Burkert 3320 User manual

Quickstart
English Deutsch Français
Type 3320, 3321,
AE3320, AE3321
Electromotive 2/2-way valve
Elektromotorisches 2/2-Wege-Ventil
Vanne électromotorisée à 2/2 voies

We reserve the right to make technical changes without notice.
Technische Änderungen vorbehalten.
Sous réserve de modifications techniques.
© 2016 - 2020 Bürkert Werke GmbH & Co. KG
Operating Instructions 2010/03_EU-ML_00810524 / Original DE

3
1 QUICKSTART ........................................................................ 4
1.1 Denitionofterms ....................................................... 4
1.2 Symbols....................................................................... 5
2 INTENDED USE .................................................................... 5
3 BASIC SAFETY INSTRUCTIONS.......................................... 6
4 GENERAL NOTES................................................................. 7
4.1 Contact address.......................................................... 7
4.2 Warranty ...................................................................... 7
4.3 InformationontheInternet.......................................... 7
5 STRUCTURE AND FUNCTION ............................................. 8
5.1 Representation–Structureoftheelectromotivevalve 8
5.2 Displayofthedevicestatus ........................................ 9
6 TECHNICAL DATA................................................................. 9
6.1 Conformity................................................................... 9
6.2 Standards.................................................................... 9
6.3 Approvals .................................................................... 9
6.4 Type label .................................................................. 10
6.5 Operating conditions................................................. 10
6.6 General technical data............................................... 13
6.7 Electrical data............................................................ 13
6.8 KvvalueforType3320 .............................................. 15
6.9 KvvalueforType3321 .............................................. 15
7 INSTALLING THE VALVE..................................................... 16
7.1 Safetyinstructions..................................................... 16
7.2 Installationofdeviceswiththreadedconnection,
 angeconnectionorclampconnection.................... 16
7.3 Installationofdeviceswithweldedconnections....... 17
7.4 Rotating the actuator................................................. 21
7.5 Holding device........................................................... 22
8 ELECTRICAL INSTALLATION ............................................. 22
8.1 Electrical installation with circular plug-in connector 22
8.2 Electrical connection Fieldbus gateway.................... 25
8.3 Electrical installation with cable gland ...................... 26
9 START-UP............................................................................ 31
9.1 Safetyinstructions..................................................... 31
9.2 Base settings............................................................. 31
9.3 Setsafetypositionandeectivedirection ................ 31
9.4 Adjustmentofpositioncontroller–executeX.TUNE 32
9.5 SetAUTOMATICoperatingstate............................... 34
10 OPERATION ........................................................................ 34
10.1 Display elements............................................................. 35
10.2 Operating elements ................................................... 35
11 BASIC FUNCTIONS ............................................................ 36
11.1 Changingtheoperatingstate,AUTOMATIC,
 MANUAL.................................................................... 36
12 MANUAL OVERRIDE OF VALVE......................................... 37
12.1 Electricaloverrideofvalve ........................................ 37
12.2 Actuating the valve mechanically.............................. 39
13 FIELDBUS GATEWAY ......................................................... 40
13.1 Technical data ........................................................... 40
Contents
Type 3320, 3321
English

4
Quickstart
Type 3320, 3321
1 QUICKSTART
TheQuickstartcontainsashortsummaryofthemostimportant
informationand instructionsfor useof thedevice. Thedetailed
descriptioncanbefoundintheoperatinginstructionsforTypes
3320 and 3321.
KeeptheQuickstartinaneasilyaccessiblelocationforeveryuser.
TheQuickstartmustbeavailabletoeachnewownerofthedevice.
Important safety information.
ReadtheQuickstartcarefullyandfully.Studyinparticularthe
chapters entitled Basic safety instructions and Intended use.
▶The Quickstart must be read and understood.
Theoperatinginstructionscanbefoundontheinternetat:
country.burkert.com
1.1 Denition of terms
•The term “Device” used in these instructions applies to all
valve types described in these instructions.
Type3320,electromotive2/2-wayangleseatvalve
Type3321,electromotive2/2-wayglobevalve
•Theabbreviation“Ex”usedintheseinstructionsstandsfor
“potentiallyexplosive”.
•Intheseinstructions,theunitbarstandsforrelativepressure.
Theabsolutepressureisstatedseparatelyinbar(abs).
13.2 Electrical connection................................................. 41
13.3 AccesstobüSserviceinterface................................ 42
14 MAINTENANCE, TROUBLESHOOTING ............................. 42
15 CLEANING .......................................................................... 43
16 ACCESSORIES ................................................................... 43
16.1 Communicationsoftware .......................................... 43
17 DISASSEMBLY.................................................................... 44
17.1 Safetyinstructions..................................................... 44
18 PACKAGING, TRANSPORT, STORAGE ............................. 44
19 DISPOSAL........................................................................... 44
English

