Location Item Description Specication
AMODULE 1 Plug-in comm
module Communication module options
BETHERNET Ethernet port built-in on-board Ethernet connection (10Base-T/100Base-T)
CUSB USB port USB connector (for rmware updates and RPS connection)
DHeartbeat LED Slow=normal, rapid=service mode
EReset Reset switch Hold ve seconds to enter or exit service mode
FB C Outputs B(2) C(3) Open collector, 50mA, active low
GTMPR Tamper Optional tamper switch connector (ICP-EZTS)
H1 COM 2 to
7 COM 8 Alarm inputs End Of Line (EOL) resistor supervised alarm inputs
IR Y G B SDI2 bus SDI2 device bus
JCOM AUX Aux power 12 VDC, 800mA
KNO C NC Output A(1) Programmable relay output
L+ BAT –
18 VAC,
Battery, Earth
ground, 18 VAC Primary/Secondary power and Earth Ground connections
MMounting Mounting holes Mounting holes for control panel
Control panel connection location
B Series Control Panel
Installer Quick Start Guide
Use this guide to quickly install a Bosch B6512/B5512/B4512/B3512 security system. Additional information is found in the Control Panels Installation Manual.
For additional training:
Bosch YouTube channel:
When you see this icon, use your smart phone with
a QR code reader app to view helpful videos.
Control panel component layout
7 COM 8
RPMT
8MOC72MOC13COM 45COM 6
TESER
COM AUX R Y G B
PWR A B COM
CB
TUPTUO
C
A
R
Y
G
B
R
Y
G
B
Step 1 Mounting the control panel
▶ Mount the enclosure prior to mounting the control panel.
▶ Mount control panel into enclosure with hardware provided.
Bosch tips:
B10
B11
7 COM 8
RPMT
8MOC72MOC13COM 45COM 6
TESER
COM AUX R Y G B
PWR A B COM
CB
TUPTUO
C
A
7 COM 8
RPMT
8MOC72MOC13COM 45COM 6
TESER
COM AUX R Y G B
PWR A B COM
CB
TUPTUO
C
A
NO
EOL
NC
+
TESER TENREHTE
NOTE: Not all
modules are available
in all regions.
B Series Installer's Site:
M
A
B
C
D
E
F
G
HIJKL
Step 2 Installing a communication module
▶ Insert leg of module into slot marked “x.”
▶Cellular: Place antenna on top of enclosure and run cable inside,
then connect to module.
▶PSTN: Connect module to a D166 (RJ31x) jack using a D161/D162
cable.
Bosch tips:
AM Step 3 Installing a keypad
▶ When installing a compatible Bosch keypad, refer to keypad
installation guide for specic wiring diagrams. Basic keypad wiring
is shown below.
▶ When installing more than one keypad, refer to keypad
installation guide for unique address settings.
Bosch tips:
I
Step 4 Installing expansion modules
▶ If installing more than one device that is similar, refer to the
module’s installation guide for address settings (for example,
two of the same device).
▶ If installing a RADION B810 wireless receiver, use address 1 only.
Bosch tips:
I
Step 7 Powering the control panel
▶ Connect wires to control panel before applying battery or AC
power.
▶ Connect earth ground to a cold water pipe (copper) or other
solid connection to ground.
Bosch tips:
L
Step 5 Installing wired inputs
▶ If using a dual EOL, 2K EOL, or no EOL, refer to control panel
installation guide for control panel settings.
▶ If using 2-wired powered devices, use a B201 or D125B.
Bosch tips:
HStep 6 Installing a bell or siren
▶ Output A can supply up to 1 A at 12 VDC when sourced from a
control panel (jumper in AUX PWR position).
▶ Output A can support up to 3 amps at 12 VDC when using a
separate power supply (jumper in DRY position).
▶ Output B and C are open collectors and are limited to 50 mA at
12 VDC.
Bosch tips:
KJ
Step 9 Connecting the control panel using RPS
Bosch tips:
CB
Installation
sequence:
Scan and follow these
videos in sequential order
to the steps listed below.
▶ Connect a computer with RPS installed. Direct RPS connections
can be done through a USB connection or Ethernet connection.
▶ The Account Assistant automatically launches when you create a
new account.
▶ For USB direct connection, use a B99 USB cable.
Step 8 Create panel accounts using RPS
▶ If conguring using the Installer Services Portal, go to Step 11.
▶ Install Remote Programming Software (RPS) v6.06 or later. You can
download RPS from the RPS product page.
▶ Follow the RPS Account Assistant instructions to create new control
panel accounts. The Account Assistant helps you create a new panel
account.
▶ If RPS is not available, keypad programming is an option. Refer to
keypad installation instructions.
Bosch tips:
(North America only)
1. Scan QR code.
2. Scroll down.
3. Locate and select your region
for additional videos.
7 COM 8
RPMT
8MOC72MOC13COM 45COM 6
TESER
COM AUX R Y G B
PWR A B COM
+ BAT -18VAC
CB
TUPTUO
NO C NC
OUTPUT A

FAQs
Test Menu
Notification Test
Revisions
Test Report
Walk Test
RFBT
Billtrap
Transmitter
RFDL–11
PIR Microwave
TriTech
35 x 25 ft.
RFPR–12
PIR, Pet
Immune
40 ft.
RFDW–RM
Recessed Door/
Window Contact
RFDW–SM
Surface Mount
Door/Window
Contact
RFGB
Glass
Break
Detector
RFUN Universal
Transmitter w/
Door/Window
Contact
RFSM
Wireless
Smoke
Detector
RFPR–C12
Curtain PIR,
Pet Immune
40 x 5 ft.
