Boya BY-M3-OP User manual

Buku Panduan
BY-M3-OP
Clip-on Digital Lavalier Microphone
for DJI OSMO™ Pocket

Panduan
Isi dalam Paket
Thanks for purchasing BOYA!
The BOYA BY-M3-OP is a digital omnidirectional lavalier
microphone, specially designed for DJI OSMO™ Pocket.
resolution with a frequency response of 50Hz to 20kHz
that captures crisp and pristine sound.
With the foam windscreen, it allows to prevent the
unwanted vocal plosive and wind noise, increasing
the intelligibility of dialogue and focusing on the
subject.
To get the best recording experience, please
attach the microphone to the front of your clothing
with the clothing clip, keeping 20cm (8 inches) from
your face.
- BY-M3-OP lavalier microphone
- Foam windscreen
- Clothing clip
- Carry pouch
- Velcro
- User manual
- Warranty card
1

Bagian Produk
1
34
2
①USB Type-C connector (Onlyfor DJI OSMO™ Pocket)
②Microphone
③Clothing clip
④Foam windscreen
2

1. Connect BY-M3-OP to your DJI OSMO™ Pocket.
2. When the DJI OSMO™ Pocket shows ”Audio Adapter
Connected and Microphone Connected,“ the
microphone gets ready to work.
Cara Penggunaan
3

4
(8 inches)
20cm
• Attach the microphone to the front of your clothing
with the clothing clip, keeping 20cm (8 inches) from
your face.
1) Attach the microphone upside down to reduce
excessive breath noises and tonal inconsistencies
due to head movements.
2) It is recommended that you use the foam wind
screen at all times to avoid wind noise, even when
recording inside.
3. Mounting the microphone to your Clothing

Fitur:
5
• USB Type-C connector specially designed
for DJI OSMO™ Pocket
• Omnidirectional digital lavalier microphone
• Improved your videos with high-quality sound
• Up to 24bit/96kHz sampling rate
• Plug and play operation
• Cable management with velcro
• Foam windshield, lapel clip, and carry pouch included
Catatan:
The BY-M3-OP only supports the DJI OSMO™ Pocket
to use while taking video. It is not suited for DJI
other series or any Type-C device.

Spesikasi:
6
Output
Polar Pattern
Frequency Response
Signal to Noise Ratio
Gain
Sensitivity
Sampling Frequency
Bitrate
Power Requirement
Weight
Cable Length
USB Type-C Connector
Omnidirectional
50Hz-20kHz
78dB and more
12 dB
-32±3dB (0dB=1v/Pa,at 1kHz)
44.1kHz/48kHz/96kHz
16Bit/24Bit
Supplied by DJI OSMO™ Pocket
20g (0.7 oz)
2m (3.3ft)
