Broyhill BL-TV-060-20A User manual

Page 1 of 14
GENERAL BEST PRACTICES FOR ASSEMBLY:
WARNINGS:
MAINTENANCE:
Determine you have adequate space for assembly.
Assembly by two adults is recommended.
Assemble on soft surfaces to prevent damage to product finish.
Keep children away during assembly. This item contains small parts which can be
swallowed by children.
Do not discard any of packaging until you have checked that you have all parts and hardware.
Retain the assembly instructions for future reference.
The manufacturer will not accept responsibility for unauthorized repairs or modifications to
this product.
This product is for residential use only, not for commercial use.
A Phillips head screwdriver is necessary for assembly but is not included.
Should this product become damaged, and/or components are broken or missing,
DO NOT USE.
This product will burn if left in contact with flame source.
To prevent serious injury or death, this product is equipped with a wall anchoring system.
Before this product can be used, the wall anchoring system must be installed as directed in
the assembly instructions.
WARNING: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
WARNING - Death or serious injury may occur when children climb on audio and/or video
equipment furniture. A remote control or toys placed on the furnishing may encourage
a child to climb on the furnishing and as a result the furnishing may tip over on to the child.
WARNING - Relocating audio and/or video equipment to furniture not specifically designed
to support audio and/or video equipment may result in death or serious injury due to the
furnishing collapsing or over turning onto a child.
Wipe with a damp cloth. Use Furniture polish or lemon oil on the wood as needed.
Avoid prolonged exposure to moisture.
Do not scratch or chip the finish.
Do not put hot objects which are more than 80 degrees Fahrenheit directly on the surface.
Check bolts/screws periodically and tighten if necessary.
To prolong the life of product we recommend storage in a dry area when not in use
or during austere weather conditions.

Page 2 of 14
Top Panel
x 1 pc
Left Side Panel
x 1 pc
Left Middle Panel
x 1 pc
Right Middle Panel
x 1 pc
Right Side Panel
x 1 pc
Left Door
x 1 pc
Right Door
x 1 pc
Front Rail
x 1 pc
Side Back Panel
x 2 pcs
AB
A
C
DE F
GH I
PARTS LIST

PARTS LIST
Center Back Panel
x 1 pc
Center Adjustable Shelves
x 2 pcs
Adjustable Shelves
x 2 pcs
Bottom Panel
x 1 pc
Connect Wood
x 8 pcs
Page 3 of 14
JKL
MNO
Bottom Crossbar
x 1 pc

HARDWARE LIST
Page 4 of 14
123
4 5 6
789
11 12
Allen Bolt x 8 pcs
Ø1/4"*12mmL
Allen Bolt x 38 pcs
Ø1/4"*32mmL
10
Spring Washer x 38 pcs
Ø1/4" *1mmT
Flat Washer x 42 pcs
Ø1/4" *16mmW*1mmT
Allen Key x 1 pc
4mm
Wood Dowel x 18 pcs
Ø8*30mmL
Plastic Block x 8 pcs
30*14*8mm
Screw x 8 pcs
Ø7*19mmL
Sliding Hardware x 4 pcs
Plastic Pad x 6 pcs Shelf Pin x 16 pcs Anti-tipping Strip x 2 pcs
25*230mmL
14
13
Wall Anchor x 2 pcs
Ø8.5*30mmL
Screw x 4 pcs
Ø8*28mmL

Page 5 of 14
STEP 1
Assembled View:
With assistance, place the Bottom Panel (M) upside down on a
smooth surface. Attach the Bottom Crossbar (N) to Bottom Panel (M)
with Flat Washer (4), Spring Washer (3) and Allen Bolt (2) using Allen
Key (5).
Fully tighten all bolts.
Return Bottom Panel (M) to upright position.
x4 x4
x1
Hardware needed
2
3
4
5
x4
2
3
4
5
MN

STEP 2
Page 6 of 14
Assembled View:
x16 x16
x1
Hardware needed
2
3
4
5
x16
Place the Left Side Panel (B) upside down on a smooth surface.
Align the holes in Connect Wood (O) with the holes in Left Side Panel (B)
as shown. Secure the Connect Wood (O) to Left Side Panel (B) with Flat
Washer (4), Spring Washer (3) and Allen Bolt (2) using Allen Key (5).
Note: The Connect Wood (O) should be flush with the edges of the panels.
Repeat the process to attach Connect Wood (O) to Right Side Panel (E),
Left Middle Panel (C) and Right Middle Panel (D).
O
O
O
O
C
D
O
O
O
O
E
B
2
3
4
5

STEP 3
Page 7 of 14
Assembled View:
Hardware needed
x8 x8
x1
2
3
4
5
x8
x8
6
Insert Wood Dowel (6) into Bottom Panel (M). Align the holes
in Right Side Panel (E) and slide to place. Secure Right Side
Panel (E) to Bottom Panel (M) with Flat Washer (4), Spring
Washer (3) and Allen Bolt (2) using Allen Key (5).
Fully tighten all bolts.
Repeat the process to attach Left Side Panel (B), Left Middle
Panel (C) and Right Middle Panel (D) to Bottom Panel (M).
2
3
4
5
M
B
C
D
E
6
6

