Bristan W BTH12 C User manual

AFTERCARE INSTRUCTIONS
Your fitting has a high quality finish and should be treated with care to
preserve the visible surfaces.
All surface finishes will wear if not cleaned correctly, the only safe way
to clean your waste is to wipe with a soft damp cloth. Stains can be
removed using washing up liquid. All bath cleaning powders and liquids
will damage the surface of your fitting even the non-scratch cleaners.
GUARANTEE
All products are manufactured to the highest standards and a 5 year
guarantee covers any defect in manufacture.
As gold and special effect finishes are softer than chromium plate,
special care must be taken when cleaning; a 3 year guarantee covers
these finishes. The new infinity finish carries a lifetime guarantee.
PRODUCT CODE: W BTH12 (*)
TELEPHONE HELP LINE! 0844 701 6273
Bristan Limited
Birch Coppice Business Park
Dordon
Tamworth
Staffordshire
B78 1SG
UK
Web site: www.bristan.com
Telephone: [phone]
Facsimile: 0844 701 6275
Email: [email protected]
FI W BTH12 (D2) MZ
Exposed Bath Waste
(W BTH12 C/G)
Fitting
Instructions
Please keep these instructions for future reference
For latest prices and delivery to your door visit MyTub Ltd 0845 303 8383 www.mytub.co.uk

INSTALLATION
N.B. please quote the name and product code of your fitting should
need to phone the help line. This will ensure a speedier service
regarding any inquiries.
1. Identify all components and check for completeness.
2. Assemble waste as shown by sliding nuts (2) onto tube with washer
(3) and rubber seal (4) inside each nut. Slide tube into waste body (14)
and overflow elbow (5) and tighten nuts. The waste can be adjusted to
fit bath by raising or lowering overflow elbow on tube.
3. The small foam washer (6) and the waste seal (13) go between the
overflow elbow and the waste body, respectively, and the bath.
Use a pure Silicon sealant where necessary.
4. Screw the overflow face (7) to the overflow elbow. Screw the waste
flange (11) to the waste body, making sure the large foam washer (12)
is between flange and bath.
Use a pure Silicon sealant where necessary.
5. If not fitted, open the triangular hook on the plug chain and close into
plug, then attach the other end of the chain to the overflow face.
6. Check all joints and connections for leaks.
7. See over the page for aftercare instructions.
COMPONENTS
1. Waste tube
2. Nut
3. Washer
4. Rubber seal
5. Overflow elbow
6. Small foam
washer
8. Screw
9. Chain assembly
10. Plug
11. Waste flange
12. Large foam
washer
13. Waste seal
14. Waste body
