Contents
The security industry goes digital 4
Digital products selection table 6
DVR1A Digital video recorder 8
Eazeo DVR Digital video recorder 10
DVR1C Digital video recorder 12
DVR4C Digital video recorder 14
Divar Digital versatile recorders 16
DiBos digital recorder and transmission system 18
IP product matrix 20
Classic line -10 series 22
Professional line 1000 series 24
Professional line 8000 series 26
VIDOS, VIDOS - NVR 27 - 28
Site installation advice 29
External storage devices 30
Technical comparison chart 31
Divar digital recording performance tables 33
Frequently asked questions 34
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 3

04
The security industry
goes digital!
Digital Video Recording is now well accepted as the
recording method of choice, offering much more than
just the well known benefits of improved constant
recording quality, lower maintenance, such as valuable
time and cost savings through the added efficiency
offered by digital systems.
Advances in compression and storage devices means
that compact units are available for storing and archiving
the recordings in much less space than was needed with
conventional tape based systems.
Remote access over public or private data or telephone
networks, or even the internet means that you can access
live video and recordings from wherever you want and
whenever the need arises.
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 4

05
The Bosch range of digital recorders is designed to meet
the widest range of applications.
Whether you simply want to upgrade from conventional
analogue time lapse recorder to Eazeo, use the Divar as
stand alone unit or part of a networked solution, fully
integrate the DiBos with a management system, use the
DVR4C as a low cost high quality recorder, or bring a
conventional matrix based system into the 21st century
by connecting to a network with IP products, Bosch has
the right unit.
To help you make the best choice from the Bosch range
of digital recorders and network products, this guide
summarizes the key features and benefits, and gives clear
reasons for choosing the best unit for your applications.
Bosch is a major player in security and observations sys-
tems, so all products are made to the highest standards.
Our warranty and advanced exchange programme are
second to none, ensuring peace of mind for the user
and installer.
The Bosch digital product range truly brings digital
CCTV within your reach.
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 5

06
Digital products
selection table
** = Highly recommended
* = Recommended
Applications
Application requirements DVR1A Eazeo DVR1C DVR4C
DVR
Use with Eazeo System **
Replace TLR in System ***
Replace Mux & TLR ****
Highest Quality Recording ****
Audio ***
Real-time Recording * **
Live Viewing over Network ****
Viewing Recordings over Network ****
Simultaneous Record and Playback **
Multiple Remote Viewers **
Complete System Control over Network *
Authenticated Recording *****
Burn CD with Event Video
External Disk Array
Analyse Events in Recording *
USB for archiving **
Typical applications
Small Retail Outlets ** ** * **
Shop and Fast Food Chains ** ** * **
Large Retail Outlets and Malls
Casinos
Sports Stadiums & Complexes
City Centers
Metro, Bus and Railway Stations
Housing Estates, Public Areas
Utilities
Large Office Buildings, Industrial Sites
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 6

07
Digital products
selection table
Application requirements Divar DiBos IP/Video
Recorder
Use with Eazeo System *
Replace TLR in System *
Replace Mux & TLR **
Highest Quality Recording ** * *
Audio *
Real-time Recording *
Live Viewing over Network ** ** **
Viewing Recordings over Network ** ** **
Simultaneous Record and Playback ** **
Multiple Remote Viewers ** ** **
Complete System Control over Network** ** *
Authenticated Recording ** ** *
Burn CD with Event Video ** ** *
External Disk Array ** ** **
Analyse Events in Recording ****
Typical applications
Small Retail Outlets *
Shop and Fast Food Chains ** *
Large Retail Outlets and Malls ** ** **
Casinos ** * *
Sports Stadiums & Complexes ** * *
City Centers ** **
Metro, Bus and Railway Stations ** * *
Housing Estates, Public Areas ** *
Utilities ** ** *
Large Office Buildings, Industrial Sites ** **
see page 20
** = Highly recommended
* = Recommended
Applications
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 7

