BLUM TANDEM plus BLUMOTION 563H User manual

Drawer insertion Drawer removal
1. Squeeze orange handles on
locking devices
2. Pull drawer straight out and up
1. Place drawer on runners and
close. Locking devices will
automatically connect to runners.
INST-TDM563H.03.12
Subject to technical modifications without notice. © 2012 Blum, Inc.
New side adjustment New rear side adjustment
2. After front side adjustment is
made with the locking devices,
rotate the rear side adjustment left
or right to re-align the back of the
drawer box with the front. Drawer
back moves in the same direction
as rotation.
R
L
R
L
drawer
front
1. Rotate side adjustment left
or right equally on both locking
devices. Drawer front moves in
the same direction as rotation.
with locking device
Maximum 1.5 (1/16") to left or right (tool-free) Maximum 1.5 (1/16") to left or right (tool-free)
Height adjustment
Tilt adjustment
Rotate the tilt adjustment lever
on the rear of each runner to
tilt the top of the drawer front
forward.
1. Press up on adjustment tab
2. Push towards back of drawer
Maximum 5 (3/16") rise of drawer back (tool-free)Maximum 3 (1/8") rise of drawer front (tool-free) 1
2
New depth adjustment on runner
TANDEM 563 runners feature elongated holes
that allow +/- 4.5 (3/16") depth adjustment.
Turning the adjustment screw allows for up to a + 2.5 (3/32") out adjustment
T51.1901.PS
Locking device
with side, height and
depth adjustment
New profile setback New bottom mounting
L
R
See blum.com for complete technical specifications and installation instructions.
3 (1/8")
X
67 (2-5/8")
9 (11/32")
12 (15/32")
19 (3/4")
9 (11/32")
32 (1-1/4") 37 (1-15/32")
10 (13/32")
37 (1-15/32")
setback 3(1/8")
New depth adjustable locking device
Runner 563H5330B 563H4570B 563H3810B All 563.
X448 (17-5/8") 378 (14-7/8") 319 (12-9/16") 358 (14-3/32")
TANDEM plus BLUMOTION 563H/563.
T51.19xx
NOTE: Hole locations to the face of the cabinet stay the same. For inset
applications see the TANDEM brochure
NOTE: For T51.1901.PS setback in inset applications, see the TANDEM brochure
NOTE: Side adjustment not available on T51.18xx locking devices
NOTE: Height adjustment available on all TANDEM locking devices
BAU0026348946 INDR 1091737 MA-578/0EN TAND 563H/.-B
Drawer preparation
562H/562. runners New 563H/563. runners ■ No change to rear hook hole location, depth
or diameter
■ Rear notch width changes from 33 (1-5/16")
to 35 (1-3/8")
■ Mounting screws change from #7 head to
#6 head wood or system screws
TANDEM template
562 runners New 563 runners ■ Color changes from orange to gray
■ Hole locations change to accommodate
new locking devices
Part no. Part no.
562/568 template T65.1000.02 563/569 template T65.1600
Locking devices
562 runners New 563 runners ■9 (11/32") difference in mounting hole
location
■ Mounting screws change from #6 truss
head screws to #6 flat head wood screws
Part no.
Part no.
Without side adjustment
T51.18xx
Locking devices T51.17xx With side adjustment T51.19xx
24 23
24 32
606N or 606P
Screws
612TH
Screws
TANDEM plus BLUMOTION
See blum.com for complete technical specifications and installation instructions.
7 (9/32")
1 1 (7/ 1 6")
Ø6 x 1 0
bo r e f or hook
33 (1-5/16") minimum rear notch
13 (1/2")
21 (13/16")
7 (9/32")
1 1 (7/ 1 6")
Ø6 x 1 0
bo r e f or hook
35 (1-3/8") minimum rear notch
13 (1/2")
21 (13/16")
707N
Screws
606N or 606P
Screws
661.1300.HG
or
662.1150.HG
or
NOTE: T51.17xx locking devices cannot be used
with new 563 runners. T51.18xx and T51.19xx
locking devices cannot be used with 562 runners.
