BRIG NAVIGATOR Series User manual

SERIES: "NAVIGATOR"
MODELS: N700 N730
complete set: N700 N730
N700H* N730H*
Design category (2013/53/EU): C
ISO6185: Category VIII
2384B.01
OWNER'S MANUAL
H* – boat tube is made of HYPALON (Du Pont registered trademark) coated fabrics.
English

2019 — 2 — BRIG
CONTENTS:
DANGER LEVELS 5
INTRODUCTION 5
IDENTIFICATION PLATE 6
SAFETY REGULATIONS 7
BEAUFORT Wind Scale and Corresponding State of the Sea, After Few Hours of Wind,
Away From the Coast. 8
Boat Design Categories 9
REMEMBER FIRE DANGER ALWAYS 9
TECHNICAL SPECIFICATIONS 10
COMPLETE SET 11
THE MAIN DIMENSIONS 13
BOAT DESIGN 14
POLYESTER HULL 17
REINFORCED BUOYANCY TUBE 18
S.S. ARC 19
STEERING CONSOLE 19
FUEL SYSTEM 21
DRAIN SYSTEM 22
WIRING DIAGRAM 24
PREPARATION FOR EXPLOITATION 25
INFLATION/DEFLATION BOAT TUBE 25
STORAGE BATTERY INSTALLATION 26
BOAT TRANSPORTATION BY TRAILER 26
HOW TO INSTALL SUNDECK 28
CREW LIMIT 29
REBOARDING MEANS 30
ANCHORING AND TOWING.Strong points. 31
MOORING.Strong points. 32
MAINTENANCE 33
OPERATING REGULATIONS 35

— 3 —
Series "NAVIGATOR" N700 N730 2384B.01
For you safety and for the validity of the guarantee expert and authorised personnel
must install the motor and inspect and check the systems. All onboard systems must
be completed and inspected.
CHECK, THAT THE CHECKS HAVE BEEN MADE AND THAT THE PLANTS HAVE
BEEN COMPLETED BEFORE DELYVERY.
BRIG Ltd declines any responsibility for systems and accessories that have not
been installed and checked by expert and authorised personnel.
The manual and all its enclosures should be stored carefully, and the manual should
always be kept aboard. If the craft is resold, the manual and all its enclosures must
be handed over to the new owner.

2019 — 4 — BRIG
CE Certification and Main Features
The CE marking indicates that the inflatable boat meets the requirements
of the Recreational Craft Directive 2013/53/EU
Certifying Body:
INTERNATIONAL MARINE CERTIFICATION INSTITUTE
Rue Abbe Cuypers 3 / B-1040Bruxelles / Belgique
Notified Body : 0609
www.imci.org
Name of Manufacture:
BRIG Ltd.
Lozovskaya 88, Dergachy 62303
Kharkovskaya obl.
UKRAINE
www.brigboats.com

— 5 —
Series "NAVIGATOR" N700 N730 2384B.01
INTRODUCTION.
This manual was written to help you to use your boat safely. It contains information on the boat, its equipment (supplied
or installed),operation and maintenance.
DANGER LEVELS.
The manual contains warnings, identified as follows:
A note like this indicates that there is serious risk, that is likely to cause death or
permanent serious injury, if appropriate precautions are not taken.
A note like this indicates the existence of risk that may cause death or injury, if
appropriate precautions are not taken.
A note like this indicates reference to the application of safety or environmental
protection practices,or draws attention to unsafe behaviour that might cause injury to
persones or damage to the craft, its components or the environment.
Before using your boat, read this MANUAL carefully and ensure that you have
understood all the procedures it describes. Before taking command of your boat, be
sure to have acquired experience and confidence in its operation.

