Birlea LYNX 2 DOOR SLIDING ROBE WITH MIRRIOR User manual

Vendor: S000139
Page 1 of 8
ASSEMBLY INSTRUCTIONS
LYNX 2 DOOR SLIDING ROBE WITH MIRROR
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR LYNX 2 DOOR
SLIDING ROBE WITH MIRROR.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT use this item if any parts are missing, damaged or worn.
DO NOT use this item unless all fixings are secured.
Please keep small parts out of reach of children.
Always use on a level, even surface.
CARE & MAINTENANCE:
Assem le in the room of use.
Assem le on a soft, clean surface to prevent damages.
Assem ly should e carried out with this item laying flat, not standing upright.
To remove the printed num ers on the pieces, use a moistened cloth.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the ed frame as this will damage the legs.
Always lift the ed with two people to reposition.
Keep any sharp o jects away from the frame.
www.birlea.com

Vendor: S000139
Page 2 of 8
Parts L st Hardware L st (found n box 2)
Part Descr pt on Box Qty Part Descr pt on Qty
1 Top Panel 2 1 A 8 x 30 mm Wooden Dowel 28
2 Shelf 1 1 B Simple Minifix Screw 20
3 Top Plinth 1 1 C Cam Lock 28
4 Left Panel 1 1 D Plastic Cap 14
5 Right Panel 1 1 E 8 x 50 mm Wooden Dowel 4
6 Shelf Divider 1 1 F 3.5 x 25 mm Screw 6
7 Back Support 1 1 G 3.5 x 20 mm Screw 2
8 Front Support 1 1 H 3.5 x 14 mm Screw 2
9 Back Rail 1 4 I 10 x 10 mm Tack 25
10 Bottom Plinth 1 2 J Small Plastic Foot 4
11 Left Door 2 1 K Dou le Minifix Screw 4
12 Right Door (mirrored) 2 1 L Metal Claw 7
13 Back Panel 2 2 M Rail Support 2
14 Base Panel 2 1 N Open Rail Support 1
15 Handle 1 2 O Metallic Angle Plates 3
16 Top Runner 1 1 P 3.5 x 14 mm Screw 12
17 Bottom Runner 1 1 R Lower Pulley 4
18 Hanging Rail 1 1 S Upper Pulley 4
** You w ll need a small mallet and a
screwdr ver for assembly.
T 3.5 x 14 mm Screw 32
U Door Stopper 1
V 4.5 x 25 mm Screw 1

Vendor: S000139
Page 3 of 8
Step 1: Prepare the parts for assem ly using hardware parts A, B, E, G, H, I, J, K, L, M, N and O. You will need
to use a small mallet and a screwdriver (not provided).
DO NOT use any power tools as th s may damage the frame and w ll nval date any cla m.

Vendor: S000139
Page 4 of 8
Step 2: Attach the ack rails (9) to the ack support (7) using hardware parts A, C and K with a small mallet
and screwdriver (not provided).
DO NOT use any power tools as th s may damage the frame and w ll nval date any cla m.
Step 3: Attach the ack support (7) and front support (8) to the ase panel (14) using hardware parts C, D
and E with a small mallet and a screwdriver (not provided).
DO NOT use any power tools as th s may damage the frame and w ll nval date any cla m.

Vendor: S000139
Page 5 of 8
Step 4: Attach the shelf (2) using hardware parts C, D and K with a screwdriver (not provided).
DO NOT use any power tools as th s may damage the frame and w ll nval date any cla m.
Step 5: Attach the shelf divider (6) and the top panel (1) using hardware parts C and D with a screwdriver
(not provided).
DO NOT use any power tools as th s may damage the frame and w ll nval date any cla m.

Vendor: S000139
Page 6 of 8
Step 6: Attach the ottom plinths (10) to the right panel (5).
DO NOT use any power tools as th s may damage the frame and w ll nval date any cla m.
Step 7: Join the assem led inner frame section to the assem led side frame section using hardware parts C
and D with a screwdriver (not provided).
DO NOT use any power tools as th s may damage the frame and w ll nval date any cla m.

Vendor: S000139
Page 7 of 8
Step 8: Position the hanging rail (18) and attach the left panel (4) using hardware parts C and D with a
screwdriver (not provided).
DO NOT use any power tools as th s may damage the frame and w ll nval date any cla m.
Step 9: Position the ack panels (13) and attach the ottom runner (17) using hardware part T and a
screwdriver (not provided).
DO NOT use any power tools as th s may damage the frame and w ll nval date any cla m.

Vendor: S000139
Page 8 of 8
Step 10: Secure the ack panels (13) using hardware parts I and L with a small mallet (not provided). Attach
the top plinth (3) using hardware part P with a screwdriver (not provided).
DO NOT use any power tools as th s may damage the frame and w ll nval date any cla m.
Step 11: Attach the doors as shown.
DO NOT use any power tools as th s may damage the frame and w ll nval date any cla m.
Additional Information:
• For complete product information, images and dimension diagrams please visit the
website www.birlea.com
• If you have any issues with your item please contact the retailer directly you
purchased it from who will be able to resolve any issues with Birlea.
• Why don’t you send us photos of your assembled furniture to [email protected] to be
shared in our #birleahome feature on Instagram.