5
Intended use
Type 3320, 3321
2 INTENDED USE
Improper use of the electromotive 2/2 way Type 3320 and 3321
valve may be dangerous for people, nearby equipment and the
environment.
The electromotive 2/2-way Type 3320 and 3321 valve
isdesigned to control the ow of liquid and gaseous media.
▶Standarddevicesmustnotbeusedinthepotentiallyexplo-
sivearea.Theydonotpossesstheseparate“Ex”type
labeldenotingtheapprovalforuseinpotentiallyexplosive
environments.
▶Theuseofalkalinecleaningagentsisnotpermittedforcleaning
thesurfaceofthedevice.
▶Ifthepositionofthevalvehasabearingonsafetyconcerns
intheeventofapowerfailure:Onlyusedevicesthathave
aSAFEPOSenergy-pack(optionalenergypack).
▶Whenusingthedevice,observetheauthoriseddata,oper-
atingconditionsanddeploymentconditionsspeciedinthe
contract documents and in the operating instructions.
▶Protectdevicefromharmfulenvironmentalinuences!
(e.g.radiation,airhumidity,fumes,etc).Foranymatters
requiringclarication,contacttherelevantsalesdepartment.
Use the device
▶Useonlyinconjunctionwiththird-partydevicesandcompo-
nents recommended or approved by Bürkert.
▶Onlywheninperfectconditionandalwaysensureproper
storage,transportation,installationandoperation.
▶Only as intended.
1.2 Symbols
DANGER!
Warns of an immediate danger.
▶Failuretoobservetheseinstructionswillresultindeathorseri-
ous injuries.
WARNING!
Warns of a potentially hazardous situation.
▶Failure to observe these instructions may result in serious inju-
ries or death.
CAUTION!
Warns of a potential danger.
▶Failure to observe these instructions may result in moderate or
minor injuries.
NOTE!
Warns of damage.
Important tips and recommendations.
Referstoinformationintheseoperatinginstructions
orinotherdocumentation.
▶Designates instructions to avoid a danger.
→Designates a procedure which you must carry out.
designates a result.
English

