Bosch D9000 Series Configuration guide

D9000,G & GV2 Series
EN
Owner’s Manual Supplement
D9000, G & GV2
Series

D9000,G & GV2 Series |Owner's Manual Supplement
2 Bosch Security Systems | 5/05 | 33267F
Contents
1.0 Introduction.......................................................3
2.0 Two-Man Rule...................................................3
2.1 Description.............................................................3
2.2 Using the Two-Man Rule.......................................3
3.0 Early Ambush....................................................4
3.1 Description.............................................................4
3.2 Using Early Ambush ..............................................4
4.0 Easy Exit Control.............................................5
4.1 Description.............................................................5
4.2 Using Easy Exit Control.........................................5
5.0 Passcode Follows Scope...............................6
5.1 Description.............................................................6
5.2 Using Passcode Follows Scope.................................6
6.0 Passcode-Controlled Menu ............................7
6.1 Description.............................................................7
6.2 Using Passcode Controlled Menus ...........................7
7.0 Invisible Walk Test .........................................8
7.1 Description.............................................................8
7.2 Using Invisible Walk Test: .....................................8
8.0 Door Activated Custom Function.............10
8.1 Description...........................................................10
8.2 Using Door Activated Custom Functions: .............10
9.0 Access Level Control....................................10
10.0 Door Control ...................................................12
10.2 Using Door Control?..................................12
10.3 Cycle Door?..................................................13
10.4 Unlock Door?................................................14
11.0 Delete User [COMMAND 53] ....................15
12.0 Add/Change User - [COMMAND 56] ......17
12.1 Description.........................................................17

D9000,G & GV2 Series |Owner's Manual Supplement
Bosch Security Systems | 5/05 | 33267F 3
1.0 Introduction
This document supplements the Security System Owner’s Manual
(P/N: 71-06633-000) with the Function List features for the D9000 Series.
The instructions for the commands listed in this document replace those
commands in the Security System Owner’s Manual. Refer to the Owner’s
Manual for the operation of your new security system and its other basic
Function List features.
Place this supplement inside the Security System Owner’s
Manual.
2.0 Two-Man Rule
2.1 Description
The Two-Man Rule adds an extra step to the disarm process by requiring
two unique pass codes to disarm an area from the same keypad. Configure
this feature according to the guidelines specified in the
D9412GV2/D7412GV2 Program Entry Guide (P/N: F01U003636).
I have this feature.
I do not have this feature.
2.2 Using the Two-Man Rule
1. Ensure the keypad shows idle armed text.
2. Enter a valid pass code with the authority to Passcode Disarm by
pressing the [passcode digits] followed by the [ENTER] key.
3. The keypad shows a request for the SECOND CODE:
4. Enter a second valid pass code with the authority to Passcode
Disarm by pressing the [passcode digits] followed by the

D9000,G & GV2 Series |Owner's Manual Supplement
4 Bosch Security Systems | 5/05 | 33267F
[ENTER] key. The second pass code must be different from the
first pass code.
The area is disarmed and ready for entry.
3.0 Early Ambush
3.1 Description
Early Ambush adds an extra step to the disarm process by requiring an
additional pass code to be entered to confirm the area is secure. The
second pass code can be same as the first or a different one, depending on
the configuration. The first entry disarms the area and the second entry
stops an automatic timer from sending a duress event. Configured this
feature according to the guidelines specified in the D9412GV2/D7412GV2
Program Entry Guide (P/N: F01U003636).
I have this feature.
I do not have this feature.
3.2 Using Early Ambush
1. Ensure the keypad shows idle armed text.
2. Enter a valid pass code with the authority to Passcode Disarm by
pressing the [passcode digits] followed by the [ENTER] key.
3. Ensure the keypad shows idle disarmed text.
4. The user can now search the area; however, the user must return
before the preset Early Ambush Time expires.
5. Enter a second valid pass code with the authority to Passcode
Disarm by pressing the [passcode digits] followed by the
[ENTER] key.
6. The keypad shows confirmation that the second passcode was
accepted and that the Early Ambush Window was canceled by
showing CODE 2 VALIDATED.
The area is disarmed and ready for entry.

