Bosch REXROTH VFC 610 Series User manual

VFC x610 Series
Brake Chopper
Operating Instructions
R912007234
Edition 01

Bosch Rexroth AG Brake Chopper
Record of Revision
Edition Release Date Notes
DOK-RCON04-VFC*BRAKE**-IT01-EN-P 2016.09 First Release
Version Matching Table
Firmware Operating Instructions
01V02 Edition 01
Copyright
© Bosch Rexroth (Xi'an) Electric Drives and Controls Co., Ltd. 2016
This document, as well as the data, specifications and other information set
forth in it, are the exclusive property of Bosch Rexroth (Xi'an) Electric Drives
and Controls Co., Ltd. It may not be reproduced or given to third parties without
its consent.
Liability
The specified data is intended for product description purposes only and shall
not be deemed to be a guaranteed characteristic unless expressly stipulated in
the contract. All rights are reserved with respect to the content of this documen-
tation and the availability of the product.
RS-20d7d2d0a025f1d20a347ea501f379a5-1-en-US-10

Table of Contents
Page
1 Safety Instructions for Electric Drives and Controls.............................. 1
1.1 Definitions of Terms............................................................................... 1
1.2 Explanation of signal words and the Safety alert symbol...................... 2
1.3 General Information............................................................................... 4
1.3.1 Using the Safety Instructions and Passing Them on to Others.............. 4
1.3.2 Requirements for Safe Use.................................................................... 4
1.3.3 Hazards by Improper Use....................................................................... 5
1.4 Instructions with Regard to Specific Dangers....................................... 7
1.4.1 Protection against Contact with Electrical Parts and Housings............. 7
1.4.2 Protective Extra-Low Voltage as Protection Against Electric Shock ...... 8
1.4.3 Protection against Dangerous Movements............................................. 8
1.4.4 Protection Against Magnetic and Electromagnetic Fields During Op-
eration and Mounting........................................................................... 10
1.4.5 Protection against contact with hot parts........................................... 10
1.4.6 Protection during handling and mounting........................................... 11
2 Important Directions for Use............................................................... 12
2.1 Appropriate Use................................................................................... 12
2.2 Inappropriate Use................................................................................ 12
3 Delivery and Storage............................................................................ 13
3.1 Product Identification.......................................................................... 13
3.1.1 Packing Nameplate.............................................................................. 13
3.1.2 Product Nameplate.............................................................................. 14
3.2 Visual Inspection.................................................................................. 14
3.3 Scope of Supply................................................................................... 14
3.4 Transport of the Components.............................................................. 15
3.5 Storage of the Components................................................................. 15
4 Brake Chopper Overview..................................................................... 16
4.1 Work Principle..................................................................................... 16
4.2 Product Features................................................................................. 17
4.2.1 Conditions........................................................................................... 17
4.3 Technical Data...................................................................................... 18
4.3.1 Electric Data........................................................................................ 18
4.3.2 Requirement of Cable Length.............................................................. 18
4.4 Applicable Model of Frequency Converter........................................... 18
Brake Chopper Bosch Rexroth AG
Table of Contents
DOK-RCON04-VFC*BRAKE**-IT01-EN-P I

