CM728B and CM729B
Fingerprint Reader Modules
Security System
Installer Reference Guide
EN
Security Systems

CM728B-CM729B Installer Reference Guide
2Bosch Security Systems 06/12 CM728B-CM729BIRG FTR1.0
The addition of a CM728B or CM729B Fingerprint reader to your installation will allow users to turn areas on and o
or open a door simply by presenting their unique ngerprint credential to the reader. The ngerprint reader fea-
tures 3D pixel sensing technology and can read virtually any nger; wet or dry. The sensor’s hard coating protects
against scratches, impacts and everyday wear-and-tear and provides in excess of 15KV ESD isolation.
The CM728B and CM729B readers include red, green and blue indicators which are used to show area and or door
lock status at all times. To simplify installation, an egress input and lock output are also provided.
A large blue reader status indicator is provided in the nger placement area to simplify user enrolment and day to
day operation. The readers also include haptic technology that takes advantage of the users sense of touch by ap-
plying vibrations to the user’s nger during the analysis and enrolment of ngerprint credentials.
Unlike other systems, the readers are fully integrated with the control panel which means that ngerprint credentials
are automatically transferred between other readers on the system reducing programming and installation time.
Credentials can also be uploaded using the Solutionlink
RAS software for backup purposes and can even be copied
from one panel to another simplifying conguration for us-
ers with multiple sites.
Fingerprint readers connect to the control panel via the
RS485 encrypted LAN and occupies a standard keypad
position in the panel conguration.
Various options can be congured via the Devices - Keypad
& Readers menu in panel programming. User access events
are stored in the panel log and can also be reported if
required.
Box Contents
The CM728B and CM729B are supplied with the following
items,
Module Base Housing
Module Top Housing
Mounting Template - 1:1 Scale
Installer Reference Guide
Plug On Connection Cable
M3 x 6mm Hex Screws x 2
2mm Hex Key
Fingerprint Reader Compatibility
Panels Supported Version Readers Supported
Solution 144 2.00 Up to 16
Table 1: Fingerprint Reader Compatibility
LAN Fingerprint Readers
CM728B - Black and CM729B - White
Figure 1: CM728B Fingerprint Reader

CM728B-CM729B Installer Reference Guide
3
Bosch Security Systems 06/12 CM728B-CM729BIRG FTR1.0
Module Addressing
Each reader tted to the system must be assigned a
unique address on the LAN using the on board rotary
address switch. The following table shows the address
setting for each reader as well as the number of keypad,
reader devices each panel can support.
Figure 2: Address Switch
Module Address Setting
Address No Keypad No
Solution 144 Panel
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
10 10
11 11
12 12
13 13
14 14
15 15
16 16
Table 2: Address Table
i
Note
Only 1 reader can be assigned to each address.
All modules are supplied from the factory set to
address 1. You must power cycle the panel or
perform a LAN scan whenever you change the
module address.
Installation
The reader should be installed onto a solid surface using
suitable mounting xtures. Wiring should only be
performed while the control panel is powered o.
1) Using the 1:1 mounting template supplied, mark
out the location of the 2 mounting holes and the
cable exit hole before drilling out all points as
necessary.
92.0mm
48.0mm
84.0mm
6 x 4.0mm
(1/8”) holes
Tamper Switch
Do Not Create A Hole
In This Location
Connection Cable
Entry Point
CM728B & CM729B Mounting Template
Scale 1:1
Rev 1CM728B & CM729B Mounting Template.ai
Figure 3: Mounting Template (Not to Scale)
2) If the reader is to occupy an address on the LAN
other than address 1, you will need set the required
address before mounting. Each reader on the
system must have a unique address. See Table 2:
for more information.
3) Once the address has been set, terminate the
required wires referring to the Connection Diagram
on page 7. Unused wires should be insulated to
prevent short circuits.
4) If using the on board lock output to open the door,
you must make sure to use a relay and protection
diode as shown.
5) Once the wiring is complete, mount the reader to
the wall and t the cover plate using the M3 x 6mm
hex screws.