D9000,G & GV2 Series |Owner's Manual Supplement
Bosch Security Systems | 5/05 | 33267F 5
4.0 Easy Exit
Control
4.1 Description
The D9412GV2 / D7412GV2 Control Panels change from one armed
state to another armed state without disarming. The Easy Exit Control
feature reduces the number of keystrokes and simplifies system operation.
This feature is available by default and is always on.
4.2 Using Easy Exit Control
Switching armed states from Master to Perimeter:
1. Ensure the keypad shows idle master armed text.
2. Press the [COMMAND] key. The keypad shows SYSTEM
COMMAND.
3. Press [3] to Perimeter Arm.
4. The keypad display shows the Exit Delay count down.
5. Enter or exit the premises.
Switching armed states from Perimeter to Master:
1. Ensure the keypad shows idle perimeter armed text.
2. Press the [COMMAND] key. The keypad shows SYSTEM
COMMAND.
3. Press [1] to Master Arm.
4. The keypad shows the Exit Delay count down.
5. Enter or exit the premises.

D9000,G & GV2 Series |Owner's Manual Supplement
6 Bosch Security Systems | 5/05 | 33267F
5.0 Passcode
Follows Scope
5.1 Description
The Passcode Follows Scope feature is an optional arming and disarming
restriction that can be enabled on keypads with access to multiple areas.
When this feature is set to No, the keypad restricts Passcode Arming and
Passcode Disarming to the home area of the keypad. When set to Yes, this
feature allows users to arm or disarm all the areas that they and the
keypad have access to. This feature causes no restrictions to the keypad
scope as it pertains to any other command or arming method other than
Passcode Arming or Passcode Disarming.
I have this feature.
I do not have this feature.
5.2 Using Passcode Follows Scope
Arming from a keypad with Panel Wide scope and Passcode Follows
Scope enabled:
1. Ensure the keypad shows idle disarmed text.
2. Ensure you have a valid pass code with the authority to Passcode
Arm in all areas.
3. Enter your code by pressing the [passcode digits] followed by the
[ENTER] key.
4. The keypad shows ARMING: 12345678, to indicate which areas
are about to enter exit delay and arm.
5. The keypad shows the exit delay count down.
6. Exit the premises.

D9000,G & GV2 Series |Owner's Manual Supplement
Bosch Security Systems | 5/05 | 33267F 7
Arming from a keypad with Panel Wide scope and Passcode Follows
Scope disabled (default):
1. Ensure the keypad shows idle disarmed text.
2. Ensure you have a valid pass code with the authority to Passcode
Arm in all areas.
3. Enter your code by pressing the [passcode digits] followed by the
[ENTER] key.
4. The keypad shows the exit delay count down.
5. Exit the premises.
6.0 Passcode-Controlled Menu
6.1 Description
When enabled, the system prompts users to enter a passcode before
viewing the keypad function list menu. The system shows the user the
menu options allowed according to their authority level; thereby,
providing users only the commands and functions pertinent to them.
Configure this feature according to the guidelines specified in the
D9412GV2/D7412GV2 Program Entry Guide (P/N: F01U003636).
I have this feature.
I do not have this feature.
6.2 Using Passcode Controlled Menus
On a D1255 keypad with the Passcode Controlled Menu enabled:
1. Press the [ESC] key. The keypad responds with the ENTER
PASSCODE display.
2. Enter your code by pressing the [passcode digits] followed by the
[ENT] key. The first menu item that you have authority to use
appears.

D9000,G & GV2 Series |Owner's Manual Supplement
8 Bosch Security Systems | 5/05 | 33267F
On a D1260 keypad with the Passcode Controlled Menu enabled:
1. Press the [Menu>] soft key in the lower right corner. The keypad
responds with the Enter passcode: then press [ENTER] display.
2. Enter your code by pressing the [passcode digits] followed by the
[ENTER] key.
The first and second menu items that you have authority to use appear.
7.0 Invisible Walk
Test
7.1 Description
The D9412GV2 / D7412GV2 has a function list menu item that allows
the user to test invisible interior or perimeter controlled points that are
within the scope of the keypad without sending a report to the central
station. This is identical to the Service Walk Test except that it is restricted
to invisible points.
I have this feature.
I do not have this feature.
7.2 Using Invisible Walk Test:
On a D1255 keypad with the Passcode Controlled Menu enabled:
1. Press the [ESC] key.
2. Press the [NEXT] key until INVISIBLE TEST? appears.
3. Press the [ENT] key to activate the Invisible Walk Test function.
The keypad shows the number of invisible points within the scope
of the keypad: ### PTS TO TEST
4. Press the [NEXT] key to see VIEW UNTESTED?.
5. Press the [ENT] key to view the untested points. The keypad
shows the total number of untested invisible points within the
keypad scope: ### PTS UNTESTED.
6. Press the [NEXT] key to view the first point’s name.

