Intrusion Alarm Systems | D202A Series Vertical LED Keypads
D202A Series Vertical LED Keypads
www.boschsecurity.com
uStep Outside excursion feature provides easy to use
bypass and restoral of entry points
uExit Only function allows users to exit when the
system is On with No Delay without turning the
system Off
uIndividual color-coded lights show system status at
a glance
uHinged door covers keys and user instructions
The D202A Series Keypads have displays that are
strategically placed, easy to read, and bright enough to
be visible from a distance. A pull-up reference card
and labeled keypad provide the user with a quick
reference to features and displays. Most users can
operate the keypad with confidence after only a few
minutes of instruction, eliminating the need for
extensive training sessions.
Functions
Individual Color-coded Lights
The keypads have the following lights to indicate
system status:
• Red light indicating the system is On
• Yellow light indicating the system is On with No Delay
• Red lights indicate each of the eight sensor loops
• Green light indicating the system is "All On"
• Green light indicating the system is "Part On"
• Green light indicating overall system operation is okay
Hinged Door Covers Keys and User Instructions
The hinged door covers the keys when they are not in
use and prevents command entry if someone
accidentally bumps into the keypad. The inside of the
door holds a custom user instruction card.
Coded Sounder
The sounder uses coded tones to provide alarm,
trouble, watch, entry and exit delay, error, and other
annunciation. Some tones can be enabled, disabled,
and otherwise altered by programming.
Three Programmable Emergency Keys
Along with the eleven action keys, there are three
programmable keys that can be programmed for
specific functions, such as Emergency, Fire, or Panic.
Single key operation controls many of the basic
functions. All of the keys illuminate during entry delay
and when a key is pressed. Custom labeling is
provided for all the keys except the "CLEAR" key.
Certifications and approvals
Keypad Approval
D202A and
D202AW
UL365, Police Station Connected Burglar Alarm Units
and Systems
UL609, Local Burglar Alarm Units and Systems
UL985, Household Fire Warning System Units
UL1023, Household Burglar-alarm System Units
UL1076, Proprietary Burglar Alarm Units and
Systems
UL1610, Central Station Burglar-alarm Units CSFM
NFPA 72 Household

Region Certification
USA UL D202A: AMCX: Central Station Alarm
Units (UL1610, UL1635), AOTX: Local
Alarm Units (UL464, UL609), APAW:
Police Station Alarm Units (UL365,
UL464), APOU: Proprietary Alarm Units
(UL1076), NBSX: Household Burglar
Alarm System Units (UL1023), UTOU:
Control Units and Accessories - House-
hold System Type (UL985)
CSFM D202A: 7167-1615: 124
Installation/configuration notes
The D202A and D202AW Keypads are compatible with
D2212B and D2212BE Control Panels.
Refer to the control panel’s installation manual for
information on the maximum number of keypads that
can be used with the specific system. Regardless of
the system or the number of keypads being wired in
parallel, the maximum wire length for all keypads
combined is 152 m (500 ft) of 0.8 mm (22 AWG) wire.
Technical specifications
Enclosure
Dimensions: 12 cm x 21 cm x 2 cm
(4.56 in. x 8.15 in. x 0.816 in.)
Power Requirements
Voltage (Input): 12 VDC supplied by the panel
Current Draw: 30 mA idle; 150 mA maximum
Trademarks
Plexiglas® is a registered trademark of Arkema.
Ordering information
D202A Vertical LED Keypad
Off-white vertical enclosure.
Order number D202A
D202AW Vertical LED Keypad
White vertical case.
Order number D202AW
Accessories
D54B Brass Flush‑mount Kit
Back box and polished brass faceplate.
Order number D54B
D54C Stainless Steel Flush‑mount Kit
Back box and stainless steel faceplate.
Order number D54C
D55 Keypad Desk Stand
Portable desk stand in smoke colored Plexiglas.
Order number D55
D56 Surface Mount Conduit Box
White surface mount box.
Order number D56
D56R Red Surface Mount Conduit Box
Red surface mount box.
Order number D56R
