Bosch AMAX 2100 User manual

AMAX panel
AMAX panel 2100 | AMAX panel 3000 | AMAX panel
3000 BE | AMAX panel 4000
en Operation Manual

Table of contents
1Safety 5
2Short information 6
2.1 Introduction 6
2.2 Technical data 6
2.3 Keypads 6
2.4 Keypad indicators 8
2.5 Quick keypad operations instructions 12
2.6 User menu 17
3Arming and disarming areas 19
3.1 Arming areas 19
3.1.1 Arming in AWAY mode 19
3.1.2 Arming in STAY mode 21
3.1.3 Forced arming 23
3.2 Disarming areas 23
3.2.1 Disarming with a keypad 23
3.2.2 Disarming with a master keypad 23
3.2.3 Disarming with key switch 24
3.2.4 Disarming with RADION RF keyfob 24
4Changing the menu language 25
5Changing date, time and daylight saving time 26
6System test 28
6.1 Siren test 28
6.2 Communication test 28
6.3 Walk test mode 28
7Bypassing/isolating 29
7.1 Bypassing/unbypassing zones 29
7.1.1 How to bypass/unbypass a zone via text keypad 29
7.1.2 How to bypass/unbypass a zone via LED/LCD keypad 29
7.1.3 How to view bypassed zones 30
7.2 Bypassing faults or tamper conditions 30
7.3 Isolating zones 30
7.3.1 How to isolate/unisolate a zone via text keypad 30
7.3.2 How to isolate/unisolate a zone via LED/LCD keypad 30
AMAX panel Table of Contents | en 3
Bosch Sicherheitssysteme GmbH 2017.04 | 07 | F.01U.295.569

7.3.3 How to view isolated zones 31
8Schedules 32
9Macros 33
9.1 Recording macros 33
9.2 Playing macros 34
10 Codes 36
10.1 Add/change user codes 36
10.2 Change individual code 38
11 Keypad alarm operation commands 39
11.1 Keypad panic alarm 39
11.2 Keypad fire alarm 39
11.3 Keypad medical alarm 39
12 Domestic dialing 40
12.1 Domestic dialing alarm 40
12.2 Confirming the domestic call 40
13 Event log recall mode 41
13.1 How to select all event log recall mode 41
13.2 How to select EN event log recall mode 41
13.3 How to select dialer event log recall mode 41
14 Faults and tamper conditions 42
14.1 System fault or tamper analysis mode via text keypad 42
14.2 System fault or tamper analysis mode via LED/LCD keypad 42
15 Resetting the control panel 47
16 Troubleshooting 48
4en | Table of Contents AMAX panel
2017.04 | 07 | F.01U.295.569 Bosch Sicherheitssysteme GmbH

Safety
Danger!
Electricity
Injuries due to electricity are possible if the system is not
operated correctly or if the system is opened or modified.
– Never open or modify the system.
– Please contact your installer if you want to get your system
modified.
!
Caution!
Sensitive components
Damage of sensitive components is possible if the system is not
handled carefully or if the system is opened or modified.
– Always handle the system carefully.
– Never open or modify the system.
– Please contact your installer if you want to get your system
modified.
1
AMAX panel Safety | en 5
Bosch Sicherheitssysteme GmbH 2017.04 | 07 | F.01U.295.569

Short information
Introduction
This manual contains information on how to operate the system
easily and quickly. It describes the main steps required for
operation of the AMAX panel 2100 / 3000 / 3000 BE / 4000
together with a text and/or a LED/LCD keypad described in
Keypads, page 6. It is possible to add an optional text keypad
as a master keypad.
Detailed information about the installation of this and other
modules and devices, advanced settings and programming can
be found in the Installation Manual. Information on the main
steps required for basic system installation and setup can be
found in the Quick Installation Guide.
Technical data
Frequency bands of operation Power level for radio
equipment
GSM900 Class 4 (2W) - GPRS Class 33
GSM1800 Class 1 (1W) - GPRS Class 33
UMTS2100 Class 3 (0.25W)
Keypads
The following text keypad can be used for operating AMAX panel
2100 / 3000 / 3000 BE / 4000.
2
2.1
2.2
2.3
6en | Short information AMAX panel
2017.04 | 07 | F.01U.295.569 Bosch Sicherheitssysteme GmbH

IUI-AMAX4-TEXT
The following LED/LCD keypads can be used for operating AMAX
panel 2100 / 3000 / 3000 BE / 4000.
IUI-AMAX3-LED8 IUI-AMAX3-LED16
AMAX panel Short information | en 7
Bosch Sicherheitssysteme GmbH 2017.04 | 07 | F.01U.295.569