08
• Superior image quality through digital recording
• Quick search by date/time, alarm events and recording list
• Easy Jog/Shuttle playback control
• Export pictures and clips to Compact Flash cards
• Uninterrupted recording for one week or longer
DVR1A
Digital video recorder
DVR1A1081
Specifications
Model DVR1A1081
Disk Capacity 80 GB
Network Connection No
Record Speeds (ips) 50, 25, 12, 8, 5, 2, 1.5, 1, 0.5, 0.2, 0.1
Quality modes Lower Low Basic Standard High Superior
File size (Bytes) 15 KB 20 KB 25 KB 30 KB 35 KB 40 KB
Approximate recording time in hours
Record Duration (25 ips) 60 45 35 30 25 22
Record Duration (8 ips) 180 135 105 90 75 65
Record Duration (5 ips) 295 220 180 150 125 110
ips = images per second
See page 31 for detailed product comparisons
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 8

09
DVR1A
general application
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 9

10
• Superior image and audio quality through digital recording
• Quick search by date/time, alarm events and recording list
• Easy Jog/Shuttle playback control
• Export pictures and clips to Compact Flash cards
• Uninterrupted recording for one week or longer
• Remotely view recordings and live pictures with
web-based browser
EAZEO DVR
Digital video recorder
DVR1B1161
Specifications
Model DVR1B1161
Disk Capacity 160 GB
Network Connection Ethernet
Record Speeds (ips) 25, 12, 8, 5, 2, 1.5, 1, 0.5, 0.2, 0.1
Quality modes Lower Low Basic Standard High Superior
File size (Bytes) 15 KB 20 KB 25 KB 30 KB 35 KB 40 KB
Approximate recording time in hours
Record Duration (25 ips) 120 90 70 60 50 44
Record Duration (8 ips) 360 270 210 180 150 130
Record Duration (5 ips) 590 440 360 300 250 220
ips = images per second
See page 31 for detailed product comparisons
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 10

1111
EAZEO
general application
remote viewer software
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 11

12
• Superior image and audio quality through digital recording
• Quick search by date/time, alarm events and recording list
• Easy Jog/Shuttle playback control
• Export pictures and clips to Compact Flash cards
• Uninterrupted recording for one week or longer
• Remotely view recordings and live pictures with
web-based browser
• Single camera or multiple camera input routed via a
multiplexer
DVR1C
Digital video recorder
DVR1C1161
Specifications
Model DVR1C1161
Disk Capacity 160 GB
Network Connection Ethernet
Record Speeds (ips) 50, 25, 12, 8, 5, 2, 1.5, 1, 0.5, 0.2, 0.1
Quality modes Lower Low Basic Standard High Superior
File size (Bytes) 15 KB 20 KB 25 KB 30 KB 35 KB 40 KB
Approximate recording time in hours
Record Duration (25 ips) 120 90 70 60 50 44
Record Duration (8 ips) 360 270 210 180 150 130
Record Duration (5 ips) 590 440 360 300 250 220
ips = images per second
See page 31 for detailed product comparisons
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 12

13
DVR1C
general application
remote viewer software
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 13

14
• 4-Channel video and audio
• Real-time recording
• Small file sizes for extended recording
• Simultaneous recording and playback
• Easy local archiving via USB
• Remote viewing, playback and control
DVR4C
Digital video recorder
Specifications
DVR4C DVR4
Cameras 4
Disk versions 80GB 160GB 320 GB 600 GB
Network connection Ethernet (TCP/IP)
Quality modes (data rates at 25 IPS)Low 250 kbps
Standard 500 kbps
Medium 750 kbps
High 1 Mbps
Superior 1,5 Mbps
Record speed 25, 12.5, 6, 3, 1.5, 0.75, 0
Record duration (medium quality) 80GB 160GB 320 GB 600 GB
25 IPS 8 days 16.5 days 33 days 62 days
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 14

