Broyhill A601000501 User manual

BROYHILL 60QT FAUX
WOOD WHEELED COOLER
Need help? We are here for you! 1(866)578.6569 24/ 7 • Toll Free
ASSEMBLY INSTRUCTIONS
ITEM#: A601000501
SKU# 810453421

MAINTENANCE:
WHAT IS COVERED?
The limited warranty is extended to the original purchaser and applies to material and manufacturer’s defect provided
the item is maintained with care and used only for personal, residential purposes.
Warranty: 6 Months
WARRANTY:
WARNINGS:
GENERAL BEST PRACTICES FOR ASSEMBLY:
• Please read and understand this entire manual before attempting to assemble or install the product.
• Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and
hardware contents list. If any part is missing or damaged, do not attempt to assemble the product.
• Some parts may contain sharp edges. Wear protective gloves if necessary, during assembly.
• Check all nuts and bolts periodically for tightness and, when required, tighten them again.
• Pay attention to the parts orientation
• Keep all children and pets away from assembly area. Children and pets should be supervised when they are in the
area of the construction.
•If scratched please use touch up paint, to prevent rusting
• Do not place the product on a damp or conductive subsurface.
• Steel components for this cooler are treated with rust inhibiting paint that protects it from rusting. However, due to the
nature of steel, surface oxidation (rusting) will occur if these protective coatings are scratched. This is not a defect and
thus not covered by the warranty.
• To minimize this condition, it is recommended to use care when assembling and handling the product to prevent
scratching the paint. Should any scratching or damage occur, it is recommended to cover the scratch immediately
with rust inhibiting paint (not included).
• Do not use bleach, acid, or other abrasive cleaners on the cooler.
• Keep instruction manual for future reference.
• When not in use, store in a cool, dry area.
2/11

EXPLODED DRAWING
3/11

PARTS LIST
Label Part Number Description Qty Part Image
A P005100112 Knob 2
B P003100072 Lid 1
C P007900031 Basin 1
C1 P005100114 Drain Plug
Pre-assembled 1
D P005100113 Pushing Handle 2
E P007100005 Bottle Opener 1
F P007200006 Bucket 1
G P000100223 Leg 2
H P002300047 Shelf 1
I P003300032 Caster 2
J P003300033 Caster with
brake 2
4/11

HARDWARE LIST
5/11
Label Part Number Description Qty Add Part Image
AA H010030066 Bolt M6*13 4 1
BB H010030064 Bolt M6*45 4 1
CC H010030065
Bolt M6*16
Pre-assembled
on C
6 0
DD H010110051
Bolt M4*30
Pre-assembled
on B
2 0
EE H090030002 Wrench M6 1 0
FF H090010015 Wrench M10 1 0

HELPFUL HINTS
• Tools needed and not included
• Separating parts before starting
Provided in hardware pack
How many people needed for the installation work
Provided
6/11

STEP 1
Assembled View:
7/11
Attached Leg (G) to Basin (C)
with Bolts (BB), tighten the bolts to
80% depth with Wrench(EE).
1x
4x
2x

Assembled View:
STEP 2
8/11
Attached Shelf (H) to Leg (G)
with Bolts (AA), tighten all the
bolts to 100% depth with
Wrench(EE).
1x
4x

Assembled View:
STEP 3
2x 2x
9/11
Attached Caster (I) and Caster with
brake (J) to Leg (G), tighten
with Wrench(FF) .

Assembled View:
STEP 4
Attached Knob (A) to Lid (B) with Bolts
(DD), attached Pushing Handle (D) to
Basin (C) with Bolts (CC), tighten
the bolts with Wrench(EE). Put the
assembled lid (A/B) to basin(C).
10/11
1x
4x
2x
1x
2x

Assembled View:
STEP 5
11/11
Attached Bottle Opener (E) to Basin
(C) with Bolts (CC),hang the
Bucket (F) on the Basin (C),
tighten the bolts with Wrench (EE).
1x 1x
2x