Page
4.5 Brake Chopper and Brake Resistor...................................................... 19
4.5.1 Braking Ratio....................................................................................... 19
4.5.2 Recommended Brake Chopper and Brake Resistor............................. 19
5 Brake Chopper Mounting..................................................................... 21
5.1 Installation Conditions......................................................................... 21
5.2 Figures and Dimensions....................................................................... 22
5.2.1 Figures................................................................................................. 22
5.2.2 Dimensions.......................................................................................... 22
6 Brake Chopper Wiring.......................................................................... 23
6.1 System Wiring...................................................................................... 23
6.1.1 Electrical Interface............................................................................... 23
6.1.2 Typical Connection Mode 1.................................................................. 24
6.1.3 Typical Connection Mode 2.................................................................. 24
6.2 Cable Specifications............................................................................ 26
6.2.1 Power Cables....................................................................................... 26
6.2.2 Control Cables..................................................................................... 28
6.3 Terminals............................................................................................. 29
6.3.1 Power Terminals.................................................................................. 29
6.3.2 Control Terminals................................................................................ 30
6.3.3 Digital Signal Internal Wiring............................................................... 32
7 Electromagnetic Compatibility (EMC)................................................. 33
7.1 Cable Connections between Brake Chopper and Frequency Convert-
er......................................................................................................... 33
7.2 Mounting and Wiring in Control Cabinet............................................. 34
7.3 Installing Signal Lines and Signal Cables............................................. 35
8 Operating Panel and Dust Cover......................................................... 36
8.1 LED Panel............................................................................................ 36
8.1.1 Appearance.......................................................................................... 36
8.1.2 Operating Descriptions........................................................................ 37
8.1.3 Fast Access to Parameters with Button Combinations........................ 37
8.2 LCD Panel............................................................................................ 39
8.2.1 LCD Panel Introduction........................................................................ 39
8.2.2 Operating Example.............................................................................. 40
8.3 Dust Cover........................................................................................... 40
Bosch Rexroth AG
Table of Contents
Brake Chopper
II DOK-RCON04-VFC*BRAKE**-IT01-EN-P

Page
9 Parameter and Typical Application...................................................... 41
9.1 Parameter Descriptions....................................................................... 41
9.1.1 Terminology and Abbreviation in Parameter List................................. 41
9.1.2 Parameter List..................................................................................... 41
9.1.3 Parameter Setting Description............................................................ 43
9.2 Typical Application............................................................................... 48
9.2.1 Quick Start-up at Default Parameter Setting....................................... 48
9.2.2 Master / Slave Control Mode............................................................... 48
10 Diagnosis............................................................................................. 49
10.1 Status Code......................................................................................... 49
10.2 Warning Code...................................................................................... 49
10.3 Error Code........................................................................................... 50
10.3.1 Error 01 (OE-b): Brake Chopper Overvoltage...................................... 50
10.3.2 Error 02 (OC-b): Brake Chopper Overcurrent...................................... 50
10.3.3 Error 03 (SC): Surge Current or Short Circuit..................................... 50
10.3.4 Error 05 (OH-b): Brake Chopper Overheat.......................................... 50
10.3.5 Error 07 (OH-r): Brake Resistor Overheat............................................ 51
10.3.6 Error 09 (E.Par): Invalid Parameter Setting......................................... 51
10.3.7 Error 10 (idE-): Brake Chopper Internal Error...................................... 51
11 Maintenance........................................................................................ 52
11.1 Safety Instructions............................................................................... 52
11.2 Daily Inspection................................................................................... 52
11.3 Periodic Inspection.............................................................................. 53
11.4 Removable Components Maintenance................................................. 54
11.4.1 Construction Overview........................................................................ 54
11.4.2 Disassembly of Dust Cover.................................................................. 55
11.4.3 Disassembly of Fans............................................................................ 56
12 Service and Support............................................................................ 57
13 Environmental protection and disposal .............................................. 58
13.1 Environmental protection.................................................................... 58
13.2 Disposal............................................................................................... 58
14 Appendix.............................................................................................. 60
14.1 Appendix I: Certification...................................................................... 60
Brake Chopper Bosch Rexroth AG
Table of Contents
DOK-RCON04-VFC*BRAKE**-IT01-EN-P III

Page
14.1.1 CE........................................................................................................ 60
14.1.2 EAC...................................................................................................... 61
14.2 Appendix II: Type Coding..................................................................... 62
Bosch Rexroth AG
Table of Contents
Brake Chopper
IV DOK-RCON04-VFC*BRAKE**-IT01-EN-P

