Bosch D621 Series User manual

D621 Series
EN User's Guide LED Keypad

D621 Series |User's Guide | Security Company
Bosch Security Systems | 8/04 | 2
This system includes a telephone line seizure
feature. The system may be programmed to
communicate with a central monitoring station to
report system events. You will not be able to use
your phone while the system is communicating
with the central monitoring station. In the unlikely
event that the central station is not able to
receive the report, your phone may be unavailable
for up to 20 minutes while the panel makes
additional communication attempts.
Figure 1:Information Box
MYSECURITYCOMPANYIS:
CALL BEFORETEST:____________________________
THISSECURITYSYSTEMISCONNECTEDTOTELEPHONENUMBER:
____________________________________
THESECURITYCONTROLPANELISCONNECTEDTOTHEPHONEJACKLOCATED:
____________________________________
TRANSFORMERLOCATION:_________________________________
CIRCUITBREAKERNUMBER:_______________________________

D621 Series |User's Guide | Contents
Bosch Security Systems | 8/04 | 3
About This User’s Guide ..................................................................5
Introduction...........................................................................................5
Security System Basics.......................................................................7
What Is A Point?....................................................................................7
What Is A Faulted Point?.....................................................................7
Are All Points The Same? ...................................................................7
Controlled Points ...................................................................................7
24-Hour Points........................................................................................7
All On .....................................................................................................8
Part On .....................................................................................................9
Command Center Keys ..................................................................10
Keypad Tones.....................................................................................11
Keypad LED Descriptions.............................................................12
Commands.............................................................................................13
System Events .....................................................................................14
Fire Alarms ............................................................................................14
Burglary Alarms ...................................................................................14
Trouble Events......................................................................................14
How Your System Reports Alarms............................................15
Silence Alarms....................................................................................15
Keypad Adjust (Cmd 49) ................................................................16
Log Out Of The System..................................................................16
Turn the System Off .........................................................................17
Turn The System All On (All On or Cmd 1)..........................18
Turn The System Part On (Part On or Cmd 2).....................20
Turn The System Part 2 On (Cmd 3).........................................21
Set Part 2 Points (Cmd 65)..............................................................23
Turn The System On With No Delay........................................24
Turn The System On With No Exit Tone................................24
Turn The System On With Points Faulted (Force Arm) ...26
Bypass Points.......................................................................................27
Date And Time (Cmd 45)...............................................................28
Change a Passcode (Cmd 55)........................................................29
Change Others’ Passcodes (Cmd 56).........................................30

D621 Series |User's Guide | Contents
Bosch Security Systems | 8/04 | 4
Change Others’ Passcode Level (Cmd 56)..............................32
Add A Passcode (Cmd 56)..............................................................33
Delete A Passcode (Cmd 58).........................................................35
Renew One-Time Passcodes (Cmd 53).....................................36
Check System Troubles (Cmd 4).................................................37
View Alarm Memory (Cmd 40)...................................................38
View System Trouble (Cmd 42) ..................................................39
View Point Trouble (Cmd 48)......................................................41
System Test (Cmd 41).......................................................................42
Walk Test (Cmd 44)..........................................................................44
Reset The System (Cmd 47)...........................................................45
Turn Watch On/Off (Cmd 61)......................................................45
Select Watch Tone (Cmd 62)........................................................46
Select Watch Points (Cmd 63) ......................................................48
Extend Auto On Time (Cmd 51).................................................49
All Areas On (Cmd 80)....................................................................50
All Areas Off (Cmd 81)....................................................................51
Auto-Forward On/Off (Cmd 82)..................................................51
Remote Arming With Telephone, Area 1...............................52
Remote Program (Cmd 43)............................................................53
Security System Limitations..........................................................53
Fire Safety And Evacuation ..........................................................54
Maintenance And Service .............................................................56
Power Failure......................................................................................57
How To Clean The Keypad..........................................................57
Glossary.................................................................................................58
Notes: ...................................................................................................61

D621 Series |User's Guide | About This User’s Guide
Bosch Security Systems | 8/04 | 5
About This User’s Guide
This user’s guide shows you how to use and maintain your
security system. It covers basic functions, such as turning the
system on and off.
This guide describes functions that are programmed by your
security company. Your system may not have all of them.
Certain functions covered may require you to enter your
personal passcode.
Introduction
Your security system helps to secure life, property, and
investments against fire, theft and bodily harm. It consists of
one or more keypads, motion sensors (such as detectors or
devices located on doors and windows), and sensing devices
designed to detect the presence of smoke or combustion. Each
device is connected to a sophisticated control panel with a
microprocessor, which processes all events registered by the
system.
Control of your security system is achieved through the
keypad (the D621, D621W or D621B), which offers a variety
of basic and advanced features. The keypads, shown in
Figure 2, are tailored to meet your individual needs. Moreover,
they have been designed with you, the user, in mind.