CM728B-CM729B Installer Reference Guide
4Bosch Security Systems 06/12 CM728B-CM729BIRG FTR1.0
Fingerprint Reader Operation
Fingerprint readers can be congured to provide system
area control, door access control or both depending on
the installation requirements.
As there is no LCD display on the reader, feedback is
provided via the red, green and blue indicators and the
reader sounder.
The readers also include an egress input and lock output
which can be used to control door access if required.
i
Note
Using the on board lock output is not recommend-
ed when the reader is being used on an external
wall of the building. In this case it is recommended
that you run the lock control wires directly to an
output located on the main panel or output ex-
pander module located inside the building.
LED Indicators
The red and green indicators on the reader show area
status while the blue indicator shows door status. The
addition of the blue indicator allows the system to
display both area and door status at the same time if
required.
LED Operation For Area Control
Led Condition Meaning
Red
On Area All On
Flashing Area Alarm
Green
On Area is OFF
Flashing Area not ready to turn on -
zone(s) unsealed
Red &
Green Both On Area armed in Part mode and all zones sealed.
Red &
Green
Red On
and Green
Flashing
Area armed in Part mode
with zones unsealed.
Red &
Green
Alternate
Flashing
Keypad initialising during
power up or LAN scan.
Red &
Green Both O
Home Area and Door not
programmed or keypad not
powered.
Table 3: Reader LED’s - Area Control
i
Note
The LED indicators will only display the status of
the programmed home area. You cannot move
between areas from this reader. If you require mul-
tiple area status visibility you should use a display
keypad like the CP700.
To have the reader control an area on the alarm system
you must assign the reader to a home area. See the
Devices-Keypads & Readers-Home Area menu option
in panel programming. If alarm system control is not
required then you should set the home area option to
No Area.
i
Note
When the reader has only been congured for
alarm area control, the blue, door indicator will
remain o at all times.
To have the reader control an output (door) on the
system you must assign the reader to a door. See the
Devices-Keypads & Readers-Door Assignment menu
option in panel programming.
Once assigned, the on-board Lock output and Egress
input are automatically assigned to the same door as the
reader.
LED Operation For Door Control
Led Condition Meaning
Blue On Door Locked
Blue Fast Flash Door Unlocked
Blue Continuous
Fast Flash
Door manually unlocked
or overridden.
Blue Continuous
2 Flashes
Door automatically
unlocked by schedule or
time zone.
Red &
Green
Alternate
Flashing
Reader initialising during
power up or LAN scan.
Blue O Door not programmed or
reader not powered.
Table 4: Reader LED‘s - Door Control
If both alarm area and door control is required, you must
assign a home area and a door to the reader.
i
Note
When the reader has been congured for door
control only, the green and red indicators will
remain o at all times.

CM728B-CM729B Installer Reference Guide
5
Bosch Security Systems 06/12 CM728B-CM729BIRG FTR1.0
Egress and Lock Control
The ngerprint reader includes an egress input and a
lock output which can be used to simplify the wiring
when the reader is being used for door or access control.
The lock output consists of a protected open collector
transistor that can be used to operate a relay to control
the door lock. The output will go from open to low for
xed 5 seconds whenever the associated door is trig-
gered.
i
Note
The on board lock output will operate for a xed
time period of 5 seconds when triggered. If a dif-
ferent time is required then you should use another
output on the system to operate the door lock.
The lock output, and LAN+ power supply are not de-
signed to operate and power the door lock directly. You
should always t a relay and protection diode to the lock
output in combination with a separate power supply.
The optional CM444 Relay Module has been designed
to suit this task. If you require the door to operate when
the mains power has failed then you will also need to t
a battery backup to the external power supply. See the
wiring diagram in Figure 5: for more details.
The Egress input on the readers allow you to simplify the
wiring required to implement a egress button on the
inside of the door. The egress input triggers the lock
output on the reader by operating or ring the associ-
ated Door.
The egress input should be connected via a momentary
or push button switch to system ground. When the but-
ton is pressed the lock output on the reader will trigger
for a xed 5 second period.
For greater security, if the egress input is not being
used it should be disabled via panel programming. See
Devices-Keypads & Readers-General Options in panel
programming.
i
Note
Any zone on the system can be congured to trigger
a door and can therefore also be used to operate
the lock output on the reader.
Tamper Switch Operation
The ngerprint reader includes a built-in tamper switch
which will trigger when the cover is removed or the unit
is removed from the wall. You should adjust the angle of
the switch leaver to suit the wall surface. If the tamper
alarm is not required it can be disabled via panel pro-
gramming.
Alert Tones
The reader emits several distinct tones to alert you
of particular system events. The volume level can be
adjusted or turned o via programming by setting the
reader volume to the lowest level. See the Devices-
Keypads & Readers-Commands menu in panel program-
ming.
Reader Alert Tones
Event Alert Tone Emitted
Fire
Alarm
If the system registers a re alarm, the
reader will sound 3 short beeps fol-
lowed by a 1.5 second pause. This will
repeat until reset by the user or until
the siren run time expires.
Burglary
Alarm
If the system registers a burglary
alarm, the reader will sound a continu-
ous siren tone until reset by a user or
until the siren run time expires.
Trouble
If a system trouble condition occurs,
the reader will sound 4 x fast short
beeps followed by a 5 second pause
and will repeat this tone until the user
acknowledges the trouble condition
from a display keypad
Exit
Delay
The exit delay warning will sound 1
short beep every second when the
area the reader has been assigned to
is armed. During the last 10 seconds
of exit time the warning tone will
speed up indicating that the time has
nearly expired.
Entry
Delay
The hi/lo entry delay warning tone will
sound once every second when an
entry delay zone in the area the reader
has been assigned to is triggered. If
the system is not disarmed before the
entry time expires then an alarm will
occur.
Error
If an invalid nger is presented to the
reader the unit will sound a 2 second
warning tone indicating that the cre-
dential was rejected for some reason.
See the panel log for more details.
Chime
Alert
If chime mode is active then the read-
er will sound fast short beeps to alert
the user when a zone programmed for
chime is opened. Chime mode is only
applicable when the area is disarmed.
Table 5: Reader Tones
i
Note
In some situations, you may prefer that the alert
tones are disabled. See the Devices-Keypads &
Readers-Indicator Options menu in panel program-
ming to disable these features. Setting the reader
volume to o will stop all audible warning signals
at the reader.