RFPB–SB
RFPB–TB
1 & 2 Button
Panic
RFKF–TBS
RFKF–FBS
2 & 4 Button
Keyfobs
ACA–ATR13 ACD–ATR14CSACD–ATR11ISO
B810 SDI2 Wireless Receiver
RFRP Wireless Repeater
Any Bosch IP camera
DS9370/
DS9371
360
TriTech
70 ft.
ISC–BDL2–WP12G/
WP6G/W12G TriTech
40 X 40 ft./20 x 20
ft./ 40 x 40 ft.
B430 Telephone
(PSTN)
D192G Bell Super
Vision Module
D125B Dual Class B
Initiating Module
B201 2–wire
powered loop
F220/F220–B6R
Smoke Detector
plus Base
D132A
Reversing Relay
B56 Keypad
Backbox
D137
Mounting
Bracket
D138
Mounting
Bracket
Right Angle
ICP–EZTS
Universal
Tamper
B10 Medium
Enclosure
B11 Small
Enclosure
B208 Octo-
Input Module
B308 Octo-
Output Module
ISC–CDL1–W15x
TriTech
50 ft.
Commercial Series
B443 Cellular (HSPA+
SIM Required)
D5500CU
RPS Upgrade
Remote Security
Control
Mobile App
B99
USB Cable
Remote Security Plus
Mobile App
G450 Z-Wave
Home Control Gateway
EN4200
Serial Receiver
B820
Wireless Interface
B942W
Touch Screen
What is my default code?
User Code: 123456
Installer Code: 123
How do I use Output B and C?
Outputs B and C are Open Collector Outputs. Wiring can be
found in control panel installation manual, section heading Open
Collector Outputs.
How do you remotely turn on and turn off the control panel?
This can be done through the use of the Remote Security Control
App.
How do I connect directly to the control panel with Ethernet?
By default, the control panel is set up to auto detect and negotiate
a connection to RPS when an ethernet cable is connected between
them.
What do I need to be able to send personal notications?
SMS (Text) messages require the use of a cellular module and
emails can be sent by either an Ethernet or Cellular connection.
How do I enter “Service Mode”?
Press and hold the yellow reset button on the control panel for 5
seconds (repeat to exit).
Control panel
B901 Access Module
(B6512 only)
(B942 is keypad shown)
D101 Lock and
Key set
ISC–CDL1–WA15x
TriTech+ w/Anti-Mask
50 ft.
Note: Not all products and features are available in all regions. Consult your Bosch representative or product datasheets for details.
*Home automation may not be available in all regions.
Consult your Bosch representative for details.
-A versions of RADION devices are used in North and South America.
Non -A versions are used in Europe, Africa, and Australia.
B442 Cellular
(GPRS SIM Required)
B444 Cellular
(Verizon LTE, hot
SIM Required)
B Series Control Panel
Installer Quick Start Guide
Step 11a
Bosch tips:
Step 12
After system installation and control panel programming, you
must perform a complete system test. A complete system test
includes testing the control panel, all devices, and communication
destinations for proper operation.
Test the system
Bosch tips:
B Series control panel accessories (partial list)
FAQs
Where can I go for additional information?
B520 AUX Power Supply *CX4010
18 VAC
Transformer
*TR1850
18 VAC
Transformer
D1218
18Ah Battery
D135A Low-Battery
Disconnect Module
D126
7Ah Battery
Power Communicators
RADION wireless devices
Keypads
B940W
Touch Screen
B920 Text w/
Function Keys
B930 Text w/
Soft Keys
B915 Text
B921C
Capacitive Touch
RFID tags (for Readers & B942 Keypads)
Inovonics wireless devices
Programing and software
IP camera integration
Enclosures & accessories
Residential re
Access
modules I/O expansion modules
*Home automation
Wired motion detectors
Blue Line Gen2 Series Classic Series
Step 10
Bosch tips:
Congure and send to control panel using RPS
▶ Program your conguration information using Account Assistant.
1. Press close Account Assistant, and connect to control panel. This
opens the Panel Communication window.
2. Press Connect and send conguration programming to control panel.
Accessing the Installer Service Portal
and create panel account
Using the Installer Services Portal:
▶ Before you can use Installer Services Portal you must register for
services at: https://sp.boschsecurity.com.
▶ Make sure the control panel is connected to the network.
1. Log into the Installer Services Portal.
2. Click on New and select Device to create a panel account.
3. Add panel account information.
4. Activate CloudID. ISP searches database for registered ID.
5. Select Activate.
6. Click Add Panel.
3. Press Disconnect from control panel when
programming is complete. Go to Step 12.
*DE-45-18
18 VAC Transformer
*Country specic, variants will apply
(Not in all regions)
(Not in all regions)
(Not in all regions)
(Not in all regions) (Not in all regions)
Step 11b
▶ Search or select device to connect to a control panel. Type in panel
account name in the Search eld to locate new account.
Bosch tips:
Connect and send using the Installer
Service Portal
Using the Installer Services Portal:
B450 Remote Cellular Interface
(Not in all regions)
(Not in all regions)
(Not in all regions)
(Not in all regions) (Not in all regions)
Installer Services
Portal
(Not in all regions)
▶Perform a Walk Test
1. Select Actions.
2. Select Test.
3. Select Walk Test.
4. Choose a test to run.
▶Send a test report
1. Select the panel account.
2. Click Connect.
3. Click Conguration. Program your
conguration information.
4. Click the 3 vertical dots and select
Push Pending Changes to Panel to
send conguration.
5. Click Disconnect when
conguration is complete.
