BRYAN STEAM
Separable Tank Tray Type Boiler Feedwater Deaerators
Capacities 70,000 to 300,000 PPH (2030 to 8695 BHP)
Form No. 6440
(5/00)
Performance Features
• Oxygen removal to .005 cc/l (7 PPB)
•CO
2 removal to 0% measurable
• Reduce chemical costs
• Reduce boiler and system corrosion
• Pre-heat boiler feedwater
• Improve boiler efficiency
• Quick equipment payback, compared
to chemical oxygen removal
Construction Features
• Constructed to ASME Section VIII,
Division I for 50 PSIG
• Hinged tray access door
• Standard 10 minutes deaerated water storage
• Easily accessible manway in storage tank
• All internal surfaces that contact
undeaerated water are constructed of type
304L stainless steel
• Internal direct contact vent condenser
for minimum steam loss
• Structural steel stand/pump platform
• 2-stage deaeration
• Available as completely packaged unit
including pumps and control panel
The Bryan tray type deaerator is unsurpassed in
performance and reliability. These units are
ASME Code pressurized units, and are guaran-
teed to deliver deaerated water at a maximum
oxygen content of .005cc/l (7PPB) and zero
measurable CO2. All internal surfaces that
come in contact with undeaerated water are
constructed of type 304L stainless steel for long
life and low maintenance. Their long residence
time makes them readily adaptable to all
systems, even where wide load swings occur.
A complete line of boiler feedpump and
control packages is available making the Bryan
tray deaerator a completely packaged unit
ready for installation with the minimum amount
of field assembly.
175,000 PPH
unit shown
Non-Condensable Gases (O , Co )
22
Deaerated Water
Steam
Tray
Access
Door
Deaerator Outlet
to Storage Tank
Stainless Steel Vent Pipe
Vented to Atmosphere
Stainless Steel
Internal Vent Condenser
Stainless Steel
Spray Tube
Welded Stainless
Steel Trays
Stainless Steel
Tray Chamber
Condensate Return
and Water Make-up

©2000 Bryan Steam LLC 50-2517A
TM
Bryan Steam LLC —Leaders Since 1916
783 N. Chili Ave., Peru, Indiana 46970 U.S.A.
Phone:[phone] • Internet:www.bryanboilers.com
Fax: [phone] • E-mail: [email protected]
Specifications
Dimensions
Capacity in inches (cm)
Model Pounds/hr Boiler hp Storage A B C*
(kg/h) (kW) in gallons Overall Overall Overall
(liters) length width height
DTA-70 70,000 2,029 1,400 176 (447) 60 (152) 180 (457)
(31,752) (19,911) (5,299)
DTA-80 80,000 2,319 1,600 194 (493) 60 (152) 184 (467)
(36,288) (22,756) (6,056)
DTA-90 90,000 2,609 1,800 190 (483) 66 (168) 173 (439)
(40,824) (25,600) (6,813)
DTA-100 100,000 2,899 2,000 200 (508) 66 (168) 177 (450)
(45,360) (28,445) (7,570)
DTA-125 125,000 3,623 2,500 187 (475) 72 (183) 203 (516)
(56,700) (36,556) (9,463)
DTA-150 150,000 4,348 3,000 217 (551) 72 (183) 207 (526)
(68,040) (42,667) (11,355)
DTA-175 175,000 5,072 3,500 247 (627) 72 (183) 211 (536)
(79,380) (49,779) (13,248)
DTA-200 200,000 5,797 4,000 228 (579) 84 (213) 220 (559)
(90,720) (56,890) (15,140)
DTA-250 250,000 7,246 5,000 274 (696) 84 (213) 239 (607)
(113,400) (71,112) (18,925)
DTA-300 300,000 8,695 6,000 249 (632) 96 (244) 244 (622)
(136,080) (85,335) (22,710)
* Not including the stand.
Bryan Separable Tank Tray Type Deaerators
*Note: Stand height varies depending upon pump specifications and job conditions.
Dimensions are for reference only and may change without notice. Consult factory for certified dimensions.
The tray assemblies in the Bryan tray deaer-
ators are constructed of type 304L stainless
steel. Trays are welded construction and are
engineered to offer maximum residence time.
This ensures complete deaeration even dur-
ing wide load swings.
1. High water level control
2. Low water level control
3. Make-up water control
4. Vacuum breaker
5. Temperature gauge
6. Pressure gauge
7. Overflow trap
8. Vent
9. Pump suction
10. Pump bypass
11. Chemical port
12. Drain
13. Sample port
14. High temperature
condensate return
15. Gauge glass
16. Manway access opening
17. Tray access door
88
4
17
56
16
2
1
56
13 12
9
3
15 10
11
14
7
C
AB
48" *
20"
REF
CONDENSATE/
MAKE-UP
WATER INLET
STEAM
INLET
