Bosch ADS?AMC2?2WCF User manual

Access Modular Controller 2
ADS‑AMC2‑2WCF | APC‑AMC2‑2WCF
en Installation manual

Access Modular
Controller 2 Table of contents | en 3
Bosch Security Systems B.V. 2019-11 | V02 |
Table of contents
1Safety 4
1.1 Unpacking 5
2Short information 6
3Introduction 8
3.1 Description 8
3.2 Product overview 10
3.3 System overview 15
4Installing 16
4.1 Mounting the device on a mounting rail 16
4.2 Unmounting the device from a mounting rail 17
4.3 Opening the case 18
4.4 Closing the case 19
4.5 Cabling 20
4.5.1 Conductor data for powering the controller 20
4.6 Grounding and shielding 22
4.6.1 Grounding for Host Interface 22
4.6.2 Grounding for Extension Interface 23
4.7 Connecting the power supply to the controller 25
4.8 Ethernet Host Interface 26
4.9 RS-485 Host Interface 27
5Operating 29
5.1 Configuring Ethernet interface 29
6Troubleshooting 30
6.1 Resetting the software 32
6.2 Resetting the device to factory default 32
7Service and repair 34
8Disposal 35
9Technical specifications 36
10 Appendices 39
10.1 Connecting diagrams 39

4en | Safety Access Modular
Controller 2
2019-11 | V02 | Bosch Security Systems B.V.
1 Safety
Read instructions
Read all technical documentation before installing or using the
device. Make sure that you have understood all information
described in the technical documentation. Do not ignore safety
messages, as this can cause property or personal damage.
Retain instructions for future reference.
!
Warning!
Risk of physical injury due to blocked escape routes
The access modular controller may block escape routes if not
installed correctly. To keep escape routes free:
- Use locks in fail-safe mode, so that doors will be released if
power fails.
- Install manual override switches, such as break-glass or lever
stations, to unlock doors in an emergency.
!
Warning!
Risk of explosion of lithium battery
The battery can explode if replaced incorrectly.
Replace battery with the same type as recommended by Bosch.
Dispose used batteries according to the instructions of the
manufacturer of the batteries.
!
Caution!
Fire hazard and risk of electric shock due to unauthorized
spare parts and accessories
Unauthorized spare parts and accessories might lack grounding
wires or other safety elements. External power supplies must
be installed and put into service by qualified personnel. The
service technician must use replacement parts or accessories
that are specified by the manufacturer.

Access Modular
Controller 2 Safety | en 5
Bosch Security Systems B.V. 2019-11 | V02 |
Notice!
Device damage due to electrostatic discharge
Protect the hardware from electrostatic discharge, especially
when the device is opened. Always disconnect the controller
from the power source before modifying the installation. The
controller does not support hot-plugging.
Notice!
Unauthorized access
If the access modular controller is installed in an unprotected
environment, unauthorized people may be able to enter.
Install the controller in a location with restricted access.
Notice!
Device damage due to incorrect mounting
The controller can fall and break. Mount the controller on the
matching mounting rails.
This product is RoHS compliant. See Technical data for the full
table of hazardous components.
1.1 Unpacking
Check the packaging for visible damage. If anything has been
damaged during transport, please inform the transport agency.
Unpack the unit carefully. This is an electronic device that must
be handled with care to avoid damage. Do not attempt to put
the unit into operation if components are damaged.
If any parts are missing, inform your customer service
representative or a Bosch Security Systems salesperson. The
shipping carton is the safest transport container for the unit.
Store it and the other packaging material for future use. If the
unit has to be sent back, use the original packaging.

6en | Short information Access Modular
Controller 2
2019-11 | V02 | Bosch Security Systems B.V.
2 Short information
This controller is able to control up to two Wiegand card
readers.
It is designed to fully process the access logic at assigned
access points. Access points consist of doors, gates, barriers,
turn stiles, revolving doors, mantraps, ID card readers, door
opening elements and sensors.
All the product versions use encrypted connections between the
access modular controller and the host system.
The controller stores all necessary information in a battery-
buffered memory and in a compact flash storage element. Even
when the unit is offline, it is able to perform:
– Independent status and authorization checks on access
points
– Take access decisions
– Activate and deactivate connected peripheral elements
– Detect and register all relevant events
The Access Modular Controller (AMC) is supported by the
Access Professional Edition (APE), BIS Access Engine (ACE) and
the Access Management System (AMS).
For more information about our products, visit our online
product catalog.
Manufacturing dates
For product manufacturing dates, go to http://
www.boschsecurity.com/datecodes/ and refer to the serial
number on the product label.
Remarks
This hardware is part of a security system.