1 Safety Instructions for Electric Drives and Controls
1.1 Definitions of Terms
Documentation
A documentation comprises the entire documentation used to inform the user of
the product about the use and safety-relevant features for configuring, integrat-
ing, mounting, installing, commissioning, operating, maintaining, repairing and
decommissioning the product. The following terms are also used for this kind of
documentation: Operating Instructions, Instruction Manual, Commissioning
Manual, Application Description, Assembly Instructions, Project Planning Man-
ual, Safety Notes, Product Insert, etc.
Component
A component is a combination of elements with a specified function, which are
part of a piece of equipment, device or system. Components of the electric drive
and control system are, for example, supply units, drive controllers, mains
choke, mains filter, motors, cables, etc.
Control System
A control system comprises several interconnected control components placed
on the market as a single functional unit.
Device
A device is a finished product with a defined function, intended for users and
placed on the market as an individual piece of merchandise.
Electrical Equipment
Electrical equipment encompasses all devices used to generate, convert, trans-
mit, distribute or apply electrical energy, such as electric motors, transformers,
switching devices, cables, lines, power-consuming devices, circuit board assem-
blies, plug-in units, control cabinets, etc.
Electric Drive System
An electric drive system comprises all components from mains supply to motor
shaft; this includes, for example, electric motor(s), motor encoder(s), supply
units and drive controllers, as well as auxiliary and additional components, such
as mains filter, mains choke and the corresponding lines and cables.
Installation
An installation consists of several devices or systems interconnected for a de-
fined purpose and on a defined site which, however, are not intended to be
placed on the market as a single functional unit.
Machine
A machine is the entirety of interconnected parts or units at least one of which
is movable. Thus, a machine consists of the appropriate machine drive elements,
Brake Chopper Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls
DOK-RCON04-VFC*BRAKE**-IT01-EN-P 1/65

as well as control and power circuits, which have been assembled for a specific
application. A machine is, for example, intended for processing, treatment,
movement or packaging of a material. The term "machine" also covers a combi-
nation of machines which are arranged and controlled in such a way that they
function as a unified whole.
Manufacturer
The manufacturer is an individual or legal entity bearing responsibility for the de-
sign and manufacture of a product which is placed on the market in the individu-
al's or legal entity's name. The manufacturer can use finished products, finished
parts or finished elements, or contract out work to subcontractors. However,
the manufacturer must always have overall control and possess the required au-
thority to take responsibility for the product.
Product
Examples of a product: Device, component, part, system, software, firmware,
among other things.
Qualified Persons
In terms of this application documentation, qualified persons are those persons
who are familiar with the installation, mounting, commissioning and operation of
the components of the electric drive and control system, as well as with the haz-
ards this implies, and who possess the qualifications their work requires. To
comply with these qualifications, it is necessary, among other things,
1) to be trained, instructed or authorized to switch electric circuits and devices
safely on and off, to ground them and to mark them
2) to be trained or instructed to maintain and use adequate safety equipment
3) to attend a course of instruction in first aid
User
A user is a person installing, commissioning or using a product which has been
placed on the market.
1.2 Explanation of signal words and the Safety alert symbol
The Safety Instructions in the available application documentation contain spe-
cific signal words (DANGER, WARNING, CAUTION or NOTICE) and, where re-
quired, a safety alert symbol (in accordance with ANSI Z535.6-2011).
The signal word is meant to draw the reader's attention to the safety instruction
and identifies the hazard severity.
The safety alert symbol (a triangle with an exclamation point), which precedes
the signal words DANGER, WARNING and CAUTION, is used to alert the reader
to personal injury hazards.
Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls
Brake Chopper
2/65 DOK-RCON04-VFC*BRAKE**-IT01-EN-P

DANGER
In case of non-compliance with this safety instruction, death or serious injury
will occur.
WARNING
In case of non-compliance with this safety instruction, death or serious injury
could occur.
CAUTION
In case of non-compliance with this safety instruction, minor or moderate injury
could occur.
NOTICE
In case of non-compliance with this safety instruction, property damage could
occur.
Brake Chopper Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls
DOK-RCON04-VFC*BRAKE**-IT01-EN-P 3/65