CM728B-CM729B Installer Reference Guide
6Bosch Security Systems 06/12 CM728B-CM729BIRG FTR1.0
Reader Front View Showing Indicators And Sensor
Cleaning the Sensor
Under normal use it is not necessary to clean the ngerprint sensor every day, however from time to time and es-
pecially in dirty environments cleaning the will help ensure reliable performance. If only minor cleaning is needed,
use a lint-free cloth and carefully wipe the sensor surface. If a more thorough cleaning is needed, follow the method
presented below.
You will need the following,
Lint-free cloth OR cotton swab.
Isopropyl alcohol (IPA)
How to clean:
1) Put a small amount of IPA on a lint-free cloth or cotton swab. Only a small amount is needed to make the cloth
or cotton swab slightly damp. If the surface is heavily contaminated with a greasy substance the amount of IPA
should be increased so that the contaminant can be fully dissolved. Do not pour the IPA directly onto the
reader.
2) Gently rub the cloth or cotton swab over the whole sensor surface. Make sure to reach the area close to the
frame where dirt/grease can accumulate.
3) Use a dry piece of cloth or cotton swab and wipe the sensor surface dry. Look carefully at the sensor surface
and make sure that no residual liquid remains on the sensor.
4) Repeat the process if necessary.
i
Note
Avoid using detergents and soaps containing oily substances since they can leave contaminants that negatively
eect the sensor performance.
Blue Reader Status Indicator
On steady indicates reader
is ready to accept nger.
Flashing indicates reader is
busy processing credential.
O indicates that the
reader is not ready.
Blue Door Status Indicator
Indicator will be o is no
door control has been
congured for this reader.
See “Table 4: Reader LED‘s -
Door Control”on page 4
for more details.
Fingerprint Sensor Area
Fingers should be placed
so they cover the entire
sensor area and that the
nger is resting along
the nger guide.
There is no need to press
down on the sensor.
Finger Placement Dimple
The small raised dimple at
the top of the placement
area is used to help with
consistent nger placement.
Always make sure that the
nger is touching the dim-
ple during placement.
Figure 4: Reader Indicators and Sensor View
Red and Green Area
Status Indicators
Indicators will be o if no
area control has been
congured for this reader.
See “Table 3: Reader LED’s -
Area Control” on page 4
for more details.