6
Basic safety instructions
Type 3320, 3321
3 BASIC SAFETY INSTRUCTIONS
Thesesafetyinstructionsdonottakeintoaccountanyunforeseen
circumstancesandeventswhichoccurduringinstallation,operation
andmaintenance. The operator is responsiblefor observingthe
location-specicsafetyregulations,alsowithreferencetopersonnel.
Risk of injury from high pressure.
▶Beforeworkingonthedeviceorsystem,switchothepressure
and vent or empty the lines.
Danger of burns and risk of re.
Followinganextendeddutycycleorasaresultofahotmedium,
thesurfaceofthedevicemaybecomehot.
▶Only touch the device when wearing protective gloves.
▶Keepthedeviceawayfromhighlyammablesubstancesand
media.
Risk of crushing by mechanically powered parts.
▶Installationworkontheswivelplate,diaphragmandvalvebody
mustonlybeperformedwhileelectricallyisolated.
▶FordeviceswithSAFEPOSenergy-packs:Ensurethatthe
SAFEPOSenergy-packisfullydischarged.Waituntilthe
LEDringisnolongerlitandensurethattheLEDstatusisnot
in“LED o” mode.
▶Donotreachintotheopeningsofthevalvebody.
Risk of uncontrolled process in the event of a power failure.
For devices withouttheoptionalSAFEPOSenergy-pack,thevalve
willnotstopinadenedpositionintheeventofapowerfailure.
▶Ifthepositionofthevalvehasabearingonsafetyconcerns
intheeventofapowerfailure:Onlyusedevicesthathave
aSAFEPOSenergy-pack(optionalenergypack).
▶Selectavalvepositionthatissafeinrespectoftheprocess
usingtheDIPswitch.
Danger due to loud noises.
▶Dependingontheusageconditions,thedevicemaygenerate
loudnoises.Detailedinformationontheprobabilityofloud
noisesisavailablefromtherespectivesalesdepartment.
▶Wearhearingprotectionwheninthevicinityofthedevice.
Discharge of medium if packing gland worn
▶Reliefboremustberegularlyinspectedforanymedium
leakages.
▶Ifmediumisleakingfromthereliefbore,thepackinggland
mustbereplaced(seechapter“Maintenance”).
▶Ifthemediumishazardous,securetheareaaroundtheleakage
to prevent risks.
General hazardous situations.
Topreventinjuries,observethefollowing:
▶Inpotentiallyexplosiveenvironmentsthedevicemustonly
beusedinaccordancewiththespecicationsonthesepa-
rate type label.
▶Theadditionalinformationandsafetyinstructionsrelating
topotentiallyexplosiveatmospheresenclosedwiththedevice
or the separate operating instructions relating to potentially
explosiveatmospheresmustbeheededwhenusingthedevice.
▶Inpotentiallyexplosiveatmospheres,onlyusedeviceswith
aseparatetypelabelforuseinsuchatmospheres.
▶Feed only those media listed in chapter “6 Technical data” into
the medium ports.
English

7
General notes
Type 3320, 3321
▶Donotmakeanyinternalorexternalchangestothedeviceand
do not subject it to mechanical stress.
▶Heavyequipmentmustonlybetransported,assembled,
installedordismantledwiththehelpofasecondperson
asappropriateandusingsuitableapparatus.
▶Secure the device against unintentional activation.
▶Only trained technicians carry out installation and maintenance
work.
▶Notethesystem-specicsafetyregulations.
▶Followinganinterruptioninthepowersupply,ensurethat
the process is restarted in a controlled manner. Observe the
sequence.
1. Connect supply voltage.
2. Charge the device with medium.
▶Observe general engineering standards & rules.
▶The valves must be installed according to the regulations appli-
cableinthecountryofuse.
NOTE!
Electrostatically sensitive components/assemblies.
The device contains electronic components that are suscep-
tibletotheeectsofelectrostaticdischarging(ESD).Com-
ponents that come into contact with electrostatically charged
personsorobjectsareatrisk.Intheworst-casescenario,they
willbedestroyedimmediatelyorwillfailafterstart-up.
▶MeettherequirementsspeciedbyEN61340-5-1tominimise
oravoidthepossibilityofdamagecausedbysuddenelectro-
static discharge.
▶Do not touch electronic components when the supply voltage
is connected.
4 GENERAL NOTES
4.1 Contact address
Germany
Bürkert Fluid Control Systems
Sales Centre
Christian-Bürkert-Str.13-17
D-74653Ingelngen
Tel.+49(0)7940-10-91111
Fax+49(0)7940-10-91448
E-mail:[email protected]
International
Thecontactaddressescanbefoundonthebackpagesofthe
printed operating instructions.
AlsoontheInternetat:
country.burkert.com
4.2 Warranty
Apreconditionforthewarrantyisthatthedeviceisusedasintended
inconsiderationofthespeciedoperatingconditions.
4.3 Information on the Internet
OperatinginstructionsanddatasheetsforType3320and3321can
befoundontheInternetat:
country.burkert.com
English

