Broyhill Legacy Castle Pines Dining Table User manual

Need help? We are here for you! 1 [phone] 24/7 • Toll Free
CASTLE PINES
ASSEMBLY INSTRUCTIONS
ITEM#: A208000304
SKU#: 810493507
CASTLE PINES DINING TABLE

• Please read and understand this entire manual before attempting to assemble or install the product.
• Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and
hardware contents list. If any part is missing or damaged, do not attempt to assemble the product.
• Do not place the product on a damp or conductive subsurface.
• Standing on or misuse of this table may result in damage and injury. Read and follow mfg. assembly and use instructions.
Not intended for commercial use.
• Keep all children and pets away from assembly area.
• Children and pets should be supervised when they are in the area of the Chair construction.
• Keep assembly area at least 6 feet from any obstruction such as a fence, garage, house, overhanging branches, laundry
line or electrical wires.
• Check all bolts for tightness before use. IMPORTANT - check and tighten bolts often to keep them secure!
• Steel components for this table are treated with rust inhibiting paint that protects it from rusting. However, due to the
nature of steel, surface oxidation (rusting) will occur if these protective coatings are scratched. This is not a defect and
thus not covered by the warranty.
• Do not use bleach, acid, or other abrasive cleaners on the roof or frame parts.
• Keep instruction manual for future reference.
• Surface rust can also be easily removed with a very light application of regular cooking oil or WD-40. If surface oxidation
(rusting) occurs and if no measure is taken to prevent this, the oxidation may start dripping onto deck or patio and caused
damaging stains, which may be difficult to remove. This can be prevented if the above-mentioned measures are taken to
keep the product from oxidizing.
WARRANTY:
WHAT IS COVERED ?
The limited warranty is extended to the original purchaser and applies to material and manufacturer’s defect provided
the item is maintained with care and used only for personal, residential purposes.
Warranty: 12 months
MAINTENANCE:
WARNINGS:
GENERAL BEST PRACTICES FOR ASSEMBLY:
2/8

EXPLODED DRAWING
B
C
3/8

PARTS LIST
HARDWARE LIST
Label Part Number Description Qty Part Image
A Umbrella cap 1
B Table top 1
C Leg2
D Connect bar 2
E Foot pad
Pre-assembled 4
Label Part Number Description Qty Add Part Image
AA H100010004 Bolt M6*15 8 1
BB H100010005 Bolt M8*30 8 1
CC H090030002 Wrench M6 1 0
4/8

HELPFUL HINTS
• Tools needed and not included
• Separating parts before starting
How many people needed for the installation work
5/8
Provided in hardware pack Provided

STEP 1
Assembled View:
Attached Table top (B) to Leg(C) with
Bolt(BB), tighten the Bolt(BB) to
80% depth with Wrench(CC).
2x
8x
1x
B
C
BB
BB
B
B
C
C
C
6/8

STEP 2
Assembled View:
8x
2x
C
C
C
7/8
Attached Connect bar (D) and Table top(B) to
Leg(C) with Bolt(AA), tighten all the Bolt to
100% depth with Wrench(CC) at last.

STEP 3
Assembled View:
Put the Umbrella cap(A) on the Table
top(B).
1x
B