CM728B-CM729B Installer Reference Guide
7
Bosch Security Systems 06/12 CM728B-CM729BIRG FTR1.0
Wiring / Connection Diagram
The optional CM444 relay module provides
an easy way to interface the readers lock
output to the door lock.
Because of its small physical size
(12.5 x 46 x 12mm) it can be easily located
in the wall cavity if required.
The mechanical tamper switch provides tamper monitoring
to the front housing and to the rear wall mounting.
The leaver on the switch should be carefully bent using
pliers so that the switch is closed when the reader is
installed on the wall.
The tamper switch can be disabled via panel
programming if required.
Lock
Output
EGRESS
INPUT
N/O
BK
RD
WH
BL
YL
GN
MODULE LAN
CONTROL PANEL
-A B
+
TO
DOOR
LOCK
+-
+12V
DF70
N/O
COM
N/C
CM444 Relay Card
RED
BLACK
WHITE
BLUE
YELLOW
GREEN
= LAN +
= LAN -
= LAN A
= LAN B
= LOCK
= EGRESS
Wiring Legend
DOOR
LOCK
PROTECTION
DIODE
+
CM444 RELAY CARD
+
Egress
Input
RD
CM720B or CM723B
Power Supply
(Battery backed up)
+ -
473 473 473 473 473 473 473 473 473
T
o
C
o
n
t
r
o
l
P
a
n
e
l
The egress input
is low (0V) to trigger.
Disable via panel
programming if not
being used.
Address Select Switch. Keypads and LAN Readers
must be set to a unique address as per“Table 2: Ad-
dress Table”on page 3.
All ngerprint readers are supplied from
the factory set to Address 1.
Figure 5: CM728B and CM729B Connection Diagram
i
Note
You must power cycle the panel or perform
a LAN scan after connecting the CM728B or CM729B
for the system to initialise the module.

CM728B-CM729B Installer Reference Guide
8Bosch Security Systems 06/12 CM728B-CM729BIRG FTR1.0
Understanding Fingerprint Analysis, Reader Limitations And Other Considerations
Fingerprint patterns are made up of shapes, which determine the general classication
characteristics of the print. In all ngerprints a centre part can be found, which is called
the ngerprint core. The area surrounding the core holds many of the interesting nger-
print characteristics that are unique for each individual.
The upper parts of all ngerprints look very much alike (parallel curves) with very few
distinct areas. To ensure adequate ngerprint detail is available, users should make sure to
place the entire core area of the ngertip onto the sensor area using the placement dimple
as a guide.
Do not point the end of the nger onto the sensor as this part of the ngerprint does not
contain enough unique biometric information for high security applications. Also note
that you do not need to place any downward pressure for the sensor to read the credential.
According to the ngerprint and system characteristics described above, the following conclusions can be made
regarding placement of the nger:
 •Thengershouldbeplacedinthesamepositioneverytime.
 •Thengertipshouldcoverthewholesensorsurface.
 •Thengerprintcoreshouldbeplacedasnearthesensorcentreaspossible.
Fingerprint recognition systems are limited by the number of calculations required for authentication, and the num-
ber of iterations can be reduced by means of correct ngertip placement and repeatability. There are several situa-
tions which can arise when the using the system that may lead to unreliable performance. These can be divided into
the following four areas; translation, rotation, nger pitch and nger roll.
Translation - is dened as the dierence in horizontal and/or vertical
direction from the enrolled template to the verication occasion.
The CM728B and CM729B readers allow a few millimetres in both
horizontal and vertical direction (between the enrolled ngerprint
and the veried ngerprint). Translation is essentially a result of the
lack of guidance of the ngertip in both directions. The level of
translation depends also on the nger size. If the user has small
ngers then there is more space for the nger to move around
compared to a bigger nger.
Finger Rotation - is dened as the angle dierence between an
imaginary centre line of the nger from one placement to another.
The CM728B and CM729B readers allow some variation from the
enrolment occasion but when the rotation exceeds a certain angle, the
algorithms will not be able to handle this variation. Small ngers are
generally more susceptible to nger roll issues.
Figure 5: Fingerprint Core
Figure 6: Fingerprint Core
Figure 7: Fingerprint Core
Enrolment Verication
Enrolment Verication

