Broyhill Legacy TWS22LW User manual

Need help? We are here for you! 1 (877) 539 – 7436 • Toll Free
ASSEMBLY INSTRUCTION
ITEM#: TWS22LW
SKU#: 810487336
CASTLE PINE 22 IN. X 19 IN.
SIDE TABLE 2PK
[email protected] • Email Address

Use the correct bolts as indicated. Do not tighten any of the bolts until the table is completely assembled.
Do not sit or stand on this table.
Do not discard of any of the packaging until you have checked that you have all of the parts and ttings required.
Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
Table is not to be used as a seating surface. Improper use of this product or failure to use may result in injury.
Do not place hot objects over 80 degrees on surface. Do not allow glasses to stand on the table surface under
the sun for a long time to avoid damage caused by high temperatures. Do not use abrasives or sharp tools when
cleaning surface.
Read all instructions before starting
Clear a at covered space to begin assembly
Always best to do it with a friend
Note that hardware required is provided for every step
Pay attention to orientation
Letter of the part corresponds to a sticker on the product
Number of the hardware corresponds to its letter in the package
Helpful hints provided along the way
MAINTENANCE:
WARNINGS:
GENERAL BEST PRACTICES FOR ASSEMBLY:
Retain these assembly instructions for future reference.
PAGE 1 OF 3
Regularly check hardware and tighten if necessary
Wash frame parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach, acid, or
other solvents on the frame parts.
Inspect and tighten all bolts and fasteners on a regular basis to ensure the proper performance and safety of your table.
When moving the table, lift. Do not drag this table.
We recommend the use of furniture covers when not in use.
In order to prolong the life and beauty of your table, we recommend that it be stored in a dry and protected area
during o season periods.

PAGE 2 OF 3E-320
PARTS LIST
STEP 1
PARTS REQUIRED: 1, 2, 4, & 5
Keep the bolts loose.
x4 x4
4 5
TWS22LW-CS05-1
TWS22LW-CS04-1
TABLE TOP
LEG
PART
NO. MATERIAL CODE PART Q’TY
1 1
2
22
3
SUPPORT
62TWS22LWQ101
58
17FA05040301-YX
WASHER d6.5*D13*1.0
417C33A0706001YX 8
BOLT M6*15
500 10 20 30 40 60 70 80 90
mm 100
Ⅰ
Ⅱ
Tools
1
1
2
2
4
5

PAGE 3 OF 3E-320
STEP 3
STEP 2
PARTS REQUIRED: 2, 3, 4, & 5
Tighten all bolts by using the supplied Hex key.
x4 x4
4 5
Warranty
• One–year limited warranty.
• Proof of purchase (dated register receipt) is required for warranty claims.
• It remains the customer’s responsibility for freight and packing charges to and from the service center.
4
5
2
2
3
3
