BLUM SPACE TOWER SLIM User manual

SPACE TOWER SLIM INSTRUCTIONS
Page | 1

SPACE TOWER SLIM INSTRUCTIONS
Page | 2
List of Parts required
PZ2 Screwdriver x 1
Drill bit either 2.5mm or 5mm diameter dependant on
which screw style* is to be used to fix runners to
cabinet
Hand drill to produce holes in cabinet (assuming not
already produced)
Tape measure to locate fixing points in cabinet as
detailed in following pages
Note: Alternatively, specific jigs are available from
www.blumkit.co.uk for fast & accurate installation
*For information on screws of fixing methods to suit the materials used, please
refer to your carcase drawer supplier. For number, and position of fixings see
https://publications.blum.com/2018/catalogue/en/260/

SPACE TOWER SLIM INSTRUCTIONS
Page | 3
Typical cabinet assembly

SPACE TOWER SLIM INSTRUCTIONS
Page | 4
Note: 20mm drilling point for horizontal plates, 37mm for cruciform (we recommend
to use 3 fixing points in either case)

SPACE TOWER SLIM INSTRUCTIONS
Page | 5
X4
1
2
3
Drawer assembly

SPACE TOWER SLIM INSTRUCTIONS
Page | 6
Screws x 6
Per drawer
4
5
6
