Bosch Digital Congress Network User manual

Digital Congress Network - DCN
Installation and Operating Manual
Digital Congress Network en
Security Systems
Get other manuals https://www.bkmanuals.com

Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
en | i
DCN
Digital Congress Network
Bosch Security Systems B.V.
© 2003
All rights strictly reserved.
Reproduction by third parties in any form is strictly forbidden, unless prior written authorisation has been given. In
the continuing quest for product improvement BOS H reserves the right to change the specification of any article or
system without prior notice.
Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
en | ii
IMPO TANT SAFEGUA DS
Prior to installing or operating this product always read the Safety Instructions,
which are available as a separate document.
Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
en | iii
About this Manual
This manual is a comprehensive guide to the installation and operation of the Digital Congress
Network System DCN. For portability and ease of use, this manual combines both installation details
and a comprehensive section on individual and system operational procedures.
The manual is divided into the following chapters:
•Chapter 1. Introduction
Chapter 1 provides an introduction to the DCN system, as well as introducing the user to its
System Philosophy based on the new technology recently introduced into congress systems.
•Chapter 2. to Chapter 9. Equipment Description.
Chapters 2 to 9 provide a comprehensive detailed description of all system units that combine
to make up the DCN system.
•Chapter 10. Installation Techniques
Chapter 10 provides an introduction to the fundamentals of system design as well as a detailed
description on how to install, configure and interconnect the DCN system units.
•Chapter 11. System Operation
Chapter 11 provides a comprehensive and detailed description on how to set-up and operate
DCN’s main system items and its individual units.
•Chapter 12. Environmental Conditions and Maintenance
Chapter 12 gives the environmental conditions in which the DCN system should operate.
A section on maintenance is also included describing how to clean and store the DCN system
units.
•Chapter 1 . Technical data
Chapter 13 gives both the mechanical and electrical details of the DCN system.The mechanical
section gives the dimensions of individual units.The electrical section gives the technical specifica-
tion of the DCN system.
Microsoft® Windows® are registered trademarks of the Microsoft Corporation. IBM is a registered
trademark. Pentium is a registered trademark of Intel Corporation.
Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
en | iv
This page has been left blank intentionally
Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
Digital Congress Network | Installation and Operating Man al | Table of Contents
en | v
Table of Contents
Table of Contents
Chapter 1. Introduction Digital Congress Network (DCN) ............................1-1
1.1 Contrib tion eq ipment .................................................................................. 1-1
1.2 Central Control Eq ipment ............................................................................ 1-1
1.3 Sim ltaneo s Interpretation and Lang age Distrib tion Eq ipment .... 1-2
1.4 Information display eq ipment ....................................................................... 1-2
1.5 Application software packages ..................................................................... 1-2
1.6 Installation eq ipment. ..................................................................................... 1-3
1.7 Q ick reference to DCN’s f nctions ............................................................ 1-4
1.8 DCN Software packages ................................................................................ 1-4
1.8.1 Microphone Management software ....................................... 1-4
1.8.2 Synoptic Microphone Control ................................................ 1-4
1.8.3 Sim ltaneo s Interpretation .................................................... 1-4
1.8.4 Lang age Distrib tion .............................................................. 1-4
1.8.5 Voting ............................................................................................ 1-5
1.8.6 Attendance Registration and Access Control .................... 1-5
1.8.7 Intercom ....................................................................................... 1-5
1.8.8 Text/Stat s Information Displays ............................................ 1-5
1.8.9 A tomatic Camera Control ..................................................... 1-5
1.8.10 Delegate Database software .................................................. 1-5
1.8.11 ID-Card Encoder software ...................................................... 1-5
1.8.12 Message Distrib tion software ............................................... 1-5
1.8.13 System Installation software ................................................... 1-5
1.8.14 Video Display .............................................................................. 1-5
1.8.15 M lti-CCU Control .................................................................... 1-5
1.8.16 DCN Start p ............................................................................... 1-6
1.8.17 DCN Open Interface ................................................................. 1-6
1.9 Glossary of Abbreviations and Acronyms ................................................... 1-7
Chapter 2. Contribution Equipment ....................................................................2-1
2.1 CONTRIBUTION EQUIPMENT .................................................................... 2-1
2.1.1 Table-top Contrib tion nits .................................................... 2-1
2.1.2 Delegate nit ............................................................................... 2-2
2.1.3 Chairman nit ............................................................................. 2-2
2.1.4 ‘Microphone Only’ F nction .................................................... 2-2
2.1.5 Interpreter desk .......................................................................... 2-2
2.2 LBB 3530/xx and LBB 3531/xx Delegate Disc ssion Unit .................... 2-3
2.3 LBB 3533/xx and LBB 3534/xx Chairman Disc ssion Unit ................... 2-3
2.3.1 Adj stment setting disc ssion nits ...................................... 2-4
2.3.2 Interconnection details disc ssion nits .............................. 2-5
2.3.3 Mo nting disc ssion nits (FIG. 2-6) ................................... 2-5
2.4 LBB 3544/00, LBB 3545/00 and LBB 3546/00
Delegate conference nits (Concent s) ..................................................... 2-6
2.5 LBB 3547/00 Chairman Conference Unit
(Concent s) .......................................................................................................2-7
2.5.1 Adj stment setting conference (Concent s) nits ...........2-9
2.6 LBB 3549/00, LBB 3549/50 Pl ggable Microphones ........................ 2-10
2.7 LBB 3555/00 Intercom handset ............................................................... 2-10
2.8 Fl sh-mo nted Contrib tion eq ipment ................................................... 2-11
2.9 LBB 3535/00 D al A dio Interface nit ................................................. 2-12
2.9.1 Fl sh Mo nting Sol tions .......................................................2-13
2.10 LBB 3536/00, /10 Hand-microphones ................................................... 2-15