D621 Series |User's Guide | Introduction
Bosch Security Systems | 8/04 | 6
Figure 2:D621/D621B Front Panel Features
1
A B C
2 345678
9 10 11 12 13 14 15 16 Part
All
Cmd
Status
TestSystemWeekly
Check ChangeWatch
Areas
4 9981 5297 9A
1
2
3 4
D621 D621B
2
1
3 4
1 -Sounder
2 -Point status indicators 3-All On and Part On indicators 4 -Status and Cmd indicators

D621 Series |User's Guide | Security System Basics
Bosch Security Systems | 8/04 | 7
Security System Basics
What Is A Point?
A Point is a detection device or group of devices connected to
your security system. Points are identified by the area they
monitor, such as a front door, bedroom window, or hallway.
What Is A Faulted Point?
When a point (such as a door or window) is closed, it is
normal. When the door or window is open, the point is
faulted or not normal. When you turn your system on, you
will usually want all of the points in your system to be normal.
However, you can turn your system on with faulted points by
using the Bypass Points command.
If a point indicator on the Keypad is on, the point is faulted.
When the faulted point has returned to normal, the point
indicator on the Keypad turns off.
Are All Points The Same?
Not all points are the same. In fact, there are two basic types
of points: Controlled and 24-Hour.
Controlled Points
Controlled Points respond to alarm conditions depending
upon whether the system is turned on or off. They are
programmed to either respond instantly to alarm conditions or
to provide a delay for you to reach the keypad and turn the
system off. Various controlled points may be located
throughout your house and/or office.
When you turn your system on, you have the option of
turning on all controlled points (All On), or just some of the
controlled points (Part On). Refer to All On and Part On on
page 9for more information.
24-Hour Points
24-Hour Points are always on, even when the system is turned
off. There are two types of 24-Hour Points: Fire and Non-Fire.
Refer to Reset the system for more information.

D621 Series |User's Guide | Security System Basics
Bosch Security Systems | 8/04 | 8
•Fire Points: Only monitor fire detection devices, such as
smoke detectors. They are always on and cannot be
turned off.
•Non-Fire Points: Monitors non-fire detection devices.
They are always on and cannot be turned off.
All On
When you turn your system All On (refer to Figure 3), you are
turning on all controlled points, bothinterior (motion
detectors) and perimeter (doors and windows of the building).
Figure 3:Controlled Points are All On
1
2
3
4
4 4
1 -Dining room
2 -Living room 3 -Kitchen 4 -Bedroom

D621 Series |User's Guide | Security System Basics
Bosch Security Systems | 8/04 | 9
Part On
When you turn your system Part On (refer to Figure 4), you
are turning on only a portion of the controlled points. The
particular points included in this portion are determined by
your security company. Part points may include only the
perimeter (doors and windows) of your system, or the points
on the first floor of a two-story house. Check with your
security company to learn which points are Part points.
Figure 4:Controlled Points are Part On
1
2
3
4
4 4
5 6
1 -Dining room
2 -Living room 3 -Kitchen 4 -Bedroom 5 -controlled
point
6 -Part point

D621 Series |User's Guide | Command Center Keys
Bosch Security Systems | 8/04 | 10
Command Center Keys
Your keypad has nineteen keys to perform the various
functions described in Table 1.
Table 1:Keypad Keys
Key Function
[1], [2], [3],
[4], [5], [6],
[7], [8], [9], [0]
Numeric keys used for entering passcodes and
issuing commands.
[Cmd] Used in conjunction with numeric keys to enter
commands. Also displays system status.
[All On] Lets you turn your system All On. Refer to Turning
the system All On.
[Part On] Lets you turn your system Part On. Refer to Turning
the system Part On.
[No Delay] Lets you turn your system All On or Part On without
entry or exit delay. Refer to Turning the system on
with no delay.
Table 1:Keypad Keys (continued)
Key Function
[Bypass] Lets you bypass one or more points. Refer to Bypass
points.
[*] When available, advances to the next display.
[A], [B], [C] Emergency functions (Fire, Panic, or Emergency
Alarms) may be assigned to these keys by your
installing company.
To activate the special function, press the key twice
(consecutively) within two seconds.
Your security company labels each key to its
assigned function.

