1 Browser connection
A computer with Microsoft Internet Explorer is used to receive
live images from the camera, control the camera, and replay
stored sequences. The camera is configured over the network
using the browser.
1.1 System requirements
– Network access (Intranet or Internet)
– Microsoft Internet Explorer version 9
– Screen resolution at least 1024 × 768 pixels
– 16- or 32-bit color depth
– Sun JVM installed
The Web browser must be configured to enable Cookies from
the IP address of the unit.
In Windows Vista, deactivate protected mode on the Security
tab under Internet Options.
To play back live video images, an appropriate ActiveX must be
installed on the computer. If necessary, install the Bosch Video
Client.

Camera Browser Interface Browser connection | en 13
Bosch Security Systems Software manual AM18-Q0635 | v5.6 | 2013.01
1.2 Establishing the connection
The camera must have a valid IP address to operate on your
network and a compatible subnet mask. By default, DHCP is
pre-set at the factory to ON and so your DHCP server assigns an
IP address. With no DHCP server the default address is
192.168.0.1
1. Start the Web browser.
2. Enter the IP address of the camera as the URL.
3. During initial installation, confirm any security questions
that appear.
Note:
If you do not connect, the camera may have reached its
maximum number of connections. Depending on the device and
network configuration, each camera can have up to 25 web
browser connections, or up to 50 connections via Bosch Video
Client or Bosch Video Management System.
1.2.1 Password protection in camera
A camera offers the option of limiting access across various
authorization levels. If the camera is password-protected, a
message to enter the password appears.
1. Enter the user name and the associated password in the
appropriate fields.
2. Click OK. If the password is correct, the desired page is
displayed.
1.3 Protected network
If a RADIUS server is used for network access control (802.1x
authentication), the camera must be configured first. To
configure the camera, connect it directly to a computer using a
network cable and configure the two parameters, Identity and
Password. Only after these have been configured can
communication with the camera via the network occur.

14 en | System Overview Camera Browser Interface
AM18-Q0635 | v5.6 | 2013.01 Software manual Bosch Security Systems
2 System Overview
When a connection is established, the Livepage is initially
displayed. The application title bar displays three items:
LIVEPAGE, PLAYBACK, SETTINGS.
Note:
The PLAYBACK link is only visible if a storage medium has been
configured for recording. (With VRM recording this option is not
active.)
2.1 Livepage
The LIVEPAGE is used to display the live video stream and
control the camera.
2.2 Recordings
The PLAYBACK page is used for playing back recorded
sequences.
2.3 Settings
The SETTINGS page is used to configure the camera and the
application interface.

Camera Browser Interface Operation via the browser | en 15
Bosch Security Systems Software manual AM18-Q0635 | v5.6 | 2013.01
3 Operation via the browser
3.1 Livepage
After the connection is established, the Livepage is initially
displayed. It shows the live video image on the right of the
browser window. Depending on the configuration, various text
overlays may be visible on the live video image.
Other information may also be shown next to the live video
image. The items shown depend on the settings on the
LIVEPAGE Functions page.
Figure 3.1 Livepage
3.1.1 Image selection
Click a tab below the video image to display a camera image
stream.

16 en | Operation via the browser Camera Browser Interface
AM18-Q0635 | v5.6 | 2013.01 Software manual Bosch Security Systems
3.1.2 Status icons
Various overlays in the video image provide important status
information. The overlays provide the following information:
Decoding error
The frame might show artefacts due to decoding errors. If other
frames reference this frame, they might also show decoding
errors but won’t be marked with the icon.
Alarm flag
Shown on a media item to indicate an alarm.
Communication error
A communication error, such as a connection failure to the
storage medium, a protocol violation or a timeout, is indicated
by this icon. An automatic reconnection procedure is started in
the background to recover from this error.
Gap
Indicates a gap in the recorded video.
Watermark flag
Watermark is set on media item.
Invalid watermark flag
Indicates that the watermark is not valid.

Camera Browser Interface Operation via the browser | en 17
Bosch Security Systems Software manual AM18-Q0635 | v5.6 | 2013.01
Motion flag
Indicates that motion is dectected.
Storage discovery
Indicates that recorded video is being retrieved.
3.1.3 Cameras with PTZ control
For cameras where PTZ control is possible, the View Control
panel is activated.
Pan and tilt
To control the pan and tilt of PTZ cameras:
Click and hold the up or down arrows to tilt.
Click and hold the left or right arrows to pan.
Click and hold the center area to control both.
Move the mouse cursor over the video image; additional options
for controlling peripherals are displayed with the mouse cursor.
Zoom, focus, and iris
To control the zoom, focus, and iris of PTZ cameras:
1. Click and hold to zoom out; click and hold
to zoom in.
2. Click and hold for far focus; click and hold
for near focus.
3. Click and hold to close the iris; click and hold
to open the iris.