8
Structure and function
Type 3320, 3321
5 STRUCTURE AND FUNCTION
Theelectromotivevalveconsistsofanelectromotivelinearactuator,
a swivel plate and a 2/2 way globe valve body or a 2/2 way angle
seat valve body.
Valve seat:
Thevalveseatisalwaysclosedagainstthemediumowsothe
owdirectionmustbedeterminedsuchthatthevalvereaches
theowundertheseat.
Globe valve Type 3321
AngleseatvalveType3320
Flow direction
Valve seat
Valve seat
Flow direction
1 2
Markingonthe
body 1 2
Markingonthe
body
Fig. 1: Flow direction below seat, ow direction
5.1 Representation – Structure of the
electromotive valve
Blind cover with
status indicator
and bayonet catch
Actuator housing
Actuator cover
Transparent
window with
position indicator
Electrical
connectors(circular
plug-in connector
orcablegland)
Body connection
(withwrenchat)
Portconnection
Angle seat valve
body
Actuator base FE Functional earth
Pressurecom-
ponent element
Donotunscrew!
Digitsforindi-
catingtheow
direction
Digitsforindi-
catingtheow
direction
Fig. 2: Structure, electromotive 2/2-way valve
English

9
Technical data
Type 3320, 3321
5.2 Display of the device status
VariousLEDmodesmaybeconguredtodisplaythedevice’s
statusandvalveposition(refertomaininstructionsfor
description).Factory-conguredLEDmode:“Valvemode+
warnings”.
5.2.1 Displays in valve mode + warnings
Ifdevicestatus“Normal”:Continuouslylitinthecolourofthe
valve position.
Ifdevicestatusisnot“Normal”:Flashesalternately
withthecoloursforthevalvepositionandthedevicestatus.
Valve
position
Colour for
valve position
Colour for device status
Failure, error or fault Function check Outside the specication Maintenance required
open yellow red orange yellow blue
in between white
closed green
Tab. 1: Display of device status in valve mode + warnings
Ifseveraldevicestatusesexistsimultaneously,thedevicestatus
with the highest priority is displayed.
Thepriorityisbasedontheseverityofthedeviationfrom
standardoperation(red=failure=highestpriority).
6 TECHNICAL DATA
The following product-specic information is provided
on the type label:
• Voltage[V](tolerance±10%)andcurrenttype
• Seal material
• Fieldbus standard
• Flow capacity
• Actuatorsize
• Maximumpermittedoperatingpressure
• Flow direction
6.1 Conformity
TheelectromotiveType3320,and3321valvesarecompliantwith
theEUdirectivesinrelationtotheEUDeclarationofConformity
(ifapplicable).
6.2 Standards
Theappliedstandards,whichareusedtodemonstrateconformity
withthedirectives,arelistedintheEUtypeexaminationcerticate
and/ortheEUDeclarationofConformity(ifapplicable).
6.3 Approvals
TheproductiscULuslisted.Refertothenextchapterforinfor-
mationonuseinULenvironments.
English

10
Technical data
Type 3320, 3321
6.4 Type label
3320ON/OFF-controlbüS
PTFEKv20
PS16barFlow2----->1
Tmed-40...+185°C
Seemanualforderating
S/N:1001W19MN
00123456
MadeinGermany
D-74653Ingelngen
U=24V Imax=5A1300N
Voltage,directcurrent,maximumcurrent,
actuatorsize(nominalforce)
Maximumpermittedoperatingpressure,owdirection
Sealmaterial,owcapacity
Serialnumber,manufacturecode(encrypted)
Identicationnumberofdevice
Permittedtemperaturerange(medium)
Forderating,pleaserefertotheoperatinginstructions
Example:
Type,function,eldbusstandard
Fig. 3: Description of the type label (example)
6.4.1 Additional type label for UL approval
(example)
Type AE3320
PowerSupply
SELV/PELVonly!
LISTED
Process control equipment
E238179
Fig. 4: Additional type label for UL approval
6.5 Operating conditions
The product-specic information on the type label
must be heeded when operating the device.
WARNING!
Loss of function if operated below or above permitted tem-
perature range.
▶Neverexposethedevicetodirectsunlightinoutdoorareas.
▶Do not operate above or below the permitted ambient temper-
ature range.
English

