BLUM TANDEM 568R5337BB User manual

NOTE: Drawer and bins not included
Description Basic components
Application
■ Pre-assembled bottom mount set
■ TANDEM plus BLUMOTION heavy duty full
extension concealed drawer runners
■ For 15", 18" and 21" wide cabinets with
12", 15" and 18" minimum opening widths
■ For 16 (5/8") max. drawer side thickness
■ For face frame and panel applications
■ Tool-free height and tilt adjustment
■ Maximum 6 (1/4") cabinet bottom recess
■ 125 lb static, 110 lb dynamic load rating
■ SERVO-DRIVE touch-to-open feature
Components
TANDEM waste/recycle set
Set includes:
■ TANDEM plus BLUMOTION heavy duty runner set with
pre-mounted #6 x 1" wood screws for installation (qty 8)
■ Standard locking device (qty 2) with #6 x 1/2" truss head wood
screws for installation (qty 4)
■ Installation template and instructions
TANDEM waste/recycle set Drawer length Part no.
For 12" min. opening width 533 (21")
568R5337BB
For 15" min. opening width 533 (21")
568R5337BD
For 18" min. opening width 533 (21")
568R5337BF
SERVO-DRIVE waste/recycle set
Set includes:
■ Drive unit (pre-attached)
■ Double bottom bracket with #6 x 1" wood screws (qty 2)
■ Adapter plate
■ 110V plug-in power supply with six feet of universal cable
■ Screw-on distance bumpers (qty 4) with #6 x 5/8" wood screws
for installation (qty 8)
■ INSERTA cable connector
■ Cable end protectors (qty 2)
■ Cable clips (qty 4)
■ Installation template, instructions and user manual
Part no.
SERVO-DRIVE waste/recycle set Z10NA20UGUS
NOTE: Power supply will operate up to two drive units in a double bottom bracket application (second drive unit sold separately)
1
2
1
2
SERVO-DRIVE
inside
BLUMOTION
inside
4
1
7
6
5
4
3
2
1
2
3
7
6
5
8
8
© 2011 Blum, Inc. Subject to technical modifications without notice.
6
TANDEM waste/recycle set
with SERVO-DRIVE

Drawer back preparation
Bin width and height must be
considered when designing your
cabinet and drawer (see diagram to
the left).
Minimum inside cabinet depth
With SERVO-DRIVE 577 (22-11/16")
Without SERVO-DRIVE 556 (21-7/8")
Front view
Drawer and cabinet specifications
Waste/recycle set
Min. inside cabinet
opening width
For drawer side thickness
16 (5/8") 15 (19/32") 14 (9/16") 13 (1/2") 12 (15/32")
568R5337BB 305 (12")
295 (11-5/8") 293 (11-17/32") 291 (11-7/16") 289 (11-3/8") 287 (11-9/32")
568R5337BD 381 (15")
371 (14-5/8") 369 (14-17/32") 367 (14-7/16") 365 (14-3/8") 363 (14-9/32")
568R5337BF 457 (18")
447 (17-5/8") 445 (17-17/32") 443 (17-7/16") 441 (17-3/8") 439 (17-9/32")
NOTE: Drawer length is 533 (21") for all sets Outside drawer width
NOTE: Detailed drawings of recommended drawer box specifications are available at blum.com
Important
minimum top
clearance
6(1/4")
Inside cabinet width
outside drawer width
drawer side
thickness
16 (5/8") max.
14 (9/16") to 21 (13/16")
bottom clearance
depending on bottom recess
inside cabinet opening width
opening height
maximum height
with bin =
opening height
minus 27 (1-1/16")
13 (1/2")
21 (13/16")
Installation
Place drawer on runners
and close. Locking devices
automatically connect to
runners.
Removal
Squeeze orange release
levers on locking devices
Pull drawer out and up
Height adjustment
Press up on adjustment tab
Push toward back of drawer
Maximum 3 (1/8") rise of
drawer front
Tilt adjustment
Rotate the tilt adjustment lever
on the rear of each runner to
tilt the top of the drawer front
forward. This allows a tool-free
tilt adjustment of +5(3/16").
1
2
1
2
1
2
7 (9/32")
11 (7/16")
Ø6 x 10
bore for hook
35 (1-3/8") minimum rear notch
13 (1/2")
Dimensions in millimeters (inch equivalents as noted) © 2011 Blum, Inc. 7
Specifications
SERVO-DRIVE
inside
BLUMOTION
inside