2.11 LBB 3540/15 M lti-p rpose connection nit ........................................ 2-15
2.11.1 Fl sh Mo nting Sol tions .......................................................2-17
2.12 LBB 3537/00, LBB 3537/50 Delegate microphone with
control panel ................................................................................................... 2-20
2.13 LBB 3537/10 Chairman microphone with control panel .................... 2-21
2.14 LBB 3537/20 Pl ggable Microphone control panel ............................ 2-21
2.15 LBB 3538/00 FM Lo dspeaker panel .................................................... 2-22
2.16 LBB 3541/00 FM Delegate Voting Control panel ................................ 2-22
2.17 LBB 3542/00, LBB 3542/20 FM Delegate/Chairman voting
control panel with LC-display ...................................................................... 2-23
2.18 LBB 3543/15 FM Chip-Card Reader ...................................................... 2-24
2.19LBB 4159/00 Set of 100 Chip Cards .....................................................2-24
2.20 LBB 4157/00 Chip Card Encoder ............................................................ 2-25
2.20.1 Position of the DIP switches ................................................ 2-25
2.21 LBB 3524/00, LBB 3524/10 and LBB 3526/10FM Electronic
channel selector panel .................................................................................. 2-27
2.22 LBB 3525/00 Table top ho sing for Channel selector or
Voting control panel ...................................................................................... 2-29
2.23 LBB 3539/00 Blanking panels ................................................................. 2-29
2.24 LBB 3527/00 Table top ho sing .............................................................. 2-29
Chapter . Interpretation Equipment ................................................................. -1
3.1 LBB 3520/10 Interpreter desk with back-lighting LC-display .............. 3-1
3.1.1 Removal cable g ide (Interpreter desk LBB 3520/10) .....3-4
3.1.2 Installing Intercom Handset to LBB 3520/10......................3-4
3.1.3 LBB 3513/00 Analog A dio Inp t/o tp t Mod le .............3-5
Chapter 4. Central Control Equipment ..............................................................4-1
4.1 Introd ction Central control eq ipment ....................................................... 4-1
4.2 LBB 3500/05, LBB 3500/05(D) Basic Central Control Unit ................4-2
4.3 LBB 3500/15, LBB 3500/15(D) Central Control Unit ............................4-2
4.4 LBB 3500/35, LBB 3500/35(D) M lti Central Control Unit ..................4-2
4.4.1 CCU Mains voltage and adj stment .....................................4-5
4.4.2 CCU Mains cable, pl g and socket ......................................4-5
4.4.3 CCU Mains f se rating ............................................................4-5
Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
Digital Congress Network | Installation and Operating Man al | Table of Contents
en | vi
Table of Contents
4.5 CCU Tr nk Comm nication Board (TCB4) ............................................... 4-6
4.5.1 Installation ........................................................................................... 4-6
4.5.2 S9 DIP-Switch settings .................................................................. 4-7
4.5.3 J mper settings .................................................................................. 4-7
4.6 CU Protocol and Serial Port settings .......................................................... 4-8
4.6.1 LBB 3500/05 Port 1 for Camera Control ................................... 4-8
4.6.2 LBB 3500/15 and LBB 3500/35 (TCB 4)................................... 4-8
4.7 M lti-CCU card ................................................................................................. 4-9
4.7.1 Installation ............................................................................................ 4-9
4.7.2 DIP-Switches S12 and S13 ............................................................ 4-9
4.7.3 J mper settings .................................................................................. 4-9
4.7.4 LED indications .................................................................................. 4-9
4.8 Connecting peripheral eq ipment to the CCU ........................................4-11
4.9 CCU A dio Ro ting Modes ........................................................................4-12
4.9.1 A dio Ro ting INSERTION mode .............................................. 4-13
4.10 LBB 4106/00, LBB 4106/00D Extension power s pply nit .............4-14
4.11 LBB 3508/00 & LBB 3508/00D A dio Media Interface and
Power S pply Unit .........................................................................................4-15
4.12 19” Rack Mo nting DCN Control Units ....................................................4-16
Chapter 5. DCN Control using Personal Computers ......................................5-1
5.1 Minim m Software and hardware req irements ........................................ 5-1
5.2 LBB 3510/00 PC Network card ................................................................. 5-2
5.2.1 Installing PC-Network card ............................................................. 5-3
5.2.2 Interconnections PC Network card ............................................... 5-3
5.3 Windows and DCN Software mod les ....................................................... 5-3
5.4 LBB 3511/00 PC Card for M lti-CCU Systems ..................................... 5-4
5.4.1 Installing PC-Card for M lti-CCU systems ................................. 5-4
5.4.2 LBB 3511/00 DIP-switch S12 and S13 settings ....................... 5-5
5.5 Connection PC to CCU .................................................................................. 5-6
5.6 PC NETWORK SYSTEM ............................................................................... 5-9
5.7 Software config ration Master CCU PC (OS/2) ....................................... 5-9
5.8 Connecting Peripheral devices ...................................................................5-13
Chapter 6. DCN Camera Control ..........................................................................6-1
6.1 Allegiant Video Switcher ................................................................................. 6-1
6.1.1 Allegiant Switcher Control Keyboards .................................. 6-1
6.1.2 Cameras and Monitors ............................................................. 6-1
6.1.3 INSTALLATION .......................................................................... 6-2
6.1.4 Set- p Camera config ration .................................................. 6-5
6.2 Direct Camera Control .................................................................................... 6-6
6.2.1 Virt al Keyboard ......................................................................... 6-6
6.2.2 Camera and Monitor ................................................................. 6-6
6.2.3 Installation ................................................................................... 6-6
6.2.4 Set- p Camera Config raion .................................................. 6-7
6.2.4.1Stand-alone DCN system .................................................... 6-7
6.2.4.2DCN PC controlled system with single CCU .................6-8
6.3 Switching options sing a personal comp ter ...........................................6-8