2019 — 6 — BRIG
It is fundamental for the plates to be aboard the boat, since they are only form of
recognition and identification. Without them the boat does not comply with the legislation
in effect. The plates must never be removed. Any tampering or removal not authorised by
the manufacturer is the full responsibility of the owner.
IDENTIFICATION PLATE.
Builder's Plate:
Plate with identification number:
UA-QRK12345A000
N700single engine
N700 twinengine
Maximum propulsion
power rating for the
boat
Boat Design Category
according to
Directive 2013/53/EU
The rated tube
pressure value
Passengers capacity
Maximum
recommended load is
including weight of the
max engine(s),
passengers and cargo
onboard, but excluding
the mass of the
contents of fixed fuel
and water tanks when
full
N700 VIII
C
2x99.3
2x135
8
1260
2778
3
N700 VIII
C
166 225 11
1260
2778
3

— 7 —
Series "NAVIGATOR" N700 N730 2384B.01
SAFETY REGULATIONS.
This manual contains recommendations and basic rules of conduct for using the boat in complete safety.Although it is not
possible to offer safety information for all potential situations, in general it is recommended that you :
Regularly check which safety requirements are in force.
Maintain the boat and the onboard plants in optimum condition.
Have the boat inspected by the dealer where it was purchased or by an authorised
mechanic at least once every year for your own safety and for maintaining the guarantee.
Always check weather and seagoing conditions before setting out.
For safe navigation, compare the design category of your boat with the table below.
When the tank is installed by the yard, the plant is prepared with a ground plait. The
installation of the motor MUST FORESEE A PLAINT CONNECTION to the boat ground plait.
Failure to connect (or failed maintenance) can result in the tank perforating leading to a
serious risk of fire / explosion caused by leaking fuel.
Max number of transportable persones is referred to an established weight of 75 kg per
person (ISO 6185), so always make reference to total maximum transportable weight.
The max weight of the installable motors indicates the maximum overall weight applicable
on the stern board, including any emergency motors. NEVER exceed the stated value.

2019 — 8 — BRIG
BEAUFORT Wind Scale and Corresponding State of the Sea, After Few Hours of Wind, Away From the Coast.
Boat Design Categories (Directive 2013/53/EU):
NOTE: The significant wave height is the mean height of the highest one-third of the waves, which approximately
corresponds to the wave height estimated by an experienced observer. Some waves will be double this height.
State of the sea
Force Denomination Knots Km/h m/sec and wave height in meters
0Calm <1 <1 0-0.2 Calm 0
1Light Air 1-3 1-5 0.3-1.5 Calm 0
2Light Breeze 4-6 6-11 1.6-3.3 Almost calm 0.2
3Gentle Breeze 7-10 12-19 3.4-5.4 Almost calm 0.2
4Moderate Breeze 11-16 20-28 5.5-7.9 Small waves 0.5
5Strong Breeze 17-21 29-38 8.0-10.7 Large waves 1.25
6Fresh Wind 22-27 39-49 10.8-13.8 Large waves 2.0
7Strong Wind 28-33 50-61 13.9-17.1 Very large waves 2.5
8Gale 34-40 62-74 17.2-20.7 Rough sea 4
9Strong Gale 41-47 75-88 20.8-24.4 Very rough sea 6
10 Storm 48-55 89-102 24.5-28.4 Heavy 9
11 Violent Storm 56-63 103-117 28.5-32.6 Very heavy 14
12 Hurricane 64 and over 118 and over 32.7and over Stormy 14 and over
Design category
"A" - "Ocean"
"B"- "Offshore"
"C"- "Inshore"
"D"- "Sheltered waters"
Wind force
(Beaufort scale)
exceeding 8
up to,and including, 8
up to,and including, 6
up to,and including, 4
Significant wave height
exceeding 4
up to,and including, 4
up to,and including, 2
up to,and including, 0.3