1.3 General Information
1.3.1 Using the Safety Instructions and Passing Them on to Others
Do not attempt to install and operate the components of the electric drive and
control system without first reading all documentation provided with the prod-
uct. Read and understand these safety instructions and all user documentation
prior to working with these components. If you do not have the user documenta-
tion for the components, contact your responsible Bosch Rexroth sales partner.
Ask for these documents to be sent immediately to the person or persons re-
sponsible for the safe operation of the components.
If the component is resold, rented and/or passed on to others in any other form,
these safety instructions must be delivered with the component in the official
language of the user's country.
Improper use of these components, failure to follow the safety instructions in
this document or tampering with the product, including disabling of safety devi-
ces, could result in property damage, injury, electric shock or even death.
1.3.2 Requirements for Safe Use
Read the following instructions before initial commissioning of the components
of the electric drive and control system in order to eliminate the risk of injury
and/or property damage. You must follow these safety instructions.
●Bosch Rexroth is not liable for damages resulting from failure to observe the
safety instructions.
●Read the operating, maintenance and safety instructions in your language be-
fore commissioning. If you find that you cannot completely understand the ap-
plication documentation in the available language, please ask your supplier to
clarify.
●Proper and correct transport, storage, mounting and installation, as well as
care in operation and maintenance, are prerequisites for optimal and safe op-
eration of the component.
●Only qualified persons may work with components of the electric drive and
control system or within its proximity.
●Only use accessories and spare parts approved by Bosch Rexroth.
●Follow the safety regulations and requirements of the country in which the
components of the electric drive and control system are operated.
●Only use the components of the electric drive and control system in the man-
ner that is defined as appropriate. See chapter "Appropriate Use".
●The ambient and operating conditions given in the available application docu-
mentation must be observed.
●Applications for functional safety are only allowed if clearly and explicitly
specified in the application documentation "Integrated Safety Technology". If
this is not the case, they are excluded. Functional safety is a safety concept in
Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls
Brake Chopper
4/65 DOK-RCON04-VFC*BRAKE**-IT01-EN-P

which measures of risk reduction for personal safety depend on electrical,
electronic or programmable control systems.
●The information given in the application documentation with regard to the use
of the delivered components contains only examples of applications and sug-
gestions.
The machine and installation manufacturers must
– make sure that the delivered components are suited for their individual ap-
plication and check the information given in this application documentation
with regard to the use of the components,
– make sure that their individual application complies with the applicable
safety regulations and standards and carry out the required measures,
modifications and complements.
●Commissioning of the delivered components is only allowed once it is sure
that the machine or installation in which the components are installed com-
plies with the national regulations, safety specifications and standards of the
application.
●Operation is only allowed if the national EMC regulations for the application
are met.
●The instructions for installation in accordance with EMC requirements can be
found in the section on EMC in the respective application documentation.
The machine or installation manufacturer is responsible for compliance with
the limit values as prescribed in the national regulations.
●The technical data, connection and installation conditions of the components
are specified in the respective application documentations and must be fol-
lowed at all times.
National regulations which the user must take into account
●European countries: In accordance with European EN standards
●United States of America (USA):
– National Electrical Code (NEC)
– National Electrical Manufacturers Association (NEMA), as well as local engi-
neering regulations
– Regulations of the National Fire Protection Association (NFPA)
●Canada: Canadian Standards Association (CSA)
●Other countries:
– International Organization for Standardization (ISO)
– International Electrotechnical Commission (IEC)
1.3.3 Hazards by Improper Use
●High electrical voltage and high working current! Danger to life or serious in-
jury by electric shock!
Brake Chopper Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls
DOK-RCON04-VFC*BRAKE**-IT01-EN-P 5/65

●High electrical voltage by incorrect connection! Danger to life or injury by
electric shock!
●Dangerous movements! Danger to life, serious injury or property damage by
unintended motor movements!
●Health hazard for persons with heart pacemakers, metal implants and hearing
aids in proximity to electric drive systems!
●Risk of burns by hot housing surfaces!
●Risk of injury by improper handling! Injury by crushing, shearing, cutting, hit-
ting!
●Risk of injury by improper handling of pressurized lines!
Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls
Brake Chopper
6/65 DOK-RCON04-VFC*BRAKE**-IT01-EN-P