Access Modular
Controller 2 Short information | en 7
Bosch Security Systems B.V. 2019-11 | V02 |
Access should be limited to authorized people only.
Some states do not allow the exclusion or limitation of implied
warranties, or limitation of liability for incidental or
consequential damages, hence the above limitation or exclusion
might not apply to you.
Bosch Security Systems retains all rights not expressly granted.
Nothing in this license constitutes a waiver of Bosch’s rights
under the U.S. Copyright laws or any other federal or state law.
If you need further assistance or have any questions, contact:
Bosch Security Systems B.V.
Torenallee 49
5617 BA Eindhoven
Netherlands
www.boschsecurity.com
© Bosch Security Systems B.V., 2019

8en | Introduction Access Modular
Controller 2
2019-11 | V02 | Bosch Security Systems B.V.
3 Introduction
3.1 Description
The controller is equipped with two independent interfaces for
Wiegand type readers. It is able to control one door with one
reader in each direction and up to two doors with a reader in
one direction only.
Figure3.1: Access Modular Controller
All necessary information for access verification is stored in a
battery buffered on-board memory and a Compact Flash (CF)
memory card. This guarantees autonomous access decisions and
complete access registrations even if the management host
system is offline. The built in compact flash card provides
adequate storage capability for cardholders and events.

Access Modular
Controller 2 Introduction | en 9
Bosch Security Systems B.V. 2019-11 | V02 |
The electronics of the controller are completely covered by a
plastic housing. The LCD (liquid crystal display) provides all
important status information.
Unsecured Area
The controller can communicate upstream to the host computer
using RS-485 multi-dropped. It has four analog input devices
and four relay outputs. With its analog input devices, the
controller verifies, for example, if a lock is closed or open. The
relay outputs can be used to activate lock mechanisms if access
is granted, or activate the burglar alarm system if an intrusion or
system alert is detected. If the four inputs and four outputs on
board are not enough to configure the system, up to three
additional extension boards can be connected. The extensions
offer 8 or 16 additional inputs and outputs.
The setup procedure for a controller is made very simple and
fast by the use of door templates. Once selected, all the inputs
and outputs are predefined. These settings can be changed to
choose every free contact of the controller or a connected
extension.

10 en | Introduction Access Modular
Controller 2
2019-11 | V02 | Bosch Security Systems B.V.
3.2 Product overview
Mainboard
Figure3.2: Upper circuit board with display (front)
1 DIL switch for RS-485 address selection , protocol, and
RS-232/RS-485 selection.
2 Lithium battery for buffering of static RAM and real time
clock (RTC). The battery life is estimated at 10 years,
nevertheless an error message is generated if the voltage
sinks below a preset minimum level.
NOTICE: In order to avoid an error message caused by an
earlier voltage drop we suggest to replace the battery
every 8 years. Spare part: VARTA CR 2032 PCB.
3 Reset push button - reachable through the casing using a
screwdriver
4 Liquid Crystal Display
5 Push button, available on top of the housing, to select
different display modes
6 Jumper: Equalization of potential between different
systems and earth ground (shield)

Access Modular
Controller 2 Introduction | en 11
Bosch Security Systems B.V. 2019-11 | V02 |
7 Jumper: Interface selector RS-485 host connection,
RS-485 two wire or RS-485 four wire (depends on
external wiring)
8 Configurable RS-485 host interface
9 Docking port for compact flash memory
10 Configurable RS-232 host interface (ribbon cable
connector)
11 Configurable 10/100 Mbit/s Ethernet host interface
Figure3.3: Interfaces - overview
12 RS-485 extension module bus
13 External tamper contact
14 Connector for power supply
15 Wiegand interfaces for card readers
16 Connectors for analog inputs
17 Connectors for relay outputs

12 en | Introduction Access Modular
Controller 2
2019-11 | V02 | Bosch Security Systems B.V.
Figure3.4: Jumper (back)
18 Jumper for setting either voltage free relay output (“dry”
mode) or looped-in voltage from the AMC internal power
supply (“wet” mode).
19 Jumper: Equalization of potential between different
systems and earth ground (shield) for the extension
interface.

Access Modular
Controller 2 Introduction | en 13
Bosch Security Systems B.V. 2019-11 | V02 |
Status display
The liquid crystal display delivers status information about the
controller. Push the dialog button to switch between different
modes.
The selected display mode remains set until the next time the
button is pressed. The order of the display pages is shown in
the following table.
Push Display (Example) Description
0 V01.00 02.03.07
or
LBUS or BG900
Software versions and date of the
firmware - every 5 sec. alternating
with the display of the reader
interface.
1a S/N1: 0910019212 Bosch serial number
1b S/N2: 00000001
2 02.06 15:35:15 (S) Current date and time
(S) = Summer; (W) = Winter
3 Dig. IO: :::::::::::::::: Display of the digital contacts: the
input signals set will be shown
with an extension above - output
signals with an extension below.
The first eight digits display the