Chapter 7. DCN Installation accessories ..........................................................7-1
7.1 Introd ction Installation accessories ............................................................7-1
7.1.1 LBB 4114/00 Tr nk-cable splitter 7 .................................................-2
7.1.2 LBB 4115/00 Tap-off Unit ............................................................... 7-2
7.1.3 Cable assemblies and connectors ................................................ 7-3
7.1.4 Connectors ......................................................................................... 7-4
7.1 .5 LB B 4117/00 Set of 25 cable locking clamps ........................... 7-4
7.1.6 LBB 4118/00 Termination pl g for DCN Cable ........................ 7-4
Chapter 8. Information Displays ......................................................................... 8-1
8.1 LBB 3512/00 Data Distrib tion Board ......................................................8-1
8.1.1 Remote Switching Sol tions ........................................................... 8-3
8.1.2 Installing Data Distrib tion board LBB 3512/00. .......................8-4
8.1.3 Connecting Hall Displays to the DCN System ...........................8-4
8.1.4 Interconnection for Video hall displays and Video
Projectors ............................................................................................8-5
Chapter 9. DCN Peripheral Equipment ..............................................................9-1
9.1 Introd ction Peripheral Eq ipment ...............................................................9-1
9.1.1 Telos Digital Telephone Interface ...................................................9-1
Chapter 10. Installation Techniques ...................................................................10-1
10.1 Introd ction Installation Techniq es .......................................................... 10-1
10.1.1 System design f ndamentals ........................................................10-1
10.2 Power Handling Capacity ............................................................................ 10-2
10.3 Tr nk o tlets and Tap-offs ........................................................................... 10-3
10.3.1 Tap-off limitations .............................................................................10-3
10.3.2 Using Tap-Off nit LBB 4115/00 .................................................10-5
10.3.3 Maxim m cable lengths sing Tr nk-o tlets
and/or Tap-offs .................................................................................10-5
10.4 Calc lating the PCF of a System with respect to cable length .......... 10-6
10.4.1 Calc lating Step-by-Step ..............................................................10-6
10.4.2 Graph explanation ...........................................................................10-8
10.4.3 Graph reference examples ............................................................10-9
10.5 Control Capacity ..........................................................................................10-10
10.6 Stand-alone Systems ..................................................................................10-10
10.6.1 Basic System (witho t extension nits) ...................................10-10
10.6.2 System layo t (witho t extension nits) ...................................10-11
10.6.3 System with Extension nits ........................................................10-11
10.7 Comp ter Based Systems ........................................................................10-12
10.7.1 PC Network System ......................................................................10-14
10.8 M lti-CCU system .......................................................................................10-15
10.8.1 M lti-CCU and PC interconnection ..........................................10-15
Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
Digital Congress Network | Installation and Operating Man al | Table of Contents
en | vii
Table of Contents
10.9 Remote Controller ....................................................................................... 10-16
10.9.1 Installation ....................................................................................... 10-16
10.9.2 Typical examples sing the Remote Controller ......................10-17
10.10 Interconnecting Interpretation Eq ipment ............................................. 10-18
10.10.1 Interconnecting Interpreter desks ..............................................10-18
10.10.2 Interconnection between booths ...............................................10-18
10.11 Lang age Distrib tion Eq ipment ........................................................... 10-19
10.11.1 Introd ction ..................................................................................... 10-19
10.11.2 Installation .......................................................................................10-20
Chapter 11. System Set-up & Operation .......................................................... 11-1
11.1 Introd ction ......................................................................................................11-1
11.1.1 Initializing a stand-alone system .................................................... 11-1
11.1.2 Initializing a PC-based system ...................................................... 11-1
11.2 Setting p a stand-alone system .................................................................11-2
11.2.1 System mode selection (M lti-CCU only) ................................. 11-2
11.2.2 Microphone control modes ............................................................ 11-2
11.3 M lti-CCU Set- p for the first-time. ............................................................11-3
11.3.1 Downloading Control PC-software ............................................. 11-3
11.4 Maintenance Men .........................................................................................11-3
11.4.1 To set system defa lt LANGUAGE ............................................. 11-4
11.4.2 To set system INTERCOM OPERATOR POSITION ............. 11-4
11.5 So nd Management .......................................................................................11-5
11.5.1 Eq alizer f nction ............................................................................ 11-5
11.5.2 Lo dspeakers ................................................................................... 11-5
11.6 Additional stand-alone operations (applicable to conference
nits only) .........................................................................................................11-6
11.6.1 Voting modes .................................................................................... 11-6
11.6.2 Intercom Facilities ............................................................................ 11-6
11.7 Delegate/Chairman nit operation (Conference nits only) .................11-7
11.7.1 Introd ction ....................................................................................... 11-7
11.7.2 OPERATION Delegate Units LBB 3544/00,
LBB 3545/00, LBB 3546/00 ...................................................... 11-8
11.7.3 OPERATION Chairman Unit LBB 3547/00 ...........................11-11
11.8 Operating Delegate/Chairman nits (Disc ssion nits only) ............ 11-14
11.8.1 Microphone ..................................................................................... 11-14
11.8.2 Priority f nction ( LBB 3533/xx and
LBB 3534/xx only) ........................................................................ 11-14
