Boya BY-M800 User manual

BY-M800
Mikrofon Condenser Cardioid
Instruction Manual

• BY-M800 condenser microphone
• Studio-grade pop shield
• Shockmount
• 3m(10ft) balanced XLR cable
Pengenalan:
Termia kasih telah membeli BOYA!
BOYA BY-M800 merupakan mikrodon cardioid condenser
dengan frekuensi rekam yang luas dan stabil, cocok untuk
perekaman suara maupun alat musik dalam berbagai
jenis lingkungan.BY-M800 juga dilengkapi pola rekam
cardioid yang mengurangi kebisingan, tombol switch
-10dB dan 2 tombol switch filter low-cut.
BY-M800 berbahan metal yang kokoh, memiliki suber
tenaga tersembunyi sebesar 24-48V, yang ditenagai oleh
output XLR. BY-M800 juga termasuk sebuah shockmount,
pop filter, Kable XLR 3m, dan case.
Isi dalam Paket:

- High-Pass Filter
- A -10 dB pad switch
Pengenalan Fungsi
- Polar Pattern
Cardioid
The cardioid polar pattern is focusing audio capture in
front of the capsule, minimizes unwanted ambient
sound from the other sides and back of the microphone.
This polar pattern is suitable for such situations when
you want to pick up specific sund sources, such as
recording vocals, guitar, pianos, stringed instruments,
and more.
A low-cut filter at 150 Hz allows you to eliminate low
frequency hum and other low-frequency noises.
A -10 dB pad switch provides more headroom when
capturing transient signals that may otherwise cause
peak distortion.

1. Mount BY-M800 on 3/8" and 5/8" microphone stands
or tripods.
2. Rotate locking knob to adjust microphone fits your
position.
Note:
When changing the mic position, always be sure to loosen
the adjustment knob first to ensure you do not damage
the shock mount.
Cara Menggunakan
Note:
When recording any sound source, whether it be vocals,
instruments or anything else, always spend time
experimenting with microphone placement to ensure you
are picking up the best possible sound. Adjust the
microphone position as many times as you need to
achieve your demand.

3. Mounted the supplied pop filter in front of microphone.
Note:
The “BOYA” Logo on the face of the BY-M800 indicates
the front of the microphone, and the pickup area of the
capsule. The “BOYA” Logo should always be facing towards
the sound source that you wish to record.

4. Insert supplied XLR cable to microphone

Fitur
• Large gold-sputtered diaphragm
• Great for studio and broadcast
• Flat, wide-range frequency response
• Cardioid pickup pattern
• Controlled by low-cut filter switch
• A selectable -10dB pad
• Included shockmount & pop filter
• 24V or 48V phantom power
• Standard XLR connector
• 3m(10ft) XLR cable included
• Included 3/8" and 5/8" thread
Spesifikasi:
Condenser
Cardioid
34mm(1.3" )
20– 20,000Hz
-33±3dB (0dB=1V/Pa @ 1KHz)
80dB and more
200 Ohm
24V or 48V Phantom
3m(10ft)
207 x 115 x 162mm
642g
Acoustic Principle:
Polar Pattern:
Diaphragm:
Frequency Response:
Sensitivity:
SN:
Output Impedance:
Power Requirement:
Cable Length:
Dimensions:
Weight:

Cardioid
Pola Rekam
Frekuensi Rekam

Perawatan
• Keep your microphone away from dust, moisture, or water.
• To clean the housing, wipe with a dry micro-fiber cloth to
remove dust.
• Store your microphone in the included pouch to protect it
from dirt and dust.
Informasi Penting
• Make sure that you follow all safety notes.
• Keep these instructions for use in a safe place. If you sell
the equipment or pass it on to someone else, you should
also pass on these instructions for use.
Simbol pada produk
Bahaya kebakaran akibat arus pendek
Waste disposal and protection of the environment
Electric and electronic appliances, as well as batteries, must
not be disposed of together with domestic waste. The user is
legally obliged to return electric and electronic appliances as
well as batteries to specially set up public collecting points or
the sales outlet once they have reached the end of their service
life. Details are regulated by national law. The symbol on the
product, the instructions for use, or the packaging refers to
these provisions. The recycling of waste equipment/batteries is
an important contribution to the protection of our environment.
• Do not operate the device with wet hands.
• Clean the equipment only in the way described in Maintaining
Your Microphone.
• Take care to avoid dropping the equipment. Make sure that
the device is properly fastened and reliably mounted. If the
device has been dropped, have it inspected by a skilled
technician before you switch it on again.
• Should the equipment be damaged or defective, or if you
notice a scorching smell, remove the batteries immediately.
Do not operate the device with a damaged housing and do
not repair the device yourself. Have the device only repaired
by a skilled service person.

www.boya-mic.com
SHENZHEN JIAYZ PHOTO INDUSTRIAL., LTD.
The BOYA logo is a trademark which is registered and owned by
Shenzhen Jiayz Photo Industrial., Ltd.
COPY RIGHT 2010-2020
Email: [email protected]
www.boya-mic.com / www.jiayz.com