D9000,G & GV2 Series |Owner's Manual Supplement
Bosch Security Systems | 5/05 | 33267F 9
7. Press the [ENT] key to view the point’s hardware state:
1PT### NORMAL HW if it is normal 1PT### OPEN HW if it is opened
1PT### SHORT HW if it is shorted 1PT### MISSNG HW if it is missing
8. Activate the point’s sensor and observe the appropriate state
change.
9. Press the [NEXT] key to advance to the next invisible point
within the scope of the keypad.
10. Repeat steps 7 through 9 until all points are tested.
On a D1260 keypad with the Passcode Controlled Menu enabled:
1. Press the [Menu>] soft key in the lower right corner.
2. Press the [Next>] soft key until the Invisible Walk Test?
appears.
3. Press the corresponding soft key to activate the Invisible
Walk Test function. The keypad shows the number of invisible
points within the scope of the keypad: ### points remain to be
tested.
5. Press the [View untested pts>] soft key to see 6 pts untested.
6. Press the [Next Pt>] soft key to view the first or next untested
point:
[Point Text]
Area #, Pt #
[Point State] HW Next PT>
<Exit Prev PT>
7. Where [Point State] can be NORMAL,OPEN,SHORT, or MISSNG.
8. Activate the point’s sensor and observe the appropriate state
change.
9. Repeat Steps 5 through 8 until all points are tested.

D9000,G & GV2 Series |Owner's Manual Supplement
10 Bosch Security Systems | 5/05 | 33267F
8.0 Door Activated
Custom Function
8.1 Description
The D9412GV2 / D7412GV2 allow a custom function to be activated
when user credentials are presented to a D9210B Door Controller Reader.
The custom function executes as if the user performed a function at the
keypad that is associated with the door controller.
I have this feature.
I do not have this feature.
8.2 Using Door Activated Custom Functions:
Executing the door’s custom function by a user that has authority to do so
when disarming the area:
1. Ensure the area you are about to enter is armed.
2. Present your user credentials to the D9210B Door Controller
Reader. The area disarms and the custom function executes.
The area is now safe to enter.
9.0 Access Level
Control
9.1 Description
Use this function to manually enable or disable access authority levels
assigned to users. This function can be used to temporarily disable a user’s
access level instead of deleting and adding the user.
I have this feature.
I do not have this feature.

D9000,G & GV2 Series |Owner's Manual Supplement
Bosch Security Systems | 5/05 | 33267F 11
9.2 Using ACCESS LEVEL CTL?
1. Ensure the display shows idle disarmed text.
2. Press the [MENU] key to enter the Function List, then press
[NEXT] repeatedly until you reach the CHANGE LEVEL
CTL? prompt. Press [ENT].
3. ACCESS LEVEL CTL appears indicating that you are affecting
the authority levels of cards or tokens and not passcodes. Press
[ENT].
4. ENTER LEVEL: appears. Enter the access authority level number
and press [ENT].
5. If the access level is currently disabled, LEVEL # ENABLE?
appears. If the access level is currently enabled, LEVEL #
DISABLE? appears. Press [ENT] to accept the choice. ENTER
LEVEL: appears again. Press [ESC].

D9000,G & GV2 Series |Owner's Manual Supplement
12 Bosch Security Systems | 5/05 | 33267F
10.0 Door Control
10.1 Description
There are three sub-functions within the door control function. They are
CYCLE DOOR?, UNLOCK DOOR? and SECURE DOOR?.
CYCLE DOOR? momentarily unlocks a door to allow a person into an
area. UNLOCK DOOR? unlocks a door to allow free access.SECURE
DOOR? unlocks a door and prohibits access regardless of a user’s authority
level.
I have this feature.
I do not have this feature.
10.2 Using Door Control?
1. Ensure the display shows idle disarmed text.
2. Press the [COMMAND] key. The display shows SYSTEM
COMMAND.
3. Press [4] and [6].
You can use the Function List in place of steps 2 and 3 to
start this function.
1. Press the [MENU] key to enter the Function List.
2. Press [NEXT] repeatedly until you reach the DOOR
CTRL? prompt.
3. Press [ENT].
4. The first sub-function that appears is CYCLE DOOR? You can
cycle through the three sub-functions by pressing [PREV] and
[NEXT].