1.4 Instructions with Regard to Specific Dangers
1.4.1 Protection against Contact with Electrical Parts and Housings
This section concerns components of the electric drive and control
system with voltages of higher than 50 V.
Contact with parts conducting voltages above 50 V can cause personal danger
and electric shock. When operating components of the electric drive and control
system, it is unavoidable that some parts of these components conduct danger-
ous voltage.
High electrical voltage! Danger to life, risk of injury by electric shock or serious
injury!
●Only qualified persons are allowed to operate, maintain and/or repair the
components of the electric drive and control system.
●Follow the general installation and safety regulations when working on power
installations.
●Before switching on, the equipment grounding conductor must have been per-
manently connected to all electric components in accordance with the con-
nection diagram.
●Even for brief measurements or tests, operation is only allowed if the equip-
ment grounding conductor has been permanently connected to the points of
the components provided for this purpose.
●Before accessing electrical parts with voltage potentials higher than 50 V, you
must disconnect electric components from the mains or from the power sup-
ply unit. Secure the electric component from reconnection.
●With electric components, observe the following aspects:
Always wait 30 minutes after switching off power to allow live capacitors to
discharge before accessing an electric component. Measure the electrical
voltage of live parts before beginning to work to make sure that the equip-
ment is safe to touch.
●Install the covers and guards provided for this purpose before switching on.
●Never touch electrical connection points of the components while power is
turned on.
●Do not remove or plug in connectors when the component has been powered.
●Under specific conditions, electric drive systems can be operated at mains
protected by residual-current-operated circuit-breakers sensitive to universal
current (RCDs/RCMs).
●Secure built-in devices from penetrating foreign objects and water, as well as
from direct contact, by providing an external housing, for example a control
cabinet.
Brake Chopper Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls
DOK-RCON04-VFC*BRAKE**-IT01-EN-P 7/65

High housing voltage and high leakage current! Danger to life, risk of injury by
electric shock!
●Before switching on and before commissioning, ground or connect the com-
ponents of the electric drive and control system to the equipment grounding
conductor at the grounding points.
●Connect the equipment grounding conductor of the components of the elec-
tric drive and control system permanently to the main power supply at all
times. The leakage current is greater than 3.5 mA.
1.4.2 Protective Extra-Low Voltage as Protection Against Electric Shock
Protective extra-low voltage is used to allow connecting devices with basic insu-
lation to extra-low voltage circuits.
On components of an electric drive and control system provided by Bosch
Rexroth, all connections and terminals with voltages between 5 and 50 volts are
PELV ("Protective Extra-Low Voltage") systems. It is allowed to connect devices
equipped with basic insulation (such as programming devices, PCs, notebooks,
display units) to these connections.
Danger to life, risk of injury by electric shock! High electrical voltage by incorrect
connection!
If extra-low voltage circuits of devices containing voltages and circuits of more
than 50 volts (e.g., the mains connection) are connected to Bosch Rexroth prod-
ucts, the connected extra-low voltage circuits must comply with the require-
ments for PELV ("Protective Extra-Low Voltage").
1.4.3 Protection against Dangerous Movements
Dangerous movements can be caused by faulty control of connected motors.
Some common examples are:
●Improper or wrong wiring or cable connection
●Operator errors
●Wrong input of parameters before commissioning
●Malfunction of sensors and encoders
●Defective components
●Software or firmware errors
These errors can occur immediately after equipment is switched on or even after
an unspecified time of trouble-free operation.
The monitoring functions in the components of the electric drive and control
system will normally be sufficient to avoid malfunction in the connected drives.
Regarding personal safety, especially the danger of injury and/or property dam-
age, this alone cannot be relied upon to ensure complete safety. Until the inte-
grated monitoring functions become effective, it must be assumed in any case
Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls
Brake Chopper
8/65 DOK-RCON04-VFC*BRAKE**-IT01-EN-P