11.8.3 Lang age channel selection (LBB 3531/..
and LBB 3534/.. only) .................................................................. 11-14
11.9 Interpretation ................................................................................................. 11-15
11.9.1 Incoming channel control (LISTENING) ..................................11-15
11.9.2 O tgoing channel control (SPEAKING) ..................................11-15
11.9.3 Microphone (Micro) ......................................................................11-15
11.9.4 Microphone locks ..........................................................................11-15
11.9.5 ‘Override’ ......................................................................................... 11-15
11.9.6 Relay Interpretation with a to-relay 11-15
11.10 Operating the Interpreter Desk 11-17
11.10.1 Incoming Channel Selection .......................................................11-17
11.10.2 Assigning Pre-select keys ............................................................11-17
11.10.3 Incoming Floor switch and A to-relay .......................................11-17
11.10.4 Lang age Q ality Indication ........................................................11-17
11.10.5 Interpreter desk Listening ............................................................11-18
11.10.6 O tgoing Channel Selection ......................................................11-18
11.10.7 Typical Displays showing o tgoing channels ..........................11-19
11.11 Programming the Interpreter desk ...........................................................11-20
11.11.1 Programming the Interpreter desk ............................................ 11-20
11.11.2 Entering the desks programming mode ...................................11-21
11.11.3 Men Programming proced res .................................................11-21
Chapter 12. Environmental Conditions and Maintenance ...........................12-1
12.1 System .............................................................................................................. 12-1
12.2 P blic areas ..................................................................................................... 12-1
12.2.1 Lighting ..............................................................................................12-1
12.2.2 P blic displays (placement/viewing distance) ..........................12-1
12.2.3 P blic walkways ...............................................................................12-1
12.2.4 Headphones with interpreter systems ........................................12-1
12.2.5 Recommended speaking distance ..............................................12-1
12.3 Technical rooms ............................................................................................. 12-1
12.4 Interpreter booths .......................................................................................... 12-2
12.5 Ventilation ........................................................................................................ 12-2
12.6 Cleaning ........................................................................................................... 12-2
12.7 Storage ............................................................................................................. 12-2
Chapter 1 . Technical Data ...................................................................................1 -1
13.1 Mechanical data ............................................................................................. 13-1
13.1.1 LBB 3500/.. Central Control Units ............................................13-1
13.1.2 Mo nting brackets (in-
cl ded with type No.s LBB 3500/xx,
LBB 4106/00, LBB 3508) ............................................................13-1
13.1.3 LBB 4106/00 and LBB 4106/00 (D)
Extension Power S pply Unit ........................................................13-2
13.1.4 LBB 3508/00 and LBB 3508 (D)
A dio Media Interface Unit ............................................................13-2
13.2 Table-top nits ................................................................................................ 13-2
13.2.1 Conference Units .............................................................................13-2
13.2.2 Disc ssion Units ..............................................................................13-2
13.2.3 LBB 3535/00 D al A dio Interface Unit ..................................13-2
13.2.4 LBB 3536/xx Hand microphones ...............................................13-3
13.2.5 LBB 3555/00 Intercom handset ................................................13-3
13.2.6 LBB 3525/00 Channel Selector ho sing ................................13-3
13.2.7 LBB 3527/00 Table-top ho sing for FM lo dspeaker
panel ...................................................................................................13-3
13.3 Fl sh Mo nted Eq ipment ........................................................................... 13-4
13.3.1 LBB 3524/00 and LBB 3424/10 FM Electronic
Channel Selector Panel .................................................................13-4
Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
Digital Congress Network | Installation and Operating Man al | Table of Contents
en | viii
Table of Contents
13.3.2 LBB 3526/10 FM Electronic Channel Selector Panel ... 13-4
13.3.3 LBB 3537/00 and LBB 3537/50 Microphone with
FM Control Panel ..................................................................... 13-5
13.3.4 LBB 3537/10 FM Chairman Priority Control Panel ........ 13-5
13.3.5 LBB 3539/00 Blank panel ................................................... 13-5
13.3.6 LBB 3537/20 and LBB 3537/50 FM Microphone
Control Panel for microphones LBB 3549/00 and
LBB 3549/50 ........................................................................... 13-6
13.3.7 LBB 3538/00 FM Lo dspeaker panel .............................. 13-6
13.3.8 LBB 3540/15 M lti-p rpose Connection Unit ................ 13-7
13.3.9 LBB 3541/00 Delegate Voting Control Panel ................. 13-7
13.3.10 LBB 3542/00 FM Delegate/Chairman Voting Control
Panel with LC-display ............................................................. 13-7
13.3.11 LBB 3543/15 Chip Card Reader ....................................... 13-8
13.4 Installation Accessories ................................................................................13-8
13.4.1 LBB 4114/00 Tr nk Cable Splitter LBB 4115/00
Tap-off Unit ................................................................................ 13-8
13.5 Electrical data ..................................................................................................13-9
13.5.1 Microphones (General) .......................................................... 13-9
13.5.2 Headphones ............................................................................. 13-9
13.5.3 Transmission links .................................................................... 13-9
13.5.4 Combined nits ...................................................................... 13-10
13.5.5 System Electrical and Electro-aco stical
characteristics ........................................................................ 13-10
13.5.6 System environmental conditions ......................................13-10
13.5.7 Interface data .......................................................................... 13-10
13.5.8 Mains s pply ........................................................................... 13-10
13.5.9 Power cons mption (nominal) ............................................ 13-10
13.6 System limitations ........................................................................................ 13-11
13.7 Connection details ...................................................................................... 13-11
13.7.1 Mains cable ............................................................................. 13-11
13.7.2 DCN circ lar connectors ..................................................... 13-11
13.7.3 Cable connection ................................................................. 13-11
13.7.4 Pl ggable microphones LBB 3549/xx ............................ 13-11
13.7.5 CONCENTUS nits .............................................................. 13-12
13.7.6 CONCENTUS nits .............................................................. 13-12
13.7.7 Cable connection ................................................................... 13-12
13.7.8 Jack-pl g .................................................................................. 13-12
13.7.9 Interpreter desk (headset socket DIN-type) .................... 13-12
13.7.10 15-pole D-type connector PC Interface ...........................13-12
13.8 Available A dio Down Link Channels 13-13
13.8.1 Stand-alone systems ............................................................. 13-13
13.8.2 Systems with a PC ................................................................ 13-13
13.9 TEMPLATE FOR TABLE CUT-OUT OF CONCENTUS UNITS ...... 13-14
Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
Digital Congress Network | Installation and Operating Man al | Chapter 1 - Introd ction to DCN
en | 1-1
Contrib tion eq ipment
Chapter 1. Introduction Digital
Congress Network
(DCN)
The BOSCH Digital Network System (DCN) provides flexible control facilities for all types of
conferences from small discussion groups to international, multi-lingual congresses with hundreds of
delegates. Facilities range from basic microphone management, to delegate identification and
registration, electronic voting, information distribution and display, up to extensive simultaneous
interpretations and automatic camera control. A single operator using a computer with DCN’s
application software can control even the largest of congresses. Systems can be expanded by adding
more contribution equipment and introducing PC control with DCN’s application software.
The full range of DCN equipment includes:
1. Contribution equipment
2. Central control equipment
3. Simultaneous interpretation and language distribution equipment
4. Information display equipment
5. Application software packages
6. Installation equipment
DCN equipment is also complemented by external equipment such as video and character displays,
TV cameras, personal computers, monitors, PA amplifiers, loudspeakers and printers all of which are
fully compatible and easily integrated into the DCN system.
1.1 Contribution equipment
Contribution equipment describes the units which participants use to contribute to a conference.