— 9 —
Series "NAVIGATOR" N700 N730 2384B.01
ALWAYS REMEMBER ABOUT FIRE DANGER .
Fire may be caused by:
The manufacturer does not supply a fire extinguisher with a boat. A fire extinguisher must be installed on the boat by the owner.
Responsibility for choosing the type of fire extinguishers, their number and capacity, as well as the installation location remains with the owner.
The owner should also know how to use a fire extinguishers and monitor its suitability.
Consult a specialist to equip your boat with suitable fire extinguishers.
Never:
— obstruct access to safety controls, e.g. fuel shut-off valves, gas shut-off valves, isolation switches of the
electrical system or fire ports;
— deliberately or inadvertently block ventilation for compartments or spaces, particularly those
containing petrol engines, fixed petrol tanks and batteries;
— obstruct access to portable fire extinguishers or fire ports;
— leave the craft unattended when cooking and/or heating appliances are in use unless the appliance is designed
to operate unattended;
— modify any of the craft’s systems unless competent to do so;
— fill any fuel tank or replace gas bottles when engines are running or open flame appliances or radiant heat
devices are in use;
— smoke while handling fuel or gas;
— store petrol containers or equipment containing petrol in any area not designated for the specific storage of
petrol.
Howevwr, if a fire does occure aboard, stop motor, disconnect the batteries immediatly, check to see if it is an electrical component or any case a small-
scale fire that does not involve flammable liquids, in which case use a suitable fire extinguisher to try and put the fire out completely.
Extinguisher or any other fire-fighting equipment must not be kept in compartments with key lock, but in easily accessible
and clearly indicated locations.
Extinguisher or any other fire-fighting equipment should be checked periodically and replaced with the same or superior
types if expired or inefficient.

2019 — 10 — BRIG
Length (without engine)
Beam
Height
Inflatable tube diameter, max.
Cockpit dimensions: - length
- width
Deadrise angle on transom
Deadrise angle in middle section
Transom height
Number of independent air-tight chambers
Nominal pressure
Crew limit
Recommended engine power
Maximum engine power*
Maximum engine weight (including
controls and battery(s))
Engine shaft length
Built-in fuel tank capacity
Weight of empty boat (without: steering
console, arc, driver seat, fuel, engine)
Weight of boat with equipments (with
consoles, without engine and fuel)
Maximum load capacity of empty boat(ISO)
Displacement in Light Craft Condition (LCC)
Maximum total load (ML)
Maximum transportable mass
Maximum recommended load*
Loaded displacement mass
TECHNICAL SPECIFICATIONS.
6.99 m
2.8 m
2.08m
0.58 m
5.05 m
1.59 m
21°
24°
615mm
5
0.15 bar / 2.2 psi
11
200HP / 148kW
225HP / 166kW
335kg
25" (Extra Long)
340L
700kg
930kg
1800kg
1275kg
1225kg
1675kg
1260*kg
2500kg
6.99 m
2.8 m
2.08m
0.58 m
5.05 m
1.59 m
21°
24°
615mm
5
0.15 bar / 2.2 psi
8
2x120HP / 2x89kW
2x135HP / 2x99.3kW
560kg
20" (Long)
340L
700kg
930kg
1800kg
1500kg
1000kg
1900kg
1260*kg
2500kg
N700 (single engine) N700 ( twin engine)
The basic parameters and dimensions of the "NAVIGATOR" boats N700 and N730 comply with the data specified in the
following table. All dimensions measurments indicated have a tolerance of +/- 3%, weight measurments indicated have a
tolerance of +/- 5%.
7.30 m
2.8 m
2.08m
0.58 m
5.05 m
1.59 m
21°
24°
615mm
5
0.15 bar / 2.2 psi
11
200HP / 148kW
225HP / 166kW
335kg
25" (Extra Long)
340L
700kg
930kg
1900kg
1275kg
1325kg
1775kg
1360*kg
2600kg
7.30 m
2.8 m
2.08m
0.58 m
5.05 m
1.59 m
21°
24°
615mm
5
0.15 bar / 2.2 psi
8
2x120HP / 2x89kW
2x135HP / 2x99.3kW
560kg
20" (Long)
340L
700kg
930kg
1900kg
1500kg
1100kg
2000kg
1360*kg
2600kg
N730 (single engine) N730 ( twin engine)
*Maximum recommended load is including weight of the max engine(s), passengers and cargo onboard, but excluding
the mass of the contents of fixed fuel and water tanks when full

