Bosch PRAESENSA User manual

PRAESENSA
Public Address and Voice Alarm System
en Installation manual

PRAESENSA Table of contents | en 3
Bosch Security Systems B.V. Installation manual 2019.11 | V1.00 |
Table of contents
1Important product information 8
1.1 Safety instructions 8
1.2 Disposal instructions 9
1.3 Class A Notice for FCC and ICES 003 9
2About this manual 10
2.1 Intended audience 10
2.2 Training 11
2.3 Related documentation 11
2.3.1 Other related documentation 11
2.4 Listing of open source components 12
2.5 Copyright notice 12
2.6 Trademarks 12
2.7 Notice of liability 12
2.8 Document history 12
3System introduction 13
3.1 Product overview 13
3.2 High level system characteristics 15
4General installation procedures and instructions 18
4.1 Location of racks and enclosures 18
4.2 Unpacking products 20
4.3 Equipment racks and cabinets 20
4.4 Mounting the 19"-rack devices 20
4.5 Cable requirements 22
4.5.1 Precautions 22
4.5.2 Cable type recommendations 23
4.6 Network requirements and considerations 25
4.6.1 Network topology 26
4.6.2 Network connector ports 26
4.6.3 Audio content and device control 26
4.6.4 Network security 26
4.6.5 Network speed and bandwidth usage 27
4.6.6 System size limits 28
4.6.7 Network switches 28
4.6.8 Setting up connections 29
4.6.9 Network redundancy 29
4.6.10 IP-addressing 30
4.6.11 Transmission methods 31
5System composition 33
5.1 Constant voltage systems 33
5.2 Amplifier selection 34
5.3 Amplifier power and crest factor 36
5.4 Battery calculation 37
5.4.1 Topology 37
5.4.2 Operating conditions 37
5.4.3 Power consumption 40
5.4.4 Accurate battery size calculation 41
5.4.5 Quick battery size calculation 42
5.4.6 Uninterruptable power supply size calculation 43

4en | Table of contents PRAESENSA
2019.11 | V1.00 | Installation manual Bosch Security Systems B.V.
5.5 Heat loss calculation 45
6From installation to configuration 47
6.1 MAC-addresses and hostname 47
6.2 Connecting the system controller 48
6.3 Network connections to devices 49
6.3.1 Star topology 49
6.3.2 Tree topology 49
6.3.3 Ring topology 49
6.3.4 Hop count 50
6.4 Device status and reset 51
7System controller | PRA-SCL/SCM/SCS 53
7.1 Introduction 53
7.2 Functions 53
7.3 Functional diagram 54
7.4 System controller variants 55
7.5 Indicators and connections 56
7.6 Installation 56
7.6.1 Parts included 56
7.6.2 Memory card 57
7.6.3 Power supply 58
7.6.4 Ethernet network 59
7.6.5 Internal battery 60
7.6.6 Reset to factory default 60
7.7 Approvals 61
7.8 Technical data 61
8*Amplifier, 600W 4-channel | PRA-AD604 64
8.1 Introduction 64
8.2 Functions 64
8.3 Functional diagram 66
8.4 Indicators and connections 67
8.5 Installation 68
8.5.1 Parts included 68
8.5.2 Safety ground 69
8.5.3 Power supply 70
8.5.4 Lifeline 71
8.5.5 Amplifier outputs 72
8.5.6 Ethernet network 77
8.5.7 Reset to factory default 77
8.6 Approvals 78
8.7 Technical data 78
9Amplifier, 600W 8-channel | PRA-AD608 82
9.1 Introduction 82
9.2 Functions 82
9.3 Functional diagram 83
9.4 Indicators and connections 84
9.5 Installation 85
9.5.1 Parts included 85
9.5.2 Safety ground 86
9.5.3 Power supply 86