D621 Series |User's Guide | Keypad Tones
Bosch Security Systems | 8/04 | 11
Keypad Tones
The keypad emits several distinct tones and illuminates lights
to alert you to system events as described in Table 2.
Table 2:Keypad Tones
Tone Tone Pattern Description
Fire Alarm
When a fire point activates, the keypad
emits a repeated one frequency tone
(on for two seconds, then briefly off).
Burglary
Alarm When a burglary point activates while your system is turned on, the keypad
emits a continuous one frequency tone.
The sounder remains on for the duration
of the time set by your security
company.
Table 2:Keypad Tones (continued)
Tone Tone Pattern Description
Exit Delay Error!
Objects
cannot be
created from
editing field
codes.
After you turn your system on, the
keypad emits an intermittent beep and
counts down the Exit Delay time. If you
do not exit before the exit delay time
expires and an Exit Delay point is
faulted, an alarm event begins.
Entry
Delay
Error
If you press an incorrect key, the keypad
emits an error tone to indicate an invalid
entry. The error tone is the same one
frequency tone as the Trouble Tone, but
is not repeated.
OK —— Indicates a keypad entry is accepted,
such as a correctly entered passcode.
The keypad emits a single, high-pitched
beep for one second.

D621 Series |User's Guide | Keypad LED Descriptions
Bosch Security Systems | 8/04 | 12
Table 2:Keypad Tones (continued)
Tone Tone Pattern Description
Watch various Keypad emits a tone to alert you when
any watched point is faulted. The tone
varies in duration, depending on the
selected Watched Tone. (Refer to
Select watch tone.)
Keypad LED Descriptions
Table 3describes the keypad LEDs.
Table 3:Keypad LED Descriptions
LED Status Description
On No system troubles.
Slow
Flash AC failure, system trouble, or keypad was moved away from its assigned area.
Status
Fast
Flash keypad in Command Mode System Test was initiated.
Off User logged off and no command is active.
Fast
Flash Waiting for passcode entry.
Cmd
On Exit Delay timer is active or a command is in
progress.

D621 Series |User's Guide | Keypad LED Descriptions
Bosch Security Systems | 8/04 | 13
Table 3:Keypad LED descriptions (continued)
LED Status Description
Off Panel disarmed or armed Part On.
Slow
Flash Panel armed All On with No Delay.
All
On Panel armed All On with Entry/Exit Delay.
Off Panel disarmed or armed All On.
Slow
Flash Panel armed Part On/Part 2 On with No Delay.
Part
On Panel armed Part On/Part 2 On with Entry/Exit
Delay.
Commands
Commands allow you to carry out various tasks such as add
or delete passcodes, set the date and time, or test the system.
Each command is detailed throughout this user guide.
Commands are written as: [Cmd] [6] [3]. To enter this
command, first press and release the [Cmd] key, followed by
the [6] key, and then the [3] key.

D621 Series |User's Guide | System Events
Bosch Security Systems | 8/04 | 14
System Events
Your system responds to four types of alarm events. If more
than one event occurs, your system sorts them into one of four
groups:
•Fire alarms (highest priority)
•Burglary alarms
•Fire troubles
•Non-Fire troubles (lowest priority)
Events grouped as highest priority are always sent to the
central station first.
Fire Alarms
Fire alarms are the highest priority events. When a fire point
activates, your keypad emits a Fire Alarm tone. Evacuate all
occupants and investigate for smoke or fire. Make sure all
occupants know the difference between the Burglary Alarm
tone and the Fire Alarm tone.
Burglary Alarms
Burglary alarms are the second priority. When a burglary
point activates, your keypad emits a Burglary Alarm tone.
Ensure all occupants know the difference between the
Burglary Alarm tone and the Fire Alarm tone (refer to Table 2
on page 11).
The keypad display shows each burglary point that went into
alarm by flashing the point number (up to Point 16).
Trouble Events
When a trouble event (such as a loose wire or low battery
condition) occurs, your keypad emits a trouble tone.
The keypad status indicator is on steady. Refer to Check System
Troubles on page 37 for more information on determining the
nature of the trouble.

D621 Series |User's Guide | How Your System Reports Alarms
Bosch Security Systems | 8/04 | 15
How Your System Reports Alarms
Your security system may be programmed to automatically
disconnect your telephone when sending reports to your
security company. Once the report is complete, the system
returns the telephone to normal operation (verify with your
installing company).
Your system makes repeated attempts to send reports to your
security company. If your system fails to report, the keypad
signals a system trouble. Refer to Check System Troubles on
page 37 for more information on determining the nature of
the trouble.
If your telephone service is interrupted, your
security system cannot send reports to your
security company unless it has an alternate
means of transmitting them.
Silence Alarms
When there is an alarm, the alarm tone sounds and the
point(s) in alarm illuminate on the display. If you enter your
passcode before the system dials your security company, the
alarm report is aborted.
1. Enter your passcode to silence the alarm and turn the
system off (if it was turned on). An alarm report is sent if
not acknowledged in time.
2. Press and hold the [Cmd] key to remove the alarm(s)
(flashing point numbers) from the keypad display. Refer
to View Alarm Memory (Cmd 40) on page 38 to see which
points caused the alarm.