— 11 —
Series "NAVIGATOR" N700 N730 2384B.01
COMPLETE SET .
1Inflatable boat pcs. 1
2Foot pump pcs. 1
3Paddle pcs. 2
Set of spare parts and repair kit:
4- mooring line m18
5- coated fabric for repair m20.06
6- glue set for repair set 1
7Bag pcs. 1
8Owner's manual pcs. 1
9Built-in fuel tank pcs 1 (340L)
10 Steering console with installation kit pcs. 1
Steering console equipment:
11 Hydraulic steering system set 1
12 Steering wheel pcs. 1
13 Fuel level clock pcs. 1
14 Switches of electrical equipment pcs. 5
15 Socket 12V with fuse pcs. 1
16 Compass pcs. 1
17 Speedometer pcs. 1
18 Tachometer pcs. 1
19 Electric horn pcs. 1
20 Front locker removable cushion pcs. 1
21 Composed driver seat/bolster with installation kit pcs. 1
22 Jockey seat with installation kit pcs. 4 (variant)
No Description Unit of N700, N730
measure
In the table is shown the maximum possible complete set, which may differ from your boat.

2019 — 12 — BRIG
Note. Perfection of the design and improvement of quality of our products is the fundamental production policy of our company.
Therefore, alternations may be made to the complete set (and as the components become available).
23 Stainless steel arc with installation kit pcs. 1
Arc equipment:
24 Anchor light (white) pcs. 1
Running lights:
25 Port (red) pcs. 1
26 Starboard (green) pcs. 1
27 Drain automatic bilge pump pcs. 1
28 Towing eye pcs. 1
29 Soft back of stern-part seat pcs. 1
Additional options:
30 Bow sun deck set with cushions pcs. 1
31 Overall cover set 1
32 Steering console/seats cover set 1
33 Foldable S.S. ladder pcs. 1
34 Collapsible sun-top set 1
35 Battery container pcs. 1
36 Valve cap pressure gauge pcs. 1
37 Shower kit (water tank 45 litres, shower pump and handset) set 1
No Description Unit of N700, N730
measure

— 13 —
Series "NAVIGATOR" N700 N730 2384B.01
The main dimensions of N700 / N730 have tolerance of +/- 3%.
The length of the boat with the engine can vary depending on the model of the engine and the angle of its deviation. (See Fig. D0)
THE MAIN DIMENSIONS.
D0
7.81m
N700 - 6.99m / N730 - 7.3m
1.37m
2.08m
1980mm (1.98m)
2.8m
N700 / N730

2019 — 14 — BRIG
2313
6
1
11
5
21 19
14
20
19
22
4
4
4
10
4
914 15
10
13 16 17 4
18
6
4
23
D1
24
22
21
17
7
18
16

— 15 —
Series "NAVIGATOR" N700 N730 2384B.01
2 3 13
6
1
11
5
21 19
14
20
19
22
4
4
4
10
4
914 15
10
13 16 17 4
18
6
4
23
D1
24
22
21
17
7
18
14
21

2019 — 16 — BRIG
1 —Polyester hull.
2 —Reinforced buoyancy tube.
3 —Doubled rubbing strake.
4 —Safety handles.
5 —Towing bow eye.
6 —Bow step-plate with bow roller.
7 —Neck for fuel fill.
9 —Steering console seat.
10 —Air fill valves (5 pcs.).
11 —Front locker removable cushion.
12 —Cockpit drain system sockets (2 pcs.).
13 —Steering console.
14 —Composed driver seat/bolster or Jockey seats (4 pcs.).
15 —Stern-part seat.
16 —Soft backs of stern-part seat (3pcs.).
17 —Mooring cleats (3pcs.).
18 —Stainless steel arc.
19 —Port running light (red).
20 —Starboard running light (green).
21 —Anchor light (white).
22 —Stern lifting eyes.
23 —Bow liftig eyes.
24 —Foldable stainless steel ladder.
The boat series "NAVIGATOR" N700/N730 consists of the next main
components (Fig. D1):
- polyester hull (1);
- reinforced buoyancy tube (2);
- polyester steering console (13);
- composed driver seat/bolster or jockey seats (14);
- stainless steel arc (18).
BOAT DESIGN.
lDESCRIPTION:
D1
12
6
13
20
21
16
5
1
19
18
3
24
2