PRAESENSA Table of contents | en 5
Bosch Security Systems B.V. Installation manual 2019.11 | V1.00 |
9.5.4 Lifeline 87
9.5.5 Amplifier outputs 89
9.5.6 Ethernet network 93
9.5.7 Reset to factory default 93
9.6 Approvals 94
9.7 Technical data 94
10 End-of-line device | PRA-EOL 98
10.1 Introduction 98
10.2 Functions 98
10.3 Functional diagram 99
10.4 Connections 99
10.5 Installation 99
10.5.1 Parts included 99
10.5.2 Wiring 100
10.5.3 Mounting 101
10.6 Approvals 102
10.7 Technical data 102
11 Multifunction power supply, large | PRA-MPS3 104
11.1 Introduction 104
11.2 Functions 104
11.3 Functional diagram 106
11.4 Indicators and connections 107
11.5 Installation 108
11.5.1 Parts included 108
11.5.2 Battery and fuse 109
11.5.3 Mains power connection 115
11.5.4 Amplifier power supply 116
11.5.5 Lifeline 117
11.5.6 Power supply connection to system controller 119
11.5.7 Power over Ethernet 120
11.5.8 Ethernet network 121
11.5.9 Control inputs 123
11.5.10 Control outputs 124
11.5.11 Reset to factory default 125
11.6 Approvals 125
11.7 Technical data 126
12 LCD call station | PRA-CSLD, PRA-CSLW 130
12.1 Introduction 130
12.2 Functions 130
12.3 Functional diagram 131
12.4 Indicators and connections 132
12.5 Installation 134
12.5.1 Parts included 134
12.5.2 Interconnection call station / extension 135
12.5.3 Power over Ethernet 135
12.5.4 Ethernet network 136
12.5.5 Line input 137
12.5.6 Call station microphone frequency response 138
12.5.7 Mounting 139

6en | Table of contents PRAESENSA
2019.11 | V1.00 | Installation manual Bosch Security Systems B.V.
12.5.8 Reset to factory default 139
12.6 Approvals 139
12.7 Technical data 140
13 Call station extension | PRA-CSE 143
13.1 Introduction 143
13.2 Functions 143
13.3 Functional diagram 144
13.4 Indicators and connections 144
13.5 Installation 145
13.5.1 Parts included 145
13.5.2 Extension connected to a call station 146
13.5.3 Labeling 147
13.5.4 Mounting a button cap 149
13.6 Approvals 151
13.7 Technical data 151
14 Ethernet switch | PRA-ES8P2S 153
14.1 Introduction 153
14.2 Functions 153
14.3 Functional diagram 154
14.4 Indicators and connections 155
14.5 Installation 156
14.5.1 Parts included 156
14.5.2 Power supply connection 157
14.5.3 Fault relay connection 157
14.6 Approvals 157
14.7 Technical data 158
15 Fiber transceiver | PRA-SFPLX, PRA-SFPSX 161
15.1 Introduction 161
15.2 Functions 161
15.3 Functional diagram 161
15.4 Installation 162
15.4.1 Parts included 162
15.4.2 Application 162
15.4.3 Transceiver 163
15.4.4 Fiber cable 163
15.5 Approvals 164
15.6 Technical data 164
16 Power supply module | PRA-PSM24, PRA-PSM48 166
16.1 Introduction 166
16.2 Functions 166
16.3 Functional diagram 167
16.4 Indicators and connections 167
16.5 Installation 168
16.5.1 Parts included 169
16.5.2 Mounting 169
16.5.3 Mains connection 170
16.5.4 Output connection 170
16.5.5 Thermal behavior 171
16.6 Approvals 171

PRAESENSA Table of contents | en 7
Bosch Security Systems B.V. Installation manual 2019.11 | V1.00 |
16.7 Technical data 171
17 Application notes 174
17.1 Connecting 100 Mbps-devices 174
17.2 Long range interconnections 174
17.3 Compatibility with other network data 175
17.4 Static IP-binding 175
18 Troubleshooting 179
19 Maintenance and service 181
19.1 Preventive maintenance 181
19.2 Corrective maintenance 182
19.3 Device replacement 182
19.3.1 System controller 182
19.3.2 Amplifier 183
19.3.3 Multifunction power supply 184
19.3.4 Call station 185
20 EN 54-16 / EN 54-4 compliance 186
20.1 Introduction 186
20.2 Checklist 186
20.3 Rack label 190