11
Technical data
Type 3320, 3321
WARNING!
Reduced sealing function if operating pressure too high.
Becausethevalveseatisclosedagainstthemediumow,
anexcessiveoperatingpressuremaycausethevalveseatto
not close tightly.
▶Theoperatingpressuremustnotexceedthemaximumvalue
speciedonthetypelabel.
Maximumpermittedoperatingpressure: seetypelabel
Media:     Neutralgasesandsteam.
Liquidmedia:Water,alcohol,oil,fuel,
hydraulicuid,saltsolution,caustic
soda,organicsolvent.
Degreeofprotection: (veriedbyBürkert/notevaluatedbyUL)
IP65inaccordancewithIEC529,
EN60529,(IP67ondemand).
NEMA2504x(notguaranteedif
installationposition:actuatorfacing
downwards).
Flowdirection:   indicatedonthetypelabelwithanarrow
and the digits 1 and 2. The 1 and 2 are
alsoonthenvalvebodyforidenti-
cation.
Theowdirectionisbelowtheseat
withowdirectionfromconnection
2toconnection1.
Altitude     upto2,000mabovesealevel
6.5.1 Permitted temperature ranges
Minimumtemperatures
Environment:  -25°C
Medium:   -10°C(-40°Conrequest)
Maximumtemperatures
 Environment:  dependsonthemediumtemperature,see
subsequent temperature diagram.
 Medium:   dependsontheambienttemperature,see
subsequent temperature diagram.
FordeviceswithPTFEvalveseatseal
max.+130°C.
FordeviceswithPEEKvalveseatseal
max.+230°C.
Temperature diagram
Themaximum permittedtemperaturefor the environmentand
mediumaredependentononeanother.Thepermittedmaximum
temperaturesofthedevicevariantscanbedeterminedusingthe
characteristicsofthetemperaturediagram.
Thevaluesarecalculatedunderthefollowingmaximumoperating
conditions:DNDN32at100%dutycyclewith16baroperating
pressure.
Individualreviewsmay be performedunder dierentoperating
conditions.Forthis,pleasecontactyourBürkertbranchoce.
English

12
Technical data
Type 3320, 3321
0 20 60 100 140 18040 80 120 160
Medium temperature [°C]
70
60
65
44
34
50
55
40
30
Ambient temperature [°C]
FordeviceswithoutSAFEPOSenergy-packs
DeviceswithSAFEPOSenergy-
pack* or Fieldbus gateway
200 220
Fig. 5: Temperature diagram
Derating pressure and temperature ranges
Usagelimitsofthearmature(deratingoperatingpressure)
Temperature Operating pressure
-10–+50°C 25bar
100°C 24.5bar
150°C 22.4bar
200°C 20.3bar
230°C 19bar
Tab. 2: Derating the operating pressure as per DINEN12516-1/PN25
* The service life of the SAFEPOS energy-pack is dependent on the
medium temperature and ambient temperature (see chapter “Electrical
data”).
Temperature Operating pressure
-29–+38°C 19bar
50°C 18.4bar
100°C 16.2bar
150°C 14.8bar
200°C 13.7bar
230°C 12.7bar
Tab. 3: Derating the operating pressure as per ASMEB16.5/
ASMEB16.34Cl.150
Temperature Operating pressure
-10–+50°C 14bar
100°C 14bar
150°C 13.4bar
200°C 12.4bar
230°C 11.7bar
Tab. 4: Derating the operating pressure as per JISB222010K
English