D9000,G & GV2 Series |Owner's Manual Supplement
Bosch Security Systems | 5/05 | 33267F 13
10.3 Cycle Door?
1. To momentarily unlock an access door and allow a person into an
area, press [ENT] at the Cycle Door? prompt.
The display shows CYCLE 1 2 3 4 5 6 7 8 if all doors are in
a normal state and available. If a door is not in a normal state, the
number of the door is replaced with one of the symbols indicated
in Table 1.
Table 1: Key to Symbols
Symbol Description
--- Door is not active, not in scope, or user does
not have access level authority
CDoor is timed door sequence
UStrike and shunt are latched active (held open)
XStrike and shunt are deactivated (secured)
P There is a problem with the door; call your
security company
2. Enter the number of the door to cycle then press [ENT]. This
door cycles and the display changes to reflect the new status of
the doors. For example, to cycle Door 3, at the following prompt:
CYCLE DOOR 1 2 3 4 5 6 7 8
press [3], then [ENT]. The display shows:
CYCLE DOOR 1 2 C 4 5 6 7 8
This indicates that all doors are in a normal state, except for Door
3, which is cycled.
3. Press [ESC] to leave this subfunction, or enter another door
number to cycle.

D9000,G & GV2 Series |Owner's Manual Supplement
14 Bosch Security Systems | 5/05 | 33267F
10.4 Unlock Door?
1. To unlock a door to allow free access, at the CYCLE DOOR?
prompt, press [NEXT] to enter the UNLOCK DOOR? subfunction.
The display shows UNLOCK 1 2 3 4 5 6 7 8 if all doors are
in a normal state and available. If a door is not in a normal state,
the number of the door is replaced with a symbol indicated in
Table 1.
2. Enter the number of the door to unlock then press [ENT]. This
door unlocks and the display changes to reflect the new status of
the doors.
For example, if you wanted to unlock Door 4, at the following
prompt:
UNLOCK DOOR 1 2 3 4 5 6 7 8
press [4] then [ENT]. The display shows:
UNLOCK DOOR 1 2 3 U 5 6 7 8
This indicates that all doors are in a normal state, except for Door
4, which is unlocked.
4. Press [ESC] to leave this subfunction, or enter another door
number to unlock.
10.5 Secure Door?
1. To secure a door to prohibit access to users regardless of their
access authority level, at the CYCLE DOOR? prompt, press
[PREV] to enter the SECURE DOOR? subfunction.
The display shows SECURE 1 2 3 4 5 6 7 8 if all doors are
in a normal state and available. If a door is not in a normal state,
the number of the door is replaced with a symbol indicated in
Table 1 on page 12.
2. Enter the number of the door to secure then press [ENT]. This
door secures, and the display changes to reflect the new status of
the doors.
For example, to secure Door 5, at the following prompt:
SECURE DOOR 1 2 3 4 5 6 7 8
Press [5] then [ENT]. The display shows:
SECURE DOOR 1 2 3 4 X 6 7 8

D9000,G & GV2 Series |Owner's Manual Supplement
Bosch Security Systems | 5/05 | 33267F 15
This indicates that all doors are in a normal state, except for Door
5, which is secured.
Press [ESC] to leave this subfunction, or enter another door
number to unlock.
Each of these subfunctions acts as a toggle switch. To
return a door to its normal state, follow the same procedure
used to change its state. For example, if Door 3 is secured,
to return it to its normal state, at the SECURE DOOR?
prompt, enter [3] and press [ENT]. The door is no longer
secured and the X is replaced with the number 3.
11.0 Delete User
[COMMAND 53]
11.1 Description
Use this function to delete a personal passcode from your system without
assistance from your security company. You must know the user number
for the passcode you want to delete.
I have this feature.
I do not have this feature.
11.2 Using DEL USER ?
1. Ensure the display shows idle disarmed text.
2. Press the [COMMAND] bar. The display shows SYSTEM
COMMAND.
3. Press [5] and [3].