Depending on the type of contribution unit, delegates can access the DCN’s wide range of facilities to
listen, speak, register a request-to-speak, receive screen messages, communicate with other delegates
via an intercom and to participate in electronic voting sessions. On insertion of an ID-card dedicated
software is required giving much more facilities.
Contribution units can be used free-standing on a table-top, or flush-mounted in desks, seat backs or
armrests. Other microphone types such as lavalier and hand-held are also available, allowing
contribution from non seated participants such as a guest speaker for example.
1.2 Central Control Equipment
The Central Control Unit (CCU) forms the heart of the DCN system.The CCU can operate stand-
alone to provide automatic conference control, or it can be accessed by an operator via a personal
computer (PC) when more extensive management control is required.
All CCU’s can control up to 240 contribution units. If more capacity is required, slave CCU’s can be
connected, each of which increases the system capacity by 240 contribution units. A maximum of 16
slave CCU’s can be connected to a system. Other extension units include an Extension Power Supply
unit and an Audio Media Interface unit which extend the systems power handling capacity.
The CCU offers basic microphone management, simultaneous interpretation and electronic voting
facilities, as well as digital audio channels, data channels and communication channels.This allows
effective unsupervised control of even large or international conferences. The extended CCU offers
all the facilities of the basic CCU, but allows operator control via a personal computer (PC).The
operator can access the wide range of DCN application software packages, each with a specific
function in controlling and monitoring conferences.This includes advanced simultaneous
interpretation and microphone management, message generation and display, voting procedures,
intercom, creating a delegate data base, attendance registration, audio processing and automatic
camera control.
Get other manuals https://www.bkmanuals.com

2
BOSCH Security Systems | 04-2003 | 3922 988 43318 en
Digital Congress Network | Installation and Operating Man al | Chapter 1 - Introd ction to DCN
en | 1-2
Sim ltaneo s Interpretation and Lang age Distrib tion Eq ipment
1.3 Simultaneous Interpretation and Language
Distribution Equipment
Interpretation.
Using the same trunk-line cabling DCN’s interpreter desks can easily be integrated into existing
systems, offering comprehensive facilities for simultaneous interpretation.The desk can accommodate
up to 15 different language channels, plus the original floor language. A maximum of six desks can be
installed per interpreter booth.They can be used stand-alone or as part of a more comprehensive
system.When used stand-alone, the units built-in microprocessor is manually programmed to allocate
language channels, channel routing and interlocks. In PC operator-controlled systems, the desk is used
in combination with DCN dedicated software, and other interpreter desks (if required) to form a
completely integrated interpretation network. An in-built facility enables direct or auto-relay
interpretation to cater for less well known languages. Each desk has two output channels, one for the
normal interpretation and one for second or auto-relay translation.
Language Distribution
Distribution of languages to individual delegates can be by wired or wireless language distribution
systems. A wired language distribution system uses delegate contribution units that include a language
channel selector, or dedicated language channel selector units. A wireless language distribution system
uses the Infra-red transmission technique.
1.4 Information display equipment
The DCN system can distribute information to conference participants quickly and efficiently to suit
all requirements. A wide range of displays are supported from simple LCD personal screens to video
equipment for venue broadcasting.
The chairman unit, interpreter desk and one type of the delegate unit is equipped with a graphic
(chairman, delegate) or alphanumeric (interpreter) LC-display which displays delegate information,
voting results and operational procedures, public and personal messages, microphone status and
multi-lingual user instructions.
Hall displays can quickly display conference information to a large number of conference participants.
Numeric, alphanumeric or geographical displays are available, to display voting results. TV receivers
and Video Displays allow high quality display of any live or recorded material, computer-generated
graphics, text, and information generated by DCN software.
1.5 Application software packages
A comprehensive range of software packages is available for use with centrally controlled PC-systems.
These packages run under Microsoft® Windows® integrate conference preparation management
and control into this versatile graphical computer environment. Any combination of packages can be
down-loaded according to specific system requirements. DCN software packages are generally used
in larger scale systems where operator control is required.
The PC running the software is connected to the DCN system and therefore has direct
communication links with contribution, interpretation and control equipment via the systems trunk-
line data bus or the CCU’s serial communication port.Therefore all aspects of conference
management can be brought to a single point of control, Leading to increased ease of use, efficiency
and data distribution.
The range of DCN software packages include
s:
• Microphone management
• Synoptic Microphone control
• System installation
• Parliamentary voting
• Multi- voting
• Delegate Database
• Simultaneous Interpretation
• Text/Status Display
• Attendance Registration
• ID-Card Encoding
• Message Distribution
• Intercom
• Video Display
• Automatic Camera Control
• DCN Start-up
• Multi-CCU
• DCN Open Interface
Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
Digital Congress Network | Installation and Operating Man al | Chapter 1 - Introd ction to DCN
en | 1-3
Installation eq ipment.
1.6 Installation equipment.
Fast cost-saving installation is an important benefit of the DCN’s digital technology. A thin twin-coaxial
cable carries all the system’s digital signals, eliminating the need for the costly and vulnerable multi-
core cables used in conventional analogue installations.The same cable is used to transport the signals
to all delegates’ microphone units throughout the system and can be ‘tapped off ’ at any desired point
to connect the microphone units or any system unit associated with the DCN system. Later capacity
extensions - for example to add extra microphone units does not demand changes to the system
cabling. All that is needed is to connect the required DCN system units or branches to the installed
cabling.Trunk-line splitters and extension cable assemblies are available to simplify installations in
difficult working areas.
DCN’s System Philosophy.
The DCN introduces the latest digital technology, bringing far reaching benefits to the audio quality, as
well as to promote the addition of a wide range of external peripheral equipment to conference
systems.
FIG 1-1 shows the concept of DCN’s digital communication techniques.The Network cabling forms
the system infrastructure providing the communication media between the Microprocessor
controlled Central Control and all units connected to it. Using standard plugs and connectors
throughout the system means that units can be connected to the Network at any convenient points,
making installation quick and simple.
