery
should be removed.
• Battery cover should be installed correctly before use to avoid potential risk
of electric shock.
WARNING:
• Use of this thermometer is not intended as a substitute for consultation with
your physician.
• Ensure that children do not use the instrument unsupervised; some parts are
small enough to be swallowed.
• It is not recommended to use infrared thermometers on children under 2
years of age.

• Infrared thermometers should not be used to manage important health
concerns, and therefore parents should not rely solely on temperature
readings to evaluate the status of your child’s health. If you have any
concerns, consult with a healthcare professional.
Using the unit in the immediate vicinity of mobile phones, microwave
appliances, or other devices with strong electromagnetic fields may result in
impaired functioning.
Do not use this device close to strong electromagnetic fields, such as mobile
telephones or radio installations. Keep a distance from such devices when using
this unit.
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may
cause undesired operation of the device.
3. Product Diagram
Measuring
sensor
Battery compartment cover
M-button (memory)
Power button
Display
START
button

4. How This Thermometer Measures
Temperature
This thermometer measures infrared energy radiated from the eardrum and the
surrounding tissue. This energy is collected through the lens and converted to
a temperature value. The measured reading obtained directly from the eardrum
(Tympanic Membrane) ensures the most accurate ear temperature.
Measurements taken from the surrounding tissue of the ear canal generate
lower readings and may result in misdiagnosis of fever.
5. Setting The Date And Time
1. When using the Ear Thermometer for the first time please remove the plastic
strip located in the battery compartment.
2. Once the Ear Thermometer is powered up, the year digits will flash on the screen.
Or by pressing and holding the M-button for 3 seconds the year digits will flash.
Press the START button to set the year digits. Press the M-button to confirm.
3. Next the month and day will appear on the screen. Press the START button
to set the month digits. Press the M-button to confirm.
4. Follow the same process to set the day, 12/24 hour mode, hours and minutes.
5. Once you have set the minutes and pressed the M-button the date and time
are set and the time is displayed.
- If no button is pressed for 20 seconds, the thermometer automatically
switches to the measuring screen and you are ready to take a reading.
- To cancel time setup, press the button. The LCD will show Date /
Time icons with “--:--”. Press the button to start the measurement.
If no further action is taken within 60 seconds, the thermometer will
automatically turn OFF.
- If the time and date need to be changed at a later time, press and hold
the M button, while the thermometer if OFF, until the year digits start to
flash. Follow steps above to update the time and date
6. Directions For Use
PLEASE NOTE: When you turn the thermometer on by
pressing the button, all segments of the screen will be
shown for 1 second and one beep is heard. (Figure 1)
Figure 1

1. When the thermometer is ready to take a reading the °C or °F icon will be
flashing, and you will see -- - on the screen.
2. Straighten the ear canal by gently pulling the middle of the ear back and up.
3. Place the probe firmly into the ear canal, press the START button and keep
the probe in the ear until the thermometer beeps to signal the completion of
the measurement. The probe LED light will turn OFF once the START button
is pressed to take the measurement.
NOTE:
• Always insert the thermometer in the same ear with the same direction and depth.
• Always clean the probe accordingly before and after each use. (See Care and
Cleaning section).
• It is recommended that you measure the temperature 3 times in the same ear.
If the 3 measurements are different, select the highest one. Allow 30 seconds
between each measurement.
• Before measurements, remain in a stable environment and avoid exercise and
bathing for 30 minutes.
• Readings from different measuring sites should not be compared as the
normal body temperature varies by measuring site and time of day, being
highest in the evening and lowest about one hour before waking up.
Normal body temperature ranges:
- Ear: 35.4 – 37.4°C / 95.7 – 99.3°F
- Axillary / Underarm: 34.7 – 37.3°C / 94.5 – 99.1°F
- Oral: 35.5 – 37.5°C / 95.9 – 99.5°F
- Rectal: 36.6 – 38.0°C / 97.9 – 100.4°F
7. Setting The Beeper
1. When the thermometer is OFF, press and hold the button
for 5 seconds to set the beeper.
2. Press the button again to either turn the beeper ON or OFF.
The beeper is activated when the beeper icon is not crossed
out. (Figure 2)
NOTE: If no button is pressed for 5 seconds, the thermometer
automatically switches to measuring mode.
Figure 2