13
Technical data
Type 3320, 3321
6.6 General technical data
Materials Actuator: PPSandaluminium,
powder-coated
Valvebody: 316L
Bodyconnection: 316L/1.4401
Spindle: 1.4401/1.4404
Spindleguide: PEEK
Packinggland: PTFEV-ringswithspring
compensation
(carbon-lledPTFE)
Seal material Actuator housing
sealingelement: EPDM
Valveseatseal: see type label
Fluidic con-
nectiontypes: Threaded socket connection G ½...G 2
(NPT,RConrequest)
WeldedconnectionasperENISO1127
(ISO4200),DIN11850R2
ClampconnectionasperISO2852,DIN
32676,ASMEBPE,BS4825
AdditionallyforType3321globevalve:
FlangeconnectionasperDIN2634,ANSI
B16.5class150,JIS10K
Otheruidicconnectionsonrequest
Electrical
connection:
with terminal connectors or circular plugs
Installation
position:
any,preferablyactuatorfaceup
Sound pressure
level:
<70dB(A),maybehigherdependingonthe
operating conditions.
Kv-value: see type label or operating instructions
6.7 Electrical data
DANGER!
Electrical shock.
ProtectionclassIIIisonlyguaranteedwhenusinganSELV
orPELVpowersupplyunit.
Operating current [A]1) max.3A
including actuator at
max.Loadandcharging
currentofoptional
SAFEPOSenergy-pack
(chargingcurrentapprox.1A)
fordesignofpowersupply
unit
Standby consumption
(electronicswithoutactuator)[W]1)
 Standardconsumption: minimum2W
    typically3W
 SAFEPOSenergy-pack: 0.5W
 Fieldbusgateway: 1W
English

14
Technical data
Type 3320, 3321
Energyconsumptionofactuator
for1cycle[Ws]1):  min.36Ws
    max.140Ws
(dependingondevicevariantandoperatingconditions)
Protectionclass  3accordingtoDINEN61140
(VDE0140)
Electricalconnections Terminalstripwithcablegland,2xM20
or2circularplug-inconnectorsM12,
5-pin und 8-pin
Operating voltage 24 V ±10%
max.residualripple10%
Energy storage
SAFEPOSenergy-pack Chargingtime:Maximum100
seconds(dependentonoperating
conditions)
Servicelife:Upto10years(dependentonoperatingconditions).
Theservicelifeof5yearswascalculatedbasedonthefollowing
conditions:
Ambienttemperature 30°C
mediumtemperature 165°C
dutycycle  100%operatingpressure5bar
DN   DN32
1) All values relate to a supply voltage of 24 V at an ambient and
medium temperature of 25°C. Note: At minimum ambient and
medium temperatures, the operating current can be up to 5 A
(incl. 1 A charging current for the optional SAFEPOS energy-pack).
NOTE!
Consider voltage drop on power supply cable.
Example:withacablecross-sectionof0.34mm2the copper
cable must not be more than 8 metres in length.
Digital outputs (optional):
  Currentlimit      100mA
Digital inputs: for position signal 0...5V=log“0”,
10...30V=log“1”
inverted input inverted
accordingly(inputcurrent<
6mA)
Communication interface: ConnectiontoPCusing
USB-büSinterfaceset
Communication software: Bürkert Communicator
Thedigitaloutputsarenotgalvanicallyisolatedfromthe
operatingvoltage.Theyrefertotheoperatingvoltage
GND.
Currentlimit:outputvoltageisreducedintheevent
ofoverload.
English

15
Technical data
Type 3320, 3321
6.8 Kv value for Type 3320
Kvvaluewater(m3/h)
Flowcoecient:Measurementat+20°C,1bar
pressureatthevalveinletandfreeoutlet.
Seatsize
Kv value water [m3/h]
forowdirection
below seat
Cv value [gal/min]
forowdirection
below seat
15 5.0 5.8
20 11.0 12.7
25 18.0 21.0
32 31.0 36.0
40 42.0 48.5
50 62 72
Tab. 5: Kv value for Type 3320
6.9 Kv value for Type 3321
Kvvaluewater(m3/h)
Flowcoecient:Measurementat+20°C,
1 bar pressure at the valveinletandfreeoutlet.
Seatsize
Kv value water [m3/h]
forowdirection
below seat
Cv value [gal/min]
forowdirection
below seat
15 4.7 5.4
20 8.1 9.4
25 13.0 15.0
32 18.1 21.0
40 31.0 36.0
50 45.0 52
Tab. 6: Kv value for Type 3321
English