Communication through the Network cabling and all units connected to it, is done using three
dedicated digital communication IC’s, ACN
1 , ACN 2 and ACN 3. Units that include an ACN 1
microprocessor - such as the delegate unit, chairman unit and interpreter desk - communicate to the
Central Control Unit, via the units ACN 2 microprocessor on a send and receive basis (active or
passive). Units that include an ACN 3 microprocessor - such as the Channel selector units - receive
information on a receive basis only, such units are known as passive units.
Praedic
The integrated circuit (IC), PRAEDIC (Professional Audio Encoder Decoder Integrated Circuit)
combines a built-in amplifier with both Analogue-to-Digital and Digital-to-Analogue convertors.The
IC converts analogue signals (such as from a delegates’ microphone) and digitizes them for
distribution throughout the DCN network cabling. In return the digitize signal is then fed back to the
Praedic and converted back to an analogue signal for distribution throughout the DCN units - such as
delegate loudspeakers and headphones.
FIG 1-1 DCN’s digital communication technique
Alternative for PC
with LBB 3510/00
Network card
DCN Disc ssion
Delegate/Chairman/Interpreter
(contrib tion & distrib tion)
Channel selector nit
(lang age distrib tion)
ACN 1 - p/down
ACN 2 - p/down
ACN 3 - down only
Central Control Unit (CCU)
Delegate/Chairman nit (Concent s)
ACN 1
ACN 1
ACN 3
ACN 1
ACN 1
ACN 3DAC
PRAEDIC
PC-bus
PRAEDIC
ACN 1 PRAEDIC
ACN 2
PERSONAL
COMPUTER
DAC
LBB 3510/00
Network card
LBB 3512/00
Data Distrib tion Board
CONTROL
PANEL
µProc.
e.g Hall Display
PRAEDIC
µProc. FLASH
EPROM RAM DSP
Network cabling
Get other manuals https://www.bkmanuals.com

2
BOSCH Security Systems | 04-2003 | 3922 988 43318 en
Digital Congress Network | Installation and Operating Man al | Chapter 1 - Introd ction to DCN
en | 1-4
Q ick reference to DCN’s f nctions
1.7 Quick reference to DCN’s functions
Stand-alone System
A discussion system; delegates control their own microphone actions - without the need of a non-
participating operator. Discussion systems cater for smaller groups, although the number of delegates
can be extended to the total capacity of the DCN system. A discussion system therefore is ideal for
small meeting halls, boardrooms, and hotels etc. where clear and concise speech intelligibility through
sound amplification is required.
PC Controlled System
Delegates’ microphone actions are controlled by a none participating operator using a personal
computer.
Microphone Management
Method by which delegates/operator control the microphone units. Microphone Management
control therefore is needed in order to conduct civilised and disciplined discussions/conferences.
The DCN system has its own built-in standard microphone control functions.These functions are
usually sufficient for use in discussion groups using a stand-alone system. In conference systems
however a central PC operator has extended microphone management capabilities when using
DCN’s dedicated microphone management software.
Microphone Management Operation Modes:
OPEN (AUTO)
The OPEN mode allows up to 1, 2 or 4 delegates (Active Micros) to control the on/off state of
their own microphones unit simultaneously without the use of operator intervention.When more
than the number of Active Micros has been reached, delegates requesting to speak join a request-
to-speak list.
OVERRIDE (First-In-First-Out)
The Override mode allows up to 1, 2 or 4 delegates to speak on a FIRST-IN FIRST-OUT basis i.e
Override.With the override mode, their is no request-to-speak list, only the pre-selected number
of Active Micro’s may be switched on simultaneously.This means that if another delegate should
switch on his microphone unit, the microphone of the first delegate having joined the group will
be switched off, allowing the latest delegate to join in the discussion.
VOICE ACTIVATION
The ‘Voice’ activation mode is an automatic method for activating the microphones of the dele-
gate and chairman units by voice.The maximum number of voice activated units available for
selection in a stand-alone system is 2 or 4.This mode of operation is intended for free discussion
amongst participating delegates. For enhanced operation an additional Public Address system is
highly recommended.
1.8 DCN Software packages
1.8.1 Microphone Management software
Microphone management software provides a text-based solution (delegates’ names) for managing
delegates’ microphones. Run under Windows® the operator controls the delegates’ microphone
operations through menus.
The Microphone Management software offers five modes of microphone control:
• Operator with *Request-to-speak list (MANUAL)
• Operator with *Request and **Response list
• Delegate with *Request-to-speak list (OPEN)
• Delegate control with override (of other delegates’ microphones)
*A Request-to-speak list is a list of delegates waiting to speak.To join the list delegates first press
their microphone keys. If the maximum number of delegates are already speaking the delegates
then joins the list. The number of delegates allowed to speak at the same time is set to 1,2,3, or
4.
** A response list is a list of delegates that need to react immediately to a current speaker.
Response requests are positioned at the top of the request list.
• Delegate withVoice activation
EFE ENCE:
For more information refer to the LBB 3570 software manual
1.8.2 Synoptic Microphone Control
Synoptic microphone control software provides a graphical solution using pictograms of microphone
units. Run under Windows® the operator controls microphone units by simply pointing and clicking a
mouse on the desired unit. Synoptic microphone control is icon based. It relies on the location of
seats and uses pictograms that show icons with seat numbers or with names.
EFE ENCE:
For more information refer to the LBB 3571 software manual
1.8.3 Simultaneous Interpretation
Interpretation is the term used where the language of the floor speaker is interpreted by interpreters
using interpreter desks into the languages of the other conference participants.
EFE ENCE:
For more information refer to the LBB 3572 software manual
Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
Digital Congress Network | Installation and Operating Man al | Chapter 1 - Introd ction to DCN
en | 1-5
DCN Software packages
1.8.4 Language Distribution
Language distribution describes the means by which delegates listen to the floor speaker in the
language of their choice. Interpretations can be forwarded to delegates headphones using units with
either a built-in language channel selector or via an infra-red receiver.
1.8.5 Voting
Parliamentary voting
Parliamentary voting allows delegates to vote ‘NO’, ‘ABSTAIN’ or ‘YES’. It provides facilities for vote
registration and display, with a choice of ‘OPEN’ (non-secret) and ‘CLOSED’ (secret) voting modes
and selectable interim voting functions. Up to 9999 voting motions can be prepared in advance in a
single script file and recalled instantly during a voting session (available with PC systems only). In PC
based systems, editing facilities are also provided to simplify the preparation of updating script files.