— 17 —
Series "NAVIGATOR" N700 N730 2384B.01
The boat hull has "deep-V" shaped bottom with four
longitudial steps. The upper deck has a special moulded
antiskid coating. There is two specified sections (Fig. D2):
—bow locker (1) is intended for arrangement of anchor
and anchor rope or for baggage arrangement;
—stern compartment (2).
The bow locker have a direct access by hinge out the
access door (18).
Onto the access door of the bow locker there is a
removable soft cushion (11, Fig. D1). Onto the stern
compartment there is soft seat (15, Fig. D1) and soft back
(16, Fig. D1).
The boat hull is arranged with the following components:
—bow towing eye (5, Fig.D2a);
—fuel tank (3, Fig.D2);
—battery disconnector (6, Fig. D2b);
—cockpit drain system sockets (7, Fig. D2b, D2d);
—two stern lifting eyes (9, Fig. D2c);
—drain out of motor recess (10, Fig. D2c);
—drain automatic bilge pump (11, Fig. D2d);
—two bow lifting eyes (14, Fig.D2);
—outer neck for fuel fill (13, Fig.D2);
—inspection hatch (12, Fig.D2);
—one bow and two stern cleats (17, Fig.D2);
The fore part of the cockpit may be simply converted into
the sundeck by means of false decks and soft cushions.
lPOLYESTER HULL.
D2
13d
a b c
2
a
4
b
d
67
510 9
11 7
c
12
10
7
18
10
17
17
13
14
9
9
17

2019 — 18 — BRIG
lREINFORCED BUOYANCY TUBE.
5 6 8 7
412 3
D3
The boat buoyancy tube has U-shaped form. The tube is separated by
means of inner elastic partitions into five chambers of a similar volume,
each being provided with an air fill valve.
The air fill valve is intended for:
—filling the compartment with air from a standard pump or filling system
and maintaining pressure in the tube for prolonged time,
—adjustable drop of pressure in compartment.
The air fill valve is designed as a tab-type non-return valve and consists
of the following components (Fig. D3):
—housing (1);
—cup (2) with strap (3);
—washer with gasket (4);
—nut (5);
—spindle (6) with spring (7) and cup diaphragm (8).
Also there are the following elements fitted on the tube (Fig. D1):
—doubled rubbing strake (3, Fig.D1);
—safety handles (4, Fig.D1);
—bow step-plate with a special moulded antiskid coating (6, Fig.D1).

— 19 —
Series "NAVIGATOR" N700 N730 2384B.01
lSTEERING CONSOLE.
Steering console is located in the central part of the boat.
The console consists of the following components
(Fig. D4):
—console base (1);
—console upper part (2);
—windscreen (3);
—stainless steel railing (4);
—front soft seat (5);
—console recess (7);
—special place for installation of analog or/and digital
devices, such as speedometer, tachometer,
trim-meter, fuel-level meter, multipurpose meters,
GPSmap, etc. (8);
—footstep (9);
—hatch in the front of the upper part of the console with
soft cursion;
—electric horn (on the right side of the upper part of
the console).
Stainless steel arc (18, Fig.D1) is located in the stern part
of the boat.
Arc is equipped with anchor light (white, 21) and
running lights:
port (red, 19) and starboard (green, 20), (Fig. D1).
lSTAINLESS STEEL ARC.
D4
7
1
5
4
3
2
8
9
7

2019 — 20 — BRIG
Console equipment (Fig. D5):
—hydraulic steering system;
—steering wheel (1);
—compass (2);
—fuel-level meter;
—speedometer;
—additional equipment (tachometer or multi-purpose meter,
trimmer, voltmeter, clock);
—socket 12V with fuse (3);
—fuse holding box with warning lights (inside of the
steering console)
—switches:
—electric horn switch (4);
—anchor light switch (5);
—running lights and meter lamp switch (6);
—bilge pump switch (7);
—shower switch (8);
Always keep a spare set the
fuse in an easily-accessible
location.
Always check the fuse. Burning
red LED display on the fuse box
warns of faulty fuse
HORN
D5
Fuse holding box
with warning lights
5
4
10
9
38
61
H OR N
27
5
6
7
4
8
2
1
3
