Intrusion Alarm Systems | DS7447V2 Series LCD Keypads
DS7447V2 Series LCD Keypads
www.boschsecurity.com
uAdjustable volume, display brightness, and display
contrast
uAccessible instruction label
uProgrammable emergency keys
The DS7447V2 is a four-wire alphanumeric liquid
crystal display (LCD) keypad that works with the
DS7060, DS7080iP-32, DS7200 Series, and DS7400Xi
Series Control Panels. It supports all system functions.
The keypad is required for programming the control
panel locally.
Functions
Adjustable Volume and Display
Adjust the non-alarm volume, display brightness, and
display contrast at the keypad.
Accessible Instruction Label
Basic user instructions are on a pull-out slide that you
can install to pull from either the left or the right.
Programmable Emergency Keys
The three unmarked keys across the bottom row of the
keypad are programmable as a fire emergency key, a
special emergency key, and a panic key. Adhesive
labels are provided.
Certifications and approvals
All DS7447V2 Keypad Models: EN50131-1 Grades 1, 2, and 3
DS7447V2-FRA Keypad: NF A2P Type 2 Certification
number: 122000076-01
Region Certification
Europe CE 2004/108/EC EMC Directive (EMC),
2006/95/EC Low-Voltage Directive
(LVD); 2011/65/EU Restriction of the
use of certain hazardous substances in
electrical and electronic equipment [-
EXP, -SWE, --FRA, -BEL, -NL, -HU]
Belgium INCERT B-509-0004/c
Installation/configuration notes
Compatibility Information
Control Panels DS7060, DS7080iP-32, DS7400Xi Series,
DS7200 Series
Wiring and Mounting Considerations
The wire length between the keypad and the control
panel cannot exceed 305 m (1000 ft). Do not mount
the keypad outdoors.
Number of Keypads Wire Type Keypad Distance
from Control Panel
Up to two Unshielded, four-wire,
0.8 mm (22 AWG)
Up to 305 m
(1000 ft)
Up to three Unshielded, four-wire,
1.2 mm (18 AWG)
Up to 305 m
(1000 ft)

Parts included
Quant. Component
1Keypad assembly
1 Info card slide
2 Info cards
1 Ferrite bead with installation instructions
1 Literature – Installation manual
Technical specifications
Environmental Considerations
Relative Humidity: 5% to 93% at +32°C (+90°F),
non‑condensing
Temperature (Operating): 0°C to +50°C (+32°F to +122°F)
Power Requirements
Current Draw: 95 mA idle; 200 mA max (with speaker
volume and backlight brightness on)
Voltage (Operating): 12 VDC
Product Characteristics
Dimensions: 12 cm x 21 cm x 2 cm
(4.6 in. x 8.2 in. x 0.8 in.)
Weight: 439 g (15.5 oz)
Ordering information
DS7447V2‑EXP LCD Keypad
Four wire, alphanumeric LCD display provides volume
controls, display brightness controls, display contrast
controls, and three programmable emergency keys.
Supports all functions on the DS7060, DS7080iP-32,
DS7200 Series, and DS7400Xi Series Control Panels.
Order number DS7447V2-EXP
DS7447V2‑BEL LCD Keypad
Four wire, alphanumeric LCD display provides volume
controls, display brightness controls, display contrast
controls, and three programmable emergency keys.
Supports all functions on the DS7060, DS7080iP-32,
DS7200 Series, and DS7400Xi Series Control Panels.
For use in Belgium.
Order number DS7447V2-BEL
DS7447V2‑DK LCD Keypad
For use in Denmark. Provides volume controls, display
brightness controls, display contrast controls, and
three programmable emergency keys.
Order number DS7447V2-DK
DS7447V2‑FI LCD Keypad
For use in Finland. Provides volume controls, display
brightness controls, display contrast controls, and
three programmable emergency keys.
Order number DS7447V2-FI
DS7447V2‑FRA LCD Keypad
Four wire, alphanumeric LCD display provides volume
controls, display brightness controls, display contrast
controls, and three programmable emergency keys.
Supports all functions on the DS7060, DS7080iP-32,
DS7200 Series, and DS7400Xi Series Control Panels.
For use in France. NF A2P Type 2 Certification number:
122000076-01.
Order number DS7447V2-FRA
DS7447V2‑DE LCD Keypad
For use in Germany. Provides volume controls, display
brightness controls, display contrast controls, and
three programmable emergency keys.
Order number DS7447V2-DE
DS7447V2‑GR LCD Keypad
For use in Greece. Provides volume controls, display
brightness controls, display contrast controls, and
three programmable emergency keys.
Order number DS7447V2-GR
DS7447V2‑HU LCD Keypad
Four wire, alphanumeric LCD display provides volume
controls, display brightness controls, display contrast
controls, and three programmable emergency keys.
Supports all functions on the DS7060, DS7080iP-32,
DS7200 Series, and DS7400Xi Series Control Panels.
For use in Hungary.
Order number DS7447V2-HU
DS7447V2‑IT LCD Keypad
For use in Italy. Provides volume controls, display
brightness controls, display contrast controls, and
three programmable emergency keys.
Order number DS7447V2-IT
DS7447V2‑NL LCD Keypad
Four wire, alphanumeric LCD display provides volume
controls, display brightness controls, display contrast
controls, and three programmable emergency keys.
Supports all functions on the DS7060, DS7080iP-32,
DS7200 Series, and DS7400Xi Series Control Panels.
For use in the Netherlands.
Order number DS7447V2-NL
DS7447V2‑NOR LCD Keypad
For use in Norway. Provides volume controls, display
brightness controls, display contrast controls, and
three programmable emergency keys.
Order number DS7447V2-NOR
2 | DS7447V2 Series LCD Keypads

DS7447V2‑SPA LCD Keypad
Four wire, alphanumeric LCD display provides volume
controls, display brightness controls, display contrast
controls, and three programmable emergency keys.
Supports all functions on the DS7060, DS7080iP-32,
DS7200 Series, and DS7400Xi Series Control Panels.
For use in Spain.
Order number DS7447V2-SPA
DS7447V2‑SWE LCD Keypad
Four wire, alphanumeric LCD display provides volume
controls, display brightness controls, display contrast
controls, and three programmable emergency keys.
Supports all functions on the DS7060, DS7080iP-32,
DS7200 Series, and DS7400Xi Series Control Panels.
For use in Sweden.
Order number DS7447V2-SWE
3 | DS7447V2 Series LCD Keypads