that faulty drive movements will occur. The extent of faulty drive movements de-
pends upon the type of control and the state of operation.
Dangerous movements! Danger to life, risk of injury, serious injury or property
damage!
A risk assessment must be prepared for the installation or machine, with its spe-
cific conditions, in which the components of the electric drive and control sys-
tem are installed.
As a result of the risk assessment, the user must provide for monitoring func-
tions and higher-level measures on the installation side for personal safety. The
safety regulations applicable to the installation or machine must be taken into
consideration. Unintended machine movements or other malfunctions are possi-
ble if safety devices are disabled, bypassed or not activated.
To avoid accidents, injury and/or property damage:
●Keep free and clear of the machine’s range of motion and moving machine
parts. Prevent personnel from accidentally entering the machine’s range of
motion by using, for example:
– Safety fences
– Safety guards
– Protective coverings
– Light barriers
●Make sure the safety fences and protective coverings are strong enough to re-
sist maximum possible kinetic energy.
●Mount emergency stopping switches in the immediate reach of the operator.
Before commissioning, verify that the emergency stopping equipment works.
Do not operate the machine if the emergency stopping switch is not working.
●Prevent unintended start-up. Isolate the drive power connection by means of
OFF switches / OFF buttons or use a safe starting lockout.
●Make sure that the drives are brought to safe standstill before accessing or
entering the danger zone.
●Disconnect electrical power to the components of the electric drive and con-
trol system using the master switch and secure them from reconnection
("lock out") for:
– Maintenance and repair work
– Cleaning of equipment
– Long periods of discontinued equipment use
●Prevent the operation of high-frequency, remote control and radio equipment
near components of the electric drive and control system and their supply
leads. If the use of these devices cannot be avoided, check the machine or in-
stallation, at initial commissioning of the electric drive and control system, for
possible malfunctions when operating such high-frequency, remote control
Brake Chopper Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls
DOK-RCON04-VFC*BRAKE**-IT01-EN-P 9/65

and radio equipment in its possible positions of normal use. It might possibly
be necessary to perform a special electromagnetic compatibility (EMC) test.
1.4.4 Protection Against Magnetic and Electromagnetic Fields During
Operation and Mounting
Magnetic and electromagnetic fields generated by current-carrying conductors
or permanent magnets of electric motors represent a serious danger to persons
with heart pacemakers, metal implants and hearing aids.
Health hazard for persons with heart pacemakers, metal implants and hearing
aids in proximity to electric components!
●Persons with heart pacemakers and metal implants are not allowed to enter
the following areas:
– Areas in which components of the electric drive and control systems are
mounted, commissioned and operated.
– Areas in which parts of motors with permanent magnets are stored, re-
paired or mounted.
●If it is necessary for somebody with a heart pacemaker to enter such an area,
a doctor must be consulted prior to doing so. The noise immunity of implan-
ted heart pacemakers differs so greatly that no general rules can be given.
●Those with metal implants or metal pieces, as well as with hearing aids, must
consult a doctor before they enter the areas described above.
1.4.5 Protection against contact with hot parts
Hot surfaces of components of the electric drive and control system. Risk of
burns!
●Do not touch hot surfaces of, for example, braking resistors, heat sinks, sup-
ply units and drive controllers, motors, windings and laminated cores!
●According to the operating conditions, temperatures of the surfaces can be
higher than 60 °C (140 °F) during or after operation.
●Before touching motors after having switched them off, let them cool down
for a sufficient period of time. Cooling down can require up to 140 minutes!
The time required for cooling down is approximately five times the thermal
time constant specified in the technical data.
●After switching chokes, supply units and drive controllers off, wait 15 minutes
to allow them to cool down before touching them.
●Wear safety gloves or do not work at hot surfaces.
●For certain applications, and in accordance with the respective safety regula-
tions, the manufacturer of the machine or installation must take measures to
avoid injuries caused by burns in the final application. These measures can
Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls
Brake Chopper
10/65 DOK-RCON04-VFC*BRAKE**-IT01-EN-P