14 en | Introduction Access Modular
Controller 2
2019-11 | V02 | Bosch Security Systems B.V.
Push Display (Example) Description
controller’s signals. The second
eight digits display the extension
board’s signals.
3a Dig. I1: :::::::::::::::: If there are I/O-Boards connected
the signals will be shown on
separate pages.
3b Dig. I2: ::::::::::::::::
3c Dig. I3: ::::::::::::::::
4 MAC
0010174C8A0C
Network device address (MAC)
5 N AMC-1234-5678 Network name of the controller
6 I 192.168.10.18 IP-address of the controller
7 G 192.168.10.255 IP-address of the gateway
(Version V 00.44 or higher)
8 M 255.255.255.0 Subnetmask
(Version V 00.44 or higher)
9 H 192.168.10.10 IP-address of the host computer
10 DHCP 1 DHCP-status:
1 = on
0 = off
11 D 192.168.10.1 IP-address of the DNS server
12 Host: + "C" Host activity:
+ = online
- = offline
"C" = Counter of the received data
packages from the host interface.
RS 485 Bus connection:
A = Address 1 … H = Address 8

Access Modular
Controller 2 Introduction | en 15
Bosch Security Systems B.V. 2019-11 | V02 |
3.3 System overview
The controller is connected to the host system via RS485 or
Ethernet, depending on the type of installation. The host
interface is selected during installation. The two interfaces are
available on the device by default. With RS485 operation, a
maximum of eight access controllers can be connected to one
party line.
2
3
3
2
1
2 2
3
3
4 4
1 Host computer
2 Access Modular Controller
3 Card reader
4 Communication and power supply
In the communication chain of a system, the access controller is
integrated between the host system and the peripheral devices.
It is possible to connect up to two readers to the access
modular controller.

16 en | Installing Access Modular
Controller 2
2019-11 | V02 | Bosch Security Systems B.V.
4 Installing
4.1 Mounting the device on a mounting rail
The controller can be attached on a standard 35mm (1.377in.)
mounting rail using a snap-in mechanism. Attach the controller
into the upper edge of the mounting rail, then push down the
device and snap it onto the rail by pushing it towards the back.
1 2
Figure4.1: Mounting the controller on a mounting rail

Access Modular
Controller 2 Installing | en 17
Bosch Security Systems B.V. 2019-11 | V02 |
4.2 Unmounting the device from a mounting
rail
Notice!
To remove the controller from a mounting rail, first remove all
pluggable connectors.
Push down the controller until the lower edge snaps out of the
mounting rail [1]. Pull the lower end of the controller from the
mounting rail [2].
1 2
Figure4.2: Unmounting the controller from a mounting rail

18 en | Installing Access Modular
Controller 2
2019-11 | V02 | Bosch Security Systems B.V.
4.3 Opening the case
Notice!
To open the controller, first remove all pluggable connectors.
The controller’s case consists of a top cover mounted with a
two-point snap-in closure on a chassis. To open the case, push
down the two snap-ins with a screwdriver, then swing the cover
down.
Figure4.3: Opening the controller’s case

Access Modular
Controller 2 Installing | en 19
Bosch Security Systems B.V. 2019-11 | V02 |
4.4 Closing the case
Before aligning the covers, unplug any pluggable screw
connectors. Insert the hooks on the lower edge of the front
cover into the lugs on lower edge of the plastic back cover [1].
Please ensure that the BOSCH logo is not upside-down. The
upper edge of the front cover now aligns with the two-point
snap-in closures on the upper edge of the back cover [2], and
may thus be clicked gently into place.
Hence the closing process is the reverse of the opening process.
1
2
Figure4.4: Closing the case
Notice!
Risk of damage to equipment
If excessive force is required to close the front cover then it is
probably incorrectly hooked into the back cover. In such cases
the display dialog button in the front cover will be misaligned
and will not function correctly.

20 en | Installing Access Modular
Controller 2
2019-11 | V02 | Bosch Security Systems B.V.
4.5 Cabling
Notice!
Risk of malfunction
The cables used in the controller are not prone to electrical
interference. However, you should avoid routing cables close to
heavy load switching cables and equipment. If this is
unavoidable, cross the cable at right angles every 1 to 2 m (3 to
6 ft) to reduce interference.
4.5.1 Conductor data for powering the controller
With the calculation below you can find out which cable type
must be used. If you connect the power supply and the
controller with the delivered cable set from the enclosure the
calculation is not necessary.
For distances below 25m (75ft) use AWG18 conductors
(1mm²). For longer distances, install an additional power supply
close to the controller.
Please, calculate the voltage drop by checking the conductor
specifications for characteristic resistance values. The voltage
drop shall not exceed 2V.
Example:
Length = 100 m/328 ft
Critical condition! Install the power supply closer to the
controller.