16
Installing the valve
Type 3320, 3321
7 INSTALLING THE VALVE
7.1 Safety instructions
WARNING!
Risk of injury due to improper installation.
▶Installation may be carried out by trained technicians only with
the appropriate tools.
▶Secure the system against unintentional activation.
▶Afterinstallation,ensurethattheprocessisrestartedinacon-
trolled manner. Observe the sequence.
1. Connect supply voltage.
2. Charge the device with medium.
CAUTION!
Risk of injury due to heavy device.
Duringtransportationorinstallationwork,thedevicemayfall
down and cause injuries.
▶Transport,installandremoveheavydevicewiththeaid
ofasecondpersononly.
▶Usesuitabletools.
NOTE!
The following must be heeded when installing the device
inthe system.
Thedeviceandreliefboremustbeaccessibleforinspections
and maintenance work.
NOTE!
Damage to valve body, seat seal or diaphragm.
▶Topreventdamage,thedevicemustbeinMANUALoperating
state during installation.
Devicesintheirfactorydefaultstatealreadyhavetheiroperat-
ingstatesettoMANUAL.
7.2 Installation of devices with
threaded connection, ange
connection orclamp connection
7.2.1 Mounting conditions
Installation position: Arbitrary,ideallywithactuatorfacingupwards.
Flow direction: indicated on the type label with an arrow and the
digits1and2.The1and2arealsoonthenvalvebodyforiden-
tication.
Theowdirectionisbelowtheseatwithowdirectionfromcon-
nection2toconnection1.
Pipelines: Ensure that pipelines are in alignment.
Filter: RequiredfordeviceswithapprovalasperEN161.
AccordingtoEN161“Automaticshut-ovalvesforgasburners
andgasappliances”,adirttrap,whichpreventsthepenetration
ofa1mmtestpin,mustbeinstalledupstreamofthevalveinthe
pipeline.
Preparation:Clearimpuritiesfrompipelines(sealmaterial,metal
chips,etc.)
English

17
Installing the valve
Type 3320, 3321
7.2.2 Installation
DANGER!
Risk of injury from high pressure.
▶Beforeworkingonthesystem,switchothepressureandvent
or empty the lines.
WARNING!
Risk of crushing by mechanically powered parts.
▶Donotreachintotheopeningsofthevalvebody.
→Connect valve body to pipeline.
Ensure that there is no voltage present and minimal
vibration during installation.
Holding device
Toprotectthevalveactuatorfromdamageresulting
fromforcesandvibrations,aholdingdeviceisrecom-
mended. This is available as an accessory. See oper-
ating instructions on the website
country.burkert.com
7.3 Installation of devices with welded
connections
The device must not be welded into the pipeline while the actuator
isstillinstalled.Theinstallationisdividedintothefollowingsteps:
1.Preparetheactuatordisassembly.
2. Disassemble the actuator.
3. Weld the valve body into the pipeline.
4.Mountingactuatoronthevalvebody.
7.3.1 Prepare the actuator disassembly
NOTE!
Damage to valve body, seat seal or diaphragm.
Toavoiddamage,thevalvemustbeopenwhentheactuator
isdisassembled.
→Ifthevalveisclosed:Openthevalvewiththemechanical
manual override. See chapter “12.2 Actuating the valve
mechanically” on page 39.
English