be, for example: Warnings at the machine or installation, guards (shieldings or
barriers) or safety instructions in the application documentation.
1.4.6 Protection during handling and mounting
Risk of injury by improper handling! Injury by crushing, shearing, cutting, hitting!
●Observe the relevant statutory regulations of accident prevention.
●Use suitable equipment for mounting and transport.
●Avoid jamming and crushing by appropriate measures.
●Always use suitable tools. Use special tools if specified.
●Use lifting equipment and tools in the correct manner.
●Use suitable protective equipment (hard hat, safety goggles, safety shoes,
safety gloves, for example).
●Do not stand under hanging loads.
●Immediately clean up any spilled liquids from the floor due to the risk of fall-
ing!
Brake Chopper Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls
DOK-RCON04-VFC*BRAKE**-IT01-EN-P 11/65

2 Important Directions for Use
2.1 Appropriate Use
Bosch Rexroth products represent state-of-the-art developments and manufac-
turing. They are tested prior to delivery to ensure operating safety and reliability.
The products can only be used in the appropriate way. Otherwise, situations re-
sulting in property damage and personal injury may occur.
Bosch Rexroth as manufacturer is not liable for any damages result-
ing from inappropriate use. In such cases, the guarantee and the
rights to payment of damages resulting from inappropriate use are
forfeited. The user alone carries all responsibility of the risks.
Before using Bosch Rexroth products, make sure that all the pre-requisites for
appropriate use of the products are satisfied.
●Personnel that in any way or form use our products must first read and under-
stand the relevant safety instructions and be familiar with appropriate use.
●If the products take the form of hardware, they must remain in their original
state, in other words, no structural changes are permitted.
●It is not permitted to decompile software products or alter source codes.
●Do not mount damaged or faulty products or use them in operation.
●Make sure that the products have been installed in the manner described in
the relevant documentation.
2.2 Inappropriate Use
Using the brake choppers outside of the operating conditions described in this
documentation and outside of the indicated technical data and specifications is
defined as "inappropriate use".
Brake choppers shall not be used under following conditions:
●They are subject to operating conditions that do not meet the specified ambi-
ent conditions. These include, for example, operation under water, extreme
temperature fluctuations or extremely high temperatures.
●Furthermore, the brake choppers shall not be used in applications which have
not been expressly authorized by Rexroth. Please carefully follow the specifi-
cations outlined in the general Safety Instructions!
Bosch Rexroth AG
Important Directions for Use
Brake Chopper
12/65 DOK-RCON04-VFC*BRAKE**-IT01-EN-P

3 Delivery and Storage
3.1 Product Identification
3.1.1 Packing Nameplate
Check if the model information on the packing nameplate is the same as you or-
dered immediately after receipt. If the model is wrong, please contact Bosch
Rexroth distributor.
1Product series
2Short text / Type code
3Volume
4Net weight
5Material number
6Product version index
7Mass weight
8Production week: e.g., 14W20 means
week 20 in 2014
9Product QR code
10 Serial number
11 Manufacturer
12 QR code (Internal use)
13 Certification
Fig. 3-1: Packing nameplate
Brake Chopper Bosch Rexroth AG
Delivery and Storage
DOK-RCON04-VFC*BRAKE**-IT01-EN-P 13/65

3.1.2 Product Nameplate
Check if the model information on product nameplate is the same as you or-
dered immediately after unpacking. If the model is wrong, please contact Bosch
Rexroth distributor.
1Brand logo
2Product series
3Short text / Type code
4Technical data
5Production week: e.g., 14W20 means
week 20 in 2014
6Certification
7Product QR code
8Manufacturer
Fig. 3-2: Product nameplate
3.2 Visual Inspection
Check the product for transport damages, e.g. deformation or loose parts, im-
mediately after unpacking. In case of damage, contact the forwarder at once and
arrange for a thorough review of the situation.
This is also applicable if the packaging is undamaged.
3.3 Scope of Supply
If any of the following standard supply items is missing, please contact Bosch
Rexroth distributor.
●Brake chopper
●Operating Instructions
Bosch Rexroth AG
Delivery and Storage
Brake Chopper
14/65 DOK-RCON04-VFC*BRAKE**-IT01-EN-P