D621 Series |User's Guide | Keypad Adjust (Cmd 49)
Bosch Security Systems | 8/04 | 16
Figure 5:Alarm indication
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16 Part
All
Cmd
Status
Keypad Adjust (Cmd 49)
oI can perform this command.
oI cannot perform this command.
Use this command to adjust the keypad sounder volume.
1. Press [Cmd] [4] [9]. Enter your passcode if necessary.
2. To adjust the keypad sounder volume, press and hold the
[*] key and then press [1] to increase the volume or [4] to
decrease the volume.
3. Press [Cmd] to exit this command function when all
adjustments are made.
Log Out Of The System
The system remembers passcodes entered for approximately
10 seconds after you have stopped pressing keys. To log out of
the system, press the [Cmd] key twice. The Cmd LED
remains off, acknowledging that you have successfully logged
out.

D621 Series |User's Guide | Turn the System Off
Bosch Security Systems | 8/04 | 17
Turn the System Off
You have __________ second(s) to enter premises and turn the
system off.
Turn off the security system by entering your passcode. When
the system is on, you must enter through a designated entry
door to prevent an alarm. Opening a designated door starts
the entry delay. During entry delay time, the keypad emits a
entry delay tone every second to remind you to turn the
system on. Enter your passcode before the entry delay time
expires to turn the system off.
If you enter through the wrong door or fail to turn the system
off before the entry delay time expires, you may cause an
alarm. If an alarm occurs, silence the alarm by entering your
passcode and call your security company to let them know it
is not an emergency situation.
1. When the system is All On, the keypad illuminates the All
On indicator. If the system is either Part On or Part 2 On
(refer to Part On on page 9for more information), the
keypad illuminates the Part On indicator.
Figure 6:All On Keypad Indication
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16 CmdPart
Status
All
2. Enter your passcode to turn the system off. Once the
system is off, the keypad turns the All On indicator or the
Part On indicator off.

D621 Series |User's Guide | Turn The System All On (All On or Cmd 1)
Bosch Security Systems | 8/04 | 18
Figure 7:Part On Keypad Indication
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
All
Cmd
Status
Part
Turn The System All On (All On or
Cmd 1)
oI can perform this command.
oI cannot perform this command.
You have __________ second(s) to exit premises before system
turns on.
Use this command to turn on the entire system. Once you
press the All On key, the Exit Delay timer starts its
countdown. Your security company programs the length of
exit delay time to ensure you have adequate time to exit.
You should leave the premises before the exit time expires.
Leaving after exit delay expires starts an alarm event.
1. Make sure all points are normal (not faulted). If your
system has a faulted point, return it to normal or bypass
the point (refer to Bypass Points on page 27).
2. Press [All On]. The keypad may prompt you to enter a
valid passcode if necessary by flashing the Cmd indicator.

D621 Series |User's Guide | Turn The System All On (All On or Cmd 1)
Bosch Security Systems | 8/04 | 19
3. Enter your passcode if necessary. Exit delay begins. The
All On, Status, and Cmd indicators light. You should
leave at this time.
Figure 8:All On Keypad Indication
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16 CmdPart
All Status
During the exit delay, you may stop the system from
turning on by entering your passcode.
If you wish, you can turn the system All On with No
Delay (refer to Section Turn The System On With No Delay on
page 24) by pressing [No Delay] or you may bypass
points by pressing [Bypass]. Refer to Bypass Points on page
27 for more information.
4. During the last 10 seconds of Exit Delay, the Exit Delay
tone becomes more urgent warning you not to exit or to
turn the system off. The system then turns All On. The
All On indicator remains on steady.
5. To turn the system off, enter your passcode.

D621 Series |User's Guide | Turn The System Part On (Part On or Cmd 2)
Bosch Security Systems | 8/04 | 20
Turn The System Part On (Part On or
Cmd 2)
oI can perform this command.
oI cannot perform this command.
You have __________ second(s) to exit premises before the
system turns on.
Part On turns on part of your system, leaving the rest of the
system turned off. Refer to the Point identification section of
your keypad reference card to identify Part points designated
for Part On activation.
Once you press the Part On key, the exit delay timer begins.
You should leave the premises before the exit time expires.
Leaving after exit delay expires starts an alarm event.
1. Make sure Part points are normal (not faulted).
2. Press [Part On]. The keypad may prompt you to enter a
valid passcode by flashing the Cmd indicator.
3. Enter your passcode, if necessary. The Part On, Status,
and Cmd indicators light (Figure 9). If your system has a
faulted point (door or window open), you can either close
it or bypass it (refer to Bypass Points on page 27).
Figure 9:Part On Keypad Indication
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
All
Cmd
Status
Part
If you wish, you can turn the system Part On with No
Delay by pressing [No Delay], or you may bypass points
by pressing [Bypass].
During the exit delay, you may stop the system from
turning on by entering your passcode.