IUI-AMAX-LCD8
Notice!
Only IUI-AMAX4-TEXT can be used as a master keypad.
Keypad indicators
The following tables show an overview and a description of the
keypad indicator icons.
All keypad types
Keypad
Indicator
Icons
Status Definition
AWAY
on Area is armed in AWAY
mode.
off Area is not armed in
AWAY mode.
Slow flash (1 second
lights on/1 second
lights off)
Exit time.
2.4
8en | Short information AMAX panel
2017.04 | 07 | F.01U.295.569 Bosch Sicherheitssysteme GmbH

Fast flash (0.25
seconds lights on/0.25
seconds lights off)
System is in
programming mode or
code function mode.
STAY indicator flashes
simultaneously.
Or:
One or more areas but
not all are in AWAY
mode (master keypad)
STAY
on Area is armed in STAY
mode.
off Area is not armed in
STAY mode.
Slow flash (1 second
lights on/1 second
lights off)
Exit time.
Fast flash (0.25
seconds lights on/0.25
seconds lights off)
System is in
programming mode or
code function mode.
AWAY indicator flashes
simultaneously. When
bypass function is
performed, only the
STAY indicator flashes.
Or:
One or more areas but
not all are in STAY
mode (master keypad)
MAINS
on AC main power is
normal.
AMAX panel Short information | en 9
Bosch Sicherheitssysteme GmbH 2017.04 | 07 | F.01U.295.569

Slow flash (1 second
lights on/1 second
lights off)
AC main power supply
failed.
FAULTS
on System fault, tamper,
bypassed zone or
isolated zone condition
is present and has been
viewed but not
restored yet.
Or:
System is in service
mode.
off System is in normal
status.
Flashes System fault, tamper,
bypassed zone or
isolated zone condition
must be acknowledged.
All icons Flashing No communication to
the keypad.
Only for LED/LCD
Keypad
Indicator
Icons
Status Definition
1 2 3 ….
on Zone is triggered.
off Zone is normal.
10 en | Short information AMAX panel
2017.04 | 07 | F.01U.295.569 Bosch Sicherheitssysteme GmbH

ZONE (1-8) Fast flash (0.25
seconds lights on/0.25
seconds lights off)
Zone was alarmed or is
in alarm status.
Slow flash (1 second
lights on/1 second
lights off)
Interior zone is in STAY
arm mode.
Or:
This zone is bypassed
or isolated in the
current area (area
keypad) / There is a
bypassed or isolated
zone in this area
(master keypad).
Only for LCD
Keypad
Indicator
Icons
Status Definition
on Area is disarmed.
The following table shows an overview and a description of the
keypad sound icons.
Sound Indicator Definition
Short beep A keypad button has been pressed.
Short beep, followed by a
one-second beep
The requested operation is refused.
Incorrect operation signal.
Two short beeps The system accepted the code. The
system executed the requested
function.
AMAX panel Short information | en 11
Bosch Sicherheitssysteme GmbH 2017.04 | 07 | F.01U.295.569

One short beep every
minute
Fault tone, unacknowledged system
failure.
One short beep every two
seconds
Exit time started.
Continued sound – Last 10 seconds on exit time
– Keypad fault or tamper sound
(fault or tamper to be
acknowledged)
– Keypad alarm sound
Continuous 0.5 second
beep, stops for 0.5
seconds
Entry delay time (until alarm occurs
or area is disarmed)
Quick keypad operations instructions
The following table shows an overview of the quick keypad
operations and the corresponding user permissions. For
information on changing codes and defining user permission
levels, refer to Codes, page 36.
Function Command
Default code for user 1 =
2580
Default code for user 2 =
2581
D A B S M
2
M
1
I
N
Arm/Disarm
AWAY Arm [code] + [#] / [#] for 3 sec.
(quick arm)
√ √ √ √ √ √ √
AWAY Arm All
Areas (only on
master keypad)
[code] + [0] [0] + [#] √ √ √ √ √ √ √
2.5
12 en | Short information AMAX panel
2017.04 | 07 | F.01U.295.569 Bosch Sicherheitssysteme GmbH

Function Command
Default code for user 1 =
2580
Default code for user 2 =
2581
D A B S M
2
M
1
I
N
Direct AWAY Arm
(only on master
keypad
[code] + [2-digit area no.] +
[#]
√ √ √
STAY Arm [code] + [*] / [*] for 3 sec.
(quick arm)
√ √ √ √ √ √ √
STAY Arm All
Areas (only on
master keypad)
[code] + [0] [0] + [*] √ √ √ √ √ √ √
Direct STAY Arm
(only on master
keypad
[code] + [2-digit area no.] +
[*]
√ √ √ √ √ √ √
Disarm [code] + [#] √ √ √ √ √ √
Disarm One Area
(only on a master
keypad)
[code] + [2-digit area no.] +
[#]
√ √ √ √ √ √
Disarm All Areas
(only on master
keypad)
[code] + [#] √ √ √ √ √ √
Display
Display Info
(Fault/Tamper
Analysis)
[code] + [2] [1] + [#] √ √ √ √
Bypass/Isolate
AMAX panel Short information | en 13
Bosch Sicherheitssysteme GmbH 2017.04 | 07 | F.01U.295.569