18 en | Operation via the browser Camera Browser Interface
AM18-Q0635 | v5.6 | 2013.01 Software manual Bosch Security Systems
Pre-position
To move the camera to a pre-position, click one of the buttons
numbered one to six.
To store the current position of the camera in a pre-position:
1. Position the camera.
2. Enter a pre-position number.
3. Click Set.
3.1.4 View Control ROI
When the stream 2 encoder stream is set for Region of Interest
(ROI), a specific type of View Control panel is activated.
Refer to Section 9.3 Encoder Regions, page 66 for more
information on setting up stream 2. (When encoder stream 2 is
set for dual ROI, open the camera in a second browser window
to set up the second ROI on stream 2.)
Zoom
To zoom in on a region of the stream 2 image:
Click and hold to zoom in; click and hold to
zoom out.
Click to see the full image.
Select an area
To select a particular region of the image:
1. Click and hold the arrows to move up and down, and from
side to side through the image.
2. Click and hold the center area to move in all directions.

Camera Browser Interface Operation via the browser | en 19
Bosch Security Systems Software manual AM18-Q0635 | v5.6 | 2013.01
Set positions
To store the current view:
1. Select a region of interest.
2. Click Set.
3. Click a number.
To display a pre-set region of interest, click one of the buttons
numbered one to six.
Tracking
For cameras with the ability to track movement, options for
tracking objects within the region of interest are displayed in
the Tracking panel.
When on, the tracking icon is displayed on the image
together with the lines that track moving objects.
Select Off, Auto or Click. If Click is selected, use the mouse to
click on an object to track it.
3.1.5 Cameras with alarm and relay I/O
Depending on the configuration of the unit, the alarm input and
the relay output are displayed in the Digital I/O panel next to
the camera image.
The alarm symbol is for information and indicates the input
status of the alarm input:
– Active 1 = Symbol lights
– Active 0 = Symbol not lit.
The camera relay allows the operation of an external device (for
example, a light or a door opener).
To operate, click the relay symbol.
– The symbol is red when the relay is activated.

20 en | Operation via the browser Camera Browser Interface
AM18-Q0635 | v5.6 | 2013.01 Software manual Bosch Security Systems
3.1.6 System Log / Event Log
The System Log field contains information about the operating
status of the camera and the connection.
Events such as the triggering or the end of alarms are shown in
the Event Log field.
To view, filter and save these messages to a file, click
in the top right-hand corner.
To clear the log, click in the top right-hand corner of
the relevant field.
3.1.7 Saving snapshots
Individual images from the video sequence that is currently
being shown on the Livepage can be saved in JPEG format on
the computer's hard drive.
Click the camera icon to save a single image.
– The storage location depends on the configuration of
the camera.
3.1.8 Recording video sequences
Sections of the video sequence that is currently being shown on
the Livepage can be saved on the computer's hard drive. The
sequences are recorded at the resolution specified in the
encoder configuration. The storage location depends on the
configuration of the camera.
1. Click the recording icon to record video sequences.
– Saving begins immediately. The red dot on the icon
indicates that a recording is in progress.
2. Click the recording icon again to stop recording.
Play back saved video sequences using the Player from
Bosch Security Systems.

Camera Browser Interface Operation via the browser | en 21
Bosch Security Systems Software manual AM18-Q0635 | v5.6 | 2013.01
3.1.9 Running recording program
The hard drive icon below the camera images on the Livepage
changes during an automatic recording.
The icon lights up and displays a moving graphic to
indicate a running recording. If no recording is taking place, a
static icon is displayed.
3.1.10 Audio communication
Audio can be sent and received via the Livepage if the active
monitor and the remote station of the camera support audio.
1. Press and hold the F12 key on the keyboard to send an
audio signal to the camera.
2. Release the key to stop sending audio.
All connected users receive audio signals sent from the camera
but only the user who first pressed the F12 key can send audio
signals; others must wait for the first user to release the key.
3.1.11 Processor load
When accessing the camera with a browser, the processor load
and network information is available in the upper right of the
window next to the Bosch logo.
Move the mouse cursor over the icons to display numerical
values. This information can help with problem solving or when
fine tuning the device.
