BRYAN STEAM
Form No. 6420
(5/00)
Low vessel height
made possible by
the innovative
“Low NPSH”
regenerative
turbine pump
which operates
with 1 ⴕ available
NPSH across
its entire curve
Low Profile Vertical Tray Type Boiler Feedwater Deaerators
Capacities 5,000 to 60,000 PPH (145 to 1740 BHP)
Performance Features
• Oxygen removal to .005 cc/l (7 PPB)
•CO
2removal to 0% measurable
• Reduce chemical costs
• Fast equipment payback
• Reduce system corrosion
• Improve boiler efficiency
Construction Features
• Constructed to ASME Section VIII,
Division I for 50 PSIG
• Completely packaged with pumps
and controls
• Standard 10 minutes
deaerated water storage
• All internal surfaces that contact
undeaerated water are constructed
of type 304L stainless steel
• Internal direct contact vent condenser
for minimum steam loss
• 2-stage deaeration
The Bryan “Low Profile” tray type deaerator is
the industry leader in compact, space saving
design. This series packs all of the same high
performance design features as other Bryan
tray type deaerators. The combination of the
Bryan tray type deaerator and the industry’s
first true 1ⴕNPSH pump has resulted in a true
space saving unit.
The overall height saved is unparalleled.
All internal surfaces that come in contact
with undeaerated water are constructed of
type 304L stainless steel for long life and low
maintenance. Tray assemblies are of welded
construction and are also made of type 304L
stainless steel.
Units are available with either simplex or
duplex pumps, and a complete range of
control options making this a total deaerator
package for ease of installation.
5,000 PPH unit
shown
Stainless Steel
Vent Pipe
Vented to Atmosphere
Stainless Steel
Internal Vent Condenser
Stainless Steel
Spray Tube
Welded
Stainless Steel
Trays
Stainless Steel
Tray Chamber
Tray
Access
Door
Non-Condensable Gases (O , Co )
22
Deaerated Water
Steam
Condensate Return
and Water Make-up

©2000 Bryan Steam LLC 50-2517C
TM
Bryan Steam LLC —Leaders Since 1916
783 N. Chili Ave., Peru, Indiana 46970 U.S.A.
Phone:[phone] • Internet:www.bryanboilers.com
Fax: [phone] • E-mail: [email protected]
Bryan Low Profile Vertical Tank Tray Type Deaerators
Dimensions are for reference only and may change without notice. Consult factory for certified dimensions.
1. High water level control
2. Low water level control
3. Make-up water control
4. Vacuum breaker
5. Temperature gauge
6. Pressure gauge
7. Overflow trap
8. Vent
9. Pump suction
10. Pump bypass
11. Chemical port
12. Drain
13. Sample port
14. High temperature
condensate return
15. Gauge glass
16. Tray access door
All tray assemblies in the Bryan tray
deaerator are constructed of type 304L
stainless steel. Bryan selects the most
superior materials for all its deaerator
applications.
Specifications
Capacity Dimensions in inches (cm)
Model Pounds/hr Boiler hp Storage A B C D
(kg/h) (kW) in gallons Overall Overall Overall Tank
(liters) length width height diameter
LDTV-5 5,000 145 100 66 (168) 54 (137) 86 (218) 42 (107)
(2,268) (1,422) (378)
LDTV-10 10,000 290 200 66 (168) 54 (137) 103 (262) 42 (107)
(4,536) (2,844) (757)
LDTV-15 15,000 435 300 66 (168) 54 (137) 120 (305) 42 (107)
(6,804) (4,267) (1,136)
LDTV-20 20,000 580 400 84 (213) 72 (183) 108 (274) 60 (152)
(9,072) (5,689) (1,514)
LDTV-25 25,000 725 500 84 (213) 72 (183) 116 (295) 60 (152)
(11,340) (7,111) (1,893)
LDTV-30 30,000 870 600 84(213) 72 (183) 124 (315) 60 (152)
(13,608) (8,533) (2,271)
LDTV-35 35,000 1,014 700 96 (244) 84 (213) 125 (318) 72 (183)
(15,876) (9,956) (2,650)
LDTV-40 40,000 1,159 800 96 (244) 84 (213) 131 (333) 72 (183)
(18,144) (11,378) (3,028)
LDTV-45 45,000 1,304 900 96 (244) 84 (213) 141 (358) 72 (183)
(20,412) (12,800) (3,407)
LDTV-50 50,000 1,449 1,000 96 (244) 84 (213) 147 (373) 72 (183)
(22,680) (14,222) (3,785)
LDTV-60 60,000 1,739 1,200 96 (244) 84 (213) 157 (399) 72 (183)
(27,216) (17,067) (4,542)
7
84
14
10
11 13
10
16
3
6
9
12
1
2
B
C
A
D
4"
15
5
