Boya BY-DM20 User manual

BY-DM20
Buku Manual

●BY-DM20 Microphone x1
●Type-C to USB cable x1
●Type-C to Type-C cable x1
●Type-C to Lightning cable x1
●Lavalier mic x2
●Foam windscreen x2
●Clip for lavalier mic x2
●Belt clip x1
●Carrying case x1
●User guide x1
Pengenalan
Terima kasih telah membeli BOYA!
BY-DM20 merupakan paket mikrofon multi fungsi dengan 2
jalur mikrofon masuk dan 1 output audio. BY-DM20
merupakan solusi perekaman suara untuk iOS, Android Type-
C dan laptop. BY-DM20 cocok digunakan dalam interview,
produksi televisi, produksi film, rekaman musik, periklanan,
dll.
Isi dalam Paket:
1

Frequency response:
Gain:
Sampling frequency:
Bitrate:
Power requirements:
Output connector:
Cable length:
Spesifikasi
Fitur
2
- All-in-one recording solution
- Compact and easy to use
- Dual-channel audio inputs
- Ideal for interview or other demands for capturing two
subjects
- Stereo and Mono mode selectable
- Volume control for each channel separately
- 3.5mm Headphone output
- Compatible with iOS, Android(Type-C), Laptop
45Hz-20kHz
0-30dB
44.1kHz /48kHz
16Bit /24Bit
Powered from the device
Type-C to Lightning
Type-C to USB
Type-C to Type-C
Mic cable: 2.0m
Output cable: 0.3m

1
2
3
4
5
9
6
7
8
① Indicate light
1) “Blue light on” for recording
2) “Green light on” for replay
3) “Both lights on” for real-time playing by compatible App
Bagian-bagian
3

②Mic/Line-in jack (Left channel)
③Type-C port
④Mic/Line-in jack (Right channel)
⑤Volume control (Right channel)
⑥Recording/Play switch
1) switch to “REC” for recording
2) switch to “PLAY” for replay
⑦Earphone jack
⑧Stereo/Mono switch
1) switch to “S” for stereo
2) switch to “M” for mono
⑨Volume control (Left channel)
4

2. Connect lavalier mics and cables to main body
Pemakaian
1. Install the clip and windscreen
5

3. Mount the microphone to your clothing
20-25cm
(8-10 inches)
• Attach the microphone to the front of your clothing
with the clothing clip, about 20-25cm (8-10 inches)
from your face.
1) Attach the microphone upside down to reduce
excessive breath noises and tonal inconsistencies
due to head movements.
2) It is recommended that you use the foam wind
screen at all times to avoid wind noise, even when
recording inside.
6

4. Connect BY-DM20 to your device
5. Settings
- Choose and connect the right cable with your device
- Open a compatible app and start recording
Please follow the instructions here if there’s any problems
- Adjust left/right channel volume from side wheel
- Select between Mono(M) or Stereo(S) mode from
side button
- Select between recording(REC) or replay(PLAY) mode
Problem
Low sound
Distortion
Unwanted sound
No sound
Reason
Didn’t switch to “Play” mode
Disability of cable connection
Disability of earphone connection
Improper sound setting
Improper sound setting
Mono earphone under stereo mode
Omni-directional polar pattern
Solution
Swicth to “Play”
Re-connect
Re-connect
Adjust sound wheel
Adjust sound wheel
Match the earphone
Adjust mic position
closer to sound source
Troubleshooting
7

www.boya-mic.com
SHENZHEN JIAYZ PHOTO INDUSTRIAL., LTD.
The BOYA logo is a trademark which is registered and owned by
Shenzhen Jiayz Photo Industrial., Ltd.
COPY RIGHT 2010-2020
