Buckleys BathyCorrometer CalChecker Pro User manual

BathyCorrometer
®
Pro’
www.buckleysinternational.com
CalChecker Pro’
www.buckleysinternational.com
Ver. 04/22

Threaded battery coverPush-button switch with LED indicator
(press to activate checker output)
2-pin socket for use with Mk5 BCM only
Standard BCM utility plug pins
and front end
www.buckleysinternational.com
Buckleys (UVRAL) Ltd, Buckleys House, Unit G Concept Court, Shearway Road, Folkestone, Kent CT19 4RG
Tel: [phone] Email: [email protected]
USER INSTRUCTIONS
CalChecker Pro’
www.buckleys.co.uk
Ver. 04/22
Description
The BathyCorrometer®Cal-Checker Pro’ is a
self-contained, battery-powered instrument
used to verify the function of the
BathyCorrometer®Pro’ electronics.
Operation
Simply insert the BathyCorrometer® Cal-Checker Pro’ into the waterproof
bulkhead socket in the BathyCorrometer®’s handle to switch the BCM
on. The BathyCorrometer® Pro’ will display a reading of 0.000V,
momentarily press the push button switch of the BathyCorrometer® Cal-
Checker Pro’ to display a reading of -1.900 volts on the BCM.
Should the BathyCorrometer® Pro’ display a reading outside this range
[-1.900V (+/- 0.1%)]; this indicates the BathyCorrometer® Pro’ electronics
may require adjustment, having verified that the BathyCorrometer®
Cal-Checker Pro’ is providing the correct output first.
Note: Repairs/servicing must ONLY be undertaken by authorised technicians.
To use the BathyCorrometer® Cal-Checker Pro’ with a Mk5 BCM connect
the short calibration lead to the 2-pin socket of the Cal-Checker. Insert
the BathyCorrometer® Cal-Checker Pro’ into the waterproof bulkhead
socket in the BathyCorrometer®‘s handle and connect the spring clip to
the pointed probe of the BCM, proceed as detailed above to operate
the BathyCorrometer® Cal-Checker Pro’.
Maintenance
Very little maintenance is required apart from keeping the brass contact
pins clean and ensuring that the output is verified regularly to provide
optimum performance.
Technical Data
Operating temperature range: 0-30°C
Storage temperature range: 0-50°C
Battery:
Output:
Accuracy:
Output socket:
Weight in air:
Instrument size:
Function indicator:
Accessories:
3V CR- 1632 coin cell
-1.900V
+/- 0.1%
Only used for Mk5 BathyCorrometers®
130g
38mm diameter x 160mm long
Red illuminated push-button switch
Calibration lead (2-pin plug to clip)
(For use with Mk5 BathyCorrometer® only)
Battery Replacement
The BathyCorrometer® CalChecker Pro’ battery will require
replacement when an output of -1.900 (+/- 0.1%) volts cannot be
obtained. This can be verified with the use of a digital multi-meter set to
the DC Volts range.
To replace the battery first unscrew the threaded end cap to reveal the
battery, slide the old battery out of the holder and replace with a new
3V CR1632 coin-cell battery.
Disposal information
Product registration number: WEE/HJ0051TQ
This Product must be disposed of in accordance with UK WEEE
Producer Responsibility Regulations, or in accordance with your
local WEEE guidance
For further information on UK WEEE regulations click on:
http://www.gov.uk/government/collections/producer-responsibility-regulations
EC Declaration of conformity
We, Buckleys (UVRAL) Ltd., as sole manufacturer of the apparatus listed,
declare that the product BathyCorrometer® Cal-Checker Pro’ is manufac-
tured in conformity with the following directives: 2014/30/EU, 2014/35/EU,
2015/863/EU and 2011/65/EU (RoHS).
Date: 01/07/2021
Authorised by:
J P Hoveman, CEO, Buckleys (UVRAL) Ltd.
UKCA Declaration of conformity
We, Buckleys (UVRAL) Ltd., as sole manufacturer of the apparatus listed,
declare that the product BathyCorrometer® Cal-Checker Pro’ is manufac-
tured in conformity with the following UK legislation: Electronic Compatibility
Regulations 2016, The Electrical Equipment (Safety) Regulations 2016 and
Restriction of the Use of Certain Hazardous Substances in Electrical and
Electronic Equipment Regulations 2012.¬
Date: 01/07/2021
Authorised by:
J P Hoveman, CEO, Buckleys (UVRAL) Ltd.
