Broyce Control P50ELR Series User manual

Broyce Control Ltd., Pool Street, Wolverhampton, West Midlands WV2 4HN. ngland
Tel: [phone] Fax: [phone] mail: [e-mail] Web: www.broycecontrol.com
The Information provided in this literature is believed to be accurate (subject to change without prior notice); however, use of such information shall be entirely at the user’s own risk
P50 LR-4-A.DOCX
Page 1 of 2
1806
• FUNCTION DIAGRAM
Terminal Protection
to IP20
 Panel (Flush) Mount enclosure
 Adjustable side clips provide quick method of mounting (no fi ing screws required)
 6 models available (3A, 10A or 30A with either SPDT or 2 N.O. relay outputs)
 Designed to monitor and detect true RMS leakage current in conjunction with separate toroid
 Adjustable Trip level (I∆
∆∆
∆n) and Time delay (∆
∆∆
∆t) settings
 Separate “Test” and “Reset” push buttons
 Toroid open and short-circuit detection forces unit to trip (Red LED flashes during this
condition)
 Relay energises when fault current e ceeds set Trip level
 LED indication for Power Supply, Leakage Current and Trip status
 SPDT relay output - 8A (Part No. P50ELR-3, P50ELR-10 and P50ELR-30)
 2 N.O. relay outputs - 3A (Part No. P50ELR-3/2, P50ELR-10/2 and P50ELR-30/2)
 Single supply voltage option – 115V or 230V AC

Compliant with
IEC 60755
Type: P50ELR
* & P50ELR*/2
Earth Leakage Relay – Type A
• INSTALLATION AND SETTING
•B FOR INSTALLATION, ISOLAT TH SUPPLY.
•Remove the P50 LR from the packaging.
•Lift the raised part of the side clip and slide towards the rear of the
housing to remove. Carry this out on both sides.
•Insert the P50 LR in to the panel cut-out and fit the side clips back
on to the housing.
•Slide the clips towards the front of the unit until they come in to
contact with the reverse side of the panel. The unit is now secured
in place.
•Connect the wires to the rear terminals as required following the
diagram shown on the next page and for the relevant model shown.
•nsure the Auxiliary supply voltage to be connected to terminals 1
and 8 matches the rating of the product.
Setting up
•The unit should be set according to the requirements of the
application.
Applying power
•Apply power and the green “Power on” ➍ L D will illuminate.
•Assuming no fault present, the output relay(s) will remain in the de-
energised state.
•Prior to a fault occurring, the L D bargraph ➎ will indicate the % of
I∆n being detected (the display is scaled between 25, 50, and 75%
of the actual trip level). After all 3 L D's have illuminated and the
unit trips due to an excessive fault current, the red “tripped” ➏ L D
will illuminate.
Fault simulation (Test mode)
• The unit can be placed into a fault condition by pressing the “Test”
button ➌ on the front of the unit. The output relay(s) will energise.
• Press the “Reset” button ➐ on the front to reset the unit. The
output relay(s) revert back to the de-energised state.
• The unit can also be reset by interrupting the power supply
• To satisfy regulations, it is recommended that the device be tested
periodically to ensure correct operation.
Troubleshooting
• If the unit fails to operate correctly check that all wiring and
connections are good.
Note:
The operating function of this unit is classed as a Type A for which
tripping is ensured for residual sinusoidal alternating currents and
residual pulsating direct currents, whether applied suddenly or slowly
rising. Additionally, this unit is protected against nuisance tripping.
This unit will also satisfy the requirements for Type AC devices which
only need to detect residual alternating currents.
• SETTING DETAILS
P50ELR-10 shown in example
➌
➋
➊
➎
➐
➍
➏
1. Trip setting adjustment (I∆n) in Amps 5. Green “Leakage Current” L D indication
2. Time delay adjustment (∆t) in seconds 6. Red “Tripped” (Fault) L D indication
3. “T ST” button 7. “R S T” button
4. Green “Power On” (Normal) L D indication
* -3, -10 or -30