CM728B-CM729B Installer Reference Guide
9
Bosch Security Systems 06/12 CM728B-CM729BIRG FTR1.0
Finger Pitch - occurs when only the upper part of the ngertip is placed
on the sensor, as if the user is pointing at something.
As the upper parts of all ngerprints look very much alike with very few
distinct areas, this situation should be avoided. To ensure the reader re-
ceives enough ngerprint detail make sure the ngertip core is covering
the sensor area during placement.
Finger Roll - is dened as an incorrect positioning due to the nger rolling in a
sideways direction.
As with the nger pitch scenario it is important to understand that the system
needs to receive enough ngerprint detail. If the nger is big enough and/or
the rolling is not too severe, then sucient information can be captured.
Working Environment - Some environments are known to negatively aect human ngerprints in a way that dam-
ages the nger skin. For example bricklaying, landscaping and other work places where the hands / ngerprints are
regularly damaged. In these situations using a proximity reader or keypad may be more suitable than the ngerprint
reader.
Ergonomics - The ergonomic considerations vary depending on which type of applications the ngerprint reader
is integrated into. Generally, the most natural position of the body is preferred and will give the most repeatable
results.
If the user is standing, the relative position to the reader is crucial. When integrating a technical system in dierent
environments, one important parameter is to try to adapt the system into the regular behaviour of the user. If for
example the reader is positioned besides the door, it might lead to one of the four main problems described earlier.
Another essential parameter is at which height the reader is placed. If it is placed too low, the nger pitch problems
are more likely to arise, and if placed too high the user cannot see where to position their ngertip.
Enrolling Fingerprints And Using The Reader
The following steps will help you to get the best performance from the ngerprint reader. You will need to select the
various programming options using the standard LCD keypad before moving to the reader. Various options can be
congured for each reader tted to the system and these are programmed via the Keypads & Readers menu.
1) When adding or enrolling ngerprints it is important to place and hold the nger in the correct position while
the system records the credential. Fingers should be placed so that the pad is making full contact with the
sensor. Do not use ngertips.
2) Enrolling can take up to 5 seconds to complete and users should keep there nger still during this process until
the reader vibrates and beeps to indicate successful enrolment. If a long error beep is heard then you should
repeat the procedure.
3) Users should present their nger in the same position as they did when it was enrolled. Use the raised dimple
on the reader surface as a guide. People with smaller ngers may nd this dicult at rst but with practice even
they will be able to use the reader.
4) The reader will vibrate as soon as it has completed reading the ngerprint. Once you feel the vibrations you
should remove your nger.
Figure 9: Fingerprint Core
Figure 8: Fingerprint Core

CM728B-CM729B Installer Reference Guide
10 Bosch Security Systems 06/12 CM728B-CM729BIRG FTR1.0
5) If authentication fails on the rst attempt, remove
your nger and wait for the large blue status
indicator to come on before trying again.
Whenever the reader is busy working you may see
the following screen on the lcd keypad. Wait for a
few seconds before trying again.
Fr9 Unit Busy. Please try
later.
Press OK or MENU
6) In some cases the unit may not be able to read a
nger because the nger is cut or damaged by
other means. Extremely wet or dry ngers may
also cause read errors but these are rare. In this
case you should revert to using your PIN number
on the standard keypad.
The following programing menus are available,
Access > Fingerprint >
Add Fingerprint MENU 1-8-0
This menu allows a master user to add a new ngerprint
for users that have been assigned to the same area(s) as
the Master user.
Enter programming mode (PIN + MENU) then,
1. Enter [MENU] + [1] + [8] + [0].
A list of users will display on the keypad.
2. Use the [] and [] keys to select the user that you
want to add a a ngerprint for, then press [OK].t.
Ur1 John Smith
Ur2 Debbie Smith
Ur3 User 3 Name
Press  OK or MENU
3. The system will prompt you to present the nger
to the reader. If more than 1 ngerprint reader
is installed then the system will prompt you to
select the reader to learn from.
Fr9 Keypad 9 Name
Fr10 Keypad 10 Name
Fr11 Keypad 11 Name
Press  OK or MENU
4. You must hold your nger on the reader without
moving until you hear a conrmation beep which
could take up to 5 seconds.
Position Finger for Ur1
John Smith at Fr9
Press OK or MENU
5. A Master user can only delete a ngerprint of a
user that has been assigned to the same area(s) as
the Master user.
i
Note
Only one ngerprint can be assigned to each user.
To change a ngerprint for an existing user, you
will need to delete the old ngerprint rst.
Access > Fingerprint >
Delete Fingerprint MENU 1-8-1
This menu allows a Master user the ability to delete a
ngerprint for those users that have been assigned to
the same area(s) as the Master user.
Enter programming mode (PIN + MENU) then,
1. Enter [MENU] + [1] + [8] + [1].
A list of users will display on the keypad.
2. Use the [] and [] keys to select the user who’s
ngerprint you want to delete, then press [OK].
Ur1 John Smith
Ur2 Debbie Smith
Ur3 User 3 Name
Press  OK or MENU
The keypad will display;
Press Ok to delete
ngerprint for Ur1
John Smith
Press OK or MENU
3. When prompted press the [OK] key to conrm
ngerprint deletion.
Access > Fingerprint >
Fingerprint Status MENU 1-8-2
This menu allows a master user the ability to identify
a ngerprint which has been programmed into the
system. Only ngerprints that have been assigned to
the same area(s) as the Master user can be identied.
Enter programming mode (PIN + MENU) then,
1. Enter [MENU] + [1] + [8] + [2].
The system will prompt you to present the nger
to the reader.
Position Finger at
Fr9
Press OK or MENU
2. Once presented the system will display the user
assigned to the ngerprint.
Finger belongs to Ur1
John Smith
Press OK or MENU