EFE ENCE: For more information refer to the LBB 3575 software manual
Multi voting
Multi-voting software allows up to 6 voting methods to be selected,‘Parliamentary, ‘Audience
response’, ‘Multiple choice’, Opinion poll, Rating and For/against. Vote related parameters can be
specified for each individual voting method, such as: vote type, result display type, interim display,
screen and print legends, hall display, vote weighting, roll call, voting LEDs and abstain options.The
user is able to print the final result and automatically export it to an MS-DOS file.
For more information refer to the LBB 3576 software manual.
EFE ENCE:
For more information refer to the LBB 3576 software manual
1.8.6 Attendance egistration and Access Control
To register delegates to the DCN system, personnel ID-cards can be programmed and allocated to
participating delegates.The card ensures that only authorised delegates are able to access the
functions of a microphone unit, participate in a voting session and to make an intercom call.This
facility is only applicable to units fitted with an ID chip card reader.
EFE ENCE:
For more information refer to the LBB 3578 software manual
1.8.7 Intercom
An intercom handsets allows two-way vocal communication between conference participants,
interpreters and operator.
EFE ENCE:
For more information refer to the LBB 3573 software manual
1.8.8 Text/Status Information Displays
Information displays range from hall displays for rooms of all sizes, down to personal displays for
individual delegates.
Most of the displayed information is in the form of alphanumeric messages, shown on microphone
units equipped with LC-displays, as well as on hall displays. A choice of solutions are available for hall
display information like voting motions and results, delegates’ names and affiliations, request-to speak
lists, personal messages, public announcements and multiple choice questions.
Display facilities for video signals and graphic information such as seating plans and statistical voting
representations can also be added to the system, using hall displays such as projection or direct view
TV receivers, or giant-screen VidiWalls for larger audiences. Personal video displays can also be added
in the form of LCD TV displays.
EFE ENCE:
For more information refer to the LBB 3583 software manual
1.8.9 Automatic Camera Control
Automatic camera control allows the speaker to be displayed on one or more video displays
connected to a video control switcher. One or more dome cameras’ with a fast moving pan and tilt,
zoom lens and a large number of pre set positions are automatically activated by the microphone
control signals of the contribution units.
EFE ENCE:
For more information refer to the LBB 3588 software manual
1.8.10 Delegate Database software
Delegate Database software is used to create names files of conference participants. It is used by
several other DCN software modules to identify the conference participant and to control the
delegates access to DCN functionality, i.e. microphone control, voting, use of intercom facilities.
EFE ENCE:
For more information refer to the LBB 3580 software manual.
1.8.11 ID-Card Encoder software
ID-Card Encoder Software enables encoding of a unique ID-card number to allow identification of
each delegate when using DCN contribution units with an ID-card reader.
EFE ENCE:
For more information refer to the LBB 3580 software manual.
1.8.12 Message Distribution software
Message Distribution Software enables an operator to send individual or group messages to
conference participants such as delegates and interpreters and to display text messages on hall
displays.
EFE ENCE:
For more information refer to the LBB 3582 software manual.
1.8.13 System Installation software
System Installation is used to configure the DCN system. It allows linking of contribution units and
users and assigning functions to audio channels.An installation file is required for DCN operation with
PC control.
EFE ENCE:
For more information refer to the LBB 3585 software manual.
1.8.14 Video Display
Video Display software enables sending of relevant information for large screen video/data display or
personal video/data display via a Video Client application.
EFE ENCE:
For more information refer to the LBB 3584 software manual.
Get other manuals https://www.bkmanuals.com

2
BOSCH Security Systems | 04-2003 | 3922 988 43318 en
Digital Congress Network | Installation and Operating Man al | Chapter 1 - Introd ction to DCN
en | 1-6
DCN Software packages
1.8.15 Multi-CCU Control
Multi-CCU Control software allows to use up to 16 CCU’s in a DCN system for a max. of 3840
contribution units. (Note: DCN’s Delegate Database software LBB 3580 supports names files with up
to 1500 names).The Multi-CCU Control software is installed on a Master CCU PC operating under
OS/2. It allows assignment of the CCU acting as "Audiomaster" and the CCU used for connection of
interpreter desks.
EFE ENCE:
For more information refer to the LBB 3586 software manual.
1.8.16 DCN Startup
DCN Startup software is the basic software module for installation of all DCN software modules.The
Startup screen shows the icons of all installed software modules that can be activated. It also can
show the system configuration, defines auto-start options, takes care for error logging and allows the
operator to control the master volume level and to listen to interpretations via a headphone.
EFE ENCE:
For more information refer to the LBB 3590 software manual.
1.8.17 DCN Open Interface
The DCN open interface software allows remote control of a selected DCN functions via third party
equipment. Control data exchange between DCN and the remote control device or system is done
via a RS-232 port on the CCU. Access to the CCU is opened with the Open Interface software via a
PC connection to the serial port of the CCU.
EFE ENCE:
For more information refer to the documentation on the disk of this module.
Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
Digital Congress Network | Installation and Operating Man al | Chapter 1 - Introd ction to DCN en | 1-7
Glossary of Abbreviations and Acronyms
1.9 Glossary of Abbreviations and Acronyms
A
ACN-1, ACN-2, ACN-3 Integrated Circuit (IC)
Active unit Sends data on the up link and receives data on the down link
Allow cancel request A pre-programmed system interlock, allowing the delegate to cancel a
request-to-speak
Allow mic. off facility A pre-programmed system interlock, allowing delegates to switch off
their microphone units without consent
C
CCU Central Control Unit
Chairman One who presides over or heads a meeting or conference
Contribution Participation within a meeting or conference using contribution units
Central Operator One who controls and organises a meeting or conference from a per-
sonal computer (PC)
D
Data Communication Communication of data between microprocessor controlled units
DCN Digital Congress Network
Delegate A representative to a conference
Distribution The distribution to delegates of interpreted languages
E
End of Voting End of Voting Displayed on the delegate unit to inform delegates that
the voting session has ended
F
Flush-mounted Units that are built into tabletops or the arm rests of seats
H
Hold Voting session on hold or temporarily halted
I
Information display Display showing related conference information
Interlocks Pre-programmed settings for use in interpretation procedures
Interpretation The art of interpreting one language into another
Interpretation (simultaneous) The art of interpreting one language into
another at the same time
Interpreter One who translates orally for people speaking in different languages
N
Network cabling See Trunk-line
M
Multi-CCU Systems using more than one CCU, linked using a Multi-CCU link.