18
Installing the valve
Type 3320, 3321
WARNING!
Risk of crushing by mechanically powered parts.
▶Switchothesupplyvoltage.
▶FordeviceswithSAFEPOSenergy-packs:Ensurethatthe
SAFEPOSenergy-packisfullydischarged.Waituntilthe
LEDringisnolongerlitandensurethattheLEDstatusisnot
in“LEDo” mode.
▶Donotreachintotheopeningsofthevalvebody.
7.3.2 Disassemble actuator
→Clamp valve body into a holding device.
→Placeonthebodyconnectionwithasuitableopen-end
wrench.
Donotuseanytoolsforunscrewing,whichcoulddamage
thebodyconnection(e.g.pipewrench).
→Unscrewactuatorfromthevalvebody.
Mechanicalposition
indicator
Valve position
open
closed
The valve must not be
closed when the actuator
is unscrewed.
Actuator
Body
connection
Valve body
Fig. 6: Installation of electromotive actuator (example angle seat valve)
7.3.3 Mounting conditions
Installation position: arbitrary
Flow direction: indicated on the type label with an arrow and the
digits1and2.The1and2arealsoonthenvalvebodyforiden-
tication.
Theowdirectionisundertheseat.
English

19
Installing the valve
Type 3320, 3321
Pipelines: Ensure that pipelines are in alignment.
Filter: RequiredfordeviceswithapprovalasperEN161.
AccordingtoEN161“Automaticshut-ovalvesforgasburners
andgasappliances”,adirttrap,whichpreventsthepenetration
ofa1mmtestpin,mustbeinstalledupstreamofthevalveinthe
pipeline.
Preparation:Clearimpuritiesfrompipelines(sealmaterial,metal
chips,etc.)
7.3.4 Weld the valve body into the pipeline
DANGER!
Risk of injury from high pressure.
▶Beforeworkingonthesystem,switchothepressureandvent
or empty the lines.
NOTE!
The electronics in the actuator will be damaged by the
eects of heat.
• Theactuatormustberemovedbeforethevalvebody
isweldedin.
→Weld the valve body into the pipeline.
Ensure that there is no voltage present and minimal vibration
during installation.
7.3.5 Mounting actuator on the valve body
→Beforeinstallationtheactuator,checkwhetherthe
graphitesealforthevalvebodyispresentandundamaged.
→Replace damaged or missing graphite seal.
Graphite seal
Angle seat valveGlobe valve
Graphite seal
Fig. 7: Valve body graphite seal
DANGER!
Danger due to incorrect lubricants.
Unsuitablelubricantmaycontaminatethemedium.Thereisarisk
ofexplosioninoxygenapplications.
▶Forspecicapplications,e.g.oxygenoranalysisapplications,
use approved lubricants only.
→Beforere-installation,greasetheexternalthreadofthebody
connection(e.g.withKlüberpasteUH196-402fromKlüber).
→Positiontheexternalthreadontheinternalthreadofthebody
connection. See “Fig.6:Installationofelectromotiveactuator
(exampleangleseatvalve)”.
→Placeonthebodyconnectionwithasuitableopen-end
wrench.
English

20
Installing the valve
Type 3320, 3321
Donotuseanytoolsforunscrewing,whichcoulddamage
thebodyconnection(e.g.pipewrench).
WARNING!
Risk of injury when failing to observe tightening torque value.
Failure to observe the tightening torque value is dangerous due
totheriskofdamagetothedevice.
▶Observe the tightening torque value.
→Screw actuator onto valve body.
DN connection
(valve body DN)
Tightening torque for body
connection [Nm]
10/15 45±3
20 50±3
25 60±3
32 65±3
40
50 70±3
65 100±3
80 120±5
100 150±5
Tab. 7: Tightening torque for body connection
Holding device
Toprotectthevalveactuatorfromdamageresulting
fromforcesandvibrations,aholdingdeviceisrecom-
mended. This is available as an accessory. See oper-
ating instructions on the website
country.burkert.com
7.3.6 After installation
→Electrically connect the device.
Thepositionoftheportscanbechangedbyturningtheactuator
through360°.Foradescriptionseechapter“7.4 Rotating the
actuator”.
Thedescriptionoftheelectricalconnectionprocesscan
befoundinchapter“8 Electrical installation”.
NOTE!
Damage to valve body, seat seal or diaphragm.
▶Topreventdamage,executethefunctionX.TUNErstafter
establishing the electrical connection. Only then should the
operatingstatebesettoAUTOMATIC.
→CarryoutX.TUNEfunctionforendposition.Seeoperating
instructions on the website
country.burkert.com
English