Function Command
Default code for user 1 =
2580
Default code for user 2 =
2581
D A B S M
2
M
1
I
N
Bypass/Unbypass
Zone
Text keypad: [code] + [3]
[1] + [#] + [1 or 2-digit
zone no.] + [#]
LED/LCD keypad: [code] +
[3] [1] + [1 or 2-digit zone
no.] + [*] + [#]
√ √ √ √ √
[code] + [3] [1] + [#]
(cancel LED keypad)
√ √ √ √ √
Bypass Fault/
Tamper
[code] + [3] [4] + [#] √ √ √ √
Inquire Bypass [code] + [3] [3] + [#] √ √ √ √ √
Isolate/Unisolate
Zone
[code] + [3] [5] + [#] √ √ √
Inquire Isolate [code] + [3] [6] + [#] √ √ √
Reset
Reset Fault/
Tamper (In some
country versions
only the installer
can reset a
tamper alarm)
[code] + [6] + [#] √ √ √ √
Macros
Record Macro 1 [code] + [8] [1] + [#] +
sequence to be recorded +
[#] for 3 sec.
√ √ √ √
14 en | Short information AMAX panel
2017.04 | 07 | F.01U.295.569 Bosch Sicherheitssysteme GmbH

Function Command
Default code for user 1 =
2580
Default code for user 2 =
2581
D A B S M
2
M
1
I
N
Record Macro 2 [code] + [8] [2] + [#] +
sequence to be recorded +
[#] for 3 sec.
√ √ √ √
Record Macro 3 [code] + [8] [3] + [#] +
sequence to be recorded +
[#] for 3 sec.
√ √ √ √
Play Macro 1 [code] + long press [1] /
[1] for 3 sec. (quick macro)
* * * * * * √
Play Macro 2 [code] + long press [2] /
[2] for 3 sec. (quick macro)
* * * * * * √
Play Macro 3 [code] + long press [3] /
[3] for 3 sec. (quick macro)
* * * * * * √
Alarm commands
Keypad
Emergency Alarm
long press [1] and [3] or
[*] and [#]
√ √ √ √ √ √ √
Keypad Fire long press [4] and [6] √ √ √ √ √ √ √
Keypad Medical
Alarm
long press [7] and [9] √ √ √ √ √ √ √
Other Commands
Switch to Master
Keypad
[code] + [0] [0] [0] + [#]
(only on text keypad)
√ √ √ √
Switch to Area
01-16
[code] + [0] [2-digit area
no.] + [#] (only on text
keypad)
√ √ √ √
AMAX panel Short information | en 15
Bosch Sicherheitssysteme GmbH 2017.04 | 07 | F.01U.295.569

Function Command
Default code for user 1 =
2580
Default code for user 2 =
2581
D A B S M
2
M
1
I
N
Display all Event
Log
[code] + [2] [2] + [#] (only
on text keypad)
√ √
Display EN Event
Log
[code] + [2] [3] + [#] (only
on text keypad)
√ √
Display Dialer
Event Log
[code] + [2] [4] + [#] (only
on text keypad)
√ √
Siren Test [code] + [4] [1] + [#] √ √ √ √
Communication
Test
[code] + [4] [2] + [#] √ √ √ √
Walk Test [code] + [4] [3] + [#] √ √ √ √
Change Date/
Time
[code] + [5] [1] + [#] √ √ √
Daylight Saving
Time (+1h)
[code] + [5] [2] + [#] √ √ √ √
Daylight Saving
Time (-1h)
[code] + [5] [3] + [#] √ √ √ √
Add/Change User
Code
[code] + [5] [4] + [#] √ √ √
Change Individual
Code
[code] + [5] [5] + [#] √ √ √ √ √ √ √
Call Back [code] + [5] [7] + [#] √ √ √ √
16 en | Short information AMAX panel
2017.04 | 07 | F.01U.295.569 Bosch Sicherheitssysteme GmbH