15
DVR4C
general application
remote viewer software
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 15

1616
Divar Digital versatile
recorders
• Integrated digital CCTV solution for managing, controlling
and viewing up to 16 cameras
• Digitally records at up to 50 IPS and plays back simultaneously
• Authenticates images for evidence
• User-friendly Control Center for remote access to multiple
Divars
• Can be expanded up to a 256 camera CCTV recording system
with video manager
• ATM/POS interface support
• Internal or external DVD writer
• Adim support
Note: Specifications are for PAL on all products.
Specifications
Model DIVAR6 DIVAR9 DIVAR16
Cameras 6 9 16
Disk versions 80, 160, 320 or 600 GB
Network connection Ethernet, TCP/IP
Quality modes file size (Bytes) Standard - 16 KB
Medium - 25 KB
High - 40 KB
Record speeds (ips) 50 total, configurable per camera:
25, 12.5, 8, 6, 5, 4, 3, 2, 1, 1/2, 1/5, 1/10,0
Record duration (standard mode) 80 GB 160 GB 320 GB 600 GB
50 ips 30 hrs 60 hrs 119 hrs 8,6 days
16 ips 93 hrs 7,8 days 15,5 days 27 days
6 ips 10 days 20 days 6 weeks 10 weeks
ips = images per second
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 16

17
Divar
DVD
Intuikey
PC Control Center
Control Center
System 1
System 2
System 3
Divar Basic Application
Divar Advanced Application
Cameras and AutoDome
Divar applications
Multiple Divar
control center
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 17

1818
DDiBos Digital recorder
and transmission system
• Image is displayed when an alarm is triggered.
• Ensures quick reaction to an alarm, by displaying
up-to-the-minute images.
• Sequence of events leading up to the alarm.
• History of events by recording image sequences.
• Web Browser access Control of several PTZ cameras.
Note: Specifications are for PAL on all products.
Specifications
Model Modular Compact Micro
Camera Inputs 16 or 32 8 or 16 4,8 or 16
Y/C Cameras inputs 8 or 16 4 or 8
Resolution of images 704 x 288 pixels 704 x 288 pixels 720 x 288 pixels
Image digitization Y:U:V, 4:2:2 Y:U:V, 4:2:2 Y:U:V, 4:2:2
Stored IPS 100 50 25/50
Contact inputs
(Camera - Y/C Cameras) 32/16 16/8 5, 8 or 16
Relay outputs
(Camera - Y/C Cameras) 16/8 8/4 no, 4 or 8
Internal hard disk 120, 300, 480 GB, 1 TB120, 300, 480 GB, 1 TB 120 or 250 GB
External hard disks Up to 2.2 TB
(DVAS or DVAD series)
19” rack (HxWxD-cm) 17,5x48,5x40 17,5x48,5x40 11x38x29,5
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 18

1919
DiBos application
DiBos user interface
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 19

2020
IP product matrix
VideoJet 10 VideoJet 10i VideoJet 10 XT S/E*
S/E* S/E*
Interfaces
Ethernet 10/100 BT autosensing
ISDN — • —
Video In 1/- 1/- 1/-
Video Out -/1 -/1 -/1
Full-Duplex Audio • • •
Trigger In 1 1 1
Relay Out 1 1 1
Serial Data 2 2 2
CompactFlash For Wireless LAN or local storage
USB — — —
Video/Audio Specifications
Video Standards PAL, NTSC
Compression Standard MPEG-2 — — —
Compression Standard MPEG-4 • • •
Compression Standard M-JPEG • • •
Presets** (per channel) 16 16 16
Max. Resolution 720x576 pixel (PAL) resp. 720x480 pixel (NTSC)
Max. Frame/Fieldrate 25 fps resp. 30 fields per second
Audio Standards G.711
Bandwidth Control • • •
Alarms and Recording
Motion Detection •/- •/- •/-
Video Loss Alarm •/- •/- •/-
Contrast Alarm •/- •/- •/-
Connection on Alarm •/• •/• •/•
Pre-/Post-Alarm Recording •/- •/- •/-
Integrated Long-Term Memory (via CompactFlash)
NVR Support (with integrated long-term memory)
Features
Password Protection •/• •/• •/•
Watermarking — — —
Multicasting •/• •/• •/•
Network Protocols RTP, Telnet, UDP, TCP, IP, ARP, HTTP, IGMP, ICMP, SNMP R
Remote Control and Configuration •/• •/• •/•
Remote Control of Peripherals •/• •/• •/•
Upgrade via FlashMemory •/• •/• •/•
Integration into Managementsystem •/• •/• •/•
• integrated optional *sender/receiver ** freely configurable *** future option
325 Dig Sec Ref Guide-EN_03.qxd 02-12-2004 12:05 Pagina 20