D9000,G & GV2 Series |Owner's Manual Supplement
16 Bosch Security Systems | 5/05 | 33267F
You can use the Function List in place of steps 2 and 3 to start
this function.
1. Press the [MENU] key to enter the Function List.
2. Press [NEXT] repeatedly until you reach the DEL USER?
prompt.
3. Press [ENT].
4. The display shows DEL USER #. Enter the user number and press
[ENT].
5. USER ## (or user text, such as the name of the user, if this feature
was programmed into your system by your security company)
appears allowing for confirmation. Press [ENT]. If this is not the
user you wish to delete, press the [NEXT] or [PREV] key until the
correct user name appears, then press [ENT].
6. The display shows DELETE USER ##? Press [ENT] to delete user,
and USER DELETED appears. If the user number is not in the
system, NOT IN USE appears. If you made an error and do not
wish to delete this user, press [ESC].

D9000,G & GV2 Series |Owner's Manual Supplement
Bosch Security Systems | 5/05 | 33267F 17
12.0 Add/Change
User - [COMMAND 56]
12.1 Description
Use this function to add or change a passcode or card without assistance
from your security company. Before adding or changing a passcode or
card, you must know which user numbers are available, the authority level
you want to assign to the new user, and the areas in which the passcode or
card are valid.
I have this feature.
I do not have this feature.
12.2 Using Add User ?
1. Ensure the display shows idle disarmed text.
2. Press the [COMMAND] bar. The display shows SYSTEM
COMMAND.
3. Press [5] and [6].
You can also use the Function List in place of steps 2 and 3 to
start this function.
1. Press the [MENU] key to enter the Function List.
2. Press [NEXT] until you reach the ADD/CHNG USER?
prompt.
3. Press [ENT].
4. The display shows ENTER USER #. Enter the user number and
press [ENT].
5. The display shows USER # (or user text, such as the name of the
user, if this feature was programmed into your system by your
security company) to allow for confirmation. Press [ENT] if the
correct user number (or user name) appears. Press [ESC] if not.
6. ADD PASSCODE? appears (If the user number already exists,
CHANGE PASSCODE? appears). Press [ENT]. ENTER NEW CODE

D9000,G & GV2 Series |Owner's Manual Supplement
18 Bosch Security Systems | 5/05 | 33267F
appears. Enter the new passcode followed by [ENT]. ENTER
AGAIN appears. Enter the new passcode a second time for
confirmation. Press [ENT]. The display shows PASSCODE ADDED
(or PASSCODE CHANGED if the user number was already in the
system).
The system does not accept a passcode that is within two
digits of an existing passcode. This is to avoid conflicts with
duress passcodes. For example, if passcode 123 is already
programmed in the system, the system does not accept 121,
122, 124, or 125 as passcodes.
Systems With Access Control...
•If your system includes access control features, such
as card readers at doors, the following prompt
appears: ADD CARD? (CHANGE CARD? appears for
users who already have cards.)
•If the user has card or token access to the building or
area, press [ENT]. PRESENT CARD appears. Present
the card at the card reader and wait for the tone. If the
card or token is read correctly, a tone sounds and the
command center keypad shows CARD ADDED (or
CARD CHANGED if the user already has a card or
token). Press [ENT].
7. ADD LEVEL? (CHANGE LEVEL? If the user number already
exists) appears. Press [ENT].
8. VALID AREA 1? appears. If you wish this user number to be
valid in Area 1, press [ENT]. If not, press [NEXT].
9. AUTH LEVEL appears. Assign the authority level you wish the
user number to have for this area and press [ENT]. Record this
information.
10. VALID AREA 2? appears. Enter the information necessary for
the areas in the scope of the keypad by following steps 8 and 9 for
each area (up to 8 areas). LEVEL ADDED
(or LEVEL CHANGED)
appears when all area assignments are made. Press [ENT].

D9000,G & GV2 Series |Owner's Manual Supplement
Bosch Security Systems | 5/05 | 33267F 19
Systems With Access Control...
SUB USER ID? appears. Press [ENT]. SUB USER #? appears.
Enter 1, 2, or 3 for the desired Sub-User and press [ENT].
PRESENT CARD appears. Present the card or token at the
reader and wait for the tone. After the tone sounds the
display shows CARD ADDED (or CARD CHANGED if the
Sub User number already existed).
At the end of each function, press [ESC] to return to the
ENTER USER # prompt. Press [ESC] again to return to idle
text.

© 2005 Bosch Security Systems
33267F
Bosch Security Systems
130 Perinton Parkway
Fairport, NY 14450-9199
Customer Service: [phone]
Technical Support: [phone]