Broyce Control Ltd., Pool Street, Wolverhampton, West Midlands WV2 4HN. ngland
Tel: [phone] Fax: [phone] mail: [e-mail] Web: www.broycecontrol.com
The Information provided in this literature is believed to be accurate (subject to change without prior notice); however, use of such information shall be entirely at the user’s own risk
P50 LR-4-A.DOCX
Page 2 of 2
1806
• DIMENSIONS
• CONNECTION DIAGRAM
• TECHNICAL SPECIFICATION (continued)
Output (continued)
lectrical life: DC load capacity:
Switching current (A)
DC current (A)
Dielectric voltage: 1kV AC (rms) I C 60947-1
Rated impulse withstand voltage: 4kV (1.2/50µS) I C 60664
Housing
Material: Grey flame retardant Lexan UL94 V0
Weight: ≈ 205g
Protection: IP40 (front face) / IP20 (rear)
Mounting: Panel mount. Cut-out (see information below)
Max. panel thickness: 10mm
Rear Terminals
Conductor size:
0.3 – 2mm
2
(22 – 14AWG)
Wire stripping length: ≈ 6mm
Recommended tightening torque: 1.3Nm (12lb-in)
Standards
Product:
I C 60755, I C 62020
MC: I C 61543, I C 61000-4 Series
C and RoHS Compliant. C-tick
Toroid options
Part number: Aperture Internal diameter/size: Rated current
BZCT035  35mm ∅ 150A
BZCT050  50mm ∅ 250A
BZCT070  70mm ∅ 400A
BZCT120  120mm ∅ 600A
BZCT160  160mm ∅ 1000A
Ordering:
Please specify product part number and voltage when ordering.
For example:
P50ELR-30 230V AC
Type:
P50ELR* & P50ELR*/2
Earth Leakage Relay – Type A
• TECHNICAL SPECIFICATION
Au iliary Power Supply (1, 8)
Supply voltage (Un): 115V or 230V AC (To be specified when ordering)
Frequency range: 50/60Hz
Supply variation: 85 – 115% of Un
Auxiliary supply is galvanically isolated from the Toroid connections
Overvoltage category: III
Rated impulse withstand voltage: 4kV (1.2/50µS) I C 60664
Power consumption (max.): 6VA
Device Characteristics
Unit classification: Type A
Measurement principle: True R.M.S.
Trip level [Sensitivity] settings (I∆n): See “Ordering” also
P50ELR-3: 30mA, 50mA, 100mA, 200mA, 300mA, 500mA, 1A, 1.5A, 2A,
3A
P50ELR-10: 30mA, 100mA, 300mA, 500mA, 750mA, 1A, 2A, 3A, 5A, 10A
P50ELR-30: 30mA, 300mA, 500mA, 1A, 3A, 5A, 10A, 15A, 20A, 30A
Trip level limits: 80 – 90% of I∆n
Reset value: ~85% of tripped level
Time delay [Operating time]
settings (∆t):
0*, 60, 100, 150, 200, 250, 300, 400, 500ms
*Actual delay when set to “0” is <25ms @ 5 x I
∆ n
Note:
1. For I∆n setting of 30mA, the time delay is fixed to 0s (instantaneous) and is not adjustable
(i.e. setting any other time delay has no effect)
2. The unit is factory set to 30mA and 0s (instantaneous) delay. Adjustment of these settings
can be made if necessary to suit the requirements of the installation. Once the settings are
made, the front window can be sealed if required to prevent unnecessary adjustment.
Reset time: <2s (from supply interruption)
Monitored input (via e ternal Toroid connected to terminals 2 and 7)
xternal Toroid ratio: 1000:1
LED indication
Power Supply: Green x1
Tripped: Red x 1
LED flashes if the external toroid is
disconnected
Bargraph (25, 50, 75%): Green x3
Test and Reset
“Test” method
(assuming unit is in the non-
tripped state):
Press once to trip the unit
“Reset” method
(assuming unit is in the tripped
state and fault current cleared):
Press once to reset the unit
Temperature rating
Operating: P50ELR* P50ELR*/2
-20 to +60°C -20 to +55°C
Storage: -30 to +70°C
Relative humidity: +95% max.
Output - Model No./Type P50ELR* P50ELR*/2
Rear Terminal No.: (3, 4, 5) (3, 4 / 5, 6)
Contact arrangement: 1 x SPDT 2 x SPNO
AC1 (250V) 8A (2000VA) 3A (750VA)
AC15 (250V) 2.5A 1.5A
DC1 (25V) 8A (200W) 3A (75W)
Where * refers to product current rating, i.e. 3, 10 or 30
Cycles
DC Voltage (V)
Resistive
load
250V AC
AC1
Resistive load
• CUT-OUT
Key: P50 LR*
P50 LR*/2
