Bosch B465 User manual

1 | Overview
2 | Installation
This section describes basic installation procedures.
For information on configuration, LED descriptions, and
troubleshooting refer to the B465 Installation and Operation
Guide (P/N: F01U311207).
CAUTION!
Remove all power (AC and battery) before making
any connections. Failure to do so might result in
personal injury and/or equipment damage.
NOTICE!
Notify the central station and the local authority
before installing the B465 in an existing system.
2
3
7
13
15
1
4
5
8
9
6
10
11
TMPR
BAT
ETHERNET
EXTERNAL
ANNUNC
X
MODULE 1
Y
MODULE
RELEASE
1 COM 2 3 COM 4 T R
PNL LINE 1
C NO
RELAY2
16.5VAC
NC C NO
RELAY1
TRBL
TX
RX
PWR
PANEL
LINE 2
USB
ETHERNET
100BASE-T
LINK
COMMUNICATION MODULE 1
3 COM 41 COM 2
R Y G B
SDI2
Device Bus
BATTERY
PANEL
LINE 1
BATTERY
POWER
RX
TX
SYSTEM TROUBLE
INPUTS
2.2 k End of
Line Resistors
C NO
RELAY3 12V
AUX COM
161214
T R
PNL LINE 2
24 VDC
or
16.5 VAC
+ -
BATTERY
The B465 Conettix Universal Dual Path Communicator links the
digital dialer from a intrusion/fire control panel to an Ethernet
connection on a local area network (LAN) or wide area network
(WAN).
Callout ― Description Callout ― Description
1― Holes to stabilize plug-in
modules
9― Control panel phone line
connectors
2 ― Plug-in module connector 10 ― Input loop terminals
(COM 1to COM 4)
3 ― Plug-in module retention clip 11 ― 12V AUX/COM terminal
4 ― Ethernet connector 12 ― Programmable output
relays to a control panel
5 ― USB connector 13 ― Heartbeat LED
6 ― Status LEDs (SYSTEM
TROUBLE, TX, RX, POWER, and
BATTERY)
14 ― 12 VDC sealed lead-acid
rechargeable battery terminals
7― External Annunciator
connector (connected to a B46)
15 ― Earth ground terminal
8 ― Tamper switch 16 ― 16.5 VAC or 24 VDC
power supply input terminals
2.1 | Remove enclosure knockouts 2.5 | Apply the wiring label into the enclosure
Apply the supplied wiring label to the inside, enclosure door.
Refer to the graphic in section 2.3 for wiring label location.
Callout ― Description
1― Suggested knockout locations for B465 wiring
2 ― Knockouts for B46 LED cover and module (optional for non-fire
applications)
3 ― Lockset mounting knockout
1
1
1
1
3
2
4
2.3 | Install the enclosure
Install the UL Listed enclosure such as the B10/B10R, B11/
B11R, or D8103 enclosure in the desired location.
2.4 | Install enclosure earth ground wiring
Install the supplied earth ground wire onto the inside clip of
the supporting enclosure door. Refer to the folowing graphic for
ground wire location.
Review knockout locations before installing. Each enclosure is
slightly different regarding knockout locations. Use a hammer
and punch tool to remove the desired knockout locations. Use
pliers to remove metal debris.
Callout ― Description
1― B10/B10R enclosure
2 ― B11/B11R enclosure
3 ― Mounting plastic standoff locations for B465
2
3
3
1
1233
3
3
4
5
Callout ― Description
1― B465 wiring label (label insertion location)
2 ― Earth ground wiring enclosure location
3 ― Enclosure mounting holes (4)
4 ― B46 mounting locations*
5 ― Tamper switch mounting locations (optional)
* Use the upper, right-hand 3-hole mounting location for installing the optional B46
module in a B10 enclosure.
2.6 | Install plastic standoff
Snap the four supplied plastic standoffs onto four enclosure
support posts. Refer tothe following graphics.
Callout ― Description
1― Module with mounting bracket installed
2 ― Enclosure (side wall)
3 ― Mounting screws (3)
1
3
2
Callout ― Description
1― B46
2 ― Enclosure
2
1
2.8 | Install the B46 module (optional)
Install the B46 into the enclosure’s side, 3-hole mounting
pattern using the supplied mounting screws. Refer to
the following graphics. For more information on the B46
installation, refer to the B46 Installation and Operation Guide
(P/N: F01U312441).
2.7 | Installing the screws
Install the B465 into the enclosure’s 4-hole plastic standoffs
using the supplied screws and a slotted screwdriver. Refer
to the graphic below.
NOTICE!
The SDI2 Device Bus terminal connector located
above callouts 11 and 12 is for future use.
2.9 | Install the cellular module (optional)
Install the module into the slot of the B465 until the module
“clicks” into place. Refer to Figure 2.9.
Callout ― Description Callout ― Description
1― B44x cellular module 3 ― B465
2 ― Antenna
TMPR
BAT
ETHERNET
EXTERNAL
ANNUNC
X
MODULE1
Y
MODULE
RELEASE
1 COM 2 3 COM 4 T R
PNLLINE 1
C NO
RELAY2
+ BAT-16.5VAC
NC C NO
RELAY1
TRBL
TX
RX
PWR
P
P
ANEL
ANEL
LINE2
LINE2
USB
USB
ETHERNET
ETHERNET
100BASE
100BASE
-
-
T
T
LINK
LINK
C
C
OMMUNI
OMMUNI
C
C
A
A
TION MODULE 1
TION MODULE 1
3
3
C
C
OM 4
OM 4
1
1
C
C
OM 2
OM 2
R
R
Y
Y
G
G
B
B
SDI2
SDI2
D
D
e
e
viceBus
viceBus
BAT
TE
TERY
P
P
ANEL
ANEL
LINE1
LINE1
B
B
A
A
T
T
TE
TE
R
R
Y
Y
POWER
POWER
RX
RX
TX
TX
S
S
Y
Y
S
S
TEMT
TEMT
R
R
OUBLE
OUBLE
INPU
INPU
T
T
S
S
2.2k Endof
2.2k Endof
L
L
ine
ine
R
R
e
e
si
si
s
s
t
t
o
o
r
r
s
s
C NO
RELAY3
12V
AUXCOM
T R
PNLLINE 2
24
24V
DC
DC
or
or
16.5VAC
16.5VAC
1 2
3
2.10 | Wire to the control panel
Refer to the enclosure wiring label supplied with the B465, or
the B465 Installation and Operation Guide for specific wire routing
information. Refer tothe following graphic for basic wiring
routes.
NOTICE!
The dialer message format sent by the B465 will
be the same dialer format which is transmitted to
the Central Station receiver from the Alarm control
panel. For example, if the SIA dialer format is sent
from the control panel to the B465, the B465 sends a
SIA dialer format to the Central Station receiver.
