BLUM TANDEM plus BLUMOTION 563F User manual

LIT.TDM563F.PI2.08013
Dimensions in millimeters (inch equivalents as noted)
Subject to technical modifications without notice. © 2013, Blum Inc.
Height adjustment Tilt adjustment
1Press up on adjustment tab
2Push towards back of drawer
Maximum 3(1/8") rise of
drawer front (tool-free)
Rotate the tilt adjustment
lever on the rear of each
runner to tilt the top of the
drawer front forward.
Maximum 5(3/16") rise of
drawer back (tool-free)
NOTE: Height adjustment available on all TANDEM locking devices
TANDEM plus BLUMOTION 563F
New side adjustment New rear side adjustment
Rotate side adjustment left or
right equally on both locking
devices. Drawer front moves in
the same direction as rotation.
with locking device
T51.19xx
After front side adjustment is
made with the locking devices,
rotate the rear side adjustment
left or right to re-align the back
of the drawer box with the front.
Drawer back moves in the
same direction as rotation.
Maximum 1.5 (1/16") to left or right (tool-free)
NOTE: Side adjustment not available on T51.18xx locking devices Maximum 1.5 (1/16") to left or right (tool-free)
R
L
R
L
drawer
front
L
R
L R
New depth adjustment on runner New depth adjustable locking device
TANDEM 563 runners feature
elongated holes that allow
±4.5 (3/16") depth adjustment.
Locking device
T51.1901.PS
with side, height
and depth adjustment
Turning the adjustment screw allows
for up to a +2.5 (3/32") out adjustment
NOTE: For T51.1901.PS setback in inset applications, see the
TANDEM brochure
1
2
New profile setback New bottom mounting
NOTE: Hole locations to the face of the cabinet stay the same.
For inset applications see the TANDEM brochure.
Runner 563F5330B 563F4570B 563F3810B
X448(17-5/8") 378 (14-7/8") 319 (12-9/16")
Drawer insertion Drawer removal
Place drawer on runners and
close. The locking devices
automatically engage with
the runners.
1Squeeze orange handles on
locking devices
2Pull drawer straight out and up
1
2
32 (1-1/4") 37 (1-15/32")
10 (13/32")
37 (1-15/32")
setback 3 (1/8") 3 (1/8")
X
67 (2-5/8")
9 (11/32")
22.5 (7/8")
9 (11/32")
15.5 (5/8")

Dimensions in millimeters (inch equivalents as noted)
Subject to technical modifications without notice. © 2013, Blum Inc. LIT.TDM563F.PI2.08013
TANDEM plus BLUMOTION 563F
TANDEM template
562 runners 562 and 563 runners ■ Color changes from orange to gray
■ Hole locations change to accommodate
new and old locking devices
Part no. Part no.
OLD TANDEM template T65.1000.02 NEW TANDEM template T65.1600.01
Drawer preparation
562F runners New 563F runners ■No change to rear hook hole location,
depth or diameter
■ Rear notch width changes from
33 (1-5/16") to 35 (1-3/8")
■ Mounting screws change from #7 head
to #6 head wood or system screws
screws
606N or 606P
or
662.1150.HG
screws
707N
or
661.1300.HG
7 (9/32")
11 (7/16")
Ø6 x 10
bore for hook
35 (1-3/8") minimum rear notch
13 (1/2")
24.5 (31/32")
7 (9/32")
11 (7/16")
Ø6 x 10
bore for hook
33 (1-5/16") minimum rear notch
13 (1/2")
24.5 (31/32")
Locking devices
562 runners New 563 runners ■9(11/32") difference in mounting hole
location
■ Mounting screws change from #6 truss
head screws to #6 flat head wood
screws
NOTE: T51.17xx locking devices cannot be
used with new 563 runners. T51.18xx and
T51.19xx locking devices cannot be used
with 562 runners.
Part no.
Part no.
Without side adjustment
T51.18xx
Locking devices T51.17xx With side adjustment T51.19xx
24 23
24
32
screws
612TH
screws
606N or 606P