STEP 4
Page 8 of 14
Assembled View:
Open Center Back Panel (J). Insert Center Back Panel (J)
down along the groove of Left Middle Panel (C) and Right
Middle Panel (D). Insert Side Back Panel (I) down along the
groove of Left Side Panel (B) and Left Middle Panel (C).
Repeat the process for the remain Side Back Panel (I) to
attach to Right Side Panel (E) and Right Middle Panel (D).
Insert Wood Dowel (6) into Left Middle Panel (C) and Right
Middle Panel (D). With assistance, align holes of Front Rail
(H) with the inserted dowels and slide to place. Secure the
Front Rail (H) to Left Side Panel (B) and Right Side Panel (E)
with Flat Washer (4), Spring Washer (3) and Allen Bolt (2)
using Allen Key (5). Fully tighten bolts.
Hardware needed
x2 x2
x1
2
3
4
5
x2
x2
6
J
J
I
I
H
6
6
2
3
4
5
BC
D
E

STEP 5
Page 9 of 14
Assembled View:
Insert Wood Dowel (6) into holes on the edge of Left Side
Panel (B), Left Middle Panel (C), Right Middle Panel (D) and
Right Side Panel (E). With assistance, align the holes in Top
Panel (A) with the inserted wood dowels and lower into place.
Secure the Top Panel (A) to Left Side Panel (B), Left Middle
Panel (C), Right Middle Panel (D) and Right Side Panel (E)
with Flat Washer (4), Spring Washer (3) and Allen Bolt (2)
using Allen Key (5). Fully tighten bolts.
Hardware needed
x8 x8
x1
2
3
4
5
x8
x8
6
A
6
6
2
3
4
5
B
C
D
E

STEP 6
Page 10 of 14
Assembled View:
Insert the Bottom Glider of Left Door (F) into the groove of the
Bottom Panel (M) and lean the door against the Middle Panels.
Hang the Sliding Hardware (9) on the Metal Rail so it rolls smoothly.
Align the holes in Sliding Hardware (9) with the holes in the door
and attach Sliding Hardware (9) to the door with Allen Bolt (1) using
Allen Key (5). Do not Fully tighten bolts.
Hang a second Sliding Hardware (9) and attach it to the Left Door
(F) with Allen Bolt (1) using Allen Key (5).
Align the hardware so it is straight and fully tighten bolts.
Repeat the process to install the Right Door (G). Once both doors
are installed, attach the Plastic Pad (10) on the outside edge of both
doors as shown in diagram.
x8 x1
Hardware needed
x4 x6
15
910
F
G
10
9
1
5
M
M

STEP 7
Page 11 of 14
Assembled View:
11
L
K
L
x16
11
78
7
Insert the Shelf Pin (11) into the pre-drilled holes as shown in the
diagram. Place Adjustable Shelf (L) onto the Shelf Pins as shown.
Repeat the process for the remaining Adjustable Shelf (L) and the
Center Adjustable Shelves (K).
You can adjust the position of shelf as needed. Place the Plastic
Block (7) into the corner of Side Back Panel (I) as shown. Insert
Screw (8) into the pre-drilled holes and secure with Phillips
Screwdriver. Fully tighten screws.
Repeat the step for the remaining Plastic Block. Insure all Plastic
blocks are used to secure both side back panels in place.
Hardware needed
Not included
78
I
I
x8 x8

WALL
NOT INCLUDED NOT INCLUDED
WALL
Hardware needed
x4 x2
x2 x4
Not included
Attach the Anti-tipping Strips (12) to the back top of the mantel with
Screw (14) and Flat Washer (4). With assistance, place the console
in the desired location and mark the wall just below the spot where
the Aniti-tipping Strips are attached to the console.
Remove the console.
Drill holes in the marked locations on the wall and insert the Wall
Anchor (13). Place the console back into position leaving room to
attach the Anti-tipping Strips (12) to the Wall Anchor (13) with Screw
(14) and Flat Washer (4). Fully tighten Srews.
Move the console tight against the wall.
NOTE:
Please insure any media equipment is plugged in and working
correctly before securing the Anti-tipping Strips to the Wall Anchors.
STEP 8
Page 12 of 14
Assembled View:
WALL
4
14
12
4
14
12
13
412
13 14
WALL

Page 13 of 14
WARNING
The maximum diagonal Plasma/LCD television screen size is 60inch (152.40cm).
For use with televisions weighing 135 lbs. (61.23 kg) or less. Using larger or
heavier televisions may cause instability or tip-over which lead to serious injury
or even death.
WARNING - Death or serious injury may occur when children climb on audio
and/or video equipment furniture. A remote control or toys placed on the furnishing
may encourage a child to climb on the furnishing and as a result the furnishing
may tip over on to the child.
WARNING - Relocating audio and/or video equipment to furniture not specifically
designed to support audio and/or video equipment may result in death or serious
injury due to the furnishing collapsing or over turning onto a child.
GRAND ART FURNITURE CO., LTD
ADDRESS: D17 STREET, MY PHUOC I INDUSTRIAL PARK,
BEN CAT DISTRICT, BINH DUONG PROVINCE, VIETNAM
MAXIMUM LOAD 20LBS
MAXIMUM LOAD 20LBS
MAXIMUM LOAD 135LBS
MAXIMUM LOAD 20LBS
MAXIMUM LOAD 20LBS
MAXIMUM LOAD 20LBS
MAXIMUM LOAD 20LBS

PRINTED IN VIETNAM
ASSEMBLY IS COMPLETED