Function Command
Default code for user 1 =
2580
Default code for user 2 =
2581
D A B S M
2
M
1
I
N
Change Language [code] + [5] [8] + [#] + [2-
digit no. for available
languages] + [#]
01=EN; 02=DE; 03=ES;
04=FR ; 05=PT; 06=PL;
07=NL; 08=SE; 09=TR
√ √ √ √
Installer Access [code] + [7] [1] + [#]
(enable)
[code] + [7] [2] + [#]
(disable)
√ √
System Reset [code] + [9] [9] [8] [9] +
[#]
√ √ √ √
D = Duress User
A = Arming User
B = Basic User
S = Super User
M1 = Master User 1
M2 = Master User 2
IN = Installer
* This function can be enabled/disabled individually for every
user.
4For further information on codes, refer to Add/change user
codes, page 36.
User menu
The following table shows an overview of the user menu.
2.6
AMAX panel Short information | en 17
Bosch Sicherheitssysteme GmbH 2017.04 | 07 | F.01U.295.569

START PLAY
SCHEDULE ENABLE
INSTALLER ACCESS
ENABLE INSTALLER
DISABLE INSTALLER
DATE/TIME
CHANGE DATE / TIME
DST OPTIONS
CHANGE INDIV CODE
INITIATE CALL BACK
CHANGE LANGUAGE
MACRO START
INPUT MACRO No 1-3
RECORD :END # 3s
AREA SWITCH
SYSTEM SETTINGS
DAYL.SAV.TIME +1h
DAYL.SAV.TIME -1h
ADD/CHG USER CODE
SYSTEM TEST
SIREN TEST
COMMUNICATION TEST
WALK TEST
ALL EVENT RECALL
EN EVENT RECALL
DIAL EVENT RECALL
EVENT PRINT
PRINTER ENABLE
RESET
ZN/FLT/TAMP BYPASS
ZONE BYPASS
BYPASS INQUIRE
BYPASS FLT./ TAMP.
INQUIRE
ZN/FAULT/TAMP INQ.
ZONE ISOLATE
ISOLATE INQUIRE
[ / ]USER MENU
ARM/DISARM
ARM AWAY
ARM STAY
DISARM
18 en | Short information AMAX panel
2017.04 | 07 | F.01U.295.569 Bosch Sicherheitssysteme GmbH

Arming and disarming areas
Arming areas
Notice!
When the number of incorrect code entries on the keypad
reaches a specified limit (configured by the installer), the
keypad will automatically lock for 180 seconds and an alarm is
reported. If the keypad is idle for one minute, the system will
automatically exit from any operational mode except from walk
test mode.
Arming in AWAY mode
The AWAY mode is used to arm the premises to detect a would-
be intruder, when you leave the premises and require that all
zones are activated in a ready state.
Keypad arming
There are two methods to arm the area assigned to your keypad
in AWAY mode.
Method 1
4Enter your code and press [#].
PThe system beeps twice, the AWAY indicator flashes slowly
and exit time starts. After the exit time, the AWAY indicator
is lit.
Method 2 (quick arm)
4Press and hold [#] until the system beeps twice.
PThe AWAY indicator flashes slowly and exit time starts.
After the exit time, the AWAY indicator is lit.
To enable/disable this function contact your installer.
Master keypad arming
With a master keypad, either all areas or a single area can be
armed in AWAY mode.
3
3.1
3.1.1
AMAX panel Arming and disarming areas | en 19
Bosch Sicherheitssysteme GmbH 2017.04 | 07 | F.01U.295.569

Arming all areas
4Enter your code, press [0] [0] and [#].
PThe system beeps twice, the AWAY indicator flashes slowly
and exit time starts. After the exit time, the AWAY indicator
is lit and all areas are displayed as armed.
Arming all areas (quick arm)
4Press and hold [#] until the system beeps twice.
PThe system beeps twice, the AWAY indicator flashes slowly
and exit time starts. After the exit time, the AWAY indicator
is lit and all areas are displayed as armed.
Arming a single area (direct AWAY arm)
Arming a single area with a master keypad is only possible for
users with the permission level master 1 or master 2.
4Enter your code, press the 2-digit area number of the area
to be armed and press [#].
PThe AWAY indicator flashes slowly and exit time starts.
After the exit time, the AWAY indicator is lit and the
selected area is displayed as armed.
4Repeat if you want to arm multiple areas.
To enable/disable this function contact your installer.
Telephone remote arming
Notice!
Telephone remote arming is only possible when the system has
only one assigned area.
Users can use a telephone to arm the system.
1. Dial the control panel number.
The control panel answers the call and issues a long beep.
2. Press [#].
PWhen the panel receives the signal it confirms the arming of
the control panel with a high tone.
To enable/disable this function contact your installer.
20 en | Arming and disarming areas AMAX panel
2017.04 | 07 | F.01U.295.569 Bosch Sicherheitssysteme GmbH
