BLUM COMPACT BLUMOTION 38C Series User manual

Cam side adjustment
Rotate front screw
counter-clockwise to
increase door overlay,
clockwise to decrease.
Range = 3 (1/8")
Large overlay Small overlay
Height adjustment
Loosen center screw.
Adjust door to position
and tighten screw.
Range = 6 (1/4")
Large overlay Small overlay
Door removal
Rotate mounting screw counter-clockwise to
remove hinge from cabinet.
Large overlay Small overlay
2Subject to technical modifications
without notice. © 2010
Cam depth adjustment
Rotate back screw to
adjust door to position.
Range = -1/+2
(-1/32"/+3/32")
COMPACT BLUMOTION and COMPACT 38C/39C and 38N
series

Blum, Inc.
7733 Old Plank Rd.
Stanley, NC 28164
800-438-6788
704-827-1345
fax [phone]
www.blum.com
Technical specifications subject to change without notice.
LIT.HN6400.11.10 © 2010 Printed in USA
COMPACT BLUMOTION deactivation switch on the hinge cup
For small or light doors, the BLUMOTION can
be deactivated on one
of the hinges.
Door must be closed once for the deactiva-
tion to be complete. To reactivate, move
switch back to original position.
1
2
POZI DRIVER and bits
A POZI screwdriver (different from Phillips)
is the most crucial tool you can use to assure that full
torque is applied to all Blum mounting screws. POZI
screws can be identified by the distinctive “tick” marks
located in the center of the screw head recess.
POZI Phillips
Tick marks
COMPACT BLUMOTION 38C/39C and 38N series
Suggested tool for installation and adjustment
