General instructions
About this Rider's Manual. . . . . . . . . . . . 6
Abbreviations and symbols . . . . . . . . . . 6
Equipment........................... 8
Technicaldata....................... 8
Actuality ............................. 8
1
5
z General instructions

About this Rider's
Manual
Read this Rider's Manual before
you start your new E-Scooter.
Here you will find important in-
formation concerning operation
of the vehicle which will allow
you to get the best out of the
advanced engineering of your E-
Scooter.
In addition, you will find inform-
ation on servicing and care that
will help with safety in use and
on the road, and will ensure that
your vehicle keeps its value.
Overview
Chapter 2 of this Rider's Manual
contains an initial overview of
your E-Scooter. Chapter 13 doc-
uments all the service and main-
tenance tasks that have been
carried out. This record of the
maintenance work you have had
performed on your vehicle is a
precondition for generous treat-
ment of goodwill claims.
Sale of the E-Scooter
Make sure that you also pass on
the Rider's Manual if you should
one day sell your E-Scooter. The
Rider's Manual is an important
part of your vehicle.
The high-voltage system on
your E-Scooter
Your E-Scooter is an electric
vehicle. The vehicle is fitted with
a high-voltage system which in-
cludes an electrical machine and
a high-voltage battery.
Warning sticker on vehicle
components
The warning sticker on vehicle
components warns you that there
is a danger of being critically
injured if you do not handle high-
voltage technology or high-
voltage components correctly.
Abbreviations and
symbols
CAUTION Low-risk hazard.
Non-avoidance can lead to
slight or moderate injury.
1
6
z General instructions

WARNING Medium-risk
hazard. Non-avoidance can
lead to fatal or severe injury.
DANGER High-risk haz-
ard. Non-avoidance leads
to fatal or severe injury.
ATTENTION Special
notes and precautionary
measures. Non-compliance can
lead to damage to the vehicle or
accessory and, consequently, to
voiding of the warranty.
NOTICE Specific instruc-
tions on how to operate,
control, adjust or look after items
of equipment on the vehicle.
Indicates the end of an
item of information.
Instruction.
Result of an activity.
Reference to a page with
more detailed informa-
tion.
Indicates the end of a
passage relating to spe-
cific accessories or items
of equipment.
Tightening torque.
Technical data.
OE Optional extras.
The vehicles are as-
sembled complete with
all the BMW Motorrad
optional extras originally
ordered.
OA Optional accessories.
You can obtain
BMW Motorrad
optional accessories
through your authorised
BMW Motorrad dealer;
optional accessories
have to be retrofitted to
the vehicle.
EWS Electronic immobiliser.
DWA Anti-theft alarm (Dieb-
stahlwarnanlage).
ABS Anti-lock brake system.
IC-
CPD
(In Cabel Control and
Protecting Device) Elec-
tronics module between
infrastructure and elec-
tric vehicle to increase
protection level and con-
trol the charging proced-
ure.
1
7
z General instructions

RBS Regenerative brake sys-
tem (brake system with
energy recovery).
TCA Torque Control Assist.
Equipment
When you ordered your E-
Scooter, you chose various
items of custom equipment.
This Rider's Manual describes
the optional extras (OE) offered
by BMW and selected optional
accessories (OA). This explains
why the manual may also contain
descriptions of equipment which
you have not ordered. Please
note, too, that your vehicle might
not be exactly as illustrated
in this manual on account of
country-specific differences.
If your E-Scooter was supplied
with equipment not described
in this Rider's Manual, you will
find these features described in
separate manuals.
Technical data
All dimensions, weights and
power ratings stated in the
Rider's Manual are quoted to the
standards and comply with the
tolerance requirements of the
Deutsches Institut für Normung
e.V. (DIN). Versions for individual
countries may differ.
Actuality
The high safety and quality
standards of BMW E-Scooters
are maintained by constant
development work on designs,
equipment and accessories.
Because of this, your vehicle
may differ from the information
supplied in the Rider's Manual.
Nor can BMW Motorrad entirely
rule out errors and omissions.
We hope you will appreciate that
no claims can be entertained on
the basis of the data, illustrations
or descriptions in this manual.
1
8
z General instructions