8en | Important product information PRAESENSA
2019.11 | V1.00 | Installation manual Bosch Security Systems B.V.
1 Important product information
1.1 Safety instructions
1. Read and keep these safety instructions. Follow all instructions and heed all warnings.
2. Download the latest version of the Installation Manual and Configuration Manual from
www.boschsecurity.com.
Information
Refer to the Installation Manual for instructions.
3. Follow all installation instructions and observe the following alert signs:
Notice! Containing additional information. Usually, not observing a notice does not
result in damage to the equipment or personal injuries.
!
Caution! The equipment or the property can be damaged, or persons can be injured if
the alert is not observed.
Caution! Risk of electric shock.
4. System installation and servicing by qualified personnel only, in accordance with
applicable local codes. No user-serviceable parts inside.
5. System installation in a Restricted Access Area only. Children may not get access to the
system.
6. For rack-mounting of system devices, make sure that the equipment rack is of suitable
quality to support the weight of the devices. Use caution when moving a rack to avoid
injury from tip over.
7. The system shall not be installed near water or heat sources.
8. System power supplies shall be connected to a mains power outlet socket with a
protective earthing connection. An external, readily operable, mains plug or all‑pole mains
switch shall be installed.
9. Only replace a power supply mains fuse with a fuse of the same type.
10. The chassis ground screw of an amplifier shall be connected to protective ground before
the amplifier is connected to a power supply.
11. Amplifier outputs may carry output voltages up to 100VRMS. Touching uninsulated
terminals or wiring may result in an unpleasant sensation.
12. The system may receive power from multiple mains power outlet sockets and backup
batteries.
Caution! To prevent a shock hazard disconnect all power sources prior to system
installation.
13. The system may use 12V sealed lead acid (SLA) backup batteries. Risk of explosion if an
incorrect type of battery is used.
14. Fiber optical converters use invisible laser radiation. To prevent injury, avoid eye
exposure to the beam.
15. The call station with its extensions are suitable for vertical mounting below 2m height.
16. To prevent hearing damage do not listen at high volume levels for long periods.
17. The system controller uses a lithium coin battery. Keep away from children. If ingested,
high risk of chemical burn hazard. Seek medical attention immediately.

PRAESENSA Important product information | en 9
Bosch Security Systems B.V. Installation manual 2019.11 | V1.00 |
1.2 Disposal instructions
Old electrical and electronic appliances.
Electrical or electronic devices that are no longer serviceable must be collected
separately and sent for environmentally compatible recycling (in accordance with the
European Waste Electrical and Electronic Equipment Directive).
To dispose of old electrical or electronic devices, you should use the return and
collection systems put in place in the country concerned.
1.3 Class A Notice for FCC and ICES 003
applies to U.S.A. and Canadian models only
Business Equipment
For commercial or professional use
This equipment has been tested and found to comply with the limits for a ClassA
digital device, pursuant to Part15 of the FCC and Canadian ICES‑003 requirements.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in residential area
is likely to cause harmful interference in which case the user will be required to
correct the interference at their own expense. Intentional or unintentional changes or
modifications not expressly approved by the party responsible for compliance shall not
be made. Any such changes or modifications may void the user’s authority to operate
the equipment.

10 en | About this manual PRAESENSA
2019.11 | V1.00 | Installation manual Bosch Security Systems B.V.
2 About this manual
The purpose of this installation manual is to provide all required information needed for the
installation and interconnection of the Bosch PRAESENSA products. It will guide new installers
step‑by‑step and serves as a reference for experienced installers.
– Unless required for the installation of the products, this manual does not describe
software installation, configuration and operating/user instructions. Refer to Related
documentation, page 11.
– This manual, or an update, in pdf format is available as download from
www.boschsecurity.com > PRAESENSA product section > System overview > Documents
tab.
Refer to the following sections before and during installation and maintenance of your system:
–Chapter 1: Important product information, page 8 - contains important instructions and
safeguards, which you should read before installing or operating your system.
–Chapter 2: About this manual, page 10 - gives information on the intended audience,
training, available documentation and explains how to use this manual.
–Chapter 3: System introduction, page 13 - provides a high‑level introduction description
of the PRAESENSA Public Address and Voice Alarm System. A brief product description
and overview is included.
–Chapter 4: General installation procedures and instructions, page 18 - describes
considerations for rack building, cable selection and network design.
–Chapter 5: System composition, page 33 - describes considerations and methods for
system composition, battery calculation and heat loss.
–Chapter 6: From installation to configuration, page 47 - describes procedures and
instructions on how to prepare a PRAESENSA system for configuration.
–Chapter 7-16: Products - detailed introduction of each product (category), including
functionality, installation and connection instructions and technical specifications.
–Chapter 17: Application notes, page 174 - provides notes on challenging installation and
system requirements.
–Chapter 18: Troubleshooting, page 179 - explains where to find troubleshooting
information, and provides a list of known issues and their solutions.
–Chapter 19: Maintenance and service, page 181 - provides useful information for
maintaining and using your system.
–Chapter 20: EN 54-16 / EN 54-4 compliance, page 186 - gives installation and configuration
directions for compliance to EN54‑16 and EN54‑4.
2.1 Intended audience
This installation manual is intended for everyone who is authorized to install PRAESENSA and
related products.