CM728B-CM729B Installer Reference Guide
11
Bosch Security Systems 06/12 CM728B-CM729BIRG FTR1.0
CM728B - CM729B Specications
Part Number: CM728B - Black - LAN Fingerprint Reader (RS485).
CM729B - White - LAN Fingerprint Reader (RS485).
Format: Proprietary
Operating Voltage: 10.0V D.C - 14.5V D.C. @ 100mA Max.
Module Connection:
(RS485 LAN)
Max total LAN length using multi strand security cable = 300m ,
Max total LAN length using 2 pair twisted shielded data cable (Belden 8723) = 1200m.
See full control panel manual for complete wiring instructions.
Lock Output: Protected open collector transistor output 500mA.
Egress Input: Low (0V) to trigger. Can be disabled via software control.
Dimensions: 74mm(W), 23mm(D), 116mm(H). CM444 = 46mm(W), 12.5mm(D), 12mm H)
Environment: -30˚ to 55˚C RH 5 to 85% at 30˚C non-condensing.
Fixing Method: The CM728B and CM729B should be mounted on a sturdy vertical wall using xtures appropriate
for the wall construction type.
Warranty: 3 years from date of manufacture (return to base).
N12138N12138 RoHS
In the interest of ongoing product development this
document is subject to change without notice.
Conguration Examples Quickstart
Using the Fingerprint reader for alarm control only.
1. Install the ngerprint reader as per instructions.
2. Set the home area for the reader (keypad).
3. Set reader (keypad) options as required.
4. Assign users to the area.
5. Learn or add users ngerprints.
Using the Fingerprint reader for access control
function only.
1. Install the reader (keypad) as per instructions.
2. Set the door for the reader (keypad).
3. Set reader (keypad) options as required.
If using the on board reader lock output, jump to step 6.
4. Set output event type to door.
5. Set output event assignment.
6. Assign users to the door.
7. Learn or add users ngerprints.
Using the Fingerprint reader for both Alarm and
Access control functions.
1. Install the reader (keypad) as per instructions.
2. Set the home area for the reader (keypad).
3. Set the Door for the reader (keypad).
4. Set reader (keypad) options as required
If using the on board reader lock output, jump to step 7.
5. Set output event type to door.
6. Set the output event assignment.
7. Assign users to the area.
8. Assign users to the door.
9. Learn or add users ngerprints.
The above examples show how to congure the
CM728B and CM729B readers to control an area and /
or a door on a Solution 144 panel. Consult the instal-
lation manual for programming information if you are
using a dierent panel.
Points To Remember
1. The reader is not weatherproof and should not be exposed to water or direct sunlight.
2. Mount the reader at a suitable height for all users where possible.
3. In some cases it may be preferable to learn a users thumb print if this helps with the presentation angle.
4. Repeatable nger placement is a critical factor in the performance and reliability of the ngerprint reader.
5. A user can enrol a dierent nger under a dierent user to allow multiple area control if required.
6. During nger presentation always wait to feel the vibration before removing the nger from the reader.
7. During enrolment it is important to hold the nger as still as possible to ensure the best image quality.
8. If the blue status light on the reader is o then the reader is busy and cannot process ngerprints.

Bosch Security Systems
25 Huntingwood Drive
Huntingwood, NSW 2148
Australia
Phone: [phone]
Facsimile: [phone]
© 2012 Bosch Security Systems
CM728B-CM729BIRG
Issue FTR1.0