P
PC Personal Computer
PCF Power Consumption Factor
PCF value The value assigned to a specific unit or system
PRAEDIC Professional Audio Encoder Decoder IC.
Passive Unit DCN unit that Receives data on the down link only
R
Rack-mounted Defines units that are capable of being mounted in a 19-inch cabinet
Request accepted Displayed on a delegate unit informing the delegate the delegate that
his request-to-speak has been accepted
Request Initiated by a delegate requesting to speak
Request cancelled Displayed on delegate units informing the delegate that his request-to-
speak has been cancelled or rejected
Restart
Response
Voting session restarted after being on Hold
Initiated by a delegate wishing to respond.
S
Speaker Floor speaker
Speak now Displayed on delegate units to inform the delegate that he may speak
T
Trunk-line Cabling between units run in a loop-through chain
Trunk-outlet Used for trunk-cable splitting and pulse regeneration purposes
Table-top Units placed on top of a table or similar type surface
V
Voting To cast one vote, exercise a choice or decision, express an opinion
Voting on-hold Displayed on a delegate unit when a voting session has been tempo-
rarily suspended
Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
Digital Congress Network | Installation and Operating Man al | Chapter 1 - Introd ction to DCN en | 1-8
Glossary of Abbreviations and Acronyms
This page has been left blank intentionally
Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
Digital Congress Network | Installation and Operating Man al | Chapter 2 - Contrib tion Eq ipment en | 2-1
CONTRIBUTION EQUIPMENT
Chapter 2. Contribution
Equipment
The following chapter describes the functionality of each unit and its interconnection and mounting
facilities. All unit’s dimensions are referenced in Chapter 13.:“Technical data”.
2.1 CONT IBUTION EQUIPMENT
The DCN range of contribution equipment falls into 3 categories: table-top, table-top + flush
mounted (universal) and flush mounted.
2.1.1 Table-top Contribution units
Table-top contribution units include delegate, chairman and interpreter units. All are designed for
uncluttered longitudinal placement on table-tops or similar type surfaces.
NOTE: DCN offers two different styles of table-top contribution units.Therefore for clar-
ity throughout this manual, they will be divided into conference and discussion units.
The range of DCN’s table top equipment includes the following units:
Unit Description Type No. Unit Type.
Active units
Delegate unit LBB 3530/xx LBB 3531/xx
LBB 3544/00 LBB 3545/00 LBB 3546/00
Discussion
Conference
Chairmans unit LBB 3533/xx LBB 3534/xx
LBB 3547/00
Discussion
Conference
Microphones for conference
units
LBB 3549/00
LBB 3549/50
Conference
Conference
Interpreter desk LBB 3520/10 Interpretation
Intercom handset LBB 3555/00 with mounting plate LBB 3556/00
Multi-purpose connection unit LBB 3540/15 (Flush-mounted applications only)
A “Microphone only” function is also available using the following:
Hand microphones LBB 3536/00, /10 (Flush-mounted applications only)
Dual Audio Interface LBB 3535/00 (Flush-mounted applications only)
Passive units (no contribution, only in FM section)
Electronic channel selector LBB 3524/00*, LBB 3524/10*, LBB 3526/10
Note: *The electronic channel selector is a flush-mounted unit but can also be used in table-top
installations (using the LBB 3525/00 housing).
Get other manuals https://www.bkmanuals.com

2
Bosch Security Systems | 04-2003 | 3922 988 43318 en
Digital Congress Network | Installation and Operating Man al | Chapter 2 - Contrib tion Eq ipment en | 2-2
CONTRIBUTION EQUIPMENT
2.1.2 Delegate unit
For use by delegates to actively participate in discussion/conference proceedings - ranging from small
discussion groups to multi-national conferences. Its basic functions allow delegates to speak, listen to
other participants, and to participate in voting sessions (conference units only) using the units voting
keys .
2.1.3 Chairman unit
For use by a chairman, the chairmans unit is similar to the delegate unit but includes a ‘priority button’.
This button when pressed temporarily mutes or permanently cancels all other microphone users. An
optional chime tone is available when the priority button is used. A system may have one or more
chairman units; for use by assigned delegates, privileged speakers or VIP’s etc. In permanent mode, all
delegates waiting to speak are also removed from the request-list. Chairman unit LBB 3547/00 has
five soft-keys that enable the chairman to control, initiate, and to participate in voting sessions, as well
as to cancel all delegates’ microphones and requests-to-speak.
FIG. 2-1 Table-top contribution units
2.1.4 ‘Microphone Only’ Function
A microphone ‘only’ function is for use by Podium and mobile floor speakers, or in installations where
no delegate units are used. DCNs range of microphones can be connected to a Dual Audio Interface
unit or a Multi-purpose connection unit.The Dual Audio Interface unit LBB 3535/00 can serve two
delegate positions.
2.1.5 Interpreter desk
For use in bi/multi-lingual discussions/conferences, the interpreter desks can handle up to 15 different
language channels in addition to the floor language. Up to six interpreter desks can be installed per
booth. Its design provides for efficient operation, and preselection of the incoming language. A back-
lit alphanumeric display shows the selected language in combination with a ‘quality indication’ (direct
or indirect interpretation). An ‘auto-relay’ facility enables interpreters to interpret from unfamiliar
languages, where the desk automatically transmits the relay language to all other interpreter desks for
onward interpretation.
FIG. 2-2 Interpreter desk LBB 3520/10
DCN Disc ssion nit
BOSCH
DCN Concent s nit (conference)
Interpretation
Get other manuals https://www.bkmanuals.com