8. Fever Alarm
If the thermometer detects a body temperature greater than 37.5°C / 99.5°F, it
will make 10 short beeping sounds and the LCD will light up RED, indicating a
potential fever.
9. Changing Between Celsius And Fahrenheit
1. To switch the display between °C and °F, simply turn OFF
the unit, press and hold the START button for 5 seconds;
after 5 seconds, the current measurement scale (°C or °F
icon) will flash on the display (Figure 3).
2. Change the measurement scale between °C and °F by
pressing the START button. When the measurement scale
has been chosen, wait for 5 seconds and the unit will
automatically enter the ready for measuring mode.
10 . Memory Storage
This thermometer recalls the last 30 readings.
• Recall mode: Press the M-button to enter Recall mode
when the power is OFF. The memory icon << M >> will
flash. (Figure 4)
• Reading 1 - the last reading: Press and release the
M-button to recall the last reading. Number 1 and a
flashing M are displayed. (Figure 5)
• The last reading displays the date and time of reading
and the temperature taken. (Figure 6)
• Reading 30 - readings in succession: Press and
release the M-button consecutively to recall the last
30 readings in succession. Pressing and releasing the
M-button after the last 30 readings have been recalled
will resume the above sequence from reading 1.
• Deleting memory: If you want to permanently delete
all stored memory in the thermometer, press and hold
the START button, when in memory mode, until CLR appears. Then press
the START button again, the screen will show PASS and the memory
will be deleted.
11. Measuring Surface Temperatures
1. Press the button. After one beep sounds, the thermometer is ready for use.
2. Aim the thermometer probe at the desired surface and press the START button.
Figure 4
Figure 5
Figure 6
Figure 3

12. Bluetooth®And MediLink App
For the most up to date information on what Android and iOS operating systems
are compatible with our device applications please visit: biosmedical.com, the
Apple Store, or the Play Store.
PLEASE NOTE: Android and iOS system and software updates may render the
app obsolete on older devices.
This thermometer and the MediLink App can work independently of each other.
However, you will want to pair the thermometer and the App before using the
thermometer, as it will send the reading to the App once it is completed.
1. To begin using the free MediLink App, download and install onto your
smartphone or tablet.
2. Turn ON Bluetooth on your device.
3. Open the MediLink App. First time users, will need to register and create a
password.
4. With the app open to the temperature tab, select ‘Add Thermometers’.
(Figure 7)
5. Select your device from the list of thermometers. (Figure 8)
6. Follow the instructions on your phone screen to pair the device. A pop up
asking you ‘Is this your thermometer?’ will appear. Select Yes. (Figure 9)
*Note: Ensure that Bluetooth settings are enabled on your phone before
attempting to pair.
7. Device has paired successfully when you can see the device listed at the
bottom of your app home screen. (Figure 10)
Figure 7 Figure 9Figure 8 Figure 10

Note: For more information on the App and how to use it, visit our website
www.biosmedical.com or call our BIOS Medical Hotline: [phone]
13. Care And Cleaning
Use an alcohol swab or cotton tissue moistened with alcohol (70% Isopropyl)
to clean and disinfect the thermometer casing and the measuring probe.
Ensure that no liquid enters the interior of the thermometer. Never use abrasive
cleaning agents, thinners, or benzene for cleaning and never immerse the
instrument in water or other cleaning liquids. Take care not to scratch the
surface of the probe lens and the display.
It is important to clean the thermometer before and after each use. A build up
of ear wax on the lens reduces the infrared picked up by the sensor, which can
result in lower temperatures. Ear wax is also acidic and can corrode the lens of
the thermometer if not cleaned regularly.
14. Battery Replacement
This thermometer is supplied with one lithium battery type, CR2032.
1. The battery needs replacing when only the icon is shown
on the display. (Figure 11)
2. Remove the battery cover by loosening the screw with a
screwdriver and then removing the battery cover by sliding it
in the direction shown. Remove the battery and replace with
a new one.
NOTE: Battery cover should be installed correctly before use to avoid potential
risk of electric shock.
Figure 11

15. Error Messages
Display Error
Measured temperature too high:
Displays “ ” when measured temperature is
higher than 100°C / 212°F
Measured temperature too low:
Displays “ ” when measured temperature is
lower than 0°C / 32°F
Ambient temperature too high:
Display “ ” when ambient temperature is higher
than 40.0°C / 104.0°F.
Ambient temperature too low:
Displays “ ” when ambient temperature is lower
than 10.0°C / 50.0°F.
Error function display:
The system has a malfunction
Make sure the probe (sensor) is clean and doesn’t
have any ear wax buildup.
Allow 30 minutes for the thermometer to
acclimate to the environment temperature where
the thermometer is being used before starting
measurements
Blank display:
Check if the battery has been loaded correctly.
Also check polarity of the battery.
Flat battery indication:
If only the “ ” icon is shown on the display, the
battery should be replaced immediately.

16. Technical Specifications
Type 1 Second Ear Thermometer with Bluetooth®240DI
Measurement Range 0°C to 100.0°C/32°F to 212.0°F
Resolution 0.1°C/°F
Measurement
Accuracy
Body mode:
±0.2°C, 35.0 - 42.0°C / ±0.4°F, 95.0 - 107.6°F
±0.3°C, 32.0 - 34.9°C and 42.1 - 43.0°C /
±0.5°F, 89.6 - 94.8°F and 107.8 - 109.4°F
Object mode:
±1.0°C, 0 - 100.0°C / ±2°F, 32.0 - 212°F
Display Liquid Crystal Display, 4 digits plus special icons
Acoustic
• The unit is turned ON and ready for the
measurement: 1 short beep
• Complete the measurement:
1 long beep (1 second) if the reading is less
than 37.5°C/99.5°F, 10 short beeps sound
if the reading is equal to or greater than
37.5°C/99.5°F
• System error or malfunction: 3 short beep
sounds
Memory • Auto-Display the last measured temperature
• 30 readings recall in the Memory Mode
Backlight
• The display light will be GREEN for 1 second,
when the unit is turned ON.
• The display light will be GREEN for 5 seconds,
when a measurement is completed with a
reading less than 37.5°C/99.5°F
• The display light will be RED for 5 seconds,
when a measurement is completed with a
reading equal to or higher than 37.5°C/99.3°F
Operating
Temperature
10°C to 40°C/50°F to 104°F 15% - 95% relative
maximum humidity
Storage Temperature -25°C to 55°C/-13°F to 131°F
15% - 95% relative maximum humidity

Automatic Switch-
Off
Approximately 1 minute after last measurement
has been taken.
Battery CR2032 Battery 3V - at least 700 measurements
Expected Service
Life 5 years
Dimensions 139 (L) x 39 (W) x 42 (H) mm
Weight 54.5 g (with battery), 51 g (without battery)
Reference to
Standards
EN 12470-5; ASTM E1965; IEC 60601-1; IEC 60601-
1-2 (EMC), IEC 60601-1-11 This device complies
with the requirements of the Medical Device
Directive 93/42/EEC.
Follow Instructions for Use. This document provides important product
operation and safety information. Please read this document thoroughly
before using the device and keep for future reference.
Type BF Applied part
Batteries and electronic devices must be disposed of in accordance with
the locally Applicable regulations, not with domestic waste.
IP22: Protected against solid foreign objects of 12.5 mm diameter and greater.
Protected against vertically falling water drops when the device is tilted up to 15°.
17. 5 Year Warranty
The 1 Second Ear Thermometer with Bluetooth has a 5 year warranty to be free
of manufacturing defects for the life of the original owner. The warranty does
not cover damage from misuse or tampering.
100% Satisfaction Guarantee
If at any time, you are not completely satisfied with the performance of this
device, call our BIOS Medical Hotline and speak with a customer service
representative, who will make arrangements to have the device tested or
replaced to your full satisfaction.
If you have questions regarding the operation of your thermometer call the
BIOS Medical Hotline: [phone]
Should correction be necessary, return the unit with all component pieces.
Enclose proof of purchase and $5.00 for return shipping and insurance. Ship the
unit prepaid and insured (at owners option) to:

Thermor Ltd.
Returns Department
16975 Leslie Street
Newmarket, ON L3Y 9A1
www.biosmedical.com
Email: [email protected]
Please include your name, return address, phone number, and email address.
Thermor will test or replace (at Thermor’s option) free of charge any parts
necessary to correct the defect in material or workmanship.
Please allow 10 days for return shipping.
